ELO TOUCH SOLUTIONS ELO E107766 Technology Factsheet [pl]

IntelliTouch Plus Surface Acoustic Wave

For Dual Touch Applications

Elo’s IntelliTouch Plus touchscreens, are the picture-

perfect, precision touch solution for high-use applications
requiring dual touch capability. The IntelliTouch Plus
touch solution is based upon proven surface acoustic
wave technology with over 20 years of reliable perform­ance and millions of installations around the world. Three
axes of touch information are used to precisely discern
two simultaneous touch locations anywhere on the
screen, thereby overcoming many of the drawbacks of
other multi-touch technologies. Meeting test criteria for
Windows 7 Additional Qualification (AQ) compliance,
IntelliTouch Plus technology enables Windows 7 users to
interact with their computing system with Windows 7
multi-touch gesture recognition.

Features

Patented IntelliTouch Plus touch technology

■

■ Available in standard and wide formats—7" to 32"

diagonal

■ Clear and anti-glare surface finishes available

■ Custom screen designs available

Benefits

Fast, accurate dual-touch response

■

■ Reliable surface acoustic wave touch technology

■ Pure-glass construction for excellent image clarity,

resolution, and light transmission

■ Durable, scratch-resistant glass continues to work

even if scratched

■ Stable drift-free operation

■ Finger, gloved hand, and soft stylus activation

Applications

Desktop Touch Computers, All-in-One (AiO) and

■

Touch Monitors

■ Point of information kiosks

■ Vending and ticket sales

■ Gaming, lottery, and amusement

■ Multimedia marketing

■ Banking and financial transactions

■ Industrial control rooms

IntelliTouch Plus Surface Acoustic Wave Specifications

MECHANICAL

Input Method Finger or gloved hand (cloth, leather, or rubber) activation
Available Sizes* 7" to 32" diagonal; visit our website for full specifications and other product offerings

ELECTRICAL

Positional Accuracy Less than ±2.5mm when touchscreen and controller are calibrated to display image
Resolution 6.19 points per mm typical
Minimum Separation

between Touches 25 mm
Touch Activation Force 2 to 3 ounces (55 to 85 grams) typical

OPTICAL

Light Transmission Up to 92% per ASTM D1003
Anti-Glare Surface Gloss 95 ±15 or 65 ±15 gloss units when measured per ASTM D2457 using a 60-degree gloss meter

ENVIRONMENTAL

Temperature Operating: 0°C to 50°C

Storage: –20°C to 71°C
Relative Humidity Operating: 40°C at 90% RH, noncondensing
Altitude Operating: 10,000 ft (3,048 m)

Storage/transport: 50,000 ft (15,240 m)
Chemical Resistance The touch active area of the touchscreen is resistant to chemicals that do not affect glass,

such as: acetone, toluene, methyl ethyl ketone, isopropyl alcohol, methyl alcohol, ethyl acetate,

ammonia-based glass cleaners, gasoline, kerosene, vinegar
Electrostatic Protection Per EN 61000-4-2, 1995 meets Level 4 (15 kV air/8 kV contact discharges)
Agency Approvals UL, cUL, TÜV, CE, FCC Class A
Sealability Can be sealed to meet NEMA 3/3R/5/12/12K/13, IP64 standards

DURABILITY

Surface Durability Surface durability is that of glass, Mohs' hardness rating of 6.5
Expected Life No known wear-out mechanism, as there are no layers, coatings, or moving parts. IntelliTouch

Plus technology has been operationally tested to more than 50 million touches in one location

without failure, using a stylus similar to a finger.
Warranty 3-year limited warranty

COMPATIBILITY

Controller Compatible with 2510 (Serial) and 2515 (USB) dual-touch controller
Software Drivers Software drivers available for all common operating systems at www.elotouch.com/support/

downloads. Windows 7 driver supports single-touch and dual-touch gesture recognition.

*See the touchscreen component drawing for details.
