Elo Touch Solutions 2702L Service Manual

2702L
27-inch LCD

Touchscreen Monitor

Edge-to-edge design with

Optional Peripherals Commercial-grade

integrated 10-touch

Product Overview

The Elo 2702L 27-inch touchscreen monitor delivers a professional-grade interactive
solution with Elo’s industry-leading TouchPro® PCAP technology featuring edge-to-edge
glass and enabling up to 10 simultaneous touches. The clear glass touchscreen provides
exceptional image clarity, resolution, and light transmission for vivid images and details.
Backed by a three-year warranty, the feature rich touchscreen monitor is equipped with
dual built-in speakers and VGA and HDMI video connectors. With a compac t form factor,
clean design aesthetic and flexible mounting options, these touchscreens are well-suited
for POS, interac tive digital signage and self-ser vice.

Designed for commercial use, the new Elo touchscreen monitor makes business operations
easy delivering energy efficiency and versatile accessories. The 2702L accessories include
MSR, barcode scanner, fingerprint reader, NFC, customer facing display, handles and
privacy screens. Third par ty peripherals can be easily added as well with the integrated USB

2.0 hub.

Other sizes available including from 10
to 27-inch displays creating a seamless
style across a variety of installation
requirements

Touchscreen is compatible with use of
finger, glove and stylus

Multiple mounting options including –
stand mount, wall mount and pole
mount

2702L 27-inch LCD Touchscreen Monitor

Specifications

Color Black

Diagonal Size 27" / 685.8 mm

Active Touch Area 23.54" x 13.24" / 597.88 mm x 336.31 mm

LCD Technology Active matrix TFT LCD

Touch Technology TouchPro PCAP

Number of Touches 10 Touches

Aspect Ratio 16:9

Native Resolution 1920 x 1080

Preset Video Timings

Number of Colors 16.7M

Brightness (typical) Panel: 300 nits; with TouchPro PCAP: 250 nits

Response Time (Tr + Tf) (typical) 14 msec

Viewing Angle (typical) Horizontal: 89°/89° or 178° total; Vertical: 89°/89° or 178° total

Contrast Ratio (typical) 1000:1

On-Screen Display (OSD)

I/O Ports VGA, HDMI, Headphone Jack, DC Jack, USB Type B, USB 2.0 Type A, 4 x Micro USB

Peripheral Ports 4 x Micro USB side ports (Top, Bottom, Left, Right)

Video

Speakers 2 x 2W internal speakers

Power

Dimensions with Stand (H x W x D) 17.75" (H) x 25.50" (W) x 9.17" (D) / 450.9 mm (H) x 647.6 mm (W) x 233 (D) mm

Shipping Dimensions

Weight Unpackaged with Stand: 23.15 lbs / 10.5 kg; Unpackaged without Stand: 15.96 lbs / 7.24 kg; Packaged: 31.53 lbs / 14.3 kg

Mounting Options VESA 4-hole 100mm mounting interface on rear of unit

Temperature Operating: 0° C to 40° C / 32°F to 104°F / Storage: -20° C to 60° C / -4°F to 140°F

Humidity (non-condensing) Operating: 20% - 80% / Storage: 10% - 95%

Regulatory approvals and declarations

Ingress Protection IPX 1 – Front only

Warranty 3 years

Extended Warranty Option

MTBF 50,000 hours demonstrated

Box Content

640 x 480 60Hz, 640 x 400 70Hz, 720 x 400 70Hz, 800 x 500 60Hz, 800 x 600 56, 60Hz, 1024 x 768 60Hz, 1280 x 800 60Hz, 1280 x 1024 60Hz,
1366 x 768 60Hz, 60Hz RB, 1440 x 900 60Hz, 60Hz RB, 1680 x 1050 60Hz, 60Hz RB, 1920 x 1080 50 60Hz

Accessible through switches along the bottom.
Controls: Menu, Power, Up, Down, Select
Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Aspect Ratio, Sharpness, Color Temperature, OSD Timeout, OSD

Language, Volume, Mute, Recall Defaults, Audio Select, Power LED ON/OFF
Languages: English, French, Italian, German, Spanish, Simplified Chinese, Traditional Chinese, Japanese, Russian, Korean
Lockouts: OSD, Power

VGA (VGA DB-15 Male connecter cable included), HDMI (HDMI cable included)
Input Video Horizontal Sync frequency range: 30 – 82KHz, Input Video Vertical Sync (frame rate) frequency range: 50 - 75Hz

Monitor input power connector: Coaxial power jack (2.1 mm pin outer diameter, 6.4mm barrel inner diameter);
Monitor input power signal specifications: 12VDC +/- 5%; Adapter input voltage range: 100-240VAC, 50/60Hz;
Power Consumption (Typical with monitor + AC/DC adapter): ON: 28W; SLEEP: 0.45W; OFF: 0.38W

22.05" (H) x 30.08" (W) x 12.68
(D) / 560 mm (H) x 764 mm (W) x 322 (D) mm

Canada CUL, IC / China CCC / Europe CE / Korea KCC / Taiwan BSMI / United States FCC, UL / Japan VCCI / International CB / Australia RCM / Russia
EAC / Mexico CoC

1 Year Extended Warranty - Elo P/N: E188404
2 Year Extended Warranty - Elo P/N: E572038
Elo Advance Unit Replacement (AUR) - Elo P/N: E67295-000

Touchmonitor with stand, Japanese language regulatory information pamphlet, Quick Install Guide, 3x Tie wraps, VGA cable, HDMI cable, Touch USB
cable, Audio cable, Power brick, NA Power cable, EU Power cable, EEI Label

Ordering Information

Part Number Part Description Technology Surface Treatment Touch Interface Color Availability

E351997 ET2702L-2UWA-0-BL-G TouchPro PCAP Clear USB Black Worldwide
