Integrated High Speed Dome Camera
ESD-370
Indoor Dome
User’s Manual
User’s Manual
Notice
The information given in this manual was current when published. The company reserves the right
to revise and improve its products. All specifications are subject to change without notice.
Copyright
Under copyright laws, the contents of this user manual may not be copied, photocopied, translated,
reproduced or reduced to any electronic medium or machine-readable format, in whole or in part,
without prior written permission of the company.
Important Information
Before proceeding, please read and observe all instructions and warnings in this manual. Retain
this manual with the original bill of sale for future reference and, if necessary, warranty service.
When unpacking your unit, check for missing or damaged items. If any item is missing, or if
damage is evident, DO NOT INSTALL OR OPERATE THIS PRODUCT. Contact your dealer for
assistance.
1
User’s Manual
Cautions
• Handle the camera carefully
Do not abuse the camera. Avoid striking, shaking, etc. The camera could be
damaged by improper handing or storage.
• Do not disassemble the camera
To prevent electric shock, do not remove screws or covers. There are no user
serviceable parts inside. Ask a qualified service person for servicing.
• Do not block cooling holes on the bracket
This camera has a cooling fan inside. Blocking the cooling holes leads to build up of
heat the camera and may cause malfunction.
• Do not operate the camera beyond the specified temperature, humidity or
power source ratings
Use the camera under conditions where temperature is between 0°C ~ 40°C (32°F ~
104°F), and humidity is below 90%.
• Do not expose the camera to rain or moisture, or try to operated it in wet areas
This product is designed for indoor use or locations where it is protected from rain
and moisture. Turn the power off immediately if the camera is wet and ask a qualified
service person for servicing. Moisture can damage the camera and also create the
danger of electric shock.
• Do not use strong or abrasive detergents when cleaning the camera body
Use a dry cloth to clean the camera when dirty. In case the dirt is hard to remove,
use a mild detergent and wipe gently.
• Never face the camera towards the sun
Do not aim the camera at bright objects. Whether the camera is in use or not, never
aim it at the sun or other extremely bright objects. Otherwise, the camera may be
smeared or damaged.
2
User’s Manual
Content
1. Overview.................................................................................................................................... 5
1.1 Product Features............................................................................................................. 6
1.2 Product Application ......................................................................................................... 7
2. Connecting the High Speed Dome.......................................................................................... 8
2.1 Package Content............................................................................................................. 8
2.2 Switch Definition.............................................................................................................. 9
2.3 RS-485 Setting................................................................................................................ 9
2.4 Dome ID Setting............................................................................................................ 10
2.5 Dome Control Protocol.................................................................................................. 10
2.6 22-Pin Connector Definition ...........................................................................................11
2.7 Alarm Pin Definition....................................................................................................... 13
2.8 RS-485 Connector ........................................................................................................ 13
3. Operation and Configuration................................................................................................. 14
3.1 OSD Display Format ..................................................................................................... 14
3.2 OSD Menu Tree............................................................................................................ 15
3.3 Configuration Menu....................................................................................................... 18
3.3.1 DEFAULT CAMERA........................................................................................ 18
3.3.2 BACKLIGHT.................................................................................................... 19
3.3.3 FOCUS............................................................................................................ 19
3.3.4 APERTURE..................................................................................................... 19
3.3.5 AE MODE........................................................................................................ 20
3.3.6 WBC MODE .................................................................................................... 21
3.3.7 ID DISPLAY..................................................................................................... 21
3.3.8 SETUP MENU................................................................................................. 22
•
FLIP (IMAGE/ME/OFF)............................................................................ 22
•
ZOOM SPEED......................................................................................... 23
•
SPEED BY ZOOM................................................................................... 23
•
AUTO CALIBRATION.............................................................................. 23
•
DIGITAL ZOOM ....................................................................................... 23
•
SLOW SHUTTER.................................................................................... 24
•
ANGLE ADJUSTER................................................................................. 24
•
RESET..................................................................................................... 24
•
EXIT......................................................................................................... 24
3.3.10 TITLE DISPLAY............................................................................................... 25
3
3.3.11 TITLE SETTING.............................................................................................. 25
3.3.12 ALARM SETTING............................................................................................ 26
User’s Manual
3.3.13 HOME SETTING............................................................................................. 27
3.3.14 SEQUENCE .................................................................................................... 29
3.3.15 AUTOPAN........................................................................................................ 30
3.3.16 CRUISE........................................................................................................... 32
3.3.17 IR FUNCTION (Removable IR Cut)................................................................. 33
3.3.18 ALARM DETECT (E/F/U Model Only)............... Error! Bookmark not defined.
3.3.19 WDR Setting (DR Model Only)........................................................................ 33
3.3.20 PRIVACY......................................................................................................... 34
3.3.21 TIME FUNCTION ............................................................................................ 36
3.3.22 SCHEDULE FUNCTION ................................................................................. 37
3.3.23 EXIT OSD........................................................................................................ 38
Appendix A: Technical Specification.......................................................................................... 39
OSD Menu Notes........................................................................................................................... 41
4
User’s Manual
1. Overview
ESD-370 is a new subcompact integrated high speed dome camera designed to deliver
superb performance and durability with an intelligent and stylish housing that is suitable
in any security and surveillance installation. ESD-370 serie s dome cameras support one
cabling for easy installation, and can be integrated with CCTV products, such as DVRs,
Control Keyboards, and CCTV accessories for a total surveillance solution.
The Integrated High Speed Dome Camera provides two models of new generation
advanced DSP color camera:
DR Model: 23× optical zoom multiply 12× digital magnifier
S Model: 22× optical zoom multiply 12× digital magnifier
The dome delivers the power of 312x zoom to allow dome cameras capture clear image
in the distance. Continuous Auto Focus, Back Light Compensation, Auto Exposure,
Digital Slow Shutter functions are provided for clear and high quality image. IR cut filter
removable ensures 24 hours operation; more Privacy Masks are specially designed to
avoid any intrusive monitoring at specific region; Wide Dynamic Range function, are
some of the salient features incorporated to fit your needs. The Home function allows
user to specify a preset position as the ‘home position’ or functions
(Sequence/Auto-pan/Cruise), dome camera can come back to home position or
functions when the user stops to control the camera for a user defined period of time.
Additionally, Scheduling function, the unique feature, enables users to program a preset
point or function (Sequence/Auto-pan/Cruise) automatically actions in certain period of
time.
The dome provides variable pan/tilt speeds ranging from a fast patrol of 400° per
second to a slow ramble of 5° per second with 0.225° pan accuracy for fast and
accurate tracking ability. The 360° endless rotation and -10°~190° tilt travel makes
tracking the object passing directly beneath the dome. Maximum 256 preset points can
5
be programmed for precise location of target areas, and you can also def ine 8 sequence,
4 auto-pan and 1 cruise routes for the camera to operate automatically. RS-485
communication port is available for remote control purposes.
The Integrated High Speed Dome Camera provides 8 alarm inputs and 2 alarm output,
and the smart alarm management mechanism can be programmed through OSD setup
menu; certain function (Preset/Sequence/Auto-Pan/Cruise) can be activated when an
User’s Manual
alarm is triggered.
Large set of built-in protocols provide connectivity to other surveillance systems. The
built-in protocols include ELMO, Pelco, VCL, Philips, AD-422 (Manchester), etc, which
allow the Integrated High Speed Dome Camera series to be integrated with other
suppliers' surveillance systems.
Dependability and ultra high reliability are key factors in the speed dome design cycle.
Every speed dome is assembled with meticulous care and thorough testing at our ISO
9001 compliant factory. High performance, reliability, and reasonably pricing make this
speed dome to be an ideal solution to your tough surveillance requirement.
1.1 Product Features
Precise and Accurate Tracking
•
Auto Calibration
•
Scheduling Functions
•
Pan driver accuracy of 0.225°
•
Preset speed up to 400°/sec.
•
Pan & Tilt proportional to Zoom Ratio
•
256 Preset Position/8 Sequence /4 Auto-Pan /1 Cruise
Day/Night Features
•
Removable IR Cut Filter (DR Model)
Low-Light Applications
•
Minimum illumination 0.01 Lux
•
Digital Slow Shutter
•
Electronic Shutter
Perfect Contrast Solution for High Image Quality
•
Wide Dynamic Range (DR Model)
•
Auto White Balance
•
Auto Gain Control
•
Backlight Compensation
•
Auto Iris Control
Multiple Built-in Protocols Enhanced High Compatibility
•
ELMO
•
Pelco D & P
•
VCL
•
Philip
6
User’s Manual
•
AD/AD-422
•
Chiper
Privacy Mask for Privacy Protection
•
Up to 24 privacy zones of camera view programmable
Dynamic Dome Configuration
•
Flexible In/Outdoor mountings
•
Compact lightweight design for easy installation
•
Weather resistant housing for temperature, sun ray, and rain
Integrated with Web, Enhanced Internet Capability (Optional)
•
Remote monitoring operation/system configuration/software upgrade
•
Include Window active applications
1.2 Product Application
Connect the dome camera to other devices as shown in the diagram to complete a
video surveillance solution.
7
User’s Manual
2. Connecting the High Speed Dome
Please refer to the following sections to connect, set and operate the dome camera. In
order to control the integrated high speed dome, basically a control keyboard or other
control device is required.
2.1 Package Content
Before proceeding, please check the box contains the items listed here. If any item is
missing, or if damage is evident, DO NOT install or operate t he product and contact your
dealer for assistance.
Dome Body
with 5” cover
Hard Ceiling Mount and
Decoration Ring
5.4” Optical Cover
Fixing Plate
50-cm cable for Power
Supply, Video and RS-485
8
User’s Manual
2.2 Switch Definition
First of all, configuring the dome ID and communication protocol is required before
connecting the dome camera to other devices. The switches used for configuring these
settings are located on the bottom of the dome camera.
Reserved
A
RS-485 Setting
B
Dome ID Setting
C
Dome Control Protocol
D
N/A
E
22-Pin Connector
F
2.3 RS-485 Setting
The RS-485 setting default is half-duplex, please do not change without qualified
specialist or supplier’s RS-485 is the interface that communicates the dome camera and
its control device; for this reason, the RS-485 setup of the dome and the control device
must the same. The RS-485 default setting is half-duplex.
RS-485 Communication
Indoor Dome
9
User’s Manual
Half-duplex
Full-duplex
Pin 3
Pin 4
Termination
Line Lock
2.4 Dome ID Setting
Use the switch to change your speed dome ID by turning the arrow to the desired
number respectively. For instance, if the dome ID is 123, the ID switch should be set as
below.
NOTE: No two domes should be given the same ID, or communication conflict
may occur.
Pin 5
Pin 6
Set Factory Default
Reserved
Centesimal decimal single digit
NOTE: The number “0” should locate upwards as shown in above diagram for
correct switch definition.
2.5 Dome Control Protocol
Protocol is a specific set of rules, procedures used for data communications. Basing on
the devices of your surveillance system and define the protocol you are going to use.
Generally , use one protocol even the devices are provided from dif ferent manufacturers.
Use the switch to set your dome control protocol and the baud rate. Refer to below table
and turn the arrow to choose a protocol for your speed dome.
Switch No. Protocol Baud Rate
00
01
02
04
05
VCL 9600
Pelco D 2400
Pelco P 4800
Chiper 9600
Philips 9600
10
User’s Manual
07
08
09
11
12
13
14
15
16
Select protocol: Pelco D, for instance, the ID switch should be set as below.
ELMO 9600
AD422 4800
DM P 9600
Pelco D 4800
Pelco D 9600
Pelco P 2400
Pelco P 9600
JVC 9600
GANZ 9600
Decimal single digit
2.6 22-Pin Connector Definition
A 50-cm data cable (as belowing figure) is shipped with the integrated high speed dome
for a quick installation for demo or testing usage.
The 22-pin connector definition is listed as below.
No. Pin Color Cable
11
1
2
3
4
5
6
AC24-1 White
Alarm Pin (Not wired)
AC24-2 Black
1007 20AWG
Alarm Pin (Not wired)
FG Green
Alarm Pin (Not wired)
User’s Manual
7
T+ Yellow
8
R- Orange
1007 24AWG
9
10
11~20
21
22
T- Green
R+ Brown
Alarm Pin (Not wired)
VGND
Video
12
User’s Manual
2.7 Alarm Pin Definition
The alarm pins are serviceable for connecting alarm in- and output devices. Following
lists the definition of alarm pin on the 22-pin connector located on the bottom of the
dome camera.
Pin Cable Color Definition
2
4
6
11
12
13
14
15
16
17
18
19
20
White ALM NO
Black ALM NC
Green ALM COM
Green/Black ISOG
Purple ALM-1
Gray ALM-3
Red ALM-2
Blue ALM-4
Blue/White ALM-5
Brown/White ALM-6
Red/White ALM-7
Purple/White ALM-8
Black/White ALM GND
2.8 RS-485 Connector
RS-485 is the interface that communicates the dome camera and its control device.
13
Please connect control keyboard to speed dome through the terminal block. The
recommended cables for RS-485 communication are CAT 5 cables; maximum cable
length for over 24-gauge wire is 4000 feet (1219 meters). If the total cable length is over
4000 feet, using a repeater to enlarge the signals is recommended.
Definition Cable Color
T+ (D+) Yellow
T- (D-) Green
R+ (D+) Brown
R- (D-) Orange
User’s Manual
3. Operation and Configuration
3.1 OSD Display Format
The information shown on the screen are described in terms of OSD display, position
and function description in the table below.
1
2
56
3
4
Position Function OSD Display Description
1
2
3
4
5
Focus Modes
Backlight
Alarm ALARM Alarm Message
Zoom Ratio ×1
Title
A Auto Focus Mode
M Manual Focus Mode
X
B
Back Light Compensation OFF
Back Light Compensation ON
Present Zoom Ratio
(Optical ZoomÆDigital Zoom)
• Maximum 20 characters for each title.
• 16 sets of title are available.
6
Camera ID Show the camera ID
14
User’s Manual
3.2 OSD Menu Tree
The OSD setup menu structure of S and DR models are listed below. The star symbol
indicates the factory default.
For detailed function description, please see section
3.3 Configuration Menu.
Item Layer 1 Layer 2 Layer 3 Default
DEFAULT
CAMERA
BACKLIGHT
FOCUS
APERTURE
AE MODE
WBC MODE
ID DISPLAY
<ON>, <OFF> ON
ON BLC Level <000> ~ <100>
OFF
AUTO Focus Length <1cm>, <10cm>, <30cm> <1m> 10 cm
MANUAL <01> ~ <08>
AUTO
MANUAL
AUTO IRIS OFFSET <00> ~ <99> 50
SHUTTER SHUTTER SPEED <1/2> ~ <1/30000>
IRIS IRIS <00> ~ <09>
AGC AGC <00> ~ <05>
AUTO
MANUAL
<ON>, <OFF> ON
FLIP <IMAGE>(DR model only), <M.E.>, <OFF> OFF
ZOOM SPEED <FAST>, <SLOW> Slow
SPEED BY ZOOM <ON>, <OFF> OFF
H APERTURE <00> ~ <31>
V APERTURE <00> ~ <31>
R Gain <00> ~ <99>
B Gain <00> ~ <99>
☆
☆
☆
SETUP MENU
TITLE DISPLAY
TITLE SETTING
ALARM SETTNG
15
AUTO CALI. <ON>, <OFF> OFF
DIGITAL ZOOM <1> ~ <12>, <OFF> OFF
SLOW SHUTTER
(DR model only)
ANGLE ADJUSTER
RESET YES
EXIT
<ON>, <OFF> OFF
<01> ~ <16> 01
ALARM PIN <1> ~ <8> 1
ALARM SWITCH <ON>, <OFF> OFF
ALARM TYPE <N.O.>, <N.C.> N.C.
ALARM ACTION
<1/2> ~ <1/60> Sec. (NTSC)
<1/1.5> ~ <1/50> Sec. (PAL)
ADJUST MIN ANGLE 00
ADJUST MAX ANGLE 90
RESET
PRESET
SEQUENCE
AUTOPAN
CRUISE
1/30
☆
User’s Manual
Item Layer 1 Layer 2 Layer 3 Default
PRESET POINT
SEQUENCE LINE
AUTOPAN LINE
CRUISE LINE
<001> ~ <256>
<1> ~ <8>
<1> ~ <4>
<1>
001
HOME SETTING
SEQUENCE
AUTOPAN
CRUISE
IR FUNCTION
(DR model only)
WDR SETTING
(DR model only)
PRIVACY
(DR model only)
DWELL TIME <001> ~ <127> Sec., ALWAYS
ALWAYS
EXIT YES
HOME FUNC. <ON>, <OFF> OFF
SELECT MODE
PRESET
☆
SEQUENCE
AUTOPAN
CRUISE
PRESET POINT
SEQUENCE LINE
AUTOPAN LINE
CRUISE LINE
<001> ~ <256>
<1> ~ <8>
<1> ~ <4>
<1>
001
RETURN TIME <001> ~ <128> Min. 001
GO ENTER
EXIT YES
SEQUENCE LINE <1> ~ <8> 1
SEQUENCE POINT <01> ~ <32> 01
PRESET POS. <001> ~ <255>, <END> 001
SPEED <01> ~ <15> 01
DWELL TIME <000> ~ <127> Sec. 000
RUN SEQUNECE ENTER
EXIT
AUTOPAN LINE <1> ~ <4> 1
START POINT <TO FIND>, <TO SAVE>
END POINT <TO FIND>, <TO SAVE>
DIRECTION <RIGHT>, <LEFT> Right
SPEED <01> ~ <04> 01
RUN AUTOP AN ENTER
EXIT
RECORD START
RECORD END
RUN CRUISE
EXIT
AUTO
THRESHOLD <LOW>, <MID>, <HI>
IR COLOR <B/W>, <COLOR>
LOW
B/W
EXIT
ON
WDR SWITCH <ON>, <OFF> OFF
WDR FUNCTION
AUTO
MANUAL
☆
RATIO LEVEL <000>~<128>
SHUTTER LEVEL <000>~<128>
IRIS OFFSET <000>~<128>
EXIT
PRIVACY SWITCH <ON>, <OFF> OFF
SHADE <BLACK>, <WHITE>, <GRAY> Gray
SET MASK <1> ~ <8>
H CENTER <000> ~ <256>
V CENTER <000> ~ <256>
H SIZE <000> ~ <127>
V SIZE <000> ~ <127>
16
User’s Manual
Item Layer 1 Layer 2 Layer 3 Default
TIME
SCHEDULE
EXIT OSD
MASK
CLEAR+RESET
MASK DSIPLAY <FIRST>, <LAST> First
EXIT YES
TIME DISPLAY <ON>, <OFF> OFF
SET YEAR
SET MONTH
SET DAY
SET HOUR
SET MINUTE
EXIT+SAVE
SCHEDULE SWITCH <ON>, <OFF> OFF
SCHEDULE POINT <01> ~ <32> 01
SCHEDULE HOUR 00
SCHEDULE MIN 00
SCHEDULE MODE
NO FUNCTION
PRESET
SEQUENCE LINE
AUTOPAN LINE
CRUISE LINE
IR FUNCTION
SCHEDULE RESET
SCHEDULE EXIT
YES
<01> ~< 08> 01
NONE
PRESET
SEQUENCE
AUTOPAN
CRUISE
IR FUNC.
<1> ~ <256>
<1> ~ <8>
<1> ~ <4>
<1>
<AUTO>, <ON>
☆
17
User’s Manual
3.3 Configuration Menu
The detailed functions and parameter settings of your high speed dome can be set by
the OSD (On Screen Display) menu with a control device, such as ELMO control
keyboard. The functions in OSD menu are described in the following sections.
E/F/U Model R/K Model
MAIN PAGE 1
DEFAULT CAMERA OFF
BACKLIGHT OFF
FOCUS AUTO
AE MODE AUTO
WBC MODE AUTO
ID DISPLAY ON
SETUP MENU1
SETUP MENU2
DEFAULT CAMERA OFF
BACKLIGHT OFF
FOCUS AUTO
APERTURE AUTO
AE MODE AUTO
WBC MODE AUTO
ID DISPLAY ON
SETUP MENU ENTER
MAIN PAGE 1
To enter the OSD menu of the selected camera, press <CAMERA MENU> button on
the control keyboard and hold for 3 seconds to enter the OSD menu.
To select the setup item, use direction keys on keyboard to move the OSD cursor in
the OSD menu.
To setup item, use direction keys on keyboard to move the OSD cursor in the OSD
menu. For items with →, press right/left direction buttons on the control keyboard to
select. For items with ↓, press <CAMERA MENU> button on the control keyboard to
enter sub menu. For items with →↓, users can use the right/left direction buttons to
select functions then press the <CAMERA MENU> button on the control keyboard to
enter its sub menu.
For further detailed setup procedures, please refer to the user’s manual of your installed
control devices.
3.3.1 DEFAULT CAMERA
The DEFAULT CAMERA is used to restore the camera settings (e.g.
Backlight/Focus/AE/WBC/Aperture). Once any one of the items is modified, the setting
will become <OFF> automatically. Select <ON> for this item to recall the mentioned
18
User’s Manual
camera parameters.
3.3.2 BACKLIGHT
The Backlight compensation function prevents the center object from being too dark in
surroundings where excessive light is behind the center object.
The Backlight Compensation Level ranges from 000 to 100.
BLC LEVEL
LEVEL 20
EXIT YES
NOTE: If this function is enabled, the WDR function (for DR model only) will be
disabled automatically. For details, refer to section
3.3.3 FOCUS
Automatically adjusts the focus position to maximize the high frequency content of the
picture in a center measurement area, taking into consideration the high luminance and
strong contrast components. The focus of the dome camera can be operated in two
modes: Manual Focus mode and Auto Focus mode. Different settings for various
models are described as follows.
• AUTO
The optimum focus is achieved by the internal digital circuit. Users can adjust the
minimum auto focus range for some special conditions; the options are <1 cm>, <10
cm>, <30 cm> and <1 m>.
• MANUAL
In this focus mode, users can adjust the lens focus manually by pressing the Focus
Near/Far button on the control keyboard.
3.3.19 WDR Setting.
3.3.4 APERTURE
Sharpness is the subjective evaluation of detail in the picture. With this APERTURE
19
FOCUS LENGTH
TURNING VALUE 10CM
EXIT YES
User’s Manual
function, users can adjust the enhancement of the edges of objects in the picture. When
shooting text, this function may help by making them sharper and achieve a better
image. There are 32 levels of adjustment; the options are <00> ~ <31>, <00> represents
“no enhancement”.
• AUTO
The dome camera will assign a proper aperture value automatically for camera to
achieve a better image.
• MANUAL
Select this item if you want to adjust aperture value manually. Higher value
enhances the incident ray of camera.
APERTURE MENU
H APERTURE 15
V APERTURE 15
3.3.5 AE MODE
The exposure is the amount of light received by the image sensor and is determined by
how wide you open the lens diaphragm (
sensor exposed (
can define how the Auto Exposure (AE) function works.
• AUTO
In this mode, the camera’s Shutter, IRIS and AGC control function work
automatically to compensate the light exposure of image sensor for consistent video
output level. IRIS OFF SET is used to set the level of IRIS variation.
• SHUTTER
With this option, the SHUTTER priority is higher than IRIS and AGC; IRIS and AGC
circuit will function automatically in cooperating with SHUTTER to get consistent
exposure.
shutter speed), and other exposure parameters. With this item, users
iris adjustment), by how long you keep the
• IRIS
With this option, the IRIS priority is higher than SHUTTER and AGC; SHUTTER and
AGC circuit will function automatically in cooperating with IRIS to get consistent
exposure. If the IRIS is modified manually, the action of exposure compensation
20
User’s Manual
depends on the AGC circuit.
• AGC
With this option, the AGC priority is higher than SHUTTER and IRIS; SHUTTER and
IRIS circuit will function automatically in cooperating with AGC to get consistent
exposure. If AGC is adjusted manually, the exposure compensation depends on the
changing of IRIS.
3.3.6 WBC MODE
A digital camera needs to find reference color temperature, which is a way of measuring
the quality of a light source, for calculating all the other colors. The unit for measuring
this ratio is in degree Kelvin (K). You can select one of the White Balance Control modes
according to the condition. The following table shows the color temperature of some
light sources.
Light Sources Color Temperature in K
Cloudy Sky 6,000 to 8,000
Noon Sun and Clear Sky 6,500
Household Lighting 2,500 to 3,000
75-watt Bulb 2,820
Candle Flame 1,200 to 1,500
• AUTO
In this mode, white balance works within its color temperature range and calculates
the best-fit white balance.
• MANUAL
In this mode, users can change the White Balance value manually; adjustable R
gain and B gain range from 0 to 99.
WBC MENU
R GAIN 50
B GAIN 50
3.3.7 ID DISPLAY
Users are allowed to choose whether the dome ID will be displayed on monitor to
identify the domes. For more information, please refer to section
21
2.4 Dome ID Setting.
User’s Manual
• ON
Display the ID address of the selected dome on the right bottom of the monitor
screen.
• OFF
Hide the ID address of the selected dome.
3.3.8 SETUP MENU
Users can adjust camera lens model parameters under SETUP MENUs. Depending on
the model of dome cameras, the SETUP MENUs are different.
E/F/U Model
SETUP MENU1
FLIP ENTER
ZOOM SPEED 1
SPEED BY ZOOM OFF
AUTO CALI. OFF
DIGITAL ZOOM 12
SLOW SHUTTER OFF
ANGLE ADJUSTER ENTER
RESET YES
EXIT YES
APERTURE 01
MASK DISPLAY FIRST
SETUP MENU2
R/K Model
SETUP PAGE
FLIP ON
ZOOM SPEED FAST
SPEED BY ZOOM ON
AUTO CALI. OFF
DIGITAL ZOOM 12
SLOW SHUTTER 1/2
ANGLE ADJUSTER ENTER
RESET YES
EXIT YES
• FLIP (IMAGE/ME/OFF)
User can track an object continuously when it passes through under dome camera
with setting Flip to IMAGE (digital flip) or M.E. (mechanical flip).
FLIP SETTING
FLIP OFF
EXIT YES
22
User’s Manual
IMAGE represents digital IMAGE FLIP, enables users to keep tracking object
seamlessly and no delay occurs in comparing with mechanical flip.
NOTE: The Privacy Mask function will be automatically disabled if the Image
Flip function is enabled, and “Masking will be disabled” will be displayed on
the screen.
M.E.
The item is a standard mechanical operation. As the dome tilts 90°, it will pan 180°,
then continuing tilt to keep tracking object.
OFF
Select this item to disable the flip function.
NOTE: The dome will only be able to tilt 90°, or -10° ~100° with angle
adjuster adjustments.
• ZOOM SPEED
This item is used to set the zoom speed for operating the dome camera.
The options are <FAST> and <SLOW> (default).
• SPEED BY ZOOM
If the item is set to <ON>, the pan/tilt speed will be adjusted by internal algorithm
when zooming automatically. The larger zoom ratio leads the lower rotation speed.
• AUTO CALIBRATION
There are one horizontal and one vertical infrared rays check points in each dome.
When the dome camera position may be moved during installation or maintenance,
the relative distance between the original set point and the check point has been
changed. Enable the Auto Calibration function, the dome will automatically detect
that and reset the point back to the original position.
• DIGITAL ZOOM
23
With this item, users can enable or disable the 12× Digital Zoom. The Digital Zoom
activate after the full Optical Zoom level is reached.
NOTE: The difference between optical and digital zoom is that optical zoom
uses the lens within the camera to draw the image closer via zoom in or out
to achieve the desired effect. Optical zoom remains the same and the full
User’s Manual
resolution of the zoomed image quality. On the other hand, Digital zoom
takes a portion of image and expands that image to the full size of the image;
however the image quality will be reduced.
Digital zoom ratio is adjustable from <1> to <12>.
• SLOW SHUTTER
The shutter speed determines how long the image sensor is exposed to light. To see
clear image in a dark environment, enable this function and select a slower shutter
speed.
The shutter speed is adjustable on DR model. With the slowest shutter speed, users
can see objects in a dark environment under 0.2 lux; or see a smooth video image
with a higher shutter speed. The options are from <1/2> to <1/60>.
• ANGLE ADJUSTER
The item is for adjusting the camera view angle. The ranges of view angle are
changed in different FLIP mode: the angle ranges from -10° to +100° with ME FLIP
and FLIP OFF modes, and from -10° ~ +190° with IMAGE FLIP mode. With IMAGE
FLIP function, users are able to adjust the view angle from -10° ~ +190° to catch
the true horizontal line.
ANGLE ADJUSTER
ADJUST MIN ANGLE -10 DEG
AX
ADJUST M
EXIT+SET YES
ANGLE 100 DEG
• RESET
Select this item to reset all the camera parameters of SETUP MENUs to the factory
default.
• EXIT
Exit the SETUP MENU1 and go back to MAIN MENU.
24
User’s Manual
3.3.10 TITLE DISPLAY
Users are allowed to name a certain view area and display its title for easy recognition.
At this item, users can choose to display or not to display the titles set in advance.
• ON
A title set for certain view will be displayed when the dome back to the view area.
• OFF
When the TITLE DISPLAY is set <OFF>, no title will be displayed on the screen
even titles are set in advance.
3.3.11 TITLE SETTING
Up to 16 zone titles can be set with maximum 20 characters for each title; two mask
zones are allowed to set in a view area. Users can name the zone titles with privacy
mask ID numbers for future recognition.
NOTE: For DR model, the available area for setting privacy mask is restricted
within tilt angle 45°.
Follow the steps to set a camera title.
STEP 1: Operate dome to certain view area where you want to set a title for it.
STEP 2: Turn on OSD and select <TITLE SETTING>.
STEP 3: Select a number to indicate the view area.
STEP 4: Press <ENTER> to go into editing mode.
TITLE SETTING: 01
0 1 2 3 4 5 6 7 8 9 EXIT
A B C D E F G H I J SAVE
K L M N O P Q R S T LEFT
U V W X Y Z : / . , RIGHT
[ ] + ? - DELETE
TITLE:
ABC
25
STEP 5: Choose a character with direction keys and then press <ENTER> to input.
Example: <A > <ENTER>, <B> <ENTER>, <C> <ENTER>
TITLE: ABC
STEP 6: To delete entered characters, move the cursor to <LEFT> or <RIGHT> and
press <ENTER> to select a character in entry field, then move the cursor to
User’s Manual
<DELETE> and press <ENTER> to delete the selected character.
STEP7: When the setting is completed, move the cursor to <SAVE> and press
<ENTER> to save.
3.3.12 ALARM SETTING
The integrated high speed dome provides eight alarm inputs and two alarm outputs (N.O.
and N.C) to connect alarm devices. With this function, dome will cooperates with alarm
system to catch the event images. For wiring, please refer to the installation guide
and/or qualified service personnel. Alarm parameters can be set on this page.
ALARM SETTING
ALARM PIN 1
ALARM SWITCH OFF
ALARM TYPE N.C.
ALARM ACTION PRESET
PRESET POINT 001
DWELL TIME ALWAY
EXIT YES
• ALARM PIN
The dome provides 8 alarm inputs and 2 outputs (1× N.O. and 1× N.C.). Select an
alarm connector which you want to set its alarm-related parameters with this item,
and then set its alarm-related parameters in Alarm Setting menu. For alarm pin
definitions, please refer to section
2.6 Alarm Pin Definition or installation guide.
• ALARM SWITCH
The item is used to enable or disable the selected alarm pin function. Use the
left/right direction keys on the control keyboard to change the setting.
• ALARM TYPE
There are two kinds of alarm types: Normal Open and Normal Close, which are
illustrated as below. Select an alarm type that corresponds with the alarm
application.
26
User’s Manual
• ALARM ACTION
Select one of these modes that choose a kind of actions that should be executed
when an alarm is triggered. The alarm actions can be set to execute the preset
position, sequence, auto-pan or cruise function. Use the right direction key of the
control keyboard to change the setting, and the bellowing items will change in
cooperating with your selection.
• PRESET
Select a preset point where the dome should go when an alarm pin is triggered. The
Preset points can be set by a control keyboard.
SEQUENCE
Select a sequence line that the dome camera should execute when alarm pin is
triggered. The Sequence line should be defined prior in SEQUENCE setup menu.
AUTOPAN
Select an auto-pan line that the dome camera should execute when alarm pin is
triggered. The Auto-pan line can be defined in setup AUTOPAN menu.
CRUISE
Select a cruise line that the dome camera should execute when alarm pin is
triggered. The Cruise line can be defined in CRUISE setup menu.
• DWELL TIME
The DWELL TIME is the duration of executing ALARM ACTION: Preset or Sequence.
When alarm takes place, the dome will go to the preset position or execute
sequence function and stay at each sequence point for a period of time (1~127
seconds). If select <Always>, the dome will go to the preset position and stay there
until alarm condition is released or users rotate the dome.
NOTE: The DWELL TIME is only accessible when selecting ALARM
ACTION: Preset or Sequence.
• EXIT
Exit the ALARM SETTING menu.
3.3.13 HOME SETTING
Users are able to set an operation mode to ensure constant monitoring; if the dome idles
for a period of time, the pre-set function will be activated automatically, this is the HOME
function. HOME function allows constant and accurate monitoring, to avoid the dome
27
User’s Manual
stops or missing events.
HOME SETTING
HOME FUNCTION OFF
SELECT MODE PRESET
PRESET POINT 001
RETURN TIME 001
GO ENTER
EXIT YES
• HOME FUNCTION
The item is used to enable or disable the HOME function. Use the left/right direction
keys of the control keyboard to change the setting.
• SELECT MODE
Select one of the modes that the dome should execute when HOME function is
enabled and the RETURN TIME is up. The options are <AUTOPAN>,
<SEQUENCE>, <CRUISE> and <PRESET>. Use the left/right direction keys of the
control keyboard to change the setting, and the bellowing items will change in
cooperating with your selection.
• PRESET
Select a preset point where the dome should go when alarm pin is triggered.
SEQUENCE
Select a sequence line that the dome camera should execute when an alarm pin is
triggered. The Sequence line should be defined prior in SEQUENCE setup menu.
AUTOPAN
Select an auto-pan line that the dome camera should execute when alarm pin is
triggered. The Auto-pan line can be defined in AUTOPAN setup menu.
CRUISE
Select a cruise line that the dome camera should execute when alarm pin is
triggered. The Cruise line can be defined in CRUISE setup menu.
• RETURN TIME
The dome starts to count down RETURN TIME when the dome idles, and will
execute the SELECT MODE function if the return time is up. The RETURN TIME
ranges from 1 to 128 minutes.
• GO
If HOME function is enabled, the users are allowed to execute HOME function
28
User’s Manual
manually by selecting this item.
• EXIT
Exit the HOME SETTING menu.
3.3.14 SEQUENCE
The function executes pre-positioning of the pan, tilt, zoom and focus features in a
certain sequence for a camera. Before set up this function, users must setup at least two
preset points.
SEQUENCE
SEQUENCE LINE 1
SEQUENCE POINT 01
PRESET POSITION 001
SPEED 1
DWELL TIME 001
RUN SEQUENCE ENTER
EXIT YES
• SEQUENCE LINE
There are eight sets of sequence lines built in the dome camera. Using LEFT/RIGHT
direction keys to select a line first and then set its sequence points.
• SEQUENCE POINT
Up to 32 points can be specified for each sequence line. The sequence points
represent the orders of the preset points that the dome will automatically run, and
the bellowing setup items; PRESET POSITION, SPEED, and DWELL TIME, are
related to this item.
• PRESET POSITION
Users can assign a specific preset position to the selected sequence point with this
item.
• SPEED
Users can set the Speed that the dome goes to the next sequence point, and the
29
setup speed range is from 1 ~ 15. Refer to below table for more information.
PAN (degree/sec.) TILT (degree/sec.)
Speed 1 10 8
Speed 2 23 12
Speed 3 35 22
User’s Manual
Speed 4 45 30
Speed 5 55 40
Speed 6 65 50
Speed 7 75 58
Speed 8 185 185
Speed 9 205 210
Speed 10 225 240
Speed 11 250 275
Speed 12 280 305
Speed 13 320 335
Speed 14 365 365
Speed 15 400 400
• DWELL TIME
The DWELL TIME is the duration time that the dome will stay at the sequence point,
and the range is from <0> to <127> seconds. The dome will go to the next sequence
point when the DWELL TIME is up. If the setting is <0>, the dome will stay at this
sequence point until users manually move the dome.
• RUN SEQUENCE
User can command the dome camera to run the selected Sequence line manually.
• EXIT
Select the item to exit the SEQUENCE menu.
3.3.15 AUTOPAN
Auto-pan means rotating or scanning side-to-side motion by a dome camera to view an
area horizontally. The parameters can be set on this page.
AUTOPAN
AUTOPAN LINE 1
START POINT
END POINT
DIRECTION RIGHT
SPEED 1
RUN AUTOPAN ENTER
EXIT YES
TO FIND
TO FIND
• AUTOPAN LINE
There are four sets of auto-pan lines built in dome camera. Users can choose a line
to execute using LEFT/RIGHT direction keys. Users are able to command the dome
camera to do continuously panning without limit by setting the start point the same
30
User’s Manual
as endpoint.
• START POINT
Follow the description to set the start position of the AUTOPAN path.
1. Move the cursor to <START POINT> and press <ENTER> while <TO FIND>
item flashes, the item will turn <TO SAVE> automatically.
2. Move the dome to a desired position and press <ENTER> to save the position as
the start point; the cursor will move to <END POINT> automatically. Ensure to
set the end point to complete the auto-pan setting.
NOTE: The tilt and zoom value of the start point will be recorded and fixed
for the selected auto-pan line.
• END POINT
Users are able to set the end point after the start point is defined. Pan the dome to
another position and press <ENTER> to save the position as the end point.
• DIRECTION
The item is for setting the AUTOPAN direction of dome camera. The dome will start
to pan clockwise from the start point to the end point if your selection is <RIGHT>,
and then return to the start point. The dome will start to pan anti-clockwise from the
start point to the end point if your selection is <LEFT>. Refer to below diagram.
• SPEED
31
The item is for defining the dome camera rotation speed while running auto-pan. The
speed is adjustable from 1 to 4; refer to the table below for details.
Speed 1
Speed 2
PAN (degree/sec.)
10
23
User’s Manual
Speed 3
35
Speed 4
• RUN AUTOPAN
After the setting is completed, select this item to manually execute the Auto-pan
function.
• EXIT
Exit the AUTOPAN setup menu.
3.3.16 CRUISE
A Cruise is a route of manual operations that can be stored and recalled to execute
repeatedly. It can be formed of pan, tilt position.
45
CRUISE
RECORD START ENTER
RECORD END ENTER
RUN CRUISE ENTER
EXIT YES
• RECORD START
Follow the description to record the CRUISE path.
1. Rotate the dome camera to a desired view area, and press <ENTER> to build
the cruise path using joystick on the control device. The percentage of the
memory buffer will be displayed on the screen.
NOTE: Beware of the memory size when building the cruise path. After the
percentage of the buffer becomes 100%, the path will not be recorded.
• RECORD END
The cursor will be moved to RECORD END while building the cruise line; when the
setting is completed, press <ENTER> to save the path.
• RUN CRUISE
After the setting is completed, select this item to manually execute the Cruise
function.
• EXIT
Exit the CRUISE setup menu.
32
User’s Manual
3.3.17 IR FUNCTION (Removable IR Cut)
With the IR cut filter, the dome can still catch clear image at night time or very dark light
condition. During day time, the IR cut filter will be on to block the infrared light for clear
image; during night time, the IR cut filter will be removed to catch infrared light to view
images in black and white. Only with DR model, users are able to view color images
when the IR function activated.
Refer to the description to operate the removable IR cut filter.
IR FUNCTION
THRESHOLD LOW
IR COLOR COLOR
EXIT YES
• AUTO
The Internal circuit will automatically decide the occasion to remove the IR cut filter
according to the image brightness level.
THRESHOLD
The dome will remove the filter immediately when the threshold value is reached.
The threshold options are <LOW>, <MID> and <HI>. <LOW> threshold indicates a
higher sensitivity and can improve the reliability of lens.
IR COLOR
When IR function is enabled, the video output can be programmed as color or B/W.
• ON
Select the item to remove the IR cut filter.
3.3.19 WDR Setting (DR Model Only)
The Wide Dynamic Range function is especially effective in solving indoor and outdoor
contrast issues to enhance better image quality and video performance. It enables the
dome to catch detailed data from the dark part (Indoor) without any saturation from the
bright part (Outdoor). The parameter of WDR function can be set on this page.
NOTE: The Backlight function will automatically turned off when the WDR
33
User’s Manual
function is enabled, because the WDR function has better effect than the
Backlight compensation.
WDR SETTING
WDR SWITCH OFF
WDR FUNCTION AUTO
EXIT YES
• WDR SWITCH
Enable or disable the WDR function with the item.
• WDR FUNCTION
This item is used to define the WDR function mode.
AUTO
If select <AUTO>, the dome camera operates the WDR function automatically.
MANUAL
Users are allowed to adjust WDR function manually by defining the RATIO LEVEL,
SHUTTER SPEED and IRIS OFFSET value.
• EXIT
Exit this setup menu.
3.3.20 PRIVACY
The Privacy Mask function aims to avoid any intrusive monitoring. Users can adjust the
camera view position using joystick, and adjust the mask size and area via the direction
keys on control keyboard. The dome camera will memorize the center of the selected
view as an original point, so the joystick will be locked as users enter the Privacy Setup
WDR MODE
RATIO LEVEL 000
SHUTTER SPEED 000
IRIS OFFSET 000
EXIT YES
menu. Refer to the description for setting Privacy masks.
NOTE: The Image Flip function will be disabled automatically while the Privacy
function is enabled.
34
User’s Manual
PRIVACY
PRIVACY SWITCH ON
SHADE GRAY
SET MASK 01
MASK CLEAR+RESET 01
MASK DISPLAY FIRST
EXIT YES
• PRIVACY SWITCH
The item is used to enable or disable masking function. Set this item to <ON> before
configuring mask zone.
• SHADE
The color of privacy mask can be selected through this item. The available colors
are black, gray and white.
• SET MASK
After pressing <ENTER> on this item, dome will memorize this position as privacy
mask position, up to 8 masks can be set. The model restricts the mask zones to be
set too close with each other.
MASK01 MENU
H CENTER 000
V CENTER 000
H SIZE 000
V SIZE 000
+
H CENTER (000~256)
The original center of mask zone is the center of screen. User can move the center
of mask zone to another position through adjust this value by pressing the
LEFT/RIGHT keys.
V CENTER (000~256)
The original center of mask zone is the center of screen. User can move the center
of mask zone to another position through adjust this value by pressing the
LEFT/RIGHT keys.
35
H SIZE (000~127)
User can adjust the horizontal size of privacy mask through this item. Set the H and
V size to 0 can also delete the selected mask.
V SIZE (000~127)
User can adjust the vertical size of privacy mask through this item. Set the H and V
size to 0 can also delete the selected mask.
User’s Manual
• MASK CLEAR+RESET
The item is used to clear the mask settings of the selected privacy mask. Use
LEFT/RIGHT direction keys to select a mask and press <ENTER> to erase its
configuration.
• MASK DISPLAY
This item is used to set the occasion to display privacy mask.
FIRST
If select this mode, the camera will detect the mask zone of the next preset position
and display the mask in advance, then pan the dome to the preset point.
LAST
If select this mode, the camera will move the dome to the preset point, then display
the mask zone.
NOTE: For DR model, the available area for setting privacy mask is restricted
within tilt angle 45°, and two mask zones are allowed to set in a view area.
• EXIT
Exit this page.
3.3.21 TIME FUNCTION
The item is used to set the TIME related parameters of the integrated high speed dome.
TIME SETTING
TIME DISPLAY OFF
SET YEAR 05
SET MONTH 10
SET DAY 02
SET HOUR 12
SET MINUTE 12
+
• TIME DISPLAY
Select <ON> to display the Time information on screen, or <NO> not to display.
• YEAR / MONTH / DAY
The items are for setting up the system date.
36
User’s Manual
• HOUR / MINUTE
The items are for setting up the system time.
• EXIT+SAVE
Exit this page.
3.3.22 SCHEDULE FUNCTION
The unique Scheduling function enables users to program a preset point or function
(Sequence/Auto-pan/Cruise) automatically actions in certain period of time.
SCHEDULE
SCHEDULE SWITCH ON
SCHEDULE POINT 01
SCHEDULE HOUR 11
SCHEDULE MINUTE 53
SCHEDULE MODE
PRESET POINT 001
SCHEDULE RESET YES
PRESET
• SCHEDULE SWITCH
Select <ON> to enable the Schedule function or <OFF> to disable.
• SCHEDULE POINT
Users are allowed to set up 32 schedule points.
• SCHEDULE HOUR / MINUTE
The items are for setting up the time of schedule points.
• SCHEDULE MODE
This is for setting the Schedule function of the selected schedule point; the options
are as follows.
NONE
No function will be executed for the schedule by selecting the item.
37
PRESET
Select one of the defined preset points for the selected schedule.
SEQUENCE
Select one of the eight defined sequence lines for the schedule.
AUTOPAN
Select one of the four defined auto-pan lines for the selected schedule.
CRUISE
User’s Manual
Enable the Cruise function for the selected schedule.
IR FUNCTION
Select <AUTO> or <ON> to enable the function for the schedule.
3.3.23 EXIT OSD
To exit the OSD setup menu, users can either select this item, or press the ESC button
on control keyboard quickly.
38
Ω
User’s Manual
Appendix A: Technical Specification
All specifications are subject to change without notice.
Items S Model DR Model
CAMERA
Effective Pixels
Resolution
Scanning Area
Scanning System
Synchronization
Video Output
S/N Ratio (AGC OFF)
Minimum Illumination 1 lux
Focal Length 4~88 mm 3.6~82.8 mm
Zoom Ratio 22× optical zoom 23× optical zoom
Digital Zoom
Focus Mode
White Balance
Iris Control
Electronic
Shutter
AGC control
Back Light
Compensation
OPERATION
Built-in Protocol ELMO, Pelco, VCL, Philips, AD-Manchester, AD-422, etc.
Pan Travel 360° endless
Tilt Travel -10°~100° -10°~190°
Manual Speed 1°~90°/s
Presets 256
Accuracy
Preset Speed**
Cruise 1
Sequence 8
Auto Pan 4
Privacy Mask - 8
Pan & Tilt Proportional
to Zoom Ratio
P/T/Z Auto-Restoring Yes Yes
Auto Turn Around Yes Yes
Zone Title Yes Yes
Home Function Yes Yes
Digital Flip - Yes
Digital Slow Shutter - Yes
Motion Detection - Wide Dynamic Range - Yes
Day/Night: IR Cut Filter - Yes
**There are D&E motors, differentiated by the type of motors of high speed dome cameras and presents various “Preset Speed” and
NTSC 380k
PAL 440k
NTSC 470 TV lines 470 TV lines Horizontal
PAL 460 TV lines 470 TV lines
Progressive
1/4" CCD
PAL, NTSC
Internal / Line Lock
1.0 Vp-p / 75
More than 49dB
×
1 ~ ×12 variable
Auto / Manual
Auto / Manual
Auto / Manual
NTSC
PAL
Pan 0.225° Preset
Tilt 0.45°
Pan 5°~400°/s, High Resolution (Both D&E Type Motor)
Tilt 5°~400°/s, Standard Resolution (D Type Motor). 5°~400°/s, High Resolution (E Type
1/2~1/4k sec. 1/2~1/4k sec.
1/1.5~1/4k sec 1/1.5~1/4k sec
Auto / Manual
On / Off
Yes Yes
, BNC
Motor)
Progressive
1/4" CCD
0.01 lux, 0 lux
(IR illuminator)
39
User’s Manual
resolutions. Standard Resolution: 768 steps/circle. High Resolution: 1600 steps/circle
GENERAL
Environment Indoor
Controller Interface RS-485
Operating Temperature 0°C~40°C (32°F~104°F)
Dimension ∅131×226mm (5.2x7.6 Inches)
Weight 1.6kg (3.5 lbs)
Power Source AC 24 V
Power Consumption 30 W
Regulatory CE, FCC
40
User’s Manual
OSD Menu Notes
The following OSD menu tables are provided for users to record the dome settings.
Item Layer 1 Layer 2 Layer 3 Note
DEFAULT CAMERA <ON>, <OFF>
BACKLIGHT
FOCUS
APERTURE
AE MODE
WBC MODE
ID DISPLAY <ON>, <OFF>
ON BLC Level <000> ~ <100>
OFF
AUTO Focus Length <1cm>, <10cm>, <30cm> <1m>
MANUAL <01> ~ <08>
AUTO
MANUAL
AUTO IRIS OFFSET <00> ~ <99>
SHUTTER SHUTTER SPEED <1/2> ~ <1/30000>
IRIS IRIS <00> ~ <09>
AGC AGC <00> ~ <05>
AUTO
MANUAL
FLIP <IMAGE>(DR model only), <M.E.>, <OFF>
ZOOM SPEED <FAST>, <SLOW>
SPEED BY ZOOM <ON>, <OFF>
H APERTURE <00> ~ <31>
V APERTURE <00> ~ <31>
R Gain <00> ~ <99>
B Gain <00> ~ <99>
AUTO CALI. <ON>, <OFF>
DIGITAL ZOOM <1> ~ <12>, <OFF>
SETUP MENU
TITLE DISPLAY <ON>, <OFF>
TITLE SETTING <01> ~ <16>
ALARM SETTNG
HOME SETTING
SEQUENCE SEQUENCE LINE <1> ~ <8>
SLOW SHUTTER
(DR model only)
ANGLE ADJUSTER
RESET YES
EXIT
ALARM PIN <1> ~ <8>
ALARM SWITCH <ON>, <OFF>
ALARM TYPE <N.O.>, <N.C.>
ALARM ACTION
PRESET POINT
SEQUENCE LINE
AUTOPAN LINE
CRUISE LINE
DWELL TIME <001> ~ <127> Sec., ALWAYS
EXIT YES
HOME FUNC. <ON>, <OFF>
SELECT MODE
PRESET POINT
SEQUENCE LINE
AUTOPAN LINE
CRUISE LINE
RETURN TIME <001> ~ <128> Min.
GO ENTER
EXIT YES
<1/2> ~ <1/60> Sec. (NTSC)
<1/1.5> ~ <1/50> Sec. (PAL)
ADJUST MIN ANGLE
ADJUST MAX ANGLE
RESET
PRESET
SEQUENCE
AUTOPAN
CRUISE
<001> ~ <256>
<1> ~ <8>
<1> ~ <4>
<1>
PRESET
SEQUENCE
AUTOPAN
CRUISE
<001> ~ <256>
<1> ~ <8>
<1> ~ <4>
<1>
41
User’s Manual
Item Layer 1 Layer 2 Layer 3 Note
SEQUENCE POINT <01> ~ <32>
PRESET POS. <001> ~ <255>, <END>
SPEED <01> ~ <15>
DWELL TIME <000> ~ <127> Sec.
RUN SEQUNECE ENTER
EXIT
AUTOPAN LINE <1> ~ <4>
START POINT <TO FIND>, <TO SAVE>
END POINT <TO FIND>, <TO SAVE>
AUTOPAN
CRUISE
IR FUNCTION
(DR model only)
WDR SETTING
(DR model only)
PRIVACY
(DR model only)
TIME
SCHEDULE
EXIT OSD YES
DIRECTION <RIGHT>, <LEFT>
SPEED <01> ~ <04>
RUN AUTOP AN ENTER
EXIT
RECORD START
RECORD END
RUN CRUISE
EXIT
AUTO
ON
WDR SWITCH <ON>, <OFF>
WDR FUNCTION
EXIT
PRIVACY SWITCH <ON>, <OFF>
SHADE <BLACK>, <WHITE>, <GRAY>
SET MASK <1> ~ <8>
MASK CLEAR+RESET <01> ~< 08>
MASK DSIPLAY <FIRST>, <LAST>
EXIT YES
TIME DISPLAY <ON>, <OFF>
SET YEAR
SET MONTH
SET DAY
SET HOUR
SET MINUTE
EXIT+SAVE
SCHEDULE SWITCH <ON>, <OFF>
SCHEDULE POINT <01> ~ <32>
SCHEDULE HOUR
SCHEDULE MIN
SCHEDULE MODE
NO FUNCTION
PRESET
SEQUENCE LINE
AUTOPAN LINE
CRUISE LINE
IR FUNCTION
SCHEDULE RESET
SCHEDULE EXIT
THRESHOLD <LOW>, <MID>, <HI>
IR COLOR <B/W>, <COLOR>
EXIT
AUTO
MANUAL
NONE
PRESET
SEQUENCE
AUTOPAN
CRUISE
IR FUNC.
<1> ~ <256>
<1> ~ <8>
<1> ~ <4>
<1>
<AUTO>, <ON>
RATIO LEVEL <000>~<128>
SHUTTER LEVEL <000>~<128>
IRIS OFFSET <000>~<128>
H CENTER <000> ~ <256>
V CENTER <000> ~ <256>
H SIZE <000> ~ <127>
V SIZE <000> ~ <127>
42
ELMO USA Corp.
1478 Old Country Rd.
Plainview, NY 11803
Loading...
