Page 1
Adelaide
Assembly Instructions
INCLUDES IMPORTANT SAFETY INFORMATION.
{ }
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Page 2
02
Should you prefer to
speak with a customer
service representative,
you may call toll free:
1-855-372-2315.
Page 3
Limited Warranty
Millwork Holdings seating products are warranted against
defects in material and workmanship while owned by the
“Original Purchaser”. The term “Original Purchaser” is
defined as that party or entity which purchases Millwork
Holdings furniture from an authorized Millwork Holdings
retailer as shown by the original sales receipt. This
warranty does not apply to “as is” or previously owned
seating products.
Millwork Holdings warrants its products to be free from
defects in materials and workmanship (normal wear and
tear, fading and stretching excepted), for one year from
the date of purchase, except as provided below under
the limited warranty.
This warranty gives you specific rights, and you may also
have other rights, which vary from state to state.
All warranties are limited to the original purchaser for
normal use by a maximum of two users. Total weight
capacity per chair is 250 pounds for a single user.
The exceptions or exclusions to this warranty are:
• Upholstery material and foam cushion material is
warranted against defects in material and workmanship for
a period of one year, beginning on the date of purchase as
shown on the original sales receipt.
• Any warranty claim that is submitted after the limited
warranty period, or without proper proof of purchase
will not include the cost of parts, labor, or delivery on the
warranted parts within a reasonable amount of time. We
reserve the right to require damaged parts to be returned
to us upon request. Natural markings such as scars, brands,
grain variations, wrinkles, color variations, etc. will be
considered normal characteristics and not construed as
defects.
• For claims or questions concerning this warranty, please
contact Millwork Holdings Customer Service department
on the web at www.truecustomersupport.com. Be prepared
to provide your name, address, daytime phone number,
the model and purchase order number of the product,
date of purchase, and the store where it was purchased.
Millwork Holdings requires that the original sales receipt
be submitted with all requests to confirm that you are the
original purchaser according to our written warranty.
03
Page 4
Guidelines
Thank you for selecting an Elle Decor piece!
Our primary objective is to provide fast, friendly
customer service to all of our customers. We are here
to help if you have any questions, comments, or are in
need of warranty replacement parts.
Please call us toll free at: 1-855-372-2315
(Monday - Friday 6:00am - 5:00pm PST)
Or visit our website:
www.truecustomersupport.com
FAILURE TO FOLLOW THESE WARNINGS
WHEN IN USE COULD RESULT IN INJURY
• Do not stand on the item or use as a step ladder.
• The chair is only designed for one person to use at
a time (per seat).
• The chair has been tested and approved for users
weighing up to 250 lbs (113kg) per seat.
• The chair is not recommended for use by individuals
weighing more than 250 lbs (113kg) per seat.
• Do not use this item unless all bolts and screws are
firmly secured and fastened.
• Check all bolts and screws every 60 days. As necessary,
tighten if any are loose.
04
Page 5
WARNING: DO NOT LET CHILDREN PLAY IN OR AROUND THE UNIT
DUE TO THE POSSIBLE RISK OF FINGER ENTRAPMENT.
Pre-Assembly Preparation:
Please read through this instruction before beginning
assembly of this item.
One adult assembly is recommended.
• Clear out space for assembly and lay out all parts
shown in parts list. Extra room will allow you to easily
determine if all the pieces are present.
• Save all packing materials until assembly is complete to
avoid accidentally discarding smaller parts or hardware.
• Keep small parts and pieces away from children
until fully assembled.
• Please check for any loose screws and tighten them
before you use.
Maintenance:
• Inspect and tighten all bolts on a regular basis to
ensure proper performance and safety.
05
Page 6
1 Step One: Inventory Parts
A
Casters
Quantity: 4
D
Seat & Back Cushions with Seat Plate
06
B C
Base
Quantity: 1
E
Allen Key
Quantity: 1Quantity: 1
Gas Lift
Quantity: 1
Page 7
2 Step Two：
Place the Base (B) upside down and insert 4 Casters (A) into
the holes on the Base (B).
3 Step Three：
B
A
Turn the Base (B) over and insert the Gas Lift (C) through the
center hole on top of Base (B).
C
B
07
Page 8
4 Step Four：
Position the assembled chair upright with the seat plate
facing down. Insert the gas lift (C) into the center hole of the
seat plate (D).
D
C
08
Page 9
Operating Instructions
To Adjust Seat Height
1
While seated, lean forward and reach under the right side of
the chair to find the handle. Lift the handle and raise your
body up slightly to allow the chair to rise to the desired
height. Once desired height is reached, release handle to lock
chair at desired height. To lower the seat, lift the handle
while seated. The chair will descend until the handle is
released or the chair reaches the bottom position.
To Adjust Tension on the Tilt
2
Reach under the front center of the chair, grasp the round
knob (R) and turn it counter - clockwise to stiffen the tilt
mechanism. Turn the knob (R) clockwise to loosen the tilt
mechanism. Rotate the knob (R) until the desired resistance is
reached.
R
09
Page 10
To Operate Tilt Lockout
3
While seated, reach under the right side of the chair to find the
height adjustment handle. Pull the handle all the way out
(away from the seat plate) to allow the chair to tilt backwards.
To lock the chair in the upright or vertical position, sit upright
and push the handle in towards the seat plate.
10
