S PECIFICAT I O NS

FINISHED WALL

HANGER BRACKET FURNISHED WITH COOLER. SEE COOLER ROUGH-IN FOR CORRECT

BRACKET HEIGHT.

FINISHED FLOOR

MTG. PLATES

INSTALLED

BEHIND

FINISHED

WALL

* ADA REQUIREMENT - REDUCE HEIGHT BY 3" FOR INSTALLATION OF CHILDRENS ADA COOLER.

** WITH STANDARD STUD LENGTH OF 6 INCHES.

NOTE - AFTER INSTALLATION, U-BOLTS AND THREADED RODS MAY NEED TO BE TRIMMED

4-3/4" MAX. (121mm)

27"

(686mm)

18-3/8"

(467mm)

18-3/8"

(467mm)

18-3/8"

(467mm)

12-15/16"

(329mm)

(25mm)

27-13/16"

(707mm)

5/8"

(16mm)

2-3/4"

(70mm)

18-7/16" (468mm)

(25mm)

33-5/16"

(846mm)

5/8"

(16mm)

2-3/4"

(70mm)

44-1/8"

(1121mm)

GENERAL

In Wall Carrier Mounting System constructed of heavy gauge steel supports up to 300 lbs. System can be installed in as little as a 2" x 4" wall. All parts painted with protective coating to last.

Universal design enables you to mount EZSTL, EMABFTL and VRCTL models all on one mounting plate.

Adjustable height setting allows for adult or child installation.

In Wall Carrier Mounting System

Model MLP200

In keeping with our policy of continuing product improvement, Elkay reserves the right to change product specifications without notice.
