Elkay LKD2448BH, LKDA2448 User Manual

Limited Lifetime Functional and Finish Warranty
Elkay warrants to the original consumer purchaser that the Elkay faucet pur­chased will be free from defects in material and workmanship for as long as the original consumer purchaser owns the faucet. Elkay will, at its option, supply replacement parts (or if no longer available a comparable product) if the faucet fails due to a defect in material or workmanship. This warranty does not apply in the event of product surface damage caused by abuse, misuse or improper care and maintenance. This warranty excludes damage caused by harsh or abrasive cleaners and/or materials. This warranty excludes all industrial, com­mercial and business use, whose purchasers are hereby extended a limited lifetime on mechanical parts and 5 years on finish. Product replacement does not include transportation cost or labor installation cost. Elkay reserves the right to examine product in question and its installation prior to replacement.
OTHER WARRANTY CONDITIONS ON FAUCETS
Our warranty does not cover product failure or damage caused by abusive treatment, misuse, environmental factors, improper care and cleaning, or damage due to handling or faulty installations. This warranty is extended only to the original consumer purchaser of the product. This warranty does not cover shipping costs, labor costs, or any other charges for such items as in­stallation or replacement of the sink, diagnosis or replacement of any faucet or component part, or any other expense or loss.
All incidental or consequential damages are specifically excluded. No additional warranties, express or implied are given. Any implied warranty, including one of merchantability or fitness for a particular purpose, is limited to the duration of this written warranty.
Some states do not allow the exclusion or limitation of incidental or con­sequential damages or limitations on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
TO OBTAIN SERVICE UNDER WARRANTY
1. Write to: Elkay Attention: Consumer Services 2222 Camden Court Oak Brook, IL 60523
2. Include a letter containing the following information: a. Date of purchase and installation b. Description of nature of defect c. Model number or description of model and/or component part if
possible.
ELKAY LIMITED LIFETIME FAUCET WARRANTY ON RESIDENTIAL FAUCETS
GENERAL
LKDA2448 Dual handle, top mount mixing faucet with stainless steel escutcheon. Clear Crystalac handles. Tubular hi-arc con­temporary swing spout with restricted flow aerator.
Overall height is 9-1/2" (241mm). Removable cartridges. A 90° turn of the handle controls water flow from drip-free
off to full
on. All operating parts are replaceable from above deck. Requires
2 faucet holes on 4" (102mm) centers. Ship. Wt. 2-1/4 lbs. LKD2448BH Same as LKDA2448 except with 4" (102mm)
blade handles. Ship. Wt. 3 lbs. Maximum Countertop Thickness: 1-1/8" (29mm).
COMPLIES WITH:
ASME A112.18.1M CSA B125-01
NSF/ANSI 61 ADA (LKD2448BH Only)
MAXIMUM FLOW RATE
2.5 GPM/9.5 L/min AT 80 P.S.I.G.
2.2 GPM/8.3 L/min AT 60 P.S.I.G.
6-1/2"
(165mm)
8-1/2"
(216mm)
9-1/2"
(241mm)
4"
(102mm)
1/2" PIPE THD.
Model LKDA2448
Hi-Arc®Dual Handle
Bar Faucet
Models LKDA2448 and LKD2448BH
®
SPECIFICATIONS
Elkay
2222 Camden Court Oak Brook, IL 60523
Printed in U.S.A. ©2005 Elkay
(10/05) 5-137
www.elkayusa.com
U
P
C
C
®
A51861 O RING
A52835 COLD BUTTON
A52834 HOT BUTTON
A52657 (2) BEARING
A52656 SPOUT NUT
SPOUT ASSEMBLY A52817 INCLUDES: A52656 A52657 (2) A51861 A51357
A51357 AERATOR
A52062 NUT
A51846 ESCUTCHEON
A70002 CARTRIDGE
A72279 HANDLE
A71951 SCREW
A52060 MOUNTING HARDWARE
{
A55179 (Red) A55180 (Blue) A55165 (Chrome) SCREW
A75163 (Hot) A75164 (Cold) BLADE HANDLE
LKD2448BH
A70001 CARTRIDGE
Hi-Arc®Dual Handle Bar Faucet Models LKDA2448 and LKD2448BH
®
PARTS LIST
Elkay
2222 Camden Court Oak Brook, IL 60523
www.elkayusa.com
Printed in U.S.A. ©2005 Elkay
5-137 (10/05)
Elkay recommends installation by a licensed plumber.
