SINK PACKAGE(S)
SP E CIFIC ATIONS
GENERAL
Highest quality sink formed of #18 (1.2mm) gauge, type 304
(18-8) nickel bearing stainless steel. Undermount.
DESIGN FEATURES
Bowl Depth: 10" (254mm).
Finish: Exposed surfaces are hand polished to a lustrous high-
lighted satin finish.
Underside: Fully protected by heavy duty Sound Guard
coating to dampen sound and reduce condensation.
OTHER
Drain Opening: 3-1/2" (89mm).
NOTE: All Elkay undermount sinks are designed to affix to the
underside of any solid surface countertop.
Sink complies with ASME A112.19.3-2008 / CSA B45.4-08
These sinks are listed by the International Association
of Plumbing and Mechanical Officials as meeting the
requirements of the Uniform Plumbing Code.
OPTIONAL ACCESSORIES
Bottom Grid: LKWOBG1616SS
Cutting Boards: CB1713, CBS1316
Drain: LK99
Mounting Clip: LKUCLIP8 (2 packages required)
Rinsing Baskets: LKWRB1316SS, LKWERBSS
Utensil Caddy for Rinsing Basket: LKWUCSS
®
under-
Gourmet®Undermount
Double Bowl Sink
Model ELUH361710
Model ELUH361710
SINKS ARE
MADE IN THE USA
MODEL SINK BOTTOM GRID QTY DRAIN QTY
ELUH361710DBG ELUH361710 LKWOBG1616SS 1 LK99 1
Installation Profile of ELUH Double Bowl Models
The template provided with each ELUH sink p rovides
the only type of installation recommended by Elkay.
COUNTERTOP
MOUNTING CLIP: LKUCLIP8
(NOT FURNISHED)
FASTENER
(NOT FURNISHED)
(ELUH Double bowl)
1-1/8"
(29mm)
1/2" (13mm)
SILICONE CAULK
(NOT FURNISHED)
SINK
SEE NEXT PAGE FOR PRODUCT DIMENSIONS.
In keeping with o ur policy o f cont inuing prod uct imp rovement, Elkay reserves the rig ht to change
product specificatio ns without notice. Please visit elkayusa.c om for most current version of Elkay
product specific ation sheets.
Elkay
elkayusa.com
This specificatio n d escribes an Elkay prod uct with design, quality and functio nal benefits to the
user. When making a comp arison of ot her produc ers’ off erings, be cert ain these features are no t
overlooked.
2222 Camden Court
Oak Brook, IL 60523
Printed in U.S.A.
©2010 Elkay
(Rev. 01/10) 1-272B
(470mm)
(254mm)
(438mm)
®
SP E CIFIC ATIONS
SINK DIMENSIONS*
Model
Number L W L W D Countertop Size
ELUH361710 353/4 181/2 16 16 10 See 39
*Length is left to right. Width is front to back.
**Template is packed with every sink.
Overall Inside Each Bowl
(908mm ) (470mm) (406mm ) (406mm) (254mm) Template** (991mm )
Cutout in Cabinet
Minimum
5"
(127mm)
Gourmet®Undermount
Double Bowl Sink
Model ELUH361710
18-1/2"
16"
(406mm)
1-3/4"
(44mm) R
(406mm)
1-3/4"
(44mm) R
16"
16"
(406mm)
35-3/4"
(908mm)
10"
17-1/4"
In keeping with o ur policy o f cont inuing prod uct imp rovement, Elkay reserves the rig ht to change
product specificatio ns without notice. Please visit elkayusa.c om for most current version of Elkay
product specific ation sheets.
Elkay
elkayusa.com
2222 Camden Court
Oak Brook, IL 60523
This specificatio n d escribes an Elkay prod uct with design, quality and functio nal benefits to the
user. When making a comp arison of ot her prod
overlooked.
ucers’ off erings, be c ertain these features are not
Printed in U.S.A.
©2010 Elkay
(Rev. 01/10) 1-272B
