SPECIFICATIONS
Elkay Asana Copper 16" x 16" x 6-1/2"
Single Bowl Vessel Bathroom Sink
Model(s) ECU15ACH
PRODUCT SPECIFICATIONS
Elkay Asana® Copper 16" x 16" x 6-1/2", Single Bowl Vessel Bathroom
Sink. Sink is hand fabricated from 16 gauge genuine, uncoated copper
that will continue to age and tarnish naturally. Sink has Center drain
placement.
Installation Type:
Vessel
Material:
Copper
Finish:
Antique Hammered
Gauge:
16
Number of Bowls:
1
Sink Dimensions:
16" x 16" x 6-1/2"
Bowl 1 Dimensions:
15-3/4" x 15-3/4" x 6-1/4"
Drain Size:
1-1/2" (38mm)
Drain Location:
Center
Minimum Cabinet Size:
21"
Mounting Hardware:
Not Included
Special Note: Vessels rests on countertop
Installation Profile:
AMERICAN PRIDE. A LIFETIME TRADITION.
Like your family, the Elkay family has values and traditions that endure.
For almost a century, Elkay has been a family-owned and operated
company, providing thousands of jobs that support our families and
communities.
Product Compliance:
ADA & ICC A117.1
CSA B45.12/IAPMO Z402
Sinks are listed by IAPMO® as meeting the applicable requirements
of the Uniform Plumbing Code®, International Plumbing Code®, and
National Plumbing Code of Canada.
Complies with ADA & ICC A117.1 accessibility requirements when
installed according to the requirements outlined in these standards.
Clean and Care Manual (PDF)
Installation Instructions (PDF)
Warranty (PDF)
PART:________________________________QTY: _____________
PROJECT:______________________________________________
CONTACT:______________________________________________
DATE:__________________________________________________
NOTES:_________________________________________________
APPROVAL:_____________________________________________
In keeping with our policy of continuing product improvement, Elkay reserves the right to change product specifications without notice. Please visit elkay.com
for the most current version of Elkay product specification sheets. This specification describes an Elkay product with design, quality, and functional benefits to the
user. When making a comparison of other producers’ offerings, be certain these features are not overlooked.
Elkay REV 11102018 2222 Camden Court © 2018 Page 1
ECU15ACH Oak Brook, IL 60523 ECU15ACH_spec.pdf
