SPECIFICATIONS
Elkay Stainless Steel 11" x 16" x 11/16" Bottom Grid
Model(s) GFOBG1217SS
PRODUCT SPECIFICATIONS
Elkay Stainless Steel 11" x 16" x 11/16" Bottom Grid. Overall
dimensions are 11" x 16" x 11/16".
Made of Stainless Steel
Bottom grids are:
Custom designed to protect and cover the bottom of your
sink.
Properly positioned opening for convenient access to drain
or disposer.
Built from solid stainless steel to resist corrosion and
provide years of service.
Material:
Stainless Steel
Finish:
Polished Stainless Steel
Dimensions:
11" x 16" x 11/16"
Fits Bowl Size(s):
Fits Crosstown bowl size: 12" x 17"
Special Note: For bowls with rear center drain opening.
AMERICAN PRIDE. A LIFETIME TRADITION.
Like your family, the Elkay family has values and traditions that
endure. For almost a century, Elkay has been a family-owned and
operated company, providing thousands of jobs that support our
families and communities.
Clean and Care Manual (PDF)
Clean and Care Manual (PDF)
Installation Instructions (PDF)
Warranty (PDF)
PART:________________________________QTY: _____________
PROJECT:______________________________________________
CONTACT:______________________________________________
DATE:__________________________________________________
NOTES:_________________________________________________
APPROVAL:_____________________________________________
In keeping with our policy of continuing product improvement, Elkay reserves the right to change product specifications without notice. Please visit elkay.com
for the most current version of Elkay product specification sheets. This specification describes an Elkay product with design, quality, and functional benefits to the
user. When making a comparison of other producers’ offerings, be certain these features are not overlooked.
Elkay REV 01122019 2222 Camden Court © 2019 Page 1
Oak Brook, IL 60523 GFOBG1217SS_spec.pdf
