Page 1
SPECIFICATIONS
Elkay Stainless Steel 23-3/16" x 16-13/16" x 6"
Single Bowl Undermount Sink
Model(s) MYSTIC211415
PRODUCT SPECIFICATIONS
Elkay Stainless Steel 23-3/16" x 16-13/16" x 6", Single Bowl
Undermount Sink. Sink is manufactured from 16 gauge 304
Stainless Steel with a Lustertone finish, Center Right drain
placement, and Bottom only pads.
Installation Type:
Undermount
Material:
304 Stainless Steel
Finish:
Lustertone
Gauge:
16
Sound Deadening:
Bottom only pads
Number of Bowls:
1
Sink Dimensions:
23-3/16" x 16-13/16" x 6"
Bowl 1 Dimensions:
20-3/8" x 14-3/16" x 6"
Drain Size:
1-1/2" (38mm)
Drain Location:
Center Right
Minimum Cabinet Size:
27"
Mounting Hardware:
Undermount brackets sold
separately
Template Included:
Yes
Cutout Template #:
1000001505
Template is available for download at elkay.com
Included with Product:
LKF293 overflow Assembly
AMERICAN PRIDE. A LIFETIME TRADITION.
Like your family, the Elkay family has values and traditions that
endure. For almost a century, Elkay has been a family-owned and
operated company, providing thousands of jobs that support our
families and communities.
Product Compliance:
ADA & ICC A117.1
ASME A112.19.3/CSA B45.4
BUY AMERICAN ACT
Sinks are listed by IAPMO® as meeting the applicable
requirements of the Uniform Plumbing Code®, International
Plumbing Code®, and National Plumbing Code of Canada.
Complies with ADA & ICC A117.1 accessibility requirements
when installed according to the requirements outlined in these
standards.
Clean and Care Manual (PDF)
Installation Instructions (PDF)
Limited Lifetime Warranty (PDF)
OPTIONAL ACCESSORIES
Drain:
LK174, LKAD174
Hardware:
LKUCLIP8
Installation Profile:
PART:________________________________QTY: _____________
PROJECT:______________________________________________
CONTACT:______________________________________________
DATE:__________________________________________________
NOTES:_________________________________________________
APPROVAL:_____________________________________________
In keeping with our policy of continuing product improvement, Elkay reserves the right to change product specifications without notice. Please visit elkay.com
for the most current version of Elkay product specification sheets. This specification describes an Elkay product with design, quality, and functional benefits to the
user. When making a comparison of other producers’ offerings, be certain these features are not overlooked.
Elkay REV 04212018 2222 Camden Court © 2018 Page 1
MYSTIC211415 Oak Brook, IL 60523 MYSTIC211415_spec.pdf
