SPECIFICATIONS
Elkay Lustertone Classic Stainless Steel 17" x 16" x 7-5/8"
Single Bowl Drop-in Sink + Faucet Kit
Model(s) LR1716C
PRODUCT SPECIFICATIONS
Elkay Lustertone™ Classic Stainless Steel 17" x 16" x 7-5/8", Single
Bowl Drop-in Sink + Faucet Kit. Sink is manufactured from 18 gauge
304 Stainless Steel with a Lustrous Satin finish, Center drain
placement, and Sides and Bottom pads.
Installation Type:
Drop-in
Material:
304 Stainless Steel
Finish:
Lustrous Satin
Gauge:
18
Sound Deadening:
Sides and Bottom pads
Number of Bowls:
1
Sink Dimensions:
17" x 16" x 7-5/8"
Bowl 1 Dimensions:
14" x 10" x 7-1/2"
Drain Size:
3-1/2" (89mm)
Drain Location:
Center
Minimum Cabinet Size:
21"
Mounting Hardware:
Part # 64090010 included for countertops
up to 3/4" (19mm) thick
Cutout Template #:
1000001269
Template is available for download at elkay.com
Cutout Dimensions for Top Mount Installation:
16-3/8" x 15-3/8" (416mm x 391mm) with 1-1/2" (38mm) corner radius
Installation Profile:
Included with Product:
LK500GN04T4C faucet,
LK18B drain,
LK500 P-trap.
AMERICAN PRIDE. A LIFETIME TRADITION.
Like your family, the Elkay family has values and traditions that endure.
For almost a century, Elkay has been a family-owned and operated
company, providing thousands of jobs that support our families and
communities.
Product Compliance:
ASME A112.19.3/CSA B45.4
Faucet:
ASME A112.18.1/CSA B125.1
NSF 61
NSF 372 (lead free)
Accessory:
ASME A112.18.2/CSA B125.2
Clean and Care Manual (PDF)
Installation Instructions (PDF) - 74180147
Installation Instructions (PDF) - 74210010_Drain
Installation Instructions (PDF) - A55483_Faucet
Limited Warranty (PDF)
Similar models are available with: N/A
OPTIONAL ACCESSORIES
Hardware:
LK364, LK463
Sinkmate:
LKSMHSL
PART:________________________________QTY: _____________
PROJECT:______________________________________________
CONTACT:______________________________________________
DATE:__________________________________________________
NOTES:_________________________________________________
APPROVAL:_____________________________________________
In keeping with our policy of continuing product improvement, Elkay reserves the right to change product specifications without notice. Please visit elkay.com
for the most current version of Elkay product specification sheets. This specification describes an Elkay product with design, quality, and functional benefits to the
user. When making a comparison of other producers’ offerings, be certain these features are not overlooked.
