SPECIFICATIONS
Elkay Stainless Steel 12" x 14" x 6-1/2"
Single Bowl Undermount Bar Sink
Model(s) SCUH1012SH
PRODUCT SPECIFICATIONS
Elkay Stainless Steel 12" x 14" x 6-1/2", Single Bowl Undermount Bar
Sink. Sink is manufactured from 18 gauge 304 Stainless Steel with a
Hammered Mirror finish, Center drain placement, and Full spray sides
and bottom.
Installation Type:
Undermount
Material:
304 Stainless Steel
Finish:
Hammered Mirror
Gauge:
18
Sound Deadening:
Full spray sides and bottom
Number of Bowls:
1
Sink Dimensions:
12" x 14" x 6-1/2"
Bowl 1 Dimensions:
10" x 12" x 6-1/2"
Drain Size:
3-1/2" (89mm)
Drain Location:
Center
Minimum Cabinet Size:
15"
Mounting Hardware:
Included
Cutout Template #:
1000001416
Template is available for download at elkay.com
Installation Profile:
AMERICAN PRIDE. A LIFETIME TRADITION.
Like your family, the Elkay family has values and traditions that endure.
For almost a century, Elkay has been a family-owned and operated
company, providing thousands of jobs that support our families and
communities.
Product Compliance:
ASME A112.19.3/CSA B45.4
Sinks are listed by IAPMO® as meeting the applicable requirements
of the Uniform Plumbing Code®, International Plumbing Code®, and
National Plumbing Code of Canada.
Clean and Care Manual (PDF)
Installation Instructions (PDF)
Limited Lifetime Warranty (PDF)
OPTIONAL ACCESSORIES
Cutting Board:
CB912
Drain:
LK99
Faucet:
LKGT1042, LKGT2042
Soap Dispenser:
LKGT1054
PART:________________________________QTY: _____________
PROJECT:______________________________________________
CONTACT:______________________________________________
DATE:__________________________________________________
NOTES:_________________________________________________
APPROVAL:_____________________________________________
In keeping with our policy of continuing product improvement, Elkay reserves the right to change product specifications without notice. Please visit elkay.com
for the most current version of Elkay product specification sheets. This specification describes an Elkay product with design, quality, and functional benefits to the
user. When making a comparison of other producers’ offerings, be certain these features are not overlooked.
Elkay REV 10232018 2222 Camden Court © 2018 Page 1
SCUH1012SH Oak Brook, IL 60523 SCUH1012SH_spec.pdf
