SPECIFICATIONS
Elkay Asana Stainless Steel 17" x 12" x 6-1/2"
Single Bowl Dual Mount Bathroom Sink
Model(s) SCF1611SH
PRODUCT SPECIFICATIONS
Elkay Asana® Stainless Steel 17" x 12" x 6-1/2", Single Bowl Dual
Mount Bathroom Sink. Sink is manufactured from 18 gauge 304
Stainless Steel with a Hammered Mirror finish, Rear Center drain
placement, and Full spray sides and bottom.
Installation Type:
Top Mount, Undermount
Material:
304 Stainless Steel
Finish:
Hammered Mirror
Gauge:
18
Sound Deadening:
Full spray sides and bottom
Number of Bowls:
1
Sink Dimensions:
17" x 12" x 6-1/2"
Bowl 1 Dimensions:
14-1/2" x 9-1/2" x 6-1/2"
Drain Size:
1-1/2" (38mm)
Drain Location:
Rear Center
Minimum Cabinet Size:
21"
Mounting Hardware:
Included
Cutout Template #:
1000001503
Template is available for download at elkay.com
Included with Product:
overflow Assembly
AMERICAN PRIDE. A LIFETIME TRADITION.
Like your family, the Elkay family has values and traditions that
endure. For almost a century, Elkay has been a family-owned and
operated company, providing thousands of jobs that support our
families and communities.
Product Compliance:
ADA & ICC A117.1
ASME A112.19.3/CSA B45.4
Sinks are listed by IAPMO® as meeting the applicable
requirements of the Uniform Plumbing Code®, International
Plumbing Code®, and National Plumbing Code of Canada.
Complies with ADA & ICC A117.1 accessibility requirements
when installed according to the requirements outlined in these
standards.
Clean and Care Manual (PDF)
Installation Instructions (PDF)
Limited Lifetime Warranty (PDF)
OPTIONAL ACCESSORIES
Drain:
LK174
Installation Profile:
PART:________________________________QTY: _____________
PROJECT:______________________________________________
CONTACT:______________________________________________
DATE:__________________________________________________
NOTES:_________________________________________________
APPROVAL:_____________________________________________
In keeping with our policy of continuing product improvement, Elkay reserves the right to change product specifications without notice. Please visit elkay.com
for the most current version of Elkay product specification sheets. This specification describes an Elkay product with design, quality, and functional benefits to the
user. When making a comparison of other producers’ offerings, be certain these features are not overlooked.
Elkay REV 04212018 2222 Camden Court © 2018 Page 1
SCF1611SH Oak Brook, IL 60523 SCF1611SH_spec.pdf
