SPECIFICATIONS
Elkay Crosstown 18 Gauge Workstation Stainless Steel
31-1/2" x 18-1/2" x 9" Single Bowl Undermount Sink Kit
Model(s) ECTRU30169RTWC
PRODUCT SPECIFICATIONS
Elkay Crosstown® 18 Gauge Workstation Stainless Steel, 31-1/2" x 181/2" x 9" Single Bowl Undermount Sink Kit. Sink is manufactured from
18 gauge 304 Stainless Steel with a Polished Satin finish, Rear Right
drain placement, and Full spray sides and bottom with Sides and
Bottom pads.
Installation Type:
Undermount
Material:
304 Stainless Steel
Special Features:
Workstation
Finish:
Polished Satin
Gauge:
18
Sound Deadening:
Full spray sides and bottom with Sides
and Bottom pads
Number of Bowls:
1
Sink Dimensions:
31-1/2" x 18-1/2" x 9"
Bowl 1 Dimensions:
30" x 17" x 9"
Drain Size:
3-1/2" (89mm)
Drain Location:
Rear Right
Minimum Cabinet Size:
36"
Mounting Hardware:
Part # 54300308 included
Template Included:
Yes
Cutout Template #:
1000001381
Template is available for download at elkay.com. CAD software will be
required to open the template.
Installation Profile:
Included with Product:
CTXBG2814 bottom grid,
LKC0717SS colander,
LKCB1217AC Cutting Board,
LKDR1317RU drying rack,
LKDR0717SS drying rack,
LKDD drain
AMERICAN PRIDE. A LIFETIME TRADITION.
Like your family, the Elkay family has values and traditions that endure.
For almost a century, Elkay has been a family-owned and operated
company, providing thousands of jobs that support our families and
communities.
Product Compliance:
ASME A112.19.3/CSA B45.4
Accessory:
ASME A112.18.2/CSA B125.2
Sinks are listed by IAPMO® as meeting the applicable requirements
of the Uniform Plumbing Code®, International Plumbing Code®, and
National Plumbing Code of Canada.
Clean and Care Manual (PDF)
Installation Instructions (PDF) - 1000005239
Installation Instructions (PDF) - 1000005235_drain
Installation Instructions (PDF) -
Warranty (PDF)
PART:________________________________QTY: _____________
PROJECT:______________________________________________
CONTACT:______________________________________________
DATE:__________________________________________________
NOTES:_________________________________________________
APPROVAL:_____________________________________________
In keeping with our policy of continuing product improvement, Elkay reserves the right to change product specifications without notice. Please visit elkay.com
for the most current version of Elkay product specification sheets. This specification describes an Elkay product with design, quality, and functional benefits to the
user. When making a comparison of other producers’ offerings, be certain these features are not overlooked.
Elkay REV 07032020 1333 Butterfield Road, Suite 200 © 2020 Page 1
ECTRU30169RTWC Downers Grove, IL 60515 ECTRU30169RTWC_spec.pdf
Page 2
SPECIFICATIONS
Elkay Crosstown 18 Gauge Workstation Stainless Steel
31-1/2" x 18-1/2" x 9" Single Bowl Undermount Sink Kit
Model(s) ECTRU30169RTWC
OPTIONAL ACCESSORIES
Hardware:
LKUCLIP8 (2 Required)
