SPECIFICATIONS
Elkay Lustertone Classic Stainless Steel 22" x 19-1/2" x 6"
Single Bowl Drop-in Classroom ADA Sink Kit
Model(s) DRKAD222060C
PRODUCT SPECIFICATIONS
Elkay Lustertone™ Classic Stainless Steel 22" x 19-1/2" x 6", Single
Bowl Drop-in Classroom ADA Sink Kit. Sink is manufactured from 18
gauge 304 Stainless Steel with a Lustrous Satin finish, Rear Center
drain placement, and Bottom only pads.
Installation Type:
Drop-in
Material:
304 Stainless Steel
Finish:
Lustrous Satin
Gauge:
18
Sound Deadening:
Bottom only pads
Number of Bowls:
1
Sink Dimensions:
22" x 19-1/2" x 6"
Bowl 1 Dimensions:
13-1/2" x 16" x 5-7/8"
Drain Size:
3-1/2" (89mm)
Drain Location:
Rear Center
Minimum Cabinet Size:
27"
Mounting Hardware:
Part # 64090012 included for countertops
up to 3/4" (19mm) thick
Cutout Template #:
1000001255
Template is available for download at elkay.com
Cutout Dimensions for Top Mount Installation:
21-3/8" x 18-7/8" (543mm x 479mm) with 1-1/2" (38mm) corner radius
Installation Profile:
Included with Product:
LKD2439C faucet,
LK1141A bubbler,
LK35 strainer
AMERICAN PRIDE. A LIFETIME TRADITION.
Like your family, the Elkay family has values and traditions that endure.
For almost a century, Elkay has been a family-owned and operated
company, providing thousands of jobs that support our families and
communities.
Product Compliance:
ADA & ICC A117.1
ASME A112.19.3/CSA B45.4
Faucet:
ASME A112.18.1/CSA B125.1
NSF 61
NSF 372 (lead free)
Accessory:
ASME A112.18.2/CSA B125.2
Complies with ADA & ICC A117.1 accessibility requirements when
installed according to the requirements outlined in these standards.
Clean and Care Manual (PDF)
Installation Instructions (PDF) - 74180147
Installation Instructions (PDF) - A55068_Bubbler
Installation Instructions (PDF) - P99175_Faucet
Limited Lifetime Warranty (PDF)
Similar models are available with: Quick-Clip Mounting System,
additional ADA depths
OPTIONAL ACCESSORIES
Hardware:
LK364, LK463
Sinkmate:
LKSMHSL
PART:________________________________QTY: _____________
PROJECT:______________________________________________
CONTACT:______________________________________________
DATE:__________________________________________________
NOTES:_________________________________________________
APPROVAL:_____________________________________________
In keeping with our policy of continuing product improvement, Elkay reserves the right to change product specifications without notice. Please visit elkay.com
for the most current version of Elkay product specification sheets. This specification describes an Elkay product with design, quality, and functional benefits to the
user. When making a comparison of other producers’ offerings, be certain these features are not overlooked.
Elkay REV 10272018 2222 Camden Court © 2018 Page 1
DRKAD222060C Oak Brook, IL 60523 DRKAD222060C_spec.pdf
