SP ECIFICATIO NS
Models DRKAD and DRKADQ Series – A.D.A. Compliant
GENERAL
Highest quality sink bowl seamlessly formed of #18 (1.2mm)
gauge, type 304 (18-8) nickel bearing stainless steel. Top Mount.
CLASSROOM/INSTITUTIONAL SINK PACKAGES
Models DRKR(Q)2220C, DRKR(Q)2517C, DRKR(Q)3119C,
DRKAD(Q)2220C, DRKAD(Q)2517C, and DRKAD(Q)3119C
feature a scratch and crack resistant stainless steel sink,
Contemporary Hi- Arc
®
faucet and No Lead Flexi-Guard
Bubbler. Package includes:
LK2439
(1) Two-handle Cont emporary Hi-Arc c oncealed
undermount faucet with 45° restricted swing spout and
aerator. Out let height: 10" (254mm); Reach: 6-1/2"
(165mm). No spray.
LK1141A
(1)
N
o Lead Flexi-Guard
®
Bubbler. Pushbutton valve
design b ub bler meets ANSI and ADA requirements.
Designed so that water never comes in contact with leadcontaining materials. Flexi-Guard safety bubbler flexes on
impact to prevent accidental injury when getting a drink.
Built-in adjustable water volume control.
LK35
(1) Duo strainer.
OTHER
DRKAD(Q)2517, DRKAD(Q)2220, DRKAD(Q)2522 and
DRKAD(Q)3119
n opening is 3-1/ 2" (89mm) and located
drai
centered left-to-right and off-center front-to-back as illustrated.
All other drain opening sizes are 3-1/ 2" (89mm) and centered in
bowl as illustrated.
Slotted hole allows for vandal-resistant faucet and bubbler.
NOTE: Unless otherwise specified, sink is furnished with 4
faucet holes as shown (see back page).
Sink complies with ASME A112.19.3-2008 / CSA B45.4-08.
Both the faucet and the bubbler are classified by
Underwriters Laboratories Inc . to NSF/ANSI61 for
residential use.
Lustertone®Single Bowl Classroom Sinks
and Sink Packages – Double Ledge
Models DRKR and DRKRQ Series
®
Model DRKR(Q)2517C
SEE NEXT PAGE FOR PRODUCT DIMENSIONS.
SINKS ARE
MADE IN THE USA
THIS PRODUCT, AS CONSTRUCTED IS SUBJECT TO INTERPRETATION OF A.D.A. REQUIREMENTS.
THE UNOBSTRUCTED KNEE SPACE REQUIRED TO SATISIFY A.D.A. STANDARDS MAY NOT BE DESIRABLE.
In keeping with our policy of continuing product improvement, Elkay reserves the right to change
product specifications without notice. Please visti elkayusa.com for most current version of Elkay
product specification sheets.
Elkay
elkayusa.com
2222 Camden Court
Oak Brook, IL 60523
This specification describes an Elkay product with design, quality, and functional benefits to the
user. When making a comparison of others producers offerings, be certain these featrues are not
overlooked.
(Rev. 06/10) 1-21J
Printed in U.S.A.
©2010 Elkay
Lustertone®Single Bowl Classroom Sinks
Off-Centered Drain
Centered Drain
and Sink Packages – Double Ledge
Models DRKR and DRKRQ Series
Models DRKAD and DRKADQ Series – A.D.A. Compliant
SINK DIMENSIONS*
Cutout in
U-Channel Quick-Clip
Model Model
Number Number A B C D E L W page) for details) Size
®
Overall Inside Bowl
L W L W D Radius Corners]
DRKR222 0 C DRKRQ22 20C 22 191/2 131/2 16 75/8 213/8 187/8 4 Centered 27
(559mm ) (495mm) (343mm) (406mm) (194mm) (543mm) (479mm) (686mm )
†DRKR22 2 0 †DRKRQ22 2 0 22 191/2 131/2 16 75/8 213/8 187/8 2, 2LM or 4 Centered 27
(559mm ) (495mm) (343mm) (406mm) (194mm) (543mm) (479mm) (686mm )
DRKR251 7 C DRKRQ25 17C 25 17 16 131/2 75/8 243/8 163/8 4 Centered 30
(635mm ) (432mm) (406mm) (343mm) (194mm) (619mm) (416mm) (762mm )
†DRKR25 1 7 †DRKRQ25 1 7 25 17 16 131/2 75/8 243/8 163/8 2, 2LM or 4 Centered 30
(635mm ) (432mm) (406mm) (343mm) (194mm) (619mm) (416mm) (762mm )
†DRKR25 2 2 †DRKRQ25 2 2 25 22 16 19 75/8 243/8 213/8 2, 2LM or 4 Centered 30
(635mm ) (559mm) (406mm) (343mm) (194mm) (619mm) (416mm) (762mm )
DRKR311 9 C DRKRQ31 19C 31 191/2 22 16 75/8 303/8 187/8 4 Centered 36
(787mm ) (495mm) (559mm) (406mm) (194mm) (772mm) (479mm) (914mm )
†DRKR31 1 9 †DRKRQ3119 31 191/2 22 16 75/8 303/8 187/8 2, 2LM or 4 Centered 36
(787mm ) (495mm) (559mm) (406mm) (194mm) (772mm) (479mm) (914mm )
DRKAD2 220C DRKADQ222 0C 22 191/2 131/2 16 ** 213/8 187/8 4 Off-Centered 27
(559mm ) (495mm) (343mm) (406mm) (543mm) (479mm ) (686mm)
†DRKAD2220 †DRKADQ2220 22 191/2 131/2 16 ** 213/8 187/8 2, 2LM or 4 Off-Centered 27
(559mm ) (495mm) (343mm) (406mm) (543mm) (479mm ) (686mm)
DRKAD2 517C DRKADQ251 7C 25 17 16 131/2 ** 243/8 163/8 4 Off-Centered 30
(635mm ) (432mm) (406mm) (343mm) (619mm) (416mm ) (762mm)
†DRKAD2517 †DRKADQ2517 25 17 16 131/2 ** 243/8 163/8 2, 2LM or 4 Off-Centered 30
(635mm ) (432mm) (406mm) (343mm) (619mm) (416mm ) (762mm)
†DRKAD2522 †DRKADQ2522 25 22 16 19 ** 243/8 213/8 2, 2LM or 4 Off-Centered 30
(635mm ) (559mm) (406mm) (343mm) (619mm) (416mm ) (762mm)
DRKAD3 119C DRKADQ311 9C 31 191/2 22 16 ** 303/8 187/8 4 Off-Centered 36
(787mm ) (495mm) (559mm) (406mm) (772mm) (479mm ) (914mm)
†DRKAD3119 †DRKADQ31 1 9 31 191/2 22 16 ** 303/8 187/8 2, 2LM or 4 Off-Centered 36
(787mm ) (495mm) (559mm) (406mm) (772mm) (479mm ) (914mm)
* Lengt h is l eft to ri ght. Width is front to back.
† Unless ot herw ise specified, all sinks which do not have suffix “ C” ar e less fittings (no faucet , bubbler or drain), but ar e dr illed for fauc et, bubbler and drain as
illustrated.
able in 4" (102m m), 4 -1/2" (114m m), 5" (127m m), 5- 1/ 2" (140mm), 6" (152mm) or 6- 1/2" (165mm) dept hs. Please consult your sales repr esentative for
** Avail
other depths or modifications.
Countertop
1
/2" (38m m)
[1
SP ECIFICATIO NS
1
No. of 3
Faucet Holes Drain Opening Minimum
(see back (see above Cabinet
/2" (59m m)
®
Elkay
1-21J (Rev. 06/10)
5"
D
1-3/4"
(44mm) R
C
A
1-3/4"
(44mm) R
DRKAD(Q) Series
B
1-3/4"
(44mm) R
B
C
A
D
E
1-3/4"
(44mm) R
E
DRKR(Q) and DRKAD(Q) Series
2222 Camden Court
Oak Brook, IL 60523
Printed in U.S.A.
©2010 Elkay
