Elkay CR2521 User Manual

®

SP EC I FI CAT I O N S

GENERAL

Good quality sink formed of #20 gauge, type 304 (18-8) nickel
bearing stainless steel. Top mount.

DESIGN FEATURES

Bowl Depth: See table below.
Coved Corners: Vertical 2-1/4"(57mm) or 2-3/4"(70mm) CR1721

Horizontal 3"(76mm) or 3-1/2"(89mm) CR3122, CRS3322
Rim Height: 1/4"(6mm) CR2522, CRS3322, 5/32"(4mm) all others.
Finish: Exposed surfaces are polished to Brushed Satin finish.

Underside: Fully undercoated to dampen sound and reduce
condensation.

OTHER

Drain Opening: 3-1/2" (89mm).
Sink complies with ASME A112.19.3-2008 / CSA B45.4-08.

These sinks are listed by the International Association
of Plumbing and Mechanical Officials as meeting the
requirements of the Uniform Plumbing Code and the

C

National Plumbing Code of Canada.

SINK DIMENSIONS*

Model

Number

CR1721

CR2521

CR2522

Overall
L W

A B

17

21-1/4

(432mm)

(540mm)

21-1/4

25

(540mm)

(635mm)

25

(635mm)22(559mm)

Inside

Bowl

L W D

C D E

14

15-3/4

(356mm)

(400mm)

21

15-3/4

(533mm)

(400mm)

21

15-3/4

(533mm)

(400mm)

6-7/8

(175mm)

6-7/8

(175mm)

7

(178mm)

Cutout in

Countertop

(1-1/2"(38mm)

Radius Corners)

L W

16-3/8

20-5/8

(416mm)

(524mm)

20-5/8

24-3/8

(524mm)

(619mm)

24-3/8

21-3/8

(619mm)

(543mm)

No. of 1

(38mm) Dia.
Faucet Holes
4" (102mm)

1, 2, 3, 4, MR2

1, 2, 3, 4, 5, MR2

Center

Single Gourmet Bowl Sink

CR Series

Model CR25214

1

/2"

Minimum

Cabinet

Size

211, 2, 3, MR2

30

30

C

A

3" or

3-1/2" R

B

D

31

CR3122

CRS3322

*

Length is left to right. Width is front to back.

(787mm)

(838mm)

22

(559mm)

33

22

(559mm)

OPTIONAL ACCESSORIES

Model

Number

CR1721

CR2521, CR2522
CR3122, CRS3322

Bottom Grid Cutting Boards Drain Rinsing Basket

LKWBG1414SS LKWUCSS

- CB1516

1-1/2

"

1

3

15-3/4

(400mm)

15-3/4

(400mm)

6-7/8

(175mm)

7

(178mm)

30-3/8

(772mm)

32-3/8

(822mm)

LK99

LK99

21-3/8

(543mm)

21-3/8

(543mm)

LKWERBSS

LKWERBSS

1, 2, 3, 4, 5, MR2

1, 2, 3, 4, 5, MR2

Utensil Caddy for

Rinsing Basket

LKWUCSS

28

(711mm)

28

(711mm)

CB1516

Hole Drilling Configurations

(38mm) Diameter Faucet Holes on 4" (102mm) Centers

2

4

MR2

5

36

2-1/4" or

36

Sink

2-3/4" R

Installation Profile

Clip

Silicone Caulk
(Not Furnished)

Screw

SINKS ARE

MADE IN THE USA

E

Countertop

In keeping with our policy of continuing product improvement, Elkay reserves the right to change
product specifications without notice.

Elkay

www.elkayusa.com

2222 Camden Court
Oak Brook, IL 60523

This specification describes an Elkay product with design, quality and functional benefits to the
user. When making a comparison of other producers’ offerings, be certain these features are not
overlooked.

Printed in U.S.A.
©2011 Elkay

(Rev. 9/11) 1-12E
