Elite Screens Kestrel Stage Series User Manual

Rev080515 www.elitescreens.com 1

Kestrel Stage Series

Electric Floor Rising Projection Screen with Travel Case

User’s Guide

Rev080515 www.elitescreens.com 2

Product description

The Kestrel Stage Series is a portable electric floor rising front projection screen that is ideal for
event applications used in Churches, hotels, schools, or other like venues. It includes two travel cases
(one for the screen and one split-two-sided storage cart). Complete the set up by attaching the
complimentary drape kit to give your presentation the finishing touch.

Product parts and hardware

Upon receiving your screen, please make sure all parts listed below are included. If anything is
missing from the package, please contact Elite Screens Inc. right away.

1. Kestrel Stage Motorized screen

w/ travel case (main) X 1

2. Storage Cart X 1

3. Remote Control Wall Box X 1

4. Double sided bolt X 4

5. Butterfly Nut X 4

6. Ring-bolt X 1

7. Curtain fabric X 1

Product Assembly and Operation

1. Unlatch: Lift the butterfly locks and rotate them 90 degrees. Then, split the case open by pulling

both sides apart.

Note: Distance the two parts of the storage-box (item 2) to the corresponding length of the Kestrel’s
case. Then proceed to step 2.
