ELITEGROUP COMPUTER SYSTEMS TMBCM4330 Users Manual
User Guide
Tablet with Android
@Copyright 2013.
All Rights Reserved.
The information in this document is subject to change without
prior notice in order to improve reliability, design and
function and does not represent a commitment on the part of the
manufacturer.
In no event will the manufacturer be liable for direct, indirect,
special, incidental, or consequential damages arising out of the
use or inability to use the product or documentation, even if
advised of the possibility of such damages.
This document contains proprietary information protected by
copyright. All rights are reserved. No part of this manual may be
reproduced by any mechanical, electronic, or other means in
any form without prior written permission of the
manufacturer.
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE
STATEMENT
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or
more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and
receiver.
– Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician
for help.
CAUTION:
Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's
authority to operate the equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference and
(2) This device must accept any interference received,
including interference that may cause undesired
operation.
RF exposure warning
• This equipment must be installed and operated in
accordance with provided instructions and must not be
co-located or operating in conjunction with any other
antenna or transmitter. End-users and installers must be
providing with antenna installation instructions and
transmitter operating conditions for satisfying RF exposure
compliance.
• SAR Value: 1.095 W/Kg.
CAN ICES-3 (*)/NMB-3(*)
* Insert either “A” or “B” but not both to identify the applicable
Class of ITE.
Contents
1. Overview ......................................................................................... 1
Package contents ........................................................................ 1
Tablet layout ................................................................................ 1
Front view .................................................................... 2
Rear view ...................................................................... 3
Left side view................................................................ 4
Initial Setup - Charge first then Turn on ...................................... 5
2. Basic Operations ............................................................................. 6
Power button operations ............................................................ 6
Locking your tablet to sleep ......................................... 6
Waking your tablet ....................................................... 6
Turning off your tablet ................................................. 6
Touchscreen operations .............................................................. 7
Finger gestures ............................................................. 7
Onscreen keyboard ...................................................... 9
Dictionary ................................................................... 12
3. Home screens ................................................................................ 13
Customizing your Home screens ............................................... 15
Adding an item to a Home screen .............................. 15
Creating an application folder on a Home screen...... 16
Moving a Home screen item ...................................... 16
Removing an item from a Home screen .................... 16
Changing the Home screen wallpaper ....................... 17
Status area ................................................................................ 17
Searching the Internet .............................................................. 19
Google Search ............................................................ 19
Google Voice Search ................................................... 19
4. Creating Accounts ......................................................................... 21
Creating an account .................................................................. 21
Removing an Account ............................................................... 21
Synchronizing your Google Account ......................................... 21
5. Wireless networks and devices ..................................................... 22
Wi-Fi networks .......................................................................... 22
Connecting to a Wi-Fi network .................................. 23
Adding a Wi-Fi network .............................................. 24
Disabling an automatic Wi-Fi connection .................. 24
Using Bluetooth devices............................................................ 25
Enabling and disabling the Bluetooth function.......... 25
Opening Bluetooth screen ......................................... 26
Changing your Bluetooth name ................................. 26
Pairing with a Bluetooth device ................................. 26
Unpairing a Bluetooth device..................................... 27
6. Battery and AC power ................................................................... 28
Charging the battery ................................................................. 28
Extending the battery life between charges ............................. 28
Checking the battery status ...................................................... 30
7. All Apps screen .............................................................................. 32
Opening the All Apps screen ..................................................... 32
Using the browser ..................................................................... 34
Taking pictures and videos ........................................................ 35
Viewing pictures and watching videos ........................................ 2
Listening to music ..................................................................... 31
Working with Email ................................................................... 31
Setting up your Email account ................................... 31
Reading an e-mail ....................................................... 32
Sending an e-mail ....................................................... 32
Managing accounts .................................................... 33
Managing your contacts ............................................................ 33
Using the clock .......................................................................... 34
Setting date and time ................................................. 34
Setting an alarm ......................................................... 34
Downloading applications ......................................................... 35
Downloading from Google Play ................................. 35
Downloading an app from non-Google sites ............. 36
8. USB and HDMI Connections .......................................................... 37
Working with the USB connector .............................................. 37
Share files with your Computer ................................. 37
USB OTG (On-The-GO) connection ........................................... 38
Using HDMI devices .................................................................. 39
9.Locking and Security ...................................................................... 40
Screen lock mode ...................................................................... 40
Protecting data against viruses ................................................. 41
Locking the tablet screen .......................................................... 41
10. Settings ........................................................................................ 43
Where to find Settings .............................................................. 43
WIRELESS & NETWORKS ........................................................... 45
Wi-Fi ........................................................................... 45
Bluetooth.................................................................... 46
DEVICE ....................................................................................... 48
Sound ......................................................................... 49
Display ........................................................................ 49
Storage ....................................................................... 50
Battery ........................................................................ 50
Apps ............................................................................ 51
PERSONAL ................................................................................. 51
Accounts & sync ......................................................... 51
Location services ........................................................ 51
Security ....................................................................... 52
Language & input ....................................................... 53
Backup & reset ........................................................... 53
SYSTEM ...................................................................................... 53
Date & time ................................................................ 53
Accessibility ................................................................ 54
Developer options ...................................................... 55
About the tablet ......................................................... 55
11. Troubleshooting .......................................................................... 56
Restoring your tablet ................................................................ 61
Using the Settings app ............................................... 61
By pressing hardware buttons ................................... 62
12. Specification ................................................................................ 63
1
1. Overview
This chapter provides an overview of the tablet, including the
locations of the connectors and controls, tablet features, and
accessories.
Package contents
Carefully unpack your box and take out the items listed below.
If any of the items are missing or damaged, please contact your
dealer immediately:
• One Tablet • One AC adapter • One USB
cable
• One Warranty card • One Quick Guide • This manual
Tablet layout
This topic introduces the tablet hardware features and basic
information you need to start using the tablet.
2
No.
Name
Function
1
Front facing
camera
Often for taking self-portraits as well as for
video conferencing.
2
Front
Microphone
Mainly for collecting the sound of your
voice for speech recognition and
communication purposes.
3
Touchscreen
The touchscreen display is a see-touch
device: You look at it and also touch it
with your fingers to control the tablet.
3
1
2
Front view
3
No.
Name
Function
1
Power Lock
Push here to power on/off or lock on/off
your tablet.
2
Volume
up/Volume
down
Press here to increase or decrease the sound
volume.
3
Rear facing
camera
The camera is mainly used when you are
taking photos or recording videos.
4
Speaker
The sound system has two speakers for
playing music, notification sounds, and
other audio data.
3
4
12
4
Rear view
4
No.
Name
Function
1
SD card slot
This is where you can insert an SD memory
card.
2
HDMI port
This is where you can connect your HDMI
external screen.
3
Headphone
connector
Here you can plug in a standard
headphone.
4
USB port
This is where you can establish a USB
connection.
5
Power port
This is where you plug in the adapter to
charge your tablet.
1 2 3 4 5
Left side view
5
2~3 Sec.
Initial Setup - Charge first then Turn on
Ensure you follow the instructions below:
1. Use the supplied AC adapter to connect your tablet to an
electrical outlet. Charge your tablet until you see the
battery indicator change from orange to blue (which
means the battery is fully charged).
2. Press and hold the power button for two or three
seconds to turn on the tablet.
3. Follow the onscreen instructions to complete the
initial setup.
During this setup, you will be asked to:
a. Select your Wi-Fi network ;
b. Set your Google account;
c. Join Google+
d. Determine whether to keep your tablet backed up
with your Google account.
e. Set date and time.
4. The main Home screen appears.
6
2. Basic Operations
To operate a tablet, you need to be familiar with how to use
the buttons and the touchscreen.
Power button operations
Locking your tablet to sleep
If you decide to leave your tablet for a while and intend to
return soon, rather than powering it off, you can lock it to
sleep by a brief press on the power button. This will block out
any operation on your tablet until you press the power
button again. This is also considered the best way to save
power.
Waking your tablet
Your tablet may also lock itself automatically if it is not
being used for a specific waiting time. The waiting time can
be specified in the Setting page. For details, see Chapter 10.
To wake your tablet, press the power button.
Turning off your tablet
To turn off your tablet, follow these steps:
1. Press and hold the Power Lock button.
2. The Power-off menu appears, as shown below.
3. Touch OK to power down your tablet.
7
Gesture name
Explanation
Touch
Tap the screen once to open items
and select options.
Double-touch
Tap the screen twice in the same
location. When viewing an image or
a map, double-tapping can be used
to zoom in and also zoom out. In this
case, it is recommended that you use
the zoom-in or zoom-out gesture (as
shown later in this table) instead
when you want to zoom.
Touchscreen operations
The most common methods are tapping and typing on the
touchscreen directly with your fingers. In this section, you
will learn to do this both ways.
Finger gestures
Most of the operations when using your tablet are done
through the touchscreen with your fingertips. The most
common fingertip operations, which we call “gestures”, are
as follows:
8
Drag
Keep your finger touching the screen
and drag across the screen toward
the direction you desire. Use this
gesture whenever you want to select
text or move icons.
Long-touch
Long touch an item to see a list of
actions available for that item.
Swipe or slide
Swipe your finger in a vertical or
horizontal direction on the screen
to scroll through Home screens, Web
pages, lists, picture thumbnails,
and so on.
Zoom-out
Start out with two fingers separated
and then bring them close together.
Zoom-in
Start out with your fingers together
and then spread them.
9
Rotate
A few apps let you rotate an image
on the screen by touching it with
two fingers and twisting them
around a center point.
To type numbers and symbols, touch the 123
key to switch to the numbers and symbols
keyboard.
Onscreen keyboard
The onscreen keyboard is a software keyboard displayed
automatically anytime you are required to type in some
information. The software keyboard preinstalled in your
tablet is the Android keyboard.
• Typing text, numbers, symbols, and other characters
When you need to type text, touch the text field to bring up
the onscreen keyboard, then touch keys on the keyboard to
type. To close the onscreen keyboard, touch the down arrow
icon from the system bar.
10
To input text by speaking, touch the
microphone key to start speaking.
Touch the shift key to capitalize a letter.
Double-tap the shift key to capitalize all
letters. By default, the auto-capitalization
function is enabled when you are typing
English.
If you have configured multiple languages for the
Android keyboard input method, and want to switch
to another language when you are typing text, do the
following:
1. Touch the keyboard icon from the system bar to
bring up the input method selection dialog box.
2. Touch the desired language from the list.
Changing the input method when typing
To change the input method when typing, do the following:
1. Long-touch the settings key to bring up the input method
selection dialog box.
2. Touch the desired input method from the list.
Using the onscreen keyboard in other languages
To configure the input language, do the following:
1. Open Settings screen and touch Language & input. All the
input methods are listed.
2. Locate the input method you are using and touch the
settings icon.
3. Configure the language settings.
4. Touch the back icon when you are done.
11
The edit menu shows up when you have text selected.
1. Long-touch the area where you
want to paste the text that you
have cut or copied. A pop-up
option is displayed.
• Editing text
To cut or copy text, do the following:
1. Long-touch the word you want to use until the edit menu
is displayed at the top right of the screen. The selected word
is highlighted and two selection tabs are displayed under
the word.
2. Drag either selection tab to expand or reduce the range of
the selected text. If you want to select all text, touch SELECT
ALL from the edit menu.
3. Touch CUT or COPY from the edit menu. The text is saved
to the clipboard.
To paste or replace text, do the following:
2. Touch PASTE to paste the text, or REPLACE to replace the
12
text selected.
Dictionary
Your tablet has dictionaries in many languages which are
helpful when composing messages and documents. The
appropriate dictionary is activated automatically when you
touch a supported keyboard.
The active dictionary suggests corrections or completes the
word while you type. You do not need to interrupt your
typing to accept the suggested word.
• Accepting or rejecting dictionary suggestions
To accept a dictionary suggestion, touch the correct word
when the dictionary suggestion is displayed. To reject a
dictionary suggestion, finish typing the word that you want,
and then touch the space key.
• Correcting a word using the dictionary suggested corrections
If you misspell a word, the word is underlined with a red
line. Touch the misspelled word and a list of suggested
corrections is displayed. Touch the one that best matches
your word. The misspelled word is replaced.
You also can create your own dictionary by using the
Personal dictionary function.
To add a word to your dictionary, Open Android Settings and
touch Language & input ➙ Personal dictionary ➙ Add.
13
No.
Name & icon
Function
1
All Apps
Tap on it when you want to view all
apps installed in your tablet. (see
Chapter 7)
2
Status area
Displays your tablet’s status and
notifications. (see Page 15)
2345
67 1
3. Home screens
Whenever you turn on and unlock your tablet, it displays the
main Home screen which looks like the one shown below.
14
3
Recent
Open a list of thumbnail images of
applications you have launched
recently. To switch to an application,
touch the thumbnail. To close an
application, long-touch the
thumbnail to bring up the pop-up
menu, and then touch Remove from
list.
4
Home
A navigation button. Tap on it when
you want to go back to the Home screen.
5
Back
A navigation button. Tap on it when
you want to go back to the previous
screen.
6
Google Voice
Search
Search for information on the Internet
by speaking. See “Searching the
Internet” on page 17 for more
information.
7
Google
Search
Google
Search for information on the Internet.
See “Searching the Internet” on page 17
for more information.
The main Home screen is actually the central one of the five
Home screens.
15
Touch a blank area on the screen and slide your finger left or
right horizontally to scroll to the other Home screens.
You can customize the five Home screens to meet your personal
preferences. For more information, see next section.
Customizing your Home screens
You might want to customize the Home screens to meet your
personal preferences. Read this topic to learn how to do this
by adding an item to a Home screen, rearranging the Home
screens, resetting the main Home screen, and changing the
wallpaper.
Adding an item to a Home screen
It is simple and easy to add apps to your Home screens.
1. Scroll to one of the Home screens for which you want to
add the app shortcut.
2. Tap the All Apps icon.
3. Long-touch the app icon that you want to add.
When you touch the icon for long enough, you will see the
background change from the All Apps screen into the
Home screen. Do not remove your finger just yet.
4. Drag and position the icon in the place in which you want
it to appear.
5. Take your finger away at the place you want the icon to be.
Loading...
