ELITEGROUP COMPUTER SYSTEMS H70QBGXB User Manual
i
Preface
Copyright 2005
All Rights Reserved.
The information in this document is subject to change without prior
notice in order to improve reliability, design and function and does
not represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect,
special, incidental, or consequential damages arising out of the
use or inability to use the product or documentation, even if
advised of the possibility of such damages.
This document contains proprietary information protected by
copyright. All rights are reserved. No part of this manual may be
reproduced by any mechanical, electronic, or other means in any
form without prior written permission of the manufacturer.
Trademarks
AutoCAD and Autoshade are trademarks of Autodesk, Inc. IBM,
OS/2, and VGA are trademarks of International Business Machines
Corp. Lotus, 1-2-3, and Symphony are trademarks of Lotus
Development Corp. Windows , Word, MS-DOS, and Microsoft are
trademarks of Microsoft Corp. VESA is a trademark of Video
Electronics Standards Association.
Other product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered
trademarks of their respective companies.
Limitation of Liability
While reasonable efforts have been made to ensure the accuracy
of this manual, the manufacturer and distributor assume no liability
resulting from errors or omissions in this manual, or from the use of
the information contained herein.
i
Notices
Federal Communications Commission Radio Frequency
Interference Statement
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate
this equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. End users must follow the specific operating
instructions for satisfying RF exposure compliance. To maintain compliance
with FCC RF exposure compliance requirements, please avoid direct
contact to the transmitting antenna during transmitting.
We declare that the Product is limited in CH1~CH11 by specified firmware
controlled in the USA.
ii
EC DECLARATION OF CONFORMITY (EUROPE)
Hereby, Elitegroup, declares that this product is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC
as listed below
Article 3.1(a): EN 60950, EN50371
Article 3.1(b): EN 301 489-1, 301 489-17
Article 3.2: EN 300 328
0976
Caution:
This equipment is intended to be used in all EU and EFTA countries.
Outdoor use may be restricted to certain frequencies and/or may require a
license for operation. Contact local Authority for procedure to follow. Note:
Combinations of power levels and antennas resulting in a radiated power
level of above 100 mW equivalent isotropic radiated power (EIRP) are
considered as not compliant with the above mentioned directive and are
not allowed for use within the European community and countries that have
adopted the European R&TTE directive 1999/5/EC.
List of national restrictions:
Bulgaria: General authorization required for outdoor use and public service.
France: Outdoor use limited to 10 mW e.i.r.p. within the band 2454-2483.5
MHz.
Italy: If used outside of own premises, general authorization is required.
Luxembourg: General authorization required for public service.
Rumania: On a secondary basis. Individual license required. T/R 22-06 not
implemented
iii
Notice:
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment. Shielded interface cables and a nonshielded AC power cord must be used in order to comply with
emission limits.
This equipment is to be used with power supply: 65W
There is no internal power supply.
iv
Table of Content
BEFORE YOU START ........................................................................1
LET YOUR COMPUTER ACCLIMATE ITSELF ..........................................6
HEAT, COLD, HUMIDITY, AND GLARE ...............................................7
SUITABLE PLACE TO WORK............................................................. 7
INTRODUCTION................................................................................ 9
POWERING UP THE TABLET PC.......................................................9
FRONT SIDE FEATURES ................................................................10
TOP SIDE FEATURES....................................................................11
RIGHT SIDE FEATURES.................................................................13
LEFT SIDE FEATURES...................................................................13
THE BACK SIDE FEATURES ...........................................................14
APPLICATION BUTTONS ................................................................14
NAVIGATION BUTTONS .................................................................15
TOUCHPAD BUTTONS ...................................................................15
GETTING STARTED .........................................................................17
CONNECTING THE AC ADAPTER.....................................................17
TURNING ON YOUR COMPUTER.....................................................18
OPERATING ON BATTERY POWER...................................................18
USING THE COMPUTER ....................................................................21
FEATURES OF THE COMBO DRIVE (DVD-ROM + CD-RW), DVD DUAL
(DVD+/-RW), SUPER MULTI (DVD-RAM+DVD+/-RW) MODULE .......22
PRECAUTIONS FOR HANDLING CD DISCS ........................................22
LOADING A DISC..........................................................................22
THE BATTERY POWER SYSTEM......................................................23
REMOVING THE BATTERY PACK .....................................................24
WRITING AREA............................................................................27
USING THE SCREEN KEYBOARD .....................................................27
ON SCREEN KEYBOARD ...............................................................27
WRITING PAD..............................................................................28
CHARACTER PAD.........................................................................28
CALIBRATION < 4 PTS CAL >..........................................................30
ADVANCED < 25 PTS CAL > ...........................................................30
v
HELP WINDOWS..........................................................................31
DESKTOP ...................................................................................31
CONTROL PANEL.........................................................................33
DESKTOP OPERATION .....................................................................35
THE MULTIMEDIA SOUND SYSTEM..................................................35
AUDIO VOLUME CONTROL.............................................................35
AUDIO SOFTWARE .......................................................................36
SOUND RECORDING.....................................................................37
PLAYING SOUND FILES.................................................................37
EXTERNAL SPEAKERS AND MICROPHONE ........................................37
INTERNET CONNECTION (OPTIONAL)..................................................39
RUNNING BIOS SETUP....................................................................47
ITEM SPECIFIC HELP ....................................................................47
THE LEGEND BAR........................................................................48
LAUNCHING SUBMENUS ................................................................49
GENERAL HELP ...........................................................................49
VGA UTILITIES...............................................................................55
INTEL (R) GRAPHICS MEDIA ACCELERATOR DRIVER FOR MOBILE ........56
VIDEO CONFERENCING (OPTION)......................................................59
USING COMMANDS AND BUTTONS ..................................................60
TROUBLESHOOTING........................................................................65
SYSTEM NOT RESUMING OPERATION .............................................66
DISPLAY SCREEN IS BLANK OR DIFFICULT TO READ ..........................66
TABLET PC IS NOT RESPONDING TO THE PEN ..................................66
THE TABLET PC CAN NOT POWER ON.............................................67
THE CURSOR NOT IN POSITION WHILE USING THE ORDINARY PEN .........67
THE COMPUTER IS UNABLE TO CONNECT TO THE INTERNET.................67
NO SOUND ON THE EXTERNAL SPEAKERS OR HEADPHONES.................67
BEEPING SOUND..........................................................................67
IF THE CURSOR IS NOT IN POSITION WITH THE TOUCH PEN ...................67
SPECIFICATION...............................................................................69
Canadian DOC Notice For Class B Computing Devices
vi
This Class B digital apparatus meets all requirements of the
Canadian Interference - Causing Equipment Regulations.
Cet appareil numerique de la classe B repecte toutes les
exigences du Règlement sur le matèriel brouilleur du Canada.
Personal Inventory
This computer system is designed for years of productive and
pleasurable computing. Use this section to keep notes about
details of your purchase. Update this section when you add new
options.
Date of Purchase:
Dealer’s Name:
Phone:
Address:
E-Mail Address:
WWW Site:
Serial Number:
CPU Type:
Hard Disk Capacity:
Memory Capacity:
Optional Equipment:
vii
Before you Start
CONVENTIONS OF THIS MANUAL
Use this manual will help you get the most from your computer.
• If you are an experienced user of computers and/or
Microsoft’s Windows operating systems, you might find it
useful to read the Quick Start Guide that comes along with
your accessories.
• If you are a less experienced user, you should through the
manual carefully before using your system.
Whether or not you are an experienced user, you should consult
on the Troubleshooting Chapter if you encounter any problems
with your computer.
SAFETY PRECAUTIONS
This section is designed to assist you in identifying potentially
unsafe conditions while working with this product. Required safety
features have been installed in the computer to protect you from
injury. However, you should use good judgment to identify potential
safety hazards:
1. Please read these safety instructions carefully.
2. Please keep this User's Manual for later reference.
3. Please disconnect this equipment from AC outlet before
cleaning. Don't use liquid or sprayed detergent for cleaning.
Use moisture sheet or cloth for cleaning.
4. For pluggable equipment, that the socket-outlet shall be
installed near the equipment and shall be easily accessible.
5. Please keep this equipment from humidity.
6. Lay this equipment on a reliable surface when installed. A
drop or fall could cause injury.
1
7. Make sure to use the right voltage for the power source when
connecting the equipment to the power outlet.
8. Place the power cord in such a way that people can not step
on it. Do not place anything on top of the power cord.
9. All cautions and warnings on the equipment should be noted.
10. If the equipment is not use for a long time, disconnect the
equipment from the main power outlet to avoid being damaged
by transient overvoltage.
11. Never pour any liquid into the opening, this could cause fire or
electrical shock.
12. Never open the equipment. For safety reason, the equipment
should only be opened by a qualified service personnel.
13. If on the following situations arises, get the equipment
checked by a service personnel:
a. The Power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment has not worked well or you cannot get it work
according to the user's manual.
e. The equipment has dropped and damaged.
f. If the equipment has obvious sign of breakage.
14. Do not leave this equipment in an environment unconditioned,
storage temperature above 60°C (140°f), it may damage the
equipment.
15. The unit can be operated at an ambient temperature of max.
35°C.
16. The sound pressure level at the operators position according
to IEC 704-1: 1982 is equal or less than 70 dB(A).
17. Power Cord Requirements
The power cord set used with the AC adaptor must meet the
requirements of the country where you use the AC adaptor,
whether it is 100-120 or 200-240 Vac. The following
information explains the requirements for power cord set
selection.
Ø The cord set must be approved for the country in
which it is used.
Ø The appliance coupler must have a configuration
for mating with a CEE22/EN6032/IEC 320
appliance inlet.
A. For U.S. and Canada:
Ø The cord set must be UL Listed and CSA Certified.
2
Ø The minimum specifications for the flexible cord
are No. 18 AWG.
B. For Japan:
Ø All components of the cord set must bear a “PSE”
or “ T ” mark and registration number in
accordance with the Japanese Dentori Law.
Ø The minimum specifications for the flexible cord
are .75m㎡ conductors.
C. For Other Countries:
Ø The cord set fittings must bear the certification
mark of the agency responsible for evaluation in a
specific country.
Ø The flexible cord must be of a HAR (harmonized)
type H03VV-F.
Ø The cord set must have a current capacity of a
least 2.5 Amperes and voltage rating of 125 or
250 Vac.
18. When using your telephone equipment, basic safety
precautions should always be followed to reduce the risk of
fire, electric shock and injury to persons. These precautions
includes the following:
Ø Do not use this product near water, for example, near a
bathtub, washbowl, kitchen sink or laundry tub, in a wet
basement or near a swimming pool.
Ø Avoid using a telephone (other than a cordless type) during
an electrical storm. There may be a remote risk of electric
shock from lightning.
Ø Do not use the telephone to report a gas leak in the vicinity
of the leak.
Ø Use only the power cord indicated in this manual.
19. Do not use the AC adapter near open water or other liquids.
Never spill liquid into the AC adapter.
20. Laser Warning: Laser Class I Product Caution - Invisible laser
radiation when open avoid exposure to beam.
21. Danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type recommended by the
manufacturer. Dispose of used batteries according to the
manufacturer's instructions. Never remove the battery pack
while the power is on as this may result in data loss when the
system loses power.
22. The input receptacle is used as the main disconnecting device.
3
WICHTIGE SICHERHEITSHINWEISE
1. Bitte lesen Sie diese Hinweis sorgfältig durch.
2. Heben Sie dirse Anleitung für den späteren Gebrauch auf.
3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen.
Versenden Sie Keine Flüssig- oder Aerosolreiniger. Am
besten eignet sich ein angefeuchtetes Tuch zur Reinigung.
4. Die Netzanschlußsteckdose soll nahe dem Gerät angebracht
und leicht zugänglich sein.
5. Das Gerät ist vor Feuchtigkeit zu schützen.
6. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu
achten. Ein Kippen oder Fallen könnte Beschädigungen
hervorrufen.
7. Beachten Sie beim Anschluß an das Stromnet die
Anschlußwerte.
8. Verlegen Sie die Netzanschlußleitung so, daß niemand
darüber fallen kann. Es sollte auch nichts auf der Leitun
abgestellt werden.
9. Alle Hinweise und Warnungen, die sich am Gerät befinden,
sind zu beachten.
10. Wird das Gerät üeinen längeren Zeitraum nicht benutzt,
sollten Sie es vom Stromnetz trennen. Somit wird im Falle
einer Überspannung eine Beschädigung vermieden.
11. Durch die Lüftungsöffnungen dürfen niemals Gegenstände
oder Flüssigkeien in das Gerät gelangen. Dies könne einen
Brand bzw. Elektrischen Schlag auslösen.
12. Öffnen Sie niemals das Gerät. Das Gerät darf aus Gründen
der elektrischen Sicherheit nur von authorisiertem
Servicepersonal geöffnet werden.
13. Wenn folgende Situationen auftreten ist das Gerät vom
Stromnetz zu trennen und von einer qualifizierten Servicestelle
zu Überprüfung.:
a. Netzlabel oder Netzstecker sind beschädigt.
b. Flüssigkeit ist in das Gerät eingedrungen.
c. Das Gerät war Feuchtigkeit ausgesetzt.
d. Wenn das Gerät nicht der Bedienungsanleitung entsprechend
funktioniert oder Sie mit Hilfe dieser Anleitung keine
Verbesserung erzielen.
e. Das Gerät ist gefallen und/oder das Gehäuse ist beschädigt.
f. Wenn das Gerät deutliche Anzeichen eines Defektes aufweist.
4
14. VORSICHT: Explosiongsgetahr bei unsachgemäßen
Austausch der Batterie. Ersatz nur durch denselben oder
einem vom Hersteller empfohlenem ähnlichen Typ.
Entsorgung gebrauchter Batterien nach Angaben des
Herstellers.
15. Dieses Schaltnetzteil kann bis zu einer Außentemperatur von
maximal 35ºC.
16. Die Ausgangswerte dürfen nicht die auf dem Label
angegebenen Werte überschreiten.
17. Anforderungen an das Stromkabel
Das Kabel-Set, das an das Netzteil angeschlossen wird, muss
den Anforderungen des Landes, in dem Sie das Netzteil
einsetzen, genügen, je nachdem, ob die Netzspannung 100120 oder 200-240V Wechselspannung beträgt.
Ø Das Kabel-Set muss für das Land, in dem es
eingesetzt wird, zugelassen sein.
Ø Der Gerätestecker des Kabels muss in eine
CEE22/ EN603/ IEC 320 Buchse passen.
A. Für die USA und Kanada:
Ø Das Kabel-Set muss UL-gelistet und CSA
zertifiziert sein.
Ø Die Minimalanforderungen für das Kabel
entsprechen No. 18 AWG.
B. Für Japan:
Ø Alle Teile des Kabel-Sets müssen entsprechend
dem japanischen Dentori Law mit einem „PSE“ or
„T”-Symbol markiert sein
Ø Die Minimalanforderungen für das Kabel
sind .75m ㎡ Leiter.
C. Für andere Länder:
Ø Die Zubehörteile des Kabel-Sets müssen das
Prüfsiegel derjenigen Stelle, die in dem jeweiligen
Land für die Sicherheitsprüfung zuständig ist,
tragen.
Ø Das Kabel muss vom HAR (harmonisierten) Typ
H03VV-F sein.
Ø Das Kabel-Set muss eine Stromkapazität von
mindestens 2,5 Ampere haben und Spannungen
von 125 oder 250 V Wechselstrom gestatten.
5
18. Bei der Benutzung Ihres Telefongerätes sollten Sie immer die
grundlegenden Sicherheitsmaßnahmen beachten, um das
Risiko von Feuer, Stromschlägen und Verletzungen zu
minimieren. Zu beachten sind u.a. folgende Punkte:
Ø Benutzen Sie das Gerät nicht in der Nähe von Wasser, wie
zum Beispiel Badewanne, Waschbecken, Spülbecken,
Waschbottich, in feuchten Kellerräumen oder in der Nähe
von Schwimmbecken.
Ø Benutzen Sie kein Telefon (ausgenommen schnurlose
Modelle) während eines Gewitters. Es besteht das geringe
Restrisiko eines Blitzschlages.
Ø Benutzen Sie das Telefon nicht um ein Gasleck zu melden,
falls es sich in der Nähe des Lecks befindet.
Ø Benutzen Sie nur solch ein Stromkabel, wie in dieser
Anleitung beschrieben.
19. Benutzen Sie das Netzteil nicht in unmittelbarer Nähe zu
Wasser oder anderen Flüssigkeiten. Gießen Sie nie
Flüssigkeiten über das Netzteil.
20. Achtung Laser: Laser Produkt der Klasse I. Achtung -
Unsichtbarer Laserstrahl, vermeiden Sie Kontakt mit dem
Strahl bei offenem Gehäuse.
21. Es besteht Explosionsgefahr, wenn der Akku nicht
ordnungsgemäß ersetzt wird. Ersetzen Sie den Akku nur
durch einen Akku gleichen oder äquivalenten Typs, der vom
Hersteller empfohlen wird. Entsorgen Sie Akkus entsprechend
den Anweisungen des Herstellers. Entfernen Sie den Akku auf
keinen Fall bei eingeschaltetem computer, da hierdurch Daten
verloren gehen könnten.
22. Der Netzeingabeanschluss dient als Hauptschalter des Geräts.
THINGS YOU MUST REMEMBER BEFORE WORKING ON YOUR
COMPUTER
LET YOUR COMPUTER ACCLIMATE ITSELF
Your computer can easily stand temperature extremes but it
doesn’t like rapid changes in temperature, like going from the cold
outdoors to a warm office. Rapid changes in temperature can
cause water droplets to condense inside your case, threatening to
damage the electronic parts inside.
6
After receiving your computer when it’s hot or cold outside, try not
to power up the computer immediately, let the computer adjust to
the room temperature gradually at least for three to four hours.
If your system arrives in cold weather, do not apply
power to the computer or monitor until they have been allowed to
come to room temperature.
HEAT , COLD, HUMIDITY, AND GLARE
Find a suitable place for your computer that’s not too hot, too cold,
too dark, or too bright. Glare can make it hard to read the screen.
• Try to avoid the computer components from being destroyed
if it is over heated, so try to allow plenty of room for air to
circulate around the case.
• Do not block the ventilation opening.
• Do not place your computer in direct sunlight.
SUITABLE PLACE TO WORK
Your computer will run well wherever you’re comfortable but
extremes of temperature and humidity can be challenging to your
system’s parts. There are some things you can tolerate that the
computer can’t – things like static electricity, dust, water, steam
and oil. In case you decide to pull over for roadside computing, try
to choose a clean, comfortable work area for your system.
A lithium-ion battery pack will be available when you are traveling.
If you are running your system for the first time on battery power,
remove the battery from the package, install it into the system and
recharge the battery to fully prepare for service.
7
8
Introduction
WELCOME TO THE TABLET PC
Congratulations on your purchase of the Tablet PC. Your computer
features the latest advances in portable computing technology.
The computer’s modular design provides maximum expandability
without compromising portability.
POWERING UP THE TABLET PC
At the top of the Tablet PC, locate on the power button and press
for a few seconds to power up the system.
9
FRONT SIDE FEATURES
Speaker
11..
Stick Pointer Button (Mouse Left Button)
22..
Media Player Adjustment Buttons
33..
Use these buttons for adjustment when you are playing
any audio or video files using the Windows’ Media Player.
Volume Up Button – Press this button to increase the
Œ
volume.
10
Play/Pause Button – Press this button to start
•
playing/pause any file.
Next Track Button – Press this button to start the next
Ž
track
Previous Track Button – Press this button to start the
•
previous track.
Volume Down Button – Press this button to decrease the
•
volume.
Stick Point Button (Mouse Right Button)
44..
Internet Explorer Button
55..
Ctrl-Alt-Del Button
66..
Built-In Camera
77..
Page Up Button
88..
Stick Point
99..
Page Down Button
1100..
Media Player Button
1111..
Camera Button
1122..
TOP SIDE FEATURES
Power Button
11..
CardReader
22..
11
Be sure the face of the card must be facing down when
inserting without using the stand or bottom side facing you when
inserting using the stand.
Lock Switch
33..
You will not be able to open the system if this button is in
lock position. To unlock, slide it back to the direction of the power
button.
LED Indicator
Battery Charge LED Indicator
44..
HDD LED Indicator
55..
Wireless LED Indicator
66..
Microphone Jack
77..
Earphone Jack
88..
USB 2.0 Port
99..
12
RIGHT SIDE FEATURES
DC-In Connector
11..
Brightness Control Buttons
22..
Pen Holder
33..
LEFT SIDE FEATURES
USB 2.0 Port
11..
13
THE BACK SIDE FEATURES
Battery Compartment
11..
Tablet’s Stand
22..
Battery Release Latch
33..
Slide the latch to right direction will lock and to left
direction will unlock the battery compartment cover.
CONTROL BUTTONS
APPLICATION BUTTONS
Icon KEYS FUNCTION(S)
Internet Button
Press this button to launch the Internet
Explorer.
14
Setting Button
Multimedia Button Press this button to execute the Media
Camera Button Press this button to turn ON the camera
NAVIGAT ION BUTTONS
This buttons consists of Page Up and Page Down
segments.
When you press the Page Up •, you will scroll up
one page.
When you press the Page Down ‚, you will scroll
down one page.
TOUCHPAD BUTTONS
This buttons consists of the equivalent function when
you are using the mouse.
When you press the button, this will execute the
double clicking function you normally use on a
conventional mouse.
When you press the button, this will execute other
list of functions.
Press this button to execute the Ctrl-AltDel function.
Player function
function.
STATUS DISPLAY
Icons appear at the bottom of each individual system status LEDs
display indicating the present status of system.
Icon Keys LED Status
Power
Battery
Blue Press this button once to power on
Off Press this button for more than 4
Green Battery capacity 10~95%
Red Low battery capacity (less than
Green Blinking
or enter the suspend/resume
mode (blinking LED).
seconds to power off the system.
10%)
Battery charging status
Remarks
15
Loading...
