ELITEGROUP COMPUTER SYSTEMS GWS BTI2 User Manual

Quick Manual

Ruggedized Intelligent Gateway

i

GWS-BTI2

Copyright

The documentation and the software included with this product are copyrighted 2017 by

ECS Co., Ltd. All rights are reserved. ECS Co., Ltd. reserves the right to make

improvements in the products described in this manual at any time without notice. No part

of this manual may be reproduced, copied, translated or transmitted in any form or by any

means without the prior written permission of ECS Co., Ltd. Information provided in this

manual is intended to be accurate and reliable. However, ECS Co., Ltd. assumes no

responsibility for its use, nor for any infringements of the rights of third parties, which may

result from its use.

Acknowledgements

Intel® BayTrial-I SoC E3825 series are trademarks of Intel Corporation.

McAfee* Embedded Control* and the Wind River* Intelligent Device Platform*

All other product names or trademarks are properties of their respective owners.

FCC Label Compliance Statement:

This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference
(2) This device must accept any interference received, including
interference that may cause undesired operation.

i GWS-BTI2 Ruggedized Intelligent Gateway

Waste disposal instruction

Do not throw this electronic device into the trash can when discarding.

To minimize pollution and ensure utmost protection of the global

environment, please recycle it in European WEEE (waste electrical and

electronic equipment) directive system or recycle system in Taiwan.

MPE 警語

Exposure to Radio Frequency Radiation:

To comply with FCC RF exposure compliance requirements, a separation distance of at least 20cm must be maintained

between the antenna of this device and all persons. This device must not be co-located or operating in conjunction with

any other antenna or transmitter.

NCC 警語

本產品符合低功率電波輻射性電機管理辦法 第十二條、第十四條等條文規定

1. 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或變更原設計之

特性及功能。

2. 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無干擾時方

得繼續使用。

前項合法通信，指依電信法規定作業之無線電通信。

低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。

電磁波曝露量MPE 標準值1mW/cm2，送測產品實測值為：0.0941mW/cm2

Caution! Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type recommended by the

manufacturer. Dispose of used batteries according to the manufa ctur er's

instructions

Warning! Any changes or modifications made to the equipment which are not

expressly approved by the relevant standards authority could void your

authority to operate the equipment.

GWS-BTI2 Ruggedized Intelligent Gateway ii

Attention!

approuvé par l'autorité des normes pertinentes peuvent annuler votre

droit à faire fonctionner l'équipement.

Attention! Danger d'explosion si la pile est remplacée de façon incorrecte.

Remplacez-la uniquement avec le même type ou équivalent recommandé

par le fabricant. Jetez les piles usagées selon les instructions du fabricant

Toute modification apportée à l'équipement qui n'est pas expressément

Packing List

Before setting up the system, check that the items listed below are included and in good condition.

If any items are missing, please contact your dealer immediately.

　　 GWS-BTI2 x1

　　 Adapter x1

　　 Power Cord x1

　　 User Manual x1

　　 USB to RS-232 cable x1 (Optional)

　　 Null Cable (RS-232) x1 (Optional)

　　 Antenna x4 (Optional)

　　 VESA Mount Bracket x1 (Optional)

Warning! 1. Input voltage rated 100-240 VAC, 47-63 Hz, 2.0 A,

Output Voltage rated 24 VDC, 5 A

2. Maintenance: to properly maintain and clean the surfaces, use only

approved products or clean with a dry applicator

Attention! 1. Tension de sortie Tension d'entrée nominale 100-240

VAC, 47-63 Hz, 2,0 A, la note de 24 VDC, 5 A

2. Entretien: bien entretenir et nettoyer les surfaces, utiliser uniquement des

produits approuvés ou nettoyer avec un applicateur sec

Warning! To prevent electric shock, Do not remove cover.

No user serviceable parts inside, refer servicing to qualified personnel.

Additional Information and Assistance

1. Visit the ECS websites at www.ECS.com.tw where you can find the latest information

about the product.

2. Contact your distributor, sales representative, or ECS's customer service center for
