ELITEGROUP COMPUTER SYSTEMS 733EABXX Users Manual
i
Preface
Copyright 2004
All Rights Reserved.
The information in this document is subject to change without prior notice in order to improve
reliability, design and function and does not represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential
damages arising out of the use or inability to use the product or documentation, even if advised of the
possibility of such damages.
This document contains proprietary information protected by copyright. All rights are reserved. No
part of this manual may be reproduced by any mechanical, electronic, or other means in any form
without prior written permission of the manufacturer.
Trademarks
AMI is a trademark of American Megatrends Inc. AutoCAD and Autoshade are trademarks of
Autodesk, Inc. IBM, OS/2, and VGA are trademarks of International Business Machines Corp. Lotus,
1-2-3, and Symphony are trademarks of Lotus Development Corp. Windows, Word, MS-DOS, and
Microsoft are trademarks of Microsoft Corp. VESA is a trademark of Video Electronics Standards
Association.
Other product names mentioned herein are used for identification purposes only and may be
trademarks and/or registered trademarks of their respective companies.
Limitation of Liability
While reasonable efforts have been made to ensure the accuracy of this manual, the manufacturer and
distributor assume no liability resulting from errors or omissions in this manual, or from the use of the
information contained herein.
i
Notices
Federal Communications Commission Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and if not installed and used in accordance
with the instruction manual may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio TV technician for help.
Notice:
Changes or modifications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment. Shielded interface cables and a non-shielded AC power
cord must be used in order to comply with emission limits.
This equipment is to be used with power supply:
I/P: 100-240 Vac, 50-60Hz, 1.5A
O/P: 19Vdc, 4.74A
There is no internal power supply.
I/P: 100-240 Vac, 50-60Hz,
or
O/P: 19Vdc, 6.3A
ii
Canadian DOC Notice For Class B Computing Devices
This Class B digital apparatus meets all requirements of the Canadian Interference - Causing
Equipment Regulations.
Cet appareil numerique de la classe B repecte toutes les exigences du Règlement sur le matèriel
brouilleur du Canada.
iii
This page is intentionally blank
iv
Table of Contents
v
Personal Inventory
This Notebook computer system is designed for years of productive and pleasurable computing. Use
this section to keep notes about details of your purchase. Update this section when you add new
options.
Date of Purchase:
Dealer’s Name:
Phone:
Address:
E-Mail Address:
WWW Site:
Serial Number:
CPU Type:
Hard Disk Capacity:
Memory Capacity:
Optional Equipment:
vi
Before you Start
Conventions of This manual
Use this manual will help you get the most from your notebook computer.
If you are an experienced user of computers and/or Microsoft’s Windows operating systems, you
might find it useful to read the Quick Start Guide that comes along with your accessories.
If you are a less experienced user, you should through the manual carefully before using your
system.
Whether or not you are an experienced user, you should consult on the Troubleshooting Chapter if
you encounter any problems with your notebook.
The check mark symbol indicates that you should take note on every
detailed information when you encounter some function that might be
useful when you are using your notebook.
The pencil symbol identifies information which is important for you to
read to avoid damage to the computer.
1
This warning cautions you against actions which might be destructive to
your data or might disrupt proper system operation.
Safety Precautions
This section is designed to assist you in identifying potentially unsafe conditions while working with
this product. Required safety features have been installed in the computer to protect you from injury.
However, you should use good judgment to identify potential safety hazards:
1. Please read these safety instructions carefully.
2. Please keep this User's Manual for later reference.
3. Please disconnect this equipment from AC outlet before cleaning. Don't use liquid or sprayed
detergent for cleaning. Use moisture sheet or cloth for cleaning.
4. For pluggable equipment, that the socket-outlet shall be installed near the equipment and shall
be easily accessible.
5. Please keep this equipment from humidity.
6. Lay this equipment on a reliable surface when installed. A drop or fall could cause injury.
7. Make sure to use the right voltage for the power source when connecting the equipment to the
power outlet.
8. Place the power cord in such a way that people can not step on it. Do not place anything on top
of the power cord.
9. All cautions and warnings on the equipment should be noted.
10. If the equipment is not use for a long time, disconnect the equipment from the main power
outlet to avoid being damaged by transient overvoltage.
11. Never pour any liquid into the opening, this could cause fire or electrical shock.
12. Never open the equipment. For safety reason, the equipment should only be opened by a
qualified service personnel.
13. If on the following situations arises, get the equipment checked by a service personnel:
The Power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment has not worked well or you cannot get it work according to the user's manual.
The equipment has dropped and damaged.
2
If the equipment has obvious sign of breakage.
14. Do not leave this equipment in an environment unconditioned, storage temperature above 60°C
(140°f), it may damage the equipment.
15. The unit can be operated at an ambient temperature of max. 35°C.
16. The sound pressure level at the operators position according to IEC 704-1: 1982 is equal or less
than 70 dB(A).
17. Power Cord Requirements
The power cord set used with the AC adaptor must meet the requirements of the country where
you use the AC adaptor, whether it is 100-120 or 200-240 Vac. The following information
explains the requirements for power cord set selection.
• The cord set must be approved for the country in which it is used.
• The appliance coupler must have a configuration for mating with a
CEE22/EN6032/IEC 320 appliance inlet.
For U.S. and Canada:
• The cord set must be UL Listed and CSA Certified.
• The minimum specifications for the flexible cord are No. 18 AWG.
For Japan:
• All components of the cord set must bear a “PSE” or “ T ” mark and registration
number in accordance with the Japanese Dentori Law.
• The minimum specifications for the flexible cord are .75m ㎡ conductors.
For Other Countries:
• The cord set fittings must bear the certification mark of the agency responsible for
evaluation in a specific country.
• The flexible cord must be of a HAR (harmonized) type H03VV-F.
• The cord set must have a current capacity of a least 2.5 Amperes and voltage rating of
125 or 250 Vac.
18. When using your telephone equipment, basic safety precautions should always be followed to
reduce the risk of fire, electric shock and injury to persons. These precautions includes the
following:
Do not use this product near water, for example, near a bathtub, washbowl, kitchen sink or
laundry tub, in a wet basement or near a swimming pool.
Avoid using a telephone (other than a cordless type) during an electrical storm. There may be
a remote risk of electric shock from lightning.
Do not use the telephone to report a gas leak in the vicinity of the leak.
3
Use only the power cord indicated in this manual.
19. Do not use the AC adapter near open water or other liquids. Never spill liquid into the AC
adapter.
20. Laser Warning: Laser Class I Product Caution - Invisible laser radiation when open avoid
exposure to beam.
21. Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type recommended by the manufacturer. Dispose of used batteries according to the
manufacturer's instructions. Never remove the battery pack while the power is on as this may
result in data loss when the system loses power.
22. The input receptacle is used as the main disconnecting device.
Wichtige Sicherheitshinweise
1. Bitte lesen Sie diese Hinweis sorgfältig durch.
2. Heben Sie dirse Anleitung für den späteren Gebrauch auf.
3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Versenden Sie Keine Flüssig-
oder Aerosolreiniger. Am besten eignet sich ein angefeuchtetes Tuch zur Reinigung.
4. Die Netzanschluβsteckdose soll nahe dem Gerät angebracht und leicht zugänglich sein.
5. Das Gerät ist vor Feuchtigkeit zu schützen.
6. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu achten. Ein Kippen oder Fallen
könnte Beschädigungen hervorrufen.
7. Beachten Sie beim Anschluß an das Stromnet die Anschlußwerte.
8. Verlegen Sie die Netzanschlußleitung so, daß niemand darüber fallen kann. Es sollte auch
nichts auf der Leitun abgestellt werden.
9. Alle Hinweise und Warnungen, die sich am Gerät befinden, sind zu beachten.
10. Wird das Gerät üeinen längeren Zeitraum nicht benutzt, sollten Sie es vom Stromnetz trennen.
Somit wird im Falle einer Überspannung eine Beschädigung vermieden.
11. Durch die Lüftungsöffnungen dürfen niemals Gegenstände oder Flüssigkeien in das Gerät
gelangen. Dies könne einen Brand bzw. Elektrischen Schlag auslösen.
12. Öffnen Sie niemals das Gerät. Das Gerät darf aus Gründen der elektrischen Sicherheit nur von
authorisiertem Servicepersonal geöffnet werden.
13. Wenn folgende Situationen auftreten ist das Gerät vom Stromnetz zu trennen und von einer
qualifizierten Servicestelle zu Überprüfung.:
4
Netzlabel oder Netzstecker sind beschädigt.
Flüssigkeit ist in das Gerät eingedrungen.
Das Gerät war Feuchtigkeit ausgesetzt.
Wenn das Gerät nicht der Bedienungsanleitung entsprechend funktioniert oder Sie mit Hilfe
dieser Anleitung keine Verbesserung erzielen.
Das Gerät ist gefallen und/oder das Gehäuse ist beschädigt.
Wenn das Gerät deutliche Anzeichen eines Defektes aufweist.
14. VORSICHT: Explosiongsgetahr bei unsachgemäßen Austausch der Batterie. Ersatz nur durch
denselben oder einem vom Hersteller empfohlenem ähnlichen Typ. Entsorgung gebrauchter
Batterien nach Angaben des Herstellers.
15. Dieses Schaltnetzteil kann bis zu einer Außentemperatur von maximal 35ºC.
16. Die Ausgangswerte dürfen nicht die auf dem Label angegebenen Werte überschreiten.
17. Anforderungen an das Stromkabel
Das Kabel-Set, das an das Netzteil angeschlossen wird, muss den Anforderungen des Landes,
in dem Sie das Netzteil einsetzen, genügen, je nachdem, ob die Netzspannung 100-120 oder
200-240V Wechselspannung beträgt.
• Das Kabel-Set muss für das Land, in dem es eingesetzt wird, zugelassen sein.
• Der Gerätestecker des Kabels muss in eine CEE22/ EN603/ IEC 320 Buchse passen.
Für die USA und Kanada:
• Das Kabel-Set muss UL-gelistet und CSA zertifiziert sein.
• Die Minimalanforderungen für das Kabel entsprechen No. 18 AWG.
Für Japan:
• Alle Teile des Kabel-Sets müssen entsprechend dem japanischen Dentori Law mit
einem „PSE“ or „T”-Symbol markiert sein
• Die Minimalanforderungen für das Kabel sind .75m ㎡ Leiter.
Für andere Länder:
• Die Zubehörteile des Kabel-Sets müssen das Prüfsiegel derjenigen Stelle, die in dem
jeweiligen Land für die Sicherheitsprüfung zuständig ist, tragen.
• Das Kabel muss vom HAR (harmonisierten) Typ H03VV-F sein.
• Das Kabel-Set muss eine Stromkapazität von mindestens 2,5 Ampere haben und
Spannungen von 125 oder 250 V Wechselstrom gestatten.
18. Bei der Benutzung Ihres Telefongerätes sollten Sie immer die grundlegenden
Sicherheitsmaßnahmen beachten, um das Risiko von Feuer, Stromschlägen und Verletzungen
zu minimieren. Zu beachten sind u.a. folgende Punkte:
5
Benutzen Sie das Gerät nicht in der Nähe von Wasser, wie zum Beispiel Badewanne,
Waschbecken, Spülbecken, Waschbottich, in feuchten Kellerräumen oder in der Nähe von
Schwimmbecken.
Benutzen Sie kein Telefon (ausgenommen schnurlose Modelle) während eines Gewitters. Es
besteht das geringe Restrisiko eines Blitzschlages.
Benutzen Sie das Telefon nicht um ein Gasleck zu melden, falls es sich in der Nähe des Lecks
befindet.
Benutzen Sie nur solch ein Stromkabel, wie in dieser Anleitung beschrieben.
19. Benutzen Sie das Netzteil nicht in unmittelbarer Nähe zu Wasser oder anderen Flüssigkeiten.
Gießen Sie nie Flüssigkeiten über das Netzteil.
20. Achtung Laser: Laser Produkt der Klasse I. Achtung - Unsichtbarer Laserstrahl, vermeiden Sie
Kontakt mit dem Strahl bei offenem Gehäuse.
21. Es besteht Explosionsgefahr, wenn der Akku nicht ordnungsgemäß ersetzt wird. Ersetzen Sie
den Akku nur durch einen Akku gleichen oder äquivalenten Typs, der vom Hersteller
empfohlen wird. Entsorgen Sie Akkus entsprechend den Anweisungen des Herstellers.
Entfernen Sie den Akku auf keinen Fall bei eingeschaltetem Notebook, da hierdurch Daten
verloren gehen könnten.
22. Der Netzeingabeanschluss dient als Hauptschalter des Geräts.
Things you must remember before working on your computer
Let your computer acclimate itself
Your notebook can easily stand temperature extremes but it doesn’t like rapid changes in temperature,
like going from the cold outdoors to a warm office. Rapid changes in temperature can cause water
droplets to condense inside your case, threatening to damage the electronic parts inside. After
receiving your notebook when it’s hot or cold outside, try not to power up the computer immediately,
let the computer adjust to the room temperature gradually at least for three to four hours.
If your system arrives in cold weather, do not apply power to the computer
or monitor until they have been allowed to come to room temperature.
Heat, Cold, Humidity, and Glare
Find a suitable place for your computer that’s not too hot, too cold, too dark, or too bright. Glare can
make it hard to read the screen.
6
Try to avoid the computer components from being destroyed if it is over heated, so try to allow
plenty of room for air to circulate around the case.
Do not block the ventilation opening.
Do not place your computer in direct sunlight.
Suitable place to work
Your computer will run well wherever you’re comfortable but extremes of temperature and humidity
can be challenging to your system’s parts.
There are some things you can tolerate that the computer can’t – things like static electricity, dust,
water, steam and oil. In case you decide to pull over for roadside computing, try to choose a clean,
comfortable work area for your system.
A lithium-ion battery pack will be available when you are traveling. If you are running your system
for the first time on battery power, remove the battery from the package, install it into the system and
recharge the battery to fully prepare for service.
7
Introduction
Welcome to the Notebook PC
Congratulations on your purchase of the Notebook PC. Your Notebook features the latest advances in
portable computing technology. The Notebook’s modular design provides maximum expandability
without compromising portability. The high-performance CPU and enhanced IDE hard drive provides
you with extra processing power for handling complex graphics and running large programs.
One PCMCIA slot gives you the ability to use standard PCMCIA cards, such as a LAN adapter or
memory cards.
Unpacking the Notebook
The Notebook comes securely packaged in a sturdy cardboard shipping carton. Upon receiving your
Notebook, open the carton and carefully remove the contents. If anything is missing or damaged,
please contact your Notebook dealer immediately. The shipping carton should contain the following
items:
The Notebook computer
An AC adapter
An AC power cord
Software Drivers CD
8
Do not throw the packaging materials away. You may need them later if you have to ship the
computer for repairs.
Getting to Know Your Computer
Opening the LCD Panel
At the front of the Notebook you will find a retaining latch on the display panel that locks the display
in closed position when the Notebook is not in use.
1. Locate the display latch on the front of the unit. Slide the latch until the display panel releases.
2. Raise the LCD screen and the machine will go to incline position.
3. At any time you can tilt the display toward or away from you to a comfortable viewing position.
To avoid damage to the display panel:
1. Try not to slam the display upon closing it.
2. Try not to place any object on top when it is closed or open.
With the LCD screen open, you will see several features important for operating your Notebook
computer. Each of these features is briefly described below:
9
10
1. LCD Cover Release Latch
2. LCD Screen
3. Short-cut Keys
1. Internet Explorer Button
2. Outlook Express Button
4. System Status Indicator Panel
Indicates the computer is accessing the PCMCIA drive.
Indicates that the computer is accessing the DVD-ROM drive.
Indicates that the computer is accessing the hard disk drive.
Indicates that the keyboard is in Num Lock mode.
Indicates when the keyboard is in Caps Lock mode. In this mode, the
keyboard produces uppercase text when you press a key. When you
press the Caps Lock key again, the indicator goes off and the keyboard
produces lowercase text.
Indicates when the keyboard is in Scroll Lock mode. Some applications
will move information across the screen differently when Scroll Lock is
on.
11
The Left Side
5. Power/Resume Button
6. Keyboard
7. TouchPad
8. Scroll Button
9. TouchPad Buttons
10. The Built-in Microphone
11. Stereo Speakers
1. Kensington Lock
2. USB Ports
3. 1394 Ports
4. PCMCIA Socket Cover
5. PCMCIA Socket Button
6. External Microphone Jack
7. Audio Line Out/SPDIF Jack
12
LED Indicator
A. Battery Charge/Suspend
An orange color light indicates the battery is in charging status. When it turn to green color
light it indicates the system is in suspend mode. When the indicator light turn off, it indicates
the system is in full charge.
B. Power On
This indicator will lit when the notebook is powered on.
13
The Right Side
1. The Modem Port
2. The DVD-ROM or DVD Combo
3. Smart Fan
4. DC IN Connector
The Rear
Always disconnect all telephone lines from the wall outlet before
servicing or disassembling this equipment. To reduce the risk of fire use
only No. 26 AWG or larger telecommunication line cord.
14
1. Parallel Port
2. External CRT Port
3. Smart Fan
4. TV Out Port
5. The LAN Port
When using a LAN, please use an EMI Shielding Cable to minimize an
inteference when transmitting.
6. Infrared Data Port
7. Ventilation Opening
The Bottom Panel
1. The CD-ROM/DVD-ROM/Combo Drive
2. Battery Release Latch
3. Battery
4. CPU Compartment
5. Hard Disk Drive
15
16
Loading...
