ELITEGROUP COMPUTER SYSTEMS 600LIABG Users Manual

600L

Preface



notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer.

In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages. This document contains proprietary information protected by copyright. All rights are reserved. No part of this manual may be reproduced by any mechanical, electronic, or other means in any form without prior written permission of the manufacturer.

Trademarks

AutoCAD and Autoshade are trademarks of Autodesk, Inc. IBM, OS/2, and VGA are trademarks of International Business Machines Corp. Lotus, 1-2-3, and Symphony are trademarks of Lotus Development Corp. Windows, Word, MS-DOS, and Microsoft are trademarks of Microsoft Corp. VESA is a trademark of Video Electronics Standards Association. Other product names mentioned herein are used for identification purposes only and may be trademarks and/or registered trademarks of their respective companies.

Limitation of Liability

While reasonable efforts have been made to ensure the accuracy of this manual, the manufacturer and distributor assume no liability resulting from errors or omissions in this manual, or from the use of the information contained herein.

Notices

Federal Communications Commission Radio Frequency Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and if not installed and used in accordance with the instruction manual may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and receiver

• Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected

• Consult the dealer or an experienced radio TV technician for help

Notice:

Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Shielded interface cables and a non-shielded AC power cord must be used in order to comply with emission limits.

This equipment is to be used with power supply: I/P: 100-240 Vac, 50-60Hz, 1.8A O/P: 19Vdc, 3.42A There is no internal power supply.

Table of Content

Chapter 1: Before you Start........................................................1

Conventions of This Manual........................................................................ 1

Safety Precautions .......................................................................................1

Wichtige Sicherheitshinweise.................................................................... 3

Things you must remember before working on your computer............... 6

Chapter 2: Introduction...............................................................9

Welcome to the Notebook PC....................................................................9

Unpacking the Notebook............................................................................. 9

Getting to Know Your Computer................................................................10

Chapter 3: Getting Started ........................................................19

Connecting to a Power Source....................................................................19

Turning On Your Notebook Computer....................................................... 20

Inserting and Removing the Battery Pack..................................................21

Charging the Battery Pack........................................................................... 22

Chapter 4: Using the Notebook Computer ...............................23

Adjusting the LCD Screen Display............................................................. 23

The TouchPad............................................................................................... 26

Data Storage and Retrieval ..........................................................................26

Power Saving Modes....................................................................................27

Resetting the System...................................................................................30

Chapter 5: Desktop Operation ..................................................31

Audio.............................................................................................................31

Connecting Peripheral Devices.................................................................. 32

Chapter 6: Internet Connection .................................................35

Using Both DHCP and Static IP for Connection to Internet....................38

Using Wireless LAN Network for Connection to Internet (Microsoft’s

Service Pack 2) (Optional).......................................................................... 40

Chapter 7: Configuring and Maintaining your System.............41

Introduction..................................................................................................41

Chapter 8: Microsoft Center Edition (MCE) (Option)...............49

Windows XP Media Center Edition (MCE).............................................. 49

MCE Application Sound Adjustment.......................................................... 50

If you are using MCE’s “My TV” application............................................ 50

If you are using InterVideo’s WinDVR application..................................51

Chapter 9: VGA Utilities ............................................................53

iii

Adapter..........................................................................................................54

General..........................................................................................................55

Color............................................................................................................. 56

Intel® Graphics Media Accelerator Driver...............................................57

Monitor.........................................................................................................58

Troubleshoot.................................................................................................59

Chapter 10: Viewing Live Video (Option) .................................61

Using the Remote Control.......................................................................... 62

WinDVR Mode............................................................................................. 62

Application buttons in DVR mode..............................................................64

Application buttons in DVD mode.............................................................. 66

Application buttons in Music mode............................................................ 68

Chapter 11: Troubleshooting....................................................69

Locating a Problem......................................................................................69

Checking Cables and Connections.............................................................. 70

The Power-On Self Test.............................................................................. 71

General Hardware Problems....................................................................... 71

Contacting Your Dealer............................................................................... 73

Chapter 12: How do I Expand my Notebook............................75

Upgrading your Memory.............................................................................76

Easy to Upgrade HDD Module................................................................... 76

Appendix A: Specification ........................................................79

Detailed Notebook Specifications .............................................................79

Canadian DOC Notice For Class B Computing Devices

This Class B digital apparatus meets all requirements of the Canadian Interference - Causing Equipment Regulations. Cet appareil numerique de la classe B repecte toutes les exigences du Règlement sur le matèriel brouilleur du Canada.

Personal Inventory

This Notebook computer system is designed for years of productive and pleasurable computing. Use this section to keep notes about details of your purchase. Update this section when you add new options.

Date of Purchase: Dealer’s Name: Phone: Address: E-Mail Address: WWW Site:

Serial Number: CPU Type: Hard Disk Capacity: Memory Capacity: Optional Equipment:

BEFORE YOU START

Conventions of This Manual

Use this manual will help you get the most from your notebook computer.

• If you are an experienced user of computers and/or Microsoft’s

Windows operating systems, you might find it useful to read the Quick Start Guide that comes along with your accessories.

• If you are a less experienced user, you should through the manual

carefully before using your system.

Whether or not you are an experienced user, you should consult on the Troubleshooting Chapter if you encounter any problems with your notebook.

Safety Precautions

This section is designed to assist you in identifying potentially unsafe conditions while working with this product. Required safety features have been installed in the computer to protect you from injury. However, you should use good judgment to identify potential safety hazards:

1. Please read these safety instructions carefully.

2. Please keep this User's Manual for later reference.

3. Please disconnect this equipment from AC outlet before cleaning.

Don't use liquid or sprayed detergent for cleaning. Use moisture sheet or cloth for cleaning.

4. For pluggable equipment, that the socket-outlet shall be installed

near the equipment and shall be easily accessible.

5. Please keep this equipment from humidity.

6. Lay this equipment on a reliable surface when installed. A drop or

fall could cause injury.

7. Make sure to use the right voltage for the power source when

connecting the equipment to the power outlet.

8. Place the power cord in such a way that people can not step on it.

Do not place anything on top of the power cord.

9. All cautions and warnings on the equipment should be noted.

10. If the equipment is not use for a long time, disconnect the equipment

from the main power outlet to avoid being damaged by transient overvoltage.

11. Never pour any liquid into the opening, this could cause fire or

electrical shock.

12. Never open the equipment. For safety reason, the equipment should

only be opened by a qualified service personnel.

13. If on the following situations arises, get the equipment checked by a

service personnel:

a. The Power cord or plug is damaged. b. Liquid has penetrated into the equipment.

c. The equipment has been exposed to moisture. d. The equipment has not worked well or you cannot get it work

according to the user's manual.

e. The equipment has dropped and damaged. f. If the equipment has obvious sign of breakage.

14. Do not leave this equipment in an environment unconditioned,

storage temperature above 60°C (140°f), it may damage the equipment.

15. The unit can be operated at an ambient temperature of max. 35°C.

16. The sound pressure level at the operators position according to IEC

704-1: 1982 is equal or less than 70 dB(A).

17. Power Cord Requirements

The power cord set used with the AC adaptor must meet the requirements of the country where you use the AC adaptor, whether it is 100-120 or 200-240 Vac. The following information explains the requirements for power cord set selection.

Ø The cord set must be approved for the country in which

it is used.

Ø The appliance coupler must have a configuration for

mating with a CEE22/EN6032/IEC 320 appliance inlet.

A. For U.S. and Canada:

Ø The cord set must be UL Listed and CSA Certified. Ø The minimum specifications for the flexible cord are

No. 18 AWG.

B. For Japan:

Ø All components of the cord set must bear a “PSE” or

“ T ” mark and registration number in accordance with the Japanese Dentori Law.

Ø The minimum specifications for the flexible cord

are .75m㎡ conductors.

C. For Other Countries:

Ø The cord set fittings must bear the certification mark of

the agency responsible for evaluation in a specific country.

Ø The flexible cord must be of a HAR (harmonized) type

H05VV-F.

Ø The cord set must have a current capacity of a least 2.5

Amperes and voltage rating of 125 or 250 Vac.

18. When using your telephone equipment, basic safety precautions

should always be followed to reduce the risk of fire, electric shock and injury to persons. These precautions includes the following:

• Do not use this product near water, for example, near a

bathtub, washbowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

• Avoid using a telephone (other than a cordless type)

during an electrical storm. There may be a remote risk of electric shock from lightning.

• Do not use the telephone to report a gas leak in the

vicinity of the leak.

• Use only the power cord indicated in this manual.

19. Do not use the AC adapter near open water or other liquids. Never

spill liquid into the AC adapter.

20. Laser Warning: Laser Class I Product Caution - Invisible laser

radiation when open avoid exposure to beam.

21. Danger of explosion if battery is incorrectly replaced. Replace only

with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions. Never remove the battery pack while the power is on as this may result in data loss when the system loses power.

22. The input receptacle is used as the main disconnecting device.

Wichtige Sicherheitshinweise

1. Bitte lesen Sie diese Hinweis sorgfältig durch.

2. Heben Sie dirse Anleitung für den späteren Gebrauch auf.

3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen.

Versenden Sie Keine Flüssig- oder Aerosolreiniger. Am besten eignet sich ein angefeuchtetes Tuch zur Reinigung.

4. Die Netzanschlußsteckdose soll nahe dem Gerät angebracht und

leicht zugänglich sein.

5. Das Gerät ist vor Feuchtigkeit zu schützen.

6. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu achten.

Ein Kippen oder Fallen könnte Beschädigungen hervorrufen.

7. Beachten Sie beim Anschluß an das Stromnet die Anschlußwerte.

8. Verlegen Sie die Netzanschlußleitung so, daß niemand darüber fallen

kann. Es sollte auch nichts auf der Leitun abgestellt werden.

9. Alle Hinweise und Warnungen, die sich am Gerät befinden, sind zu

beachten.

10. Wird das Gerät üeinen längeren Zeitraum nicht benutzt, sollten Sie

es vom Stromnetz trennen. Somit wird im Falle einer Überspannung eine Beschädigung vermieden.

11. Durch die Lüftungsöffnungen dürfen niemals Gegenstände oder

Flüssigkeien in das Gerät gelangen. Dies könne einen Brand bzw. Elektrischen Schlag auslösen.

12. Öffnen Sie niemals das Gerät. Das Gerät darf aus Gründen der

elektrischen Sicherheit nur von authorisiertem Servicepersonal geöffnet werden.

13. Wenn folgende Situationen auftreten ist das Gerät vom Stromnetz zu

trennen und von einer qualifizierten Servicestelle zu Überprüfung.:

a. Netzlabel oder Netzstecker sind beschädigt. b. Flüssigkeit ist in das Gerät eingedrungen. c. Das Gerät war Feuchtigkeit ausgesetzt. d. Wenn das Gerät nicht der Bedienungsanleitung entsprechend

funktioniert oder Sie mit Hilfe dieser Anleitung keine Verbesserung erzielen.

e. Das Gerät ist gefallen und/oder das Gehäuse ist beschädigt. f. Wenn das Gerät deutliche Anzeichen eines Defektes aufweist.

14. VORSICHT: Explosiongsgetahr bei unsachgemäßen Austausch der

Batterie. Ersatz nur durch denselben oder einem vom Hersteller empfohlenem ähnlichen Typ. Entsorgung gebrauchter Batterien nach Angaben des Herstellers.

15. Dieses Schaltnetzteil kann bis zu einer Außentemperatur von

maximal 35ºC.

16. Die Ausgangswerte dürfen nicht die auf dem Label angegebenen

Werte überschreiten.

17. Anforderungen an das Stromkabel

Das Kabel-Set, das an das Netzteil angeschlossen wird, muss den Anforderungen des Landes, in dem Sie das Netzteil einsetzen, genügen, je nachdem, ob die Netzspannung 100-120 oder 200-240V Wechselspannung beträgt.

Ø Das Kabel-Set muss für das Land, in dem es eingesetzt

wird, zugelassen sein.

Ø Der Gerätestecker des Kabels muss in eine CEE22/

EN603/ IEC 320 Buchse passen.

A. Für die USA und Kanada:

Ø Das Kabel-Set muss UL-gelistet und CSA zertifiziert

sein.

Ø Die Minimalanforderungen für das Kabel entsprechen

No. 18 AWG.

B. Für Japan:

Ø Alle Teile des Kabel-Sets müssen entsprechend dem

japanischen Dentori Law mit einem „PSE“ or „T”Symbol markiert sein

Ø Die Minimalanforderungen für das Kabel sind .75m ㎡

Leiter.

C. Für andere Länder:

Ø Die Zubehörteile des Kabel-Sets müssen das Prüfsiegel

derjenigen Stelle, die in dem jeweiligen Land für die Sicherheitsprüfung zuständig ist, tragen.

Ø Das Kabel muss vom HAR (harmonisierten) Typ

H05VV-F sein.

Ø Das Kabel-Set muss eine Stromkapazität von

mindestens 2,5 Ampere haben und Spannungen von 125 oder 250 V Wechselstrom gestatten.

18. Bei der Benutzung Ihres Telefongerätes sollten Sie immer die

grundlegenden Sicherheitsmaßnahmen beachten, um das Risiko von Feuer, Stromschlägen und Verletzungen zu minimieren. Zu beachten sind u.a. folgende Punkte:

• Benutzen Sie das Gerät nicht in der Nähe von Wasser,

wie zum Beispiel Badewanne, Waschbecken, Spülbecken, Waschbottich, in feuchten Kellerräumen oder in der Nähe von Schwimmbecken.

• Benutzen Sie kein Telefon (ausgenommen schnurlose

Modelle) während eines Gewitters. Es besteht das geringe Restrisiko eines Blitzschlages.

• Benutzen Sie das Telefon nicht um ein Gasleck zu

melden, falls es sich in der Nähe des Lecks befindet.

• Benutzen Sie nur solch ein Stromkabel, wie in dieser

Anleitung beschrieben.

19. Benutzen Sie das Netzteil nicht in unmittelbarer Nähe zu Wasser

oder anderen Flüssigkeiten. Gießen Sie nie Flüssigkeiten über das Netzteil.

20. Achtung Laser: Laser Produkt der Klasse I. Achtung - Unsichtbarer

Laserstrahl, vermeiden Sie Kontakt mit dem Strahl bei offenem Gehäuse.

21. Es besteht Explosionsgefahr, wenn der Akku nicht ordnungsgemäß

ersetzt wird. Ersetzen Sie den Akku nur durch einen Akku gleichen oder äquivalenten Typs, der vom Hersteller empfohlen wird. Entsorgen Sie Akkus entsprechend den Anweisungen des Herstellers. Entfernen Sie den Akku auf keinen Fall bei eingeschaltetem Notebook, da hierdurch Daten verloren gehen könnten.

22. Der Netzeingabeanschluss dient als Hauptschalter des Geräts.

Things you must remember before working on your computer

Let your computer acclimate itself

Your notebook can easily stand temperature extremes but it doesn’t like rapid changes in temperature, like going from the cold outdoors to a warm office. Rapid changes in temperature can cause water droplets to condense inside your case, threatening to damage the electronic parts inside. After receiving your notebook when it’s hot or cold outside, try not to power up the computer immediately, let the computer adjust to the room temperature gradually at least for three to four hours.

If your system arrives in cold weather, do not

apply power to the computer or monitor until they have been allowed to come to room temperature.

Heat, Cold, Humidity, and Glare

Find a suitable place for your computer that’s not too hot, too cold, too dark, or too bright. Glare can make it hard to read the screen.

• Try to avoid the computer components from being destroyed if it is

over heated, so try to allow plenty of room for air to circulate

around the case.

• Do not block the ventilation opening.

• Do not place your computer in direct sunlight.

Suitable place to work

Your computer will run well wherever you’re comfortable but extremes of temperature and humidity can be challenging to your system’s parts. There are some things you can tolerate that the computer can’t – things like static electricity, dust, water, steam and oil. In case you decide to pull over for roadside computing, try to choose a clean, comfortable work area for your system.

A lithium-ion battery pack will be available when you are traveling. If you are running your system for the first time on battery power, remove the battery from the package, install it into the system and recharge the battery to fully prepare for service.

INTRODUCTION

Welcome to the Notebook PC

Congratulations on your purchase of the Notebook PC. Your Notebook features the latest advances in portable computing technology. The Notebook’s modular design provides maximum expandability without compromising portability. The high-performance CPU and enhanced IDE hard drive provides you with extra processing power for handling complex graphics and running large programs. A premium notebook designed for successful executives who demand the very best and featuring ultimate power, ultimate wide screen display, ultimate AV capabilities and ultimate connectivity. A Media solution is a combination of Windows XP software augmented by InterVideo WinCinema – including WinDVR for watching television, WinDVD for viewing movies and WinRIP for playing music.

Unpacking the Notebook

The Notebook comes securely packaged in a sturdy cardboard shipping carton. Upon receiving your Notebook, open the carton and carefully remove the contents. If anything is missing or damaged, please contact your Notebook dealer immediately. The shipping carton should contain the following items:

• The Notebook computer

• An AC adapter

• An AC power cord

• Software Drivers CD

Do not throw the packaging materials away. You may need them later if you have to ship the computer for repairs.

Because the Notebook computer is available in different configurations, some of the features mentioned in this manual might not be included on your computer or may

differ slightly.

Getting to Know Your Computer

Opening the LCD Panel

To avoid damage to the display panel:

1. Try not to slam the display upon closing it.

2. Try not to place any object on top when it is closed or open.

3. Be sure the system is turned off or in suspend mode before you

close the display panel. With the LCD screen open, you will see several features important for operating your Notebook computer. Each of these features is briefly

described below:

1. LCD Screen

2. System Status Indicator Panel

CardReader access NumLock mode

ScrollLock mode

Hard Disk access CapsLock mode

3. Wireless LAN Switch Button

4. TV Button

5. DVD Button

6. Internet Explorer Button

7. Outlook Express Button

(Launch the WinDVR application)

(Launch the WinDVD application)

8. Power/Resume Button

9. Stereo Speakers

10. Keyboard

11. The Built-in Microphone

12. TouchPad

13. TouchPad Buttons

The Front Side

LED Indicators

1. Power On

This LED will light when the system is power on.

2. Suspend

This LED will light when the system is in suspend mode.

3. Battery Charge

This LED will light when the battery is in charging mode.

The Left Side

1. DC IN Connector

2. The CD-ROM/DVD-ROM or DVD CD-RW Combo

3. PCMCIA

4. CardReader

Be sure the face of the card must be facing down when inserting it to the cardreader slot.

5. PCMCIA Eject Button

6. 1394 Port

The Right Side

1. Kensington Lock

2. Ventilation Opening

3. MCE Port

4. External CRT Port

5. S-Video Port

6. Modem Port

Always disconnect all telephone lines from the wall outlet before servicing or disassembling this equipment. To reduce the risk of fire use only No. 26 AWG or larger telecommunication line cord.

7. LAN Port

When using a LAN, please use an EMI Shielding Cable to minimize an inteference when transmitting.

8. USB Ports

9. Audio Line Out Jack

10. ExternalMicrophone Jack

The Rear

1. Cable TV Input

Before connecting the cable into the connector, be sure to remove first the cover on the cable TV connector at the rear of the computer with the aid of a screw driver. One more thing that you need to be aware of is to know the video standard being used in your country that you are viewing. This system supports 3 video standard namely: NTSC, PAL and SECAM. For detailed information on the proper connection of the cable TV, please refer to Chapter 9 on “Viewing Live Video”.

2. USB Ports

The Bottom Panel

1. Expansion Compartment

2. Hard Disk

3. Optical Drive

4. CPU Compartment

5. Battery Release Latch

6. Battery Lock

7. Battery

Page intentionally left blank

GETTING STARTED

Connecting to a Power Source

Connecting the AC Adapter

A universal AC adapter is provided to supply your computer with power and also charge the computer’s battery pack. The adapter’s AC input voltage can range anywhere from 100 to 240 volts, covering the standard voltages available in almost every country.

The power cord for the AC adapter requires a three-hole grounded AC outlet. To connect the computer to an external power source:

1. Plug the AC adapter’s connector into the DC-IN connector at the left

side of the computer.

2. Connect the power cord to the AC adapter and then to a wall outlet.

Do not use inferior extension cords as this may result in damage to your Notebook. The Notebook comes with its own AC adapter. Do not use a different adapter to power the computer and other electrical devices.

Whenever possible, keep the AC adapter plugged into the Notebook and an electrical outlet to recharge the battery.

Never turn off or reset your Notebook while the hard disk is in use and the HDD status icon is lit; doing so can result in loss or destruction of your data. Always wait at least 5 seconds after turning off your Notebook before turning it back on; turning the power on and off in rapid succession can damage the Notebook’s electrical circuitry.

Turning On Your Notebook Computer

Turn on your Notebook by pressing the power button. Hold the button down for a 1 or 2 second and release. The Power-On Self Test (POST) runs automatically.

After the POST is completed, the computer reads the operating system from the hard disk drive into computer memory (this is commonly referred to as “booting” a computer). If your OS (Operating System such as Windows XP etc) is installed, it should start automatically.

To turn the Notebook off, save your work and close all open applications, click on Start, then select the “Turn off the computer”. A selection box will be displayed and click on the “Turn Off” button to shut down your computer.

When your computer hangs up, press the power button for 4-6 seconds to shut down the computer.

Operating on Battery Power

Your computer comes with a rechargeable battery pack that lets you operate the computer without an external power source. When the battery pack is fully charged, you can operate the computer for approximately 2 hours under the following conditions:

• The battery pack initially has a full charge.

+ 64 hidden pages
