ALUMINUM ELECTROLYTIC CAPACITORS
PC Series
Downsize, high ripple current design.
Load life 2,000 hours at 105
Ideal for low profile power supply application
SPECIFICATIONS
Item Performance Characteristics
Category Temperature Range
Working Voltage Range 200 ~ 450Vdc
Capacitance Range 56 ~ 560 μF
Capacitance Tolerance
Dissipation Factor
(tanδ)
(at 25℃, 120Hz)
Leakage Current
Endurance
Shelf Life
Others Conforms to JIS-C-5101-4 (1998), characteristic W.
℃
±20% (at 25℃ and 120Hz)
Rated Voltage (V) 200 400 450
tanδ(Max) 0.15 0.20 0.20
The above values should be increased by 0.02 for every additional 1000μF
I=0.03CV + 10μA
I : Leakage current (μA) C : Rated capacitance (μF) V : Rated voltage (V)
Impress the rated voltage for2 minutes.
The following requirements shall be satisfied when the capacitor are restored to 25℃ after the rated
voltage applied for 2,000 hours at 105℃.
Capacitance change
Dissipation factor(tanδ) ≦ 200% of the specified value
Leakage current ≦ specified value
The following requirements shall be satisfied when the capacitor are restored to 25℃ after the rated
voltage applied for 1,000 hours at 105℃ without voltage applied.
Capacitance change
Dissipation factor(tanδ) ≦ 200% of the specified value
Leakage current ≦ 200% of the specified value
≦ ±20% of the initial value
≦ ±20% of the initial value
-25 ~ +105℃
DIMENSIONS (mm)
ФD 16 18
ФD ФD +0.5 Max ФD +1.0 Max
Фd 0.8 0.8
F 7.5 7.5
Page 2
ALUMINUM ELECTROLYTIC CAPACITORS
PC Series
Case size & Permissible rated ripple current: (mA rms) at 105℃ / 120Hz
Vdc
uF
56 16×30 390
68 16×25 400 16×30 430 16×35 450
82
100
120
ФD × L RC ФD × L RC ФD × L RC ФD × L RC
200 400 420 450
16×40 510
16×35 490
16×40 520
16×35 500
16×40 570 18×32 570
18×30 570 18×35 620
18×30 520
18×30 510
18×35 600
18×40 700
16×45 700
150
18×35 700
180 18×45 880
220 18×51 1000
270 16×35 810
16×40 930
330
18×35 930
16×45 1050
390
18×35 1050
470 18×40 1180
560 18×51 1320
RIPPLE CURRENT MULTIPLIERS
Frequency Multipliers
Vdc Cap.(uF)
18×40 790 18×45 810
Frequency (Hz)
120 1K 10K 100K
200 ~ 450
56 ~ 82 1.00 1.50 1.75 1.80
100 ~ 560 1.00 1.30 1.40 1.50
