eLine Technology EPTZ-27DN User Manual

PTZ Dome Camera

Operation Manual

ELI-EPTZ-27DN

Read this Manual carefully before installation and keep it for future reference.

Notice:

Precautions:

1.Non-techinician is forbidden to operate this dome device before

reading this manual thoroughly.

2.Cut the power supply off before operating the dome device to avoid

damage caused by improper operation.

3.Interior of the Dome device are precision optical and electrical device.

4.Please do not remove and disassemble any internal parts of Dome

5.All the wiring of the dome device should be conducted strictly

6.Please do not use the product under the situations of exceeding

Operation Manual ELI-EPTZ-27DN eLineTechnology.com

Heavy pressure, shock and other incorrect operations should be

prevented. Otherwise, may cause damage on product.

video camera by self in order to avoid normal usage being impacted.

There is no part inside the device, which can be repaired by users

themselves.

according to the wiring instruction. When necessary, thunder-proof,

surge-proof and other protecting measures should be carried out.

specified temperature, humidity or power supply specifications.

Content

Chapter 1 Product Overview ...................................................................................... 2

1.1 Performance Instructions ............................................................................ 2

Operation Manual ELI-EPTZ-27DN eLineTechnology.com

1.2 Feature Functions Instruction ..................................................................... 3

Chapter 2 Menu setting ............................................................................................... 4

2.1 Operation instructions ................................................................................ 4

2.2 Main menu ................................................................................................. 5

2.3 Dome information ...................................................................................... 5

2.4 Display Options .......................................................................................... 6

2.4.1 Camera Name Setup ............................................................................ 6

2.5 Control Options .......................................................................................... 6

2.5.1 Dome Addr Setup ................................................................................ 7

2.5.2 Control Option Operation .................................................................... 7

2.6 Camera Options .......................................................................................... 7

2.6.1 Zoom and Focus .................................................................................. 8

2.6.2 Camera Exposure ................................................................................ 8

2.6.3 Others ................................................................................................. 11

2.7 Function Programming .............................................................................. 11

2.7.1 Preset .................................................................................................. 11

2.7.2 Program VectorScan .......................................................................... 14

2.7.3 Pattern ............................................................................................... 15

2.7.4 Sector Setup ...................................................................................... 16

2.7.5 Mask Zone ......................................................................................... 17

2.7.6 Mask Color ........................................................................................ 18

2.7.7 Motion ............................................................................................... 18

2.8 System setup ............................................................................................. 20

2.8.1 Clear Memory ................................................................................... 20

2.8.2 Restore Def Setting ........................................................................... 20

2.8.3 Color System ..................................................................................... 20

2.8.4 Dome Reset ....................................................................................... 21

Chapter 3 Short-cut Operations and Specification of Dome Device ............... 21

Chapter 4 Trouble Shooting of Dome Device ..................................................... 24

Chapter 1 Product Overview

1.1 Performance Instructions

 Address of Dome device is from 0～255. The number (address) of dome device in

the control system is setup by the hardware (8-digit on and off switch) of dome device.

 Integrated multi-protocol and auto protocol differentiation. Note: The dome device

only auto differentiate controller of the first communication.

Operation Manual ELI-EPTZ-27DN eLineTechnology.com

 Pan 360 degree continuous scanning.

 Tilt 90 degree action plus 2 degree angle adjustment. Plus the 2 degree

adjustment, the view angle can be 90 or 92 degree.

 Pan manual operation speed can be 0.1 to 300 degree per second.

 Tilt manual operation speed can be 0.1 to 120 degree per second.

 128 preset positions.(A fixed position that aimed by the dome camera, which can

be set and revised by user arbitrarily)

 The maximum running speed when preset position is being called can reach 400

degree per second with accuracy of ±0.1 degree.

 Compatible with many kinds of Module Camera.(Sony, Hitachi, Sanyo, Yoke, CNB,

LG, Haitron, Samsung, Dahua)

 Power supply: AC 24V/3A.

 Easy installation interface.

 Pass environmental protection grade IP66 (outdoor type).

 Adopts long distance RS-485 transmission mode.

Transmission speed, i.e. Baud rate is selectable. (2400bps/4800bps/9600bps

/19200bps).

1.2 Feature Functions Instruction

 English operation menu and function display.

 Camera name, operation position and angle display. (The name of the camera

can be edited and the coordinate angle of the dome device can be displayed on the screen.)

 Operation crosshair function.(Enable this option, the target can be captured more

effectively with crosshair on the screen.)

 Three PTZ tours operation with 8 minutes record of each tour.(Can real-time

monitor and record the action of manual operation)

 Six group of programmable vector scans.(including scan speed, dwell time, preset

position and interruption between tours)

 Auto flip function with 10 degree move up.

 24 sectors of programmable sectional mask.(Can mask part of the sectors of

camera, which differs depending on different types of camera)

 8 sectors of programmable sectional display.(Can display the name and nature of

Operation Manual ELI-EPTZ-27DN eLineTechnology.com

concrete position shooting by the camera)

 Auto enter function running after self-test of the dome device and auto enter

function running when there is no transmission.(Dwell time can be set from 5 to 999 seconds)

 Freeze video picture function.(frozen picture function)

 Operation return function.(after executing operation return, the dome device will

return to the previous operation)

 Intelligent manual scan function.(execute this function in manual pan operation, you

can adjust the manual pan operation)

 Intelligent power off real time memory.(If power is cut off when a certain function is

in operation, the dome device can resume working at where the power is cut off.)

 High efficient 3-dimension scan.

 Camera zoom in speed limit function.(When it is zooming in, the speed

of the dome device will auto slow down.)

 Remote setting of dome address.

Chapter 2 Menu setting

2.1 Operation instructions

Menu operation instruction

To make a selection, move the joystick in the Up or Down direction. The on-screen arrow

points to the selected option. Using the joystick to the Left or Right position you can change the

value of your selection or enter the submenu for the selected option. Press the button CLOSE on

the keyboard controller to exit the menu or return to the previous menu(one layer up)

Number setup.

 Joystick Left or Right when programming to select preset.

 Press OPEN to confirm, open and display the number selection cursor

 Joystick Left or Right to select the number to be entered

 Press OPEN to confirm selection. The selected number is displayed on the

corresponding data bit.

 Number of respective data bits are input as above.

 Press CLOSE to exit or return to the previous menu level when programming is

done.

Operation Manual ELI-EPTZ-27DN eLineTechnology.com

2.2 Main menu

95+SHOT+ACK to enter the main menu of the dome as illustrated down.

1 LANGUAGE ENGLISH

2 DOME INFORMATION

3 DISPLAY OPTIONS

4 CONTROL OPTIONS

5 CAMERA OPTIONS

6 FUNCTION PROGRAMMING

7 SYSTEM SETUP

4. Control Options

Set the pan or tilt and camera of the dome manually or auto compatible with the entire

control system. User individualized operation setting.

5.Camera Options

Set camera function.

6. Function Programming

Program and execute PTZ and VectorScan etc.

7. SYSTEM SETUP

System setup, Including, restore default setup clear memory, color system,

dome reset.

TITLE

The title may be different with different type

of dome.

1. Language Setup

Language: English.

2. Dome Information

Joystick down to move the cursor to press

OPEN or joystick left or right to move the

joystick to enter the menu.

3. Display Options

Display dome info or function.

2.3 Dome information

Joystick down to move the cursor to press OPEN or joystick left or right to move the joystick to

enter the menu.

CAMERA : xxxx

PROTOCOL : xxxx

BAUDRATE : xxxx

DOME ID : xxx

VERSION : xxx

IRIS CLOSE TO EXIT

TITLE

The title may be different with different type

of dome.

Display camera type\ protocol\

baundrate\dome ID\ software version

Operation Manual ELI-EPTZ-27DN eLineTechnology.com

2.4 Display Options

Set the display of dome info or function.

DISPLAY OPTIONS

1 CAMERA NAME SETUP

2 COORDINATES ON

3 START_UP SCR MSG ON

4 CROSSHAIRS ON

Operation steps

[1].Joystick up/down to move the cursor to

select Display Options

[2].Joystick left/right to enter Display Option

[3].Joystick up/down to select either one of the

sub-menu

[4].Joystick left/right to select ON/OFF

2.4.1 Camera Name Setup

Set the camera name

CAMERA NAME SETUP

1 NAME ___________

2 NAME DISPLAY OFF

PLEASE ENTER:

WELCOME_________

ABCDEFGHIJKLN

OPQRSTUVWXYZ

0123456789_

IRIS OPEN WHEN DONE

IRIS CLOSE TO EXIT

1.NAME

[1].Move the joystick up/down to move the

cursor to select the Name.

[2].Move the joystick left/right or press OPEN

to enter name editing menu.

[3].Joystick left/right to select programming

position and press OPEN to confirm,

joystick left/right again to select( 0~9 or

A~Z ). Press OPEN to confirm selection.

Press CLOSE to exit or return to the

previous menu level when programming

is done.

2.5 Control Options

Set Auto Flip、Auto Focus、Auto AE, etc Move the joystick left/right or press

OPEN to enter control options

CONTROL OPTIONS

1 DOME ADDR STETUP

2 AUTO FLIP ON

3 PROPORTIONAL SPD ON

4 PAN REVERSE OFF

5 TILT REVERSE OFF

6 VECTORSCAN STILL OFF

7 AUTO FOCUS OFF

8 AUTO AE OFF

9 VECTORSCAN AF OFF

10 -2 TILT LIMIT OFF

11 SPEED LIMIT OFF

Operation Manual ELI-EPTZ-27DN eLineTechnology.com

2.5.1 Dome Addr Setup

2 DOME ID 1

DOME ADDR SETUP

1 ADDR TYPE PHYSIC

3 BROADCAST ID OFF

2.5.2 Control Option Operation

1. Joystick left/right to setup the addr type.

addr type through Physic/Logic.

2.Joystick left/right to change the dome ID(only

when addr type selects logic).

3.Joystick left/right to setup the broadcast ID

ON/OFF.

Move the cursor to select Auto Flip/Proportional Speed/Pan Reverse/ Tilt

Reverse/VectorScan Still/VectorScan AF/-2 Tilt Limit/Speed Limit.

Move the joystick left/right or press OPEN to Display on/off/PTZ/Z/OFF

 Auto Flip: If the camera lens auto rotates pan 180° then tilt 10° to auto track forward

when the lens goes down tilt 90°.

 Auto AE: If the camera is AE when the dome device changes its pan or tilt or zoom.

 VectorScan AF: If the camera AF when vector scan is running.

 Speed Limit: the moving speed of dome device matching the video ratio to lower the

speed.

2.6 Camera Options

As the dome can support many type of cameras, so the camera menu will be different with different

cameras, the following camera menu take Sony camera menu as an example.

CAMERA OPTIONS

1 ZOOM AND FOCUS

2 CAMERA EXPOSURE

3 OTHERS

Move the joystick left/right or press

OPEN to enter Camera options.
