ElfinX MC-2W User Manual
Press the button once, the siren would beep once , the alarm system is in
ARM mode. If move the motorcycle or ignit ion on, the siren will sound and the direction lights will
icons in LCD display. Press any button, the icons will be removed.. Press again the lights will
Keyb oa rd lo c k
Se nd ing sig na l
Shoc king ala rm
1
Press the button once, the siren would give 2 beeps, the lights would flash twice,
Press the button once, the direc tion li ght will flash 8 times, the siren will beep 8
Press the button twice within 3s to start the engine. Press on the
button for 3.5s, turn on the background light. After starting the engine by remote controller, the
Adjust the sensitivity on the mainframe by hand, turn clockwise to increase
sensitivity, turn anti-clockwise to decrease sensitivity. The sensi tivity has been adjusted well when
7. Anti-robbery and assistance:
When the motorcycle is robbed and driven away, the owner-
driver can stop it by pressing the button once, the siren will sound urgently and the direction
In disarm mode, put the motorcycle key in the key lock and turn it from ACC
OFF to ACC ON, 3 times in 3s, when the lights flash and the siren beeps once, press any button on
the remote controller in 10s, the direct ion lights will flash once, it means the system learn the
Fu nction Ke y
A r m:
2-Way Moto r cycle alar m system
Disa rm/ Ig initio n o ff
Arm/ Anti-ro bb ery
Sho c king al arm
Disarm:
Remote Start Engine:
Fu nction Operat i o n
Assista nt f unc tio n
Disa rm
Arm
Ba tter y
1. Arm/Mute arm:
flash, the engine will be locked at the same time. And the remote controller will beep and show
flash once, the motorcycle is in mute arm status. When the motorcycle is moved, the direction
lights will flash and engine will be locked; if turn key to ACC ON, the siren will sound, the direction
lights will flash and engine will be locked. And the remote will beep and show icons as in normal
arm mode.
2. Disarm:
the motorcycle is in the DISARM st atus.
3. Locate motorr:
times, and you can know where your motorcy cle is.
4. Remote Start Engine:
engine will be on until you stop it by remote controller. You can drive the motorc ycle without using
the key.
5. Adjust Sensitivity:
leaving factory.
lights will flash at the same time.
8. Code Learning:
2
http://www.elfinx.com MC-2W
3
Anti-theft main engine and common vehicle distribution wire
Code of the remote control ler. The other remote controller can be learnt code in the same way.
( The code has been learnt well before leaving factory, the user need not learn it again if
unnecessary.)
Remark: one mainframe could learn at most two remote controllers once.
9. Emergent disarming
: If remote controller is lost, the driver need to turn key ON/OFF 8 times
within 8s, and disable the system.
10. Keyboard lock :
Press the buttons and at the same time and hold for 3.5 s to lock
keyboard ; press these two buttons for 3.5s again to unlock the keyboard.
function contrast form
Vehi cl e Wire
12v(+)
12v(-)
Key on+ 12v
Start Wir e
Igni tion of f
(Up)
Igni tion of f
(Dowm)
Direction
Light
Direction
Light
Mainfram e
Wire Color
Red
Black
Orange
Blue
Pink
Gray
Yellow
Yellow
HONDA
Wire Color
Red
Green
Black
Yellow /Red
Black and
White(Up )
Black and
White
(Down)
Lighte Blue
Orange
SANYAN G
Wire Color
Red
Green
Black
Yellow /Red
Black and
White(Up )
Black and
White
(Down)
Light Blue
Orange
YAMAHA
Wire Color
Red Red
Black
Bro wn
Blue/W hi te
Black and
White(Up)
Black and
White
(Down)
Deep Brown
Deep Green
SUZUKI
Wire Color
Black/White
Orange
Black/White
(Remark1)
Black
Green
