RolMotion M-868 Roller Blind Drive
1 Operating and assembly instructions
Follow these instructions for safe and proper use. Observe
all assembly instructions. Incorrect assembly can lead
to serious injuries. Please keep this operating manual
for future reference to ensure that it can be accessed
throughout the entire service life of the product!
The German operating manual is the original version.
All documents in other languages are translations of the
original version.
All rights reserved in the case of patent, utility model or
design registrations.
2 General information on these instructions
The content structure is based on the life cycles of the electric
motor drive (hereinafter referred to as „the product“).
The manufacturer reserves the right to make changes
to the technical data in these operating instructions. In
some cases, this technical data may dier from those of
the respective product version; however, the functional
information will not undergo signicant changes or become
invalid. The current version of the technical specications
may be requested from the manufacturer at any time.
No claims may be asserted against the manufacturer
as a result of this provision. Deviations from textual or
visual statements may occur depending on the product's
technical development, features and accessories. Deviating
information for special versions will be provided by the
manufacturer in the sales documentation. Other information
shall remain unaected by these provisions.
138251101_EN_1219
Symbol
Signal word
Meaning
Standards and guidelines | Safety
2.1 Standards and guidelines
During construction, the fundamental health and safety
requirements were applied and provision was made for the
appropriate legislation, standards, directives and guidelines.
The safety of the product is conrmed by the declaration
of conformity (see EC Declaration of Conformity). All
information relating to safety in these operating instructions
refers to the laws and regulations that are currently valid
in Germany. All information in these operating instructions
must be complied with at all times and without limitation.
In addition to the safety notes in these operating
instructions, the regulations on accident prevention,
environmental protection and occupational health and
safety applicable at the location of use must be observed
and adhered to. The regulations and standards for safety
assessment can be found in the EC Declaration of
Conformity.
2.2 Intended use
The product is intended for use in facade constructions as a
drive for electrically powered roller shutters and blinds.
The elero calculation program is central to dening the
drive.
www.elero.com/en/downloads-service/eleroapps/drive-calculation-program-app/
Other applications must be agreed upon in advance with
the manufacturer, elero GmbH Antriebstechnik
(see „Address“).
The plant operator shall be solely responsible for any
damages arising from the improper use of this product. The
manufacturer cannot be held liable for personal or material
damages caused by misuse or procedural errors, nor by
improper operation or commissioning.
The product may only be operated by instructed and
authorised specialist personnel while observing all safety
notes.
The safe and error-free use and operational reliability of
the product are only guaranteed when it is used properly
according to the specications contained in these operating
and assembly instructions.
Only use radio receivers with equipment and units approved
by the manufacturer. The operator has no protection
whatsoever from interferences by other radio emitters
and local terminals (e.g. also from radio systems), that
are normally used on the same frequency range. Radio
systems must not be operated in areas with an increased
risk of interference (e.g. hospitals, airports). The radio
control is only permitted for devices and units with which
a functional interference in hand-held/wall transmitters or
receivers poses no danger for persons, animals or materials
or where this risk is covered by other safety appliances.
Use according to its intended purpose includes the
observation and compliance of all safety instructions
contained in these operating instructions as well as all
valid trade Accident Insurance regulations and valid laws
on environmental protection. Use according to its intended
purpose also includes the compliance with all prescribed
operating regulations in these operating and assembly
instructions.
2.3 Foreseeable misuse
Any use that deviates from the intended use as stated
by the manufacturer, elero GmbH Antriebstechnik (see
„Address“) is deemed as foreseeable misuse.
2.4 Warranty and liability
The General Terms and Conditions of the manufacturer,
elero GmbH Antriebstechnik, apply at all times (see
„Address“). The conditions of sale and delivery are included
in the sales documents and shall be presented to the plant
operator upon delivery. Any liability claims for personal or
material damages are excluded when they can be attributed
to one or more of the following causes:
• Opening the product by the customer
• Improper use of the product
• Improper installation, commissioning or operation of the
product
• Structural modications to the product without the written
consent of the manufacturer
• Operation of the product with improperly installed
connections, defective safety devices or improperly
installed safeguards
• Failure to observe the safety regulations and
information presented in these operating
instructions
• Failure to observe the specied technical data
2.5 Customer service provided by the
manufacturer
In the event of a fault, the product may only be repaired
by the manufacturer. The address for sending the
product to Customer Service can be found in the Section
„Address“. If you did not purchase the product directly
from elero, please contact the supplier of the product.
3 Safety
3.1 General safety instructions
General safety instructions for use of tubular drives can be
found in the „Safety instructions“ leaet supplied with each
drive (leaet article number 138200001). These operating
and assembly instructions contain all the safety information
that must be observed in order to avoid and prevent danger
when working with the product in the individual life cycles.
When all specied safety instructions are complied with,
safe operation of the device is guaranteed.
3.2 Layout of safety instructions
The safety instructions in this document are marked using
hazard and safety symbols and are designed according to
the SAFE principle. They contain information on the type
and source of the danger, possible consequences and on
avoiding danger.
The following table denes the representation and
description of hazard levels with possible physical damage
as used in these operating instructions.
DANGER Warns about an accident
that will occur if the
instructions are not
followed, which can
lead to fatal, irreversible
injuries or death.
2 | EN © elero GmbH
Symbol
Meaning
Safety | Product description | Assembly
Symbol Signal word Meaning
WARNING Warns about an accident
that may occur if the
instructions are not
followed, which can lead
to serious, possibly fatal,
irreversible injuries or
death.
CAUTION Warns about an accident
that can occur if the
instructions are not
followed, which can
lead to slight, reversible
injuries.
Fig. 1 Notation for personal injuries
The table below describes the pictograms used in these
operating instructions to illustrate the hazard situation in
relation with the symbol for the hazard level.
Danger caused by electrical voltage,
electric shock:
This symbol indicates dangers due to
electric current.
Fig. 2 Notation for specic danger
The table below denes the representation and description
of situations used in these operating instructions for
situations in which damage can occur to the product or
indicates important facts, conditions, tips and information.
4 Product description
The RolMotion M-868 is a radio-controlled
electromechanical tubular drive for roller blinds and
textile sun protection. During operation, it executes radial
movements.
Commissioning of the RolMotion M-868 with elero
assembly cable or radio transmitter for setting various
functions.
Blind protection with free travel (torque limiting).
Standstill detection (simple obstacle detection) of drive
shaft.
Relief function for the blind (blind protection).
Cyclical reference runs compensate for changes in the
winding behaviour of the roller blind slats.
In addition to the usual travel prole (travel prole
standard), the RolMotion M-868 drive also has a
reduced-speed travel prole (travel prole motion).
Slow travel when lowering the roller blind slats.
Slow travel with timed and light-triggered release.
4.1 Product contents
Drive with safety instructions and operating instructions and
any additional components and accessories according to
the order conrmation or delivery note.
4.2 Accessories
Connection and assembly cable, adapter sets, motor
bearing, ProLine control units, sensors, receivers.
5 Assembly
Symbol Signal word Meaning
ATTENTION This symbol warns
against possible damage
to property or equipment.
IMPORTANT This symbol indicates
important facts and states
as well as referring to
further information in
these operating and
assembly instructions.
It also refers to certain
additional instructions,
which provide additional
information or help you
to carry out a procedure
more simply.
Symbol indicating
successful grounding
with protection class I
( Protective conductor
system)
Fig. 3 Notation for damage to property and additional
information
The following example illustrates the basic structure of a
safety note:
SIGNAL WORD
Type and source of danger
Explanation of type and source of danger
►Measures to avoid the danger
© elero GmbH EN | 3
WARNING
Important safety instructions
Observe all assembly instructions. Incorrect assembly can
lead to serious injuries.
►Commissioning of the RolMotion M-868 with elero
assembly cable for setting various functions.
►Before installation, all cables and components that are
not required and all facilities that are not needed for
operation with a power drive are to be disabled.
►The required components are: drive, connection
and assembly cable, motor bearing, adapter sets, if
necessary rigid shaft connectors, sensors, control
devices, receivers.
►If components are not delivered with the drive, these can
be identied via our catalogue „Drives and control units
for intelligent building technology“ in the relevant valid
version. Further details can be found on our website
under „Contact - dealer search“ and „Contact - contact
persons for specialist companies“.
►The rated torque and rated operating time must be
suitable for the properties of the driven part (the blind).
►The coupling of the drive with the powered part is
described in the section „Mechanical fastening“.
CAUTION
Risk of injuries due to hot surfaces.
The drive will heat up during operation, the drive casing
can become hot. Skin burns are possible.
►Wear personal protection equipment (protective gloves).
Triggered by a possible material fault, knocks or impact
injuries may arise due to a gear fracture, burring fracture or
a coupling defect.
Assembly | Mechanical fastening | Electrical connection
►Suitable materials have been used for the engineering
design and random sample testing by means of a double
load test has been performed in accordance with DIN EN
60335-2-97.
Risk of injury due to knocks or impact triggered by motor
bearings that are incorrectly mounted or engaged. Hazard
due to insufficient stability or steadiness and accumulated
energy (gravity).
►Selection of motor bearing by torque specications.
►The drive must be protected with all the enclosed safety
devices.
►Check for correct engagement on motor bearing and the
correct screw tightening torques.
WARNING
Risk of injury due to electric current.
Risk of electric shock.
►Always have electrical work carried out by an authorised
electrician.
Risk of injury due to electric current.
Possible danger due to parts that are faulty becoming
energised.
►Electrical connection is described in the operating and
assembly instructions, including cable routing.
CAUTION
Risk of injury due to malfunctions as a result of incorrect
assembly.
Drive is overwound and may destroy parts of the
application.
►For safe operation, the end positions must be set/taught
in.
►Manufacturer training is available for specialist
companies.
NOTICE
Power failures, breaking of machine parts and other
malfunctions.
►For safe operation, assembly must be correct and the
end position adjustments will have to be carried out upon
commissioning.
Damage to RolMotion M-868 due to ingress of moisture
►On devices with protection class IP 44, the ends of all
cables or plugs will need to be protected from ingress
of moisture. This measure needs to be implemented
immediately after removing the RolMotion M-868 from the
original packaging.
►The drive must be installed in such a way that it cannot
get wet.
Important
In its delivery condition (factory setting), the RolMotion
M-868 will be in commissioning mode.
►The end positions will need to be set (see
section 5.6).
Optimal use of the radio signal.
►Extend the antenna as far as possible. If reception is
poor, adjust the antenna.
►Do not kink, shorten or extend the antenna.
►Do not position the two radio drives closer than the
minimum distance of 15 cm.
5.1 Mechanical fastening
Important preliminary consideration:
The working area around the installed drive is usually
very small. For this reason, obtain an overview of how the
electrical connection has been implemented prior to the
mechanical installation (see section 5.2) and make the
necessary changes beforehand.
NOTICE
Crushing or tension will damage the electrical cables.
►Install all electrical cabling so that it is not subject to any
crushing or tensile load
►Observe the bending radii of cables (at minimum 50 mm).
►Route connecting cables in a downward loop to prevent
water running into the drive.
Damage to the drive due to the effect of impact forces.
►Slide the drive into the shaft. Never knock the drive in or
use force!
►Take care not to drop the drive!
Damage or destruction to the drive by drilling.
►Never drill the drive!
Important
Only fasten the RolMotion M-868 to the designated
fastening elements.
Fixed installed control devices need to be attached so they
are visible.
• The blind must be attached to the winding shaft.
• The prole tube must have sucient clearance from the
motor tube.
• Make sure there is sucient axial play (1 - 2 mm)
Installationinproletubes
ⒶPush drive with relevant adapter and
crown into the prole tube.
Install the motor cable so it is
protected to prevent damage from
the driven part.
ⒷSecure the counterpart support to
prevent axial movement, e.g. screw
or rivet on the idler.
Secure the drive axially in the
support!
ⒸAttachtheblindtotheshaft.
Only operate the drive horizontally, as intended, with the
connection cable leading out from the side and out of the
blind winding area.
5.2 Electrical connection
WARNING
Faulty electrical connections constitute a fatal hazard.
Risk of electric shock.
►Prior to initial commissioning, check the PE wire is
correctly connected.
NOTICE
Damage to the RolMotion M-868 due to incorrect electrical
connection.
►Prior to initial commissioning, check the PE wire is
correctly connected.
A
B
C
4 | EN © elero GmbH
HOHUR
HOHUR
HOHUR
HOHUR
Assembly | Electrical connection | relief function
Ingress of moisture will damage or even destroy the
RolMotion M-868.
►For devices with protection class IP 44, the customer-
side connection of the cable ends or plugs (cable feedthrough) can also be implemented according to protection
class IP 44.
Damage or destruction of the RolMotion M-868 for variants
with 230 V ~ due to incorrect activation.
►Switches with an OFF presetting (dead-man's switches)
for drives are to be attached within visible range of the
RolMotion M-868 but away from spontaneously moving
parts and at a height of more than 1.5 m.
Connect only in de-energised state. To do this, switch
the drive cable so it is de-energised.
1Press locking mechanism on the motor cable plug
towards the cable using a suitable screwdriver.
2Pull out the plug.
3Insert the motor cable plug until the lock engages.
Removing and inserting the motor cable plug
Delivery condition
Removing plug Inserting plug
→
3
1
2
Fig. 4 Removing and inserting the motor cable plug
5.3 Connection example for RolMotion M-868
230 V / 50 Hz
→
→
Important
The drive is in commissioning mode when delivered.
►The end positions must be adjusted using the elero
assembly cable (see Fig. 6) or an elero wall or hand-held
transmitter (see Fig. 7).
►The assembly cable may only be connected to
commission the drive and for adjustment operations
5.4.1 Connection for assembly cable
%OXHQHXWUDOFRQGXFWRU
%ODFN
%URZQ
*UHHQ\HOORZ
Fig. 6 Connection for assembly cable
►Switch on mains.
►You can now set the end positions with the elero
assembly cable.
5.4.2 Radio connection (transmitter operation)
%OXHQHXWUDOFRQGXFWRU
%ODFN
%URZQ
*UHHQ\HOORZ
Fig. 7 Radio connection (transmitter operation)
3
2
1
Fig. 5 Connection diagram RolMotion M-868
230 V / 50 Hz and cable assignment when using
Hirschmann plug connection STAS-3 (with jumper)
Important
The motor controls in the up or down travel directions must
be locked against each other.
A switching time of at least 0.5 seconds must be observed.
5.4 Commissioning
►Connect cable wires „UP“ and „DOWN/CLOSE“ together
to phase L (outer conductor).
►Switch on mains. The drive buzzes and travels upwards
and downwards for a short time.
The drive is in radio mode.
Teaching or deleting the transmitter, xing or deleting the
blind positions: see instructions for the corresponding handheld transmitter.
5.4.3 Operation in non-radio mode
Important
If the drive is to be operated in non-radio mode, follow the
instructions for the RolMotion M (article no. 138251001).
5.5 Setting the end positions
Important
To use travel profiles, the upper and lower end positions
must first be set. First program the upper end position,
then the lower end position.
As long as the direction of travel does not have the
correct logical assignment, the upper end position actually
corresponds to the lower end position.
The end positions are set alternatively
• using the elero assembly cable (correct connection
according to Chapter 5.5.1) or
• using a programmed transmitter. (To
program a transmitter, see Chapter 5.7.)
© elero GmbH EN | 5
Variant A:
Variant B: Fixed upper limit stop, lower
Relief function | End position adjustment
5.5.1 Changing/deleting the end positions
It is not possible to change or delete individual end
positions. This is always done in pairs (upper and lower end
position simultaneously).
Before you can change or delete the end positions, the
power supply must rst be interrupted.
After a brief disconnection from the power supply, the end
positions can be deleted within 5 minutes.
Changing/deleting the end positions
Restore the power supply after the mains have been
1
switched o.
Starting from a central blind position, use the assem-
2
bly cable or a programmed transmitter to simultaneously press both direction buttons [UP ▲]+[DOWN/
CLOSE ▼], and hold them down until the drive briey
moves up and down.
The end position settings have been deleted.
The end positions may be readjusted.
5.5.2 Four variants of end position settings
Four dierent end position settings are possible. These can
be clearly selected according to the technical requirements
of the blind.
End position settings (4
possible with
variants)
Upper and lower end
A
position freely adjustable
Fixed upper limit stop,
B
lower end position freely
adjustable
Fixed upper and lower limit
C
stop
Upper end position freely
D
adjustable, xed lower limit
stop
Suspension spring,
tapes, belt
T-straps, tapes, belt,
limit plugs, angle
bracket
Anti push-up device,
rigid shaft connectors,
limit plugs, angle
bracket
Anti push-up device,
tapes, rigid shaft
connectors
Important
When programming an end position to the limit stop, the
relief function for the blind is activated automatically.
The blind always remains resting on the limit stop in an
unstrained position.
If the blind is programmed with a xed limit stop, reference
runs are performed. Initially upon the rst travel run, then
cyclically later. During reference runs, the blind moves to
the limit stop and then relieves itself of any strain.
The blind protection system is only adapted to the blind
after a complete, uninterrupted upwards and downwards
travel.
5.5.3 Variant A:
Upper and lower end position
freely adjustable
Upper and lower end position freely adjustable
Starting from a central blind position, press the
①
[UP ▲] button with the assembly cable or a
programmed transmitter until the blind reaches the
desired upper end position.
The drive begins to travel, briey stops and travels
further (for as long as the [UP ▲] button remains
pressed).
You can make corrections using the [UP ▲] and
[DOWN/CLOSE ▼] buttons.
Press the [DOWN/CLOSE ▼] button until the drive
②
stops automatically.
The upper end position has been set.
Press the [DOWN/CLOSE ▼] button again until the
③
blind has reached the desired end position.
The drive begins to travel, briey stops and travels
further (for as long as the [DOWN/CLOSE ▼]
button remains pressed).
You can make corrections using the [UP ▲]
and [DOWN/CLOSE ▼] buttons.
Press the [UP ▲] button until the drive stops
④
automatically.
By default, the lower end position has been set.
Non-standard setting for placement of the blind slats
at the lower end position: See chapter 5.6.
Adjustment of the variant A end position is complete.
5.5.4 Variant B: Fixed upper limit stop, lower end
position freely adjustable
end position freely adjustable
Starting from a central blind position, press the
①
[UP ▲] button with the assembly cable or a
programmed transmitter until the blind has reached
the upper end position (travels to the upper limit
stop).
The drive begins to travel, briey stops and travels
further (for as long as the [UP▲] button remains
pressed).
The drive switches o automatically when the upper
limit stop is reached.
Press the [DOWN/CLOSE ▼] button until the drive
②
stops automatically.
The upper end position has been set.
Press the [DOWN/CLOSE ▼] button again until the
③
blind has reached the desired lower end position.
The drive begins to travel, briey stops and travels
further (for as long as the button remains pressed).
You can make corrections using the [UP ▲]
and [DOWN/CLOSE ▼] buttons.
Press the [UP ▲] button until the drive stops
④
automatically.
By default, the lower end position has been set.
Non-standard setting for placement of the blind slats
at the lower end position: See chapter 5.6.
Adjustment of the variant B end position is complete.
6 | EN © elero GmbH
Variant C: Fixed upper and lower limit stop
Variant D: Upper end position freely adjustable,
End position settings
5.5.5 Variant C: Fixed upper and lower limit stop
Starting from a central blind position, press the
①
[UP ▲] button with the assembly cable or a
programmed transmitter until the blind has reached the
upper end position (travels to the upper limit stop).
The drive begins to travel, briey stops and travels
further (for as long as the [UP ▲] button remains
pressed).
The drive switches o automatically when the upper
limit stop is reached.
Press the [DOWN/CLOSE ▼] button until the drive
②
stops automatically.
The upper end position has been set.
Press the [DOWN/CLOSE ▼] button again until the
③
blind has reached the desired end position (travels
to the lower limit stop).
The drive begins to travel, briey stops and travels
further (for as long as the [DOWN/CLOSE ▼] button
remains pressed).
The drive switches o automatically when the lower
limit stop is reached.
Press the [UP ▲] button until the drive stops
④
automatically.
By default, the lower end position has been set.
Non-standard setting for placement of the blind slats
at the lower end position: See chapter 5.6.
Adjustment of the variant C end position is complete.
5.5.6 Variant D: Upper end position freely
adjustable,xedlowerlimitstop
xed lower limit stop
Starting from a central blind position, press the [UP
①
▲] button with the assembly cable or a programmed
transmitter until the blind reaches the desired upper
end position.
The drive begins to travel, briey stops and travels
further (for as long as the button remains pressed).
You can make corrections using the [UP ▲] and
[DOWN/CLOSE ▼] buttons.
Press the [DOWN/CLOSE ▼] button until the drive
②
stops automatically.
The upper end position has been set.
Press the [DOWN/CLOSE ▼] button again until the
③
blind has reached the desired end position (travels
to the lower limit stop).
The drive begins to travel, briey stops and travels
further (for as long as the [DOWN/CLOSE ▼] button
remains pressed).
The drive switches o automatically when the lower
limit stop is reached.
Press the [UP ▲] button until the drive stops auto-
④
matically.
By default, the lower end position has been set.
Non-standard setting for placement of the blind slats
at the lower end position: See chapter 5.6.
Adjustment of the variant D end position is complete.
5.6 Placement of the roller blind slats
For slow lowering of the roller shutter bars, a standard
travel path is set after setting the end positions.
It is possible to change this position when the end positions
have been programmed:
• After the blind starts to rise from the lower end position,
hold down the [UP▲] button until the drive starts to move
further up after approx. 2 seconds. As soon as the lowest
blind slat is raised from the lower limit stop, release the
[UP▲] button. This is now the position from which slow
downward travel commences.
5.7 Program the transmitter
Important
Precondition: The drive must be in radio operation mode.
►If the end positions have not been programmed, remove
the blind from the winding shaft.
5.7.1 Programmingthersttransmitter
Programming the (rst) transmitter
Operating procedure Result
Switch the power o and
1
on again
Press the programming
2
button P on the transmitter
to be programmed for
approximately 1 second.
Immediately (maximum
3
1 second) after the start of
upward travel, press the
[UP ▲] button.
Immediately (maximum
4
1 second) after the start of
downward travel, press the
[DOWN/CLOSE ▼] button.
The (rst) transmitter is now programmed.
5.7.2 Programming additional transmitters
Up to 16 transmitters can be programmed.
Programming additional transmitters
Operating procedure Result
On an already programmed
1
transmitter, hold down
the buttons [UP ▲] +
[DOWN/CLOSE ▼] + [P]
(programming button)
simultaneously for
approximately 3 seconds.
(alternative to the previous
line)
Switch the power o and
on again
On the (additional)
2
transmitter to be
programmed, press the
programming button [P].
The drive is in
learning mode for
approximately
5 minutes.
The status display
lights up. The drive is
now in learning mode
(up/down travel) for
approximately
2 minutes.
The status display
lights briey. The blind
stops briey, starts
moving again and then
moves downwards.
The status display
lights briey. The drive
will stop.
The status display
lights up.
The drive is in
learning mode for
approximately
5 minutes.
The drive is in
learning mode for
approximately
5 minutes.
The status display
lights briey. The drive
is in learning mode
(up/down travel) for
approximately
2 minutes.
© elero GmbH EN | 7
Default mode
Whisper mode
Transmitterprogramming|Travelproles
Programming additional transmitters
6 Travelproles
Operating procedure Result
On the (additional)
3
transmitter to be programmed, press the [UP ▲]
button immediately (within
1 second) after the blind
starts moving upwards.
On the (additional)
4
transmitter to be programmed, press the [DOWN/
CLOSE ▼] button
immediately (within 1
second) after the blind
starts moving downwards.
The additional transmitter is programmed.
Stop bidirectional wireless mode:
Hold down the [STOP■] button for at least 6 seconds until
the status display lights up (depends on transmitter).
5.8 Deleting the radio connection between
ransmitters and receivers
Refer to the respective instructions for the transmitter.
5.9 Programming or deleting further blind
positions
• Intermediate position: Blind at any position between
upper and lower end position.
Dening the
interim position
in the receiver
Prerequisite: The blind
is in the upper end
position.
1. Press the [DOWN/
CLOSE ▼] button
until the desired
intermediate position
is reached.
2. Additionally press the
[STOP ■] button.
The blind will stop.
The status LED lights
up briey.
The intermediate
position is now stored.
• Ventilation position:
Ventilation gaps for application of the roller blinds open
Dening the
ventilation
position in the
receiver
Prerequisite: The blind
is in the lower end
position.
1. Press the [UP ▲]
button until the
ventilation gaps
open.
2. Then press the
[STOP ■] button.
The blind will stop.
The position of the
ventilation is now
saved.
Approach to the intermediate position and the ventilation
position takes place in the whisper mode travel prole
(see Chapter 6).
8 | EN © elero GmbH
The status display
lights briey. The blind
stops briey, starts
moving again and then
moves downwards.
The status display
lights briey. The drive
will stop.
Approaching
the intermediate
position
Prerequisite: The
intermediate position is
dened.
• Double click the
[DOWN/CLOSE ▼]
button twice (in quick
succession): Blind
moves to the saved
intermediate position.
If no intermediate
position has been
dened, the blind moves
to the lower end position.
If an intermediate
position is to be
controlled for several
receivers simultaneously,
the receivers must be
programmed on one
channel (single channel).
Approaching
the ventilation
position
Prerequisite: Position
of the ventilation is
dened.
• Double click on the
[UP ▲] button: The
blind travels upwards
to the saved position.
If no ventilation position
is dened, the blind
moves to the upper
end position.
Deleting the
intermediate
position
• Hold down
the buttons
[DOWN/
CLOSE ▼]+
[STOP ■]
simultaneously
for
approximately
3 seconds.
The intermediate
position is now
deleted. The status
LED lights up briey.
Deleting the
ventilation
position
• Press the [UP
▲]+[STOP ■] buttons
simultaneously for
approximately 3
seconds.
The position of the
ventilation is now
deleted.
The RolMotion M-868 drive has the two travel proles
default mode and whisper mode.
Travels at high speed
except before the end
positions. The roller blind
Travel the full path at a
reduced speed
slats are lowered slowly.
Activation in down direction
of travel:
• Briey press the [DOWN/
CLOSE ▼] button:
Travel to lower end
position.
When placing the blind
slats onto the end
position, the speed is
reduced.
Activation in down direction
of travel:
• Press the [DOWN/
CLOSE ▼] button for
about 3 seconds: Travel
at reduced speed to
lower end position.
• Double click the [DOWN/
CLOSE ▼] button: The
blind travels to the saved
intermediate position
(if this is not dened,
travel to the lower end
position).
Activation in up direction of
travel:
• Briey press the [UP ▲]
button: Travel to upper
end position.
Activation in up direction of
travel:
• Press the [UP ▲] button
for approx. 3 seconds:
Travel at reduced speed
to the upper end position
• Double click the [UP ▲]
button: The blind travels
to the saved ventilation
position (if this is not
dened, travel to the
upper end position).
Switching to travel prole
whisper mode:
• Press the travel button
for approx. 3 seconds
in the same direction as
the current direction of
Switching to travel prole
default mode:
• Press the travel button
briey in the same
direction as the current
direction of travel.
travel.
The drive responds to
the timer functions of
programmed controllers
(TempoTel 2, AstroTec,
MultiTec Touch, Centero
Home).
The drive responds
to commands from
programmed sensors:
• Sun sensor: Travel to
intermediate position or
lower end position.
The travel prole whisper mode is not available during the
„Setting the end positions“ operation.
7 Troubleshooting
Problem / Error Possible cause Remedial
• Drive stops
during travel
• End positions
are not set
• Drive is in
setting mode
action
• Setting end
positions: First
program the
upper end
position, then
the lower end
position.
Troubleshooting | Disassembly and disposal
Problem / Error Possible cause Remedial
action
• Drive stops
after short time
• Drive moves
in the opposite
direction
without a
new travel
command and
stops after a
short travel
• Drive runs only
in one direction
• Drive does not
react
• Drive does
not accept
programmed
end positions
• Drive moves
opposite
transmitter
commands
Fig. 8 Troubleshooting the RolMotion M-868
• End position
programmed
• Blind dicult to
move
• Obstacle in the
travel area
• Drive
overloaded /
under dimensioned
• Faulty connection
• No power
supply
• Temperature
limiter has
triggered
• Random travel
• Travel to end
position or limit
stop too short
• Down direction
was tought in
rst
• Set second
end position
• Check the
smooth running of the
blind
• Removing
obstacle
• Check drive
size, install
more powerful
drive
• Check
connection
• Check mains
voltage
• Allow drive to
cool down
• Delete end
positions, reprogram end
positions
• Drive must
move, stop
briey and
continue its
travel (as long
as a button
is pressed
on the elero
assembly
cable or on a
programmed
transmitter).
• Delete
endlimits and
re-programme
(see chapter
5.5)
8 Servicing
The RolMotion M-868 is maintenance-free.
9 Service/manufacturer's address
If malfunctions occur or the device is damaged despite
correct handling, contact your contractor.
elero GmbH
Drive technology
Maybachstr. 30
73278 Schlierbach,
Germany
Deutschland / Germany
Please visit our website if you require a contact partner
outside Germany.
Tel: +49 7021 9539-0
Fax: +49 7021 9539-212
info@elero.de
www.elero.com
10 Repairs
Please contact your specialist if you have any questions.
Please always provide the following information:
• Item number and designation on the type plate
• Type of fault
• Accompanying conditions
• Your own theories regarding the cause of the problem
11 Disassembly and disposal
After unpacking, dispose of the packaging in accordance
with the valid regulations.
Dispose of the product in accordance with the relevant
regulations when you no longer need it. Disposal is partially
subject to applicable legal regulations. Bring the product to
be disposed of to authorised collection points only.
Environmental information
No superuous packaging materials have been used.
The packaging can be easily separated into three material
types: cardboard (box), polystyrene (padding) and
polyethylene (bag, protective foam).
The device is made of materials that can be reused if
dismantled by a specialist company. Please note the local
regulations on disposal of packaging materials and old
appliances.
On disassembly, additional dangers must be reckoned with,
which do not occur during operation.
Before disassembling the drive, the system is to be
mechanically secured. The drive must not be forcibly
disconnected from the system.
WARNING
Risk of injury due to electric current.
Risk of electric shock.
►Separate power supply cables physically and discharge
any energy accumulators still charged. After switching o
the device, wait at least 5 minutes so that the motor can
cool down and the voltage can be discharged from the
capacitors.
►During disassembly work above head height, use
suitable, inspected and structurally stable climbing aids.
►Work on the electrics may only be performed by
personnel described in the section „Safety notes on
electrical installation“.
Removal for scrap
The international, national and regional laws and
regulations prevailing at the time of scrapping the product
must be observed.
Ensure that materials and components are recycled,
dismantled and separated properly in addition to observing
the environmental and health hazards relating to recycling
and disposal.
CAUTION
Environmental damage in case of incorrect disposal
►Electrical scrap and electronic components must be
handled as special waste and may only be disposed of by
approved specialist companies.
►Groups of materials such as various types of plastics and
metals must be separated before recycling/disposal.
Disposal of electrical and electronic components
The disposal and recycling of electrical and electronic
components must be carried out in accordance with the
relevant laws and national regulations.
© elero GmbH EN | 9
Declaration of conformity | Technical data and dimensions
12 Comments on EU Declaration of
Conformity
elero GmbH hereby declares that the RolMotion M-868
tubular drive is in compliance with all applicable regulations
of Machinery Directive 2006/42/EC and the Directive
2014/53/EU. The full text of the EU Declaration of
Conformity is available at the following Internet address:
www.elero.com/en/downloads-service/
13 Technical data and dimensions
The technical data specied is subject to tolerance factors
(according to applicable standards) and refer to an ambient
temperature of 20 °C.
13.1 RolMotion M-868
Size / Type M6-868 M10-868 M20-868 M25-868
Rated torque [Nm]
Rated speed default mode [1/min]
Rated speed whisper mode [1/min]
Rated voltage [V]
Rated frequency [Hz]
Noiseless soft brake
Rated current [A]
Rated power consumption [W]
Shaft diameter [mm]
Degree of protection (IP-Code)
Limit switch range (revolutions)
Operating time (min. S2)
Radio frequency [MHz] (band)
Transmission power [mW] | [dBm]
Length C [mm]
Length D [mm]
Length E [mm]
(elero, round head, star head)
Weight [kg]
Ambient operating temperature [°C]
Protection class I
Conformity ,
Plug-in connecting cable [m]
Article no. (elero,
RH round head,
SH star head)
6 10 20 25
14 14 14 14
5 5 5 5
1 ~ 230 1 ~ 230 1 ~ 230 1 ~ 230
50 50 50 50
■ ■ ■ -
0.4 0.5
92 115
50 50 50 50
44 44 44 44
70 70 40 tbd
10 10 4 tbd
868 868 868 868
≤ 500 | ≤ 10 ≤ 500 | ≤ 10 ≤ 500 | ≤ 10 ≤ 500 | ≤ 10
466 466 526 516
449 449 509 499
14 | 12 | 19 14 | 12 | 19 14 | 12 | 19 14 | 12 | 19
1.7 1.7 2.1 2.3
-20 ... 60 -20 ... 60 -20 ... 60 -20 ... 60
■ ■ ■ ■
-, ■ -, ■ ■, ■ ■, ■
2,0 2,0 2,0 2,0
443020001
483020001
493020001
442220001
482220001
492220001
442320001
482320001
492320001
442420001
482420001
492420001
10 | DE © elero GmbH
33
D
C
E
55
45
O
33
D
C
E
55
C
D
E
E
45
O
55
C
D
33
33
45
O
45
O
29
O
49,5
33
E
Baugröße Typ
55
C
D
E
E
45
O
55
C
D
33
33
C
D
33
E
O
45
O
45
O
C
D
33
45
O
O
57,5
E
29
O
49,5
O
49,5
Technical data and dimensions
C
D
45
O
E
C
D
45
O
E
C
33
33
55
49,5
O
D
45
O
E
33
57,5
O
© elero GmbH EN | 11
elero GmbH
Drive technology
Maybachstr. 30
73278 Schlierbach, Germany
info@elero.de
www.elero.com
We reserve the right to make technical changes
Loading...
