ELEPHAS RD606 Instruction Manual
INSTRUCTION
MANUAL
Mini DLP Projector
●Projector Overview
1
2
6
1
7 8
1. Power on / o button
2. Ventilation slots
3. Focus ring
4. Projector lens
3
4
5. Ventilation slots
6. Charge LED (charge blue, full o)
7. Ventilation slots
8. Stand hole (1/4inch)
5
1
32 4 5 6 7
1. Speaker
2. IR Remote control receiver
3. AUX cord jack (Earphone jack)
4. HDMI port
5. USB port
6. Master Switch
7. Micro USB Charging port
Warning tips:
It’s strictly prohibited to block the air intake window.
This may cause over heating and damage the projector.
2
2
●Specifications
Optical Parameters:
Display chip:
Lens:
Brightness uniformity:
NTSC:
Resolution:
3D display:
Physical Parameters:
Projection size:
Throw ratio:
Oset:
Keystone:
Focus mode:
Power adapter:
Power:
Speaker:
Size:
N.W.:
Accessories:
Make sure your projector box includes all of these parts:
1 Projector
2 Remote control (batteries are not included)
3 Projector bag
4 Power cord
5 Bracket
6 Manual
0.2" DMD RGB-LED
High light transmittance coating glasses
98%
≥120%
Max support 1080p
Yes
20-100 inch
1.2:1
100%
Electronical adjusting±40°
manual focus
DC5V/3A
15W
4Ω/3W
100×108×40mm
280g
3
●Remote Control
1. Power
2. Menu
3. Arrow keys
4. Mute
5. Volume Down
6. Aspect Ratio
7. 3D conversion
8. Enter
9. Volume Up
10. Exit
11. Homepage
4
