Element FLX-3702, FLX-2602, FLX-3202 User Manual

FCC

Federal Communications

Commission Statement

This equipment has been tested and found to comply with the limits of a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1. Reorient/Relocate the receiving antenna.

2. Increase the separation between the equipment and receiver.

3. Connect the equipment into an outlet on a circuit which is different from what the receiver is connected to.

4. Consult the dealer or an experienced radio/TV technician for help.

Changes or modi cations not expressly approved by the manufacturer responsible for compliance could void the user authority to operate the equipment.

ENGLISHENGLISH

1

Warnings and Precautions

To prevent any injuries, the following safety precautions should be observed in the installation, use, servicing and maintenance of this equipment. Before operating this equipment, please read this manual completely, and keep it nearby for future reference.

This symbol is intended to alert the user to avoid the risk of electric shock.

WARNING

CAUTION

This equipment must not be disassembled by anyone except qualiﬁ ed service personnel.

This symbol is intended to alert the user to the presence of important operating and maintenance instructions in the literature accompanying the appliance.

To reduce the risk of ﬁ re or electric shock, do not expose this equipment to rain or moisture.

▪ TO REDUCE THE RISK OF ELECTRIC SHOCK, ▪ DO NOT REMOVE COVER (OR BACK). ▪ NO USER-SERVICEABLE PARTS INSIDE. ▪ REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Use of controls, adjustments or performance of procedures other than those speciﬁ ed herein may result in hazardous radiation exposure.

Important Safety Instructions

This symbol indicates caution points.

This symbol indicates actions that should not be done.

This symbol indicates actions that must be performed.

▪ Do not place the equipment on any uneven or unstable carts, stands, tables, shelves etc.

The equipment may fall, causing serious injury to children or adults and serious damage to the equipment itself.

▪ Use only a cart or stand recommended by the manufacturer. This equipment and

recommended cart or stand should be handled with care. Quick stops, excessive force, and uneven surfaces may cause the equipment and cart/stand to overturn.

▪ Do not disable the 3-wire grounding type plug. The grounding pin on the 3-prong plug is an

important feature. Removing the grounding pin will increase the risk of damaging the equipment.

▪ If you can not ﬁ t the plug into the electrical outlet, contact an electrician to install a grounding

outlet.

▪ Always operate this equipment from the type of power source indicated on the rear of the

serial/model plate.

▪ Never overload wall outlets and extensions.

2

Warnings and Precautions

▪ Use and handle the power cord with care. Do not place any heavy objects on the AC

power cord.

▪ Do not pull the AC power cord. Do not handle the AC power cord with a wet hand.

▪ Do not touch the power cord and antenna cable during lightning. ▪ Remove the plug from the wall outlet, if the equipment will not be used for a long period

of time.

▪ Do not place, use or handle this equipment near water.

▪ Never expose the equipment to liquid, rain, or moisture.

Seek for service if any of the above is spilled into the equipment.

▪ Do not expose the equipment to extreme temperature or to direct sunlight, as the

equipment may heat up and suffer damage.

▪ Do not install the equipment near any heat sources such as radiators, heat registers,

stoves, or any other apparatus that might produce heat.

▪ Do not attempt to service the equipment yourself.

▪ Opening and removing the covers may expose you to dangerous voltage or other

hazards and may void your warranty. Refer service to qualiﬁ ed personnel.

▪ Do not place or drop any other objects on top.

▪ Do not insert anything into the ventilation holes of your equipment.

Inserting any metal or ﬂ ammable objects may result to ﬁ re or electric shock.

▪ Protect the power cord from being walked on or pinchrd particularly at plugs ,convenience

receptacles, and the point where they exit from the apparatus.

▪ Do not place the equipment on uneven or unstable carts, stands, tables, shelves etc. The

equipment may fall, causing serious injury to children or adults and serious damage to the equipment itself.

Always place the equipment on the ﬂ oor or on a surface that is sturdy, level, stable and

strong enough to support the weight of the equipment.

▪ Do not block any ventilating openings. Leave an open space around the equipment. Never place the equipment : on a bed, sofa, rug, or any other similar surfaces; too close to drapes/curtains/walls, in a

bookcase, built-in cabinet, or any other similar places that may cause poor ventilation.

▪ Unplug this apparatus during lightning storms or when unused for long periods of time.

▪ Refer all servicing to qualified service personnel. Servicing is required when the

apparatus has been admaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

▪ Always remove the power cord from the outlet before cleaning the equipment.

▪ Never use liquid or aerosol cleaners on the equipment.

Clean only with a soft dry cloth.

ENGLISHENGLISH

▪ Only use attachments/accessories specified by the manufacturer.

3

Warnings and Precautions

Outdoor Antenna Safety Instructions

If an outdoor antenna is connected, follow the precautions below:

▪ An outdoor antenna should not be located in any area where it could come in contact with

overhead power lines, or any other electric light or power circuits.

▪ When installing an outdoor antenna system, extreme caution should be taken to prevent

contact with power lines. Direct contact with power lines may be fatal and should be avoided at all costs.

Section 810 of National Electrical Code (NEC) provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

Antenna lead-in wire

Ground clamps

Electric service equipment

EXAMPLE OF OUTDOOR ANTENNA GROUNDING

Ground clamps

Power service grounding (NEC Art250 part H)

NEC : National Electrical code

4

Antenna discharge unit (NEC section 810-20)

Grounding conductors (NEC section 810-20)

TABLE OF CONTENTS

Federal Communications Commission Statement .......................... 1

Warnings and Precautions

Important Safety Instructions ....................................................................................... 2

Antenna Safety Instructions ......................................................................................... 4

Chapter 1 Introducing the LCD TV

Key Features ............................................................................................................... 6

Package Contents ....................................................................................................... 7

Setting Your LCD TV .................................................................................................... 8

Your LCD TV .............................................................................................................. 10

Your Remote Control ................................................................................................. 12

Chapter 2 Installing the LCD TV

Connecting a TV Cable or an Antenna ...................................................................... 14

Connecting a VCR ..................................................................................................... 18

Connecting a Video Camera or Play Station ............................................................. 19

Connecting a DVD Player .......................................................................................... 20

Connecting a Digital TV Cable Box or Digital Satellite Receiver ............................... 22

Connecting an AV Equipment with HDMI Connector ................................................. 23

Connecting an AV Equipment with DVI Connector .................................................... 24

Connecting a PC........................................................................................................ 25

Connecting an Audio Receiver or a Dolby Digital 5.1 Sound System........................ 26

ENGLISHENGLISH

Chapter 3 USING THE FEATURES

Using Picture-In-Picture .............................................................................................................................27

Wide Screen Viewing ...................................................................................................................................29

Operating the Menu ..................................................................................................................................... 30

Setting up the HDTV Function ................................................................................................................32

Customizing the VIDEO Settings ...........................................................................................................35

Customizing the AUDIO Settings ...........................................................................................................36

Customizing the SETUP Settings .........................................................................................................37

Using the V-CHIP Settings ........................................................................................................................39

Using the Parental Settings ...................................................................................................................... 41

Customizing the TV Settings ...................................................................................................................42

Speciﬁ cations ........................................................................................................ 43

Chapter 4 Programming your Remote Control

Introduction............................................................................................................... A

Programming a Device ............................................................................................. A

Troubleshooting ...................................................................................................... B

Manufacturer’s Codes ..............................................................................................C

5

Chapter 1 Introducing the LCD TV

Key Features

Various Audio/Video terminals for external equipment connection

▪ 2 set of composite A/V input terminals ▪ 1 set of S-VIDEO terminals ▪ 2 set of component Video input terminals ▪ 1 VGA/ Audio input terminal ▪ 1 HDMI/Auido input terminal ▪ 1 sets of Audio(L/R) output terminals ▪ 2 SPDIF output terminal (Optical x 1 /Coaxial x 1) ▪ 1 Headphone terminal

The built-in TV tuner to receive HD ATSC

▪ This function allows the reception of HD broadcasting without the addition of a set top

box.

High De nition Multimedia Interface (HDMI)

▪ High Deﬁ nition Multimedia Interface (HDMI) is a small, user-friendly interconnect that

can carry up to 5 Gbps of combined video and audio in a single cable. This system eliminates the cost, complexity and confusion of multiple cables used to connect current A/V systems.

HDTV Component Video Inputs

▪ Offers the best video quality for DVD(480p) and digital set-top-box (HD1080i, 720p)

connections.

3D Digital Noise Reduction

▪ This function can digitally reduce image noise to provide better picture quality.

Film-Mode Detection (3:2 Reverse Pull Down)

▪ This function can automatically detect content derived from ﬁ lm and adjust the

interlacer’s frame matching to provide a more natural-looking, clearer image of the moving picture.

PIP Function

▪ Provides viewing of two programs simultaneously, in either picture-in-picture mode or

picture-on-picture (side by side) mode.

6

Package Contents

Chapter 1 Introducing the LCD TV

Make sure all of the following contents are included.

 LCD TV

AA Batteries x 2

 Power Cord

 VIDEO Cable Remote Control/

 AUDIO Cable  Warranty Card

ENGLISH

 Bottom Stand / Screw Driver and 6 Screws

 Component Cable

 Quick Start Guide

 User’s Manual

These items are all you need to set up and operate the LCD TV in its basic conﬁ guration.

Make sure all of the above contents are included in the package. If you are missing any items, please contact the Polaroid customer service department.

7

Chapter 1 Introducing the LCD TV

Setting Up Your LCD TV

Attach the Stand

If you prefer to mount your new Polaroid TV on a wall instead of attaching it to the stand, please reference the instructions included in the wall mounting kit (not included).

IMPORTANT : Attach the Stand to the TV with the bottom foam packaging material still attached.

Read all instructions before continuing with the stand installation.

a) Lift foam packaging material from the top of the TV out of the box. b) Lift TV out of box, with the bottom foam packaging material still attached, and place onto a stable furface.

c) Remove the protective bag from the LCD unit, but DO NOT remove the bottom foam packaging material. d) Locate the place on the back of the TV to attach the stand. Secure the stand to the LCD with all six screws.

8

Chapter 1 Introducing the LCD TV

 Use a supplied antenna cable to connect the VHF/UHF signal to the LCD TV’s ANT. terminal

(refer to page17).

 Connect the AC power cord at the back of the TV and connect the power cord to wall outlet.

 Insert the 2 batteries supplied in remote control.

Step1 Slide the back cover up to open the

battery compartment of the remote control.

Step2 Insert two AA size batteries.

Make sure to match the (+) and ( - ) ends of the batteries with the (+) and ( - ) ends indicated in the battery compartment.

Slide the cover back into place.

ENGLISH

Do not use caustic cleaners (porcelain, stainless steel, toilet, or oven cleaner etc.) on the remote, as it may su er damage.

 Connect other an external A/V device (refer to page14-26).

9

Chapter 1 Introducing the LCD TV

Your LCD TV

Front/Right Side View and Controls

LED

The LED light indicates when the LCD TV is activated.

IR

Infrared Receiver

▲▼

VOLUME

Adjusts the volume up and down. Selects the main-menu item and change values for items when in the OSD mode.

CHANNEL▲▼

Scans up and down through channels. Selects sub-menu item when in the OSD mode.

MENU

Press once to display the OSD (on screen display), press again to turn the OSD off.

INPUT

Chooses from different input signal sources.

Turns the LCD TV on and into standby mode.

10

VIDEO

L

AUDIO

R

VIDEO1 IN

Connects to the composite Video and Audio output jacks on external video equipment.

EARPHONE

Connects to the external headhone for private listening.

Rear View and Jacks

VIDEO2 IN

Connects to the composite VIDEO and AUDIO(L/R) output jacks on external video equipment.

Chapter 1 Introducing the LCD TV

HDMI IN

Connects the all digital AV equipment with HDMI connector.HDMI supports enhanced, high-deﬁ nition video and two-channel digital audio. The AUDIO(L/R) of HDMI IN is for DVI connection.

S-VIDEO IN

Connects to the S-VIDEO and AUDIO(L/R) output jacks on external video equipment.

VGA IN

Connects the PC, or other AV equipment with VGA and AUDIO(L/R) output jacks.

ENGLISH

HDMI IN

AUD IO

LR

VIDEO AUD IO

VIDEO2 IN

YPbPr1 IN/YPbPr2 IN

Connects to the DVD player, Digital Set-Top-Box, or other AV equipment with component(YPbPr) video and audio output jacks.

AUDIO OUT-STEREO

Connects to the AUDIO(L/R) input jacks on AV equipment.

VGA IN

AUD IO

LR LR

LR

S-VIDEO AUD IO

S-VIDEO IN

AUDIO OUT-DIGITAL-OPTICAL/COAXIAL

Connects to the OPTICAL AUDIO jack on the digital/standard 5.1 audio system.

VHF/UHF IN-TV-CABLE

Connects RF input from VHF/UHF antenna or cable.

YPbPr1 IN

Y Pb Pr AUD IO

LR

YPbPr2 IN

VHF/UHF IN-HDTV-AIR

Connects RF input from VHF/UHF antenna or cable to receive high/standard deﬁ nition television.

AC IN

Connects to the AC power cord.

11

STEREO

AUD IO OUT

L

R

DIGITAL

OPTICAL

COAXIAL

TV

CABLE

VHF/UHF IN

HDTV

AIR

Chapter 1 Introducing the LCD TV

Your Remote Control

This package includes a Polaroid remote that enables control of up to four devices. To select a device, simply select one of the following device mode controls: TV, CBL/SAT, DVD/VCR, or AUDIO.

Turns the LCD TV on and off.

1

2

3

5

1

4

SET Remote control universal code setup.For

2

TV Controls this LCD TV.

3

more information on setting up your remote control, please see the “Programming Your Remote Control” section.

6

7

8

9

10

DVD Controls DVD player or Video player.

2

4

CBL Controls Cable Converter or Satellite

Receiver.

AUX Controls Audio Ampliﬁ er

2

5

0-9/ENTER Pressing a number selects a channel.

2

6

INPUT Pressing INPUT to display a source list,

▪ In HDTV mode, use with 0-9 and

LAST Returns to previously selected channel.

2

7

CH+- Change channel up and down.

2

8

Following selection, pressing ENTER activates the channel, or channel activates automatically in 3 seconds.

use ▲▼buttons to select the video equipment connected to the video inputs of your LCD TV: TV/HDTV/VIDEO1/ VIDEO2/VIDEO3/VIDEO4/VIDEO5/ VIDEO6/COMPUTER.

ENTER buttons to select a digital channels.

VOL+- Increases and decreases volume.

2

9

10

MUTE Pressing once mutes audio. Pressing

12

again restores audio.

Chapter 2 Installing the LCD TV

11

MENU Displays the OSD menu on the screen.

INFO Pressing once displays a variety of

12

13

▲▼►◄,

information such as the current channel and the input source.

OK Cycles through OSD options and selects

individual menu items. OK conﬁ rms option settings.

ENGLISH

OK In HDTV mode, pressing OK to display a

digital channel list.

14

GUIDE In HDTV mode, pressing GUIDE

15

11

14

17

18

12

13

15

16

19

20

EXIT Exits the OSD menu.

16

  ►  Other device function keys

   

17

SLEEP Cycles through the LCD TV sleep time:

18

CAPTION Cycles through the Closed Caption:

ASPECT Cycles through Wide mode settings:

19

20

PIP Turns PIP/POP on and off.

displays the Program Guide on the screen.

OFF/30/60/90/120 mins.

OFF/CC1/CC2/CC3/CC4/TT1/TT2/TT3/ TT4.

NORMAL/FULL/WIDE/ZOOM.

E ective range: The remote can control the LCD TV from up to 5m away, if pointed directly at the receiver.

13

Chapter 2 Installing the LCD TV

Refer to the owner’s manual of any external equipment to be connected. When connecting any external equipment, do not connect any AC power cords to wall outlets until all other connections are completed.

Connecting a TV Cable or an Antenna

Antenna Connection

The antenna requirements for good color TV reception are more important than those for a black & white TV reception. For this reason, a good quality outdoor antenna is strongly recommended. The following is a brief explanation of the type of connection that is provided with the various antenna systems.

■ A 75-ohm system is generally a round cable (not included) with F-

type connector that can easily be attached to a terminal without tools.

F-type connector

75-ohm coaxial cable (round)

■ A 300- ohm system is a  at t win-lead cable (not included) that can

be attached to a 75-ohm terminal through a 300 -75-ohm adapter (not included).

300-ohm twin-lead cable ( at)

14

Chapter 2 Installing the LCD TV

Use one of the following two diagrams when connecting an outdoor antenna. A: Shows how to use a VHF/UHF combination outdoor antenna. B: Shows how to use a separate VHF and/or UHF outdoor antenna.

A. Combination VHF/UHF antenna

VHF/UHF Antenna

300-ohm twinlead cable

300/75-ohm adapter (not included)

B. Separate VHF and/or UHF antennas

75-ohm coaxial cable

VHF/UHF Antenna

ENGLISH

15

Combiner (not included)

IN

OUT

300-ohm twinlead cable

75-ohm coaxial cable

300-ohm twinlead cable

UHF Antenna

VHF Antenna

Chapter 2 Installing the LCD TV

Cable TV (CATV) Connection

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the National Electrical Code (NEC) that provides guidelines for proper grounding and, in particular, speciﬁ es that the cable ground shall be connected to the grounding system of the building accurately, or as close to the point of cable entry as possible. Use of this TV for other than private viewing of programs broadcasted on UHF, VHF or transmitted by cable companies for the use of the general public may require authorization from the broadcast/cable company, and/ or program owner.

■ A 75-ohm coaxial cable connector is built into the set for easy hookup. When connecting the 75-ohm coaxial cable to the set, connect the 75-

ohm cable into the ANT. terminal.

■ Some cable TV companies o er premium pay channels. Since the

signals of these premium pay channels are scrambled, a cable TV converter/descrambler is generally provided to the subscriber by the cable TV company.

This converter/descrambler is necessary for normal viewing of scrambled channels. (Set your TV to channel 3 or 4, typically one of these channels is used. If this is unknown, consult your cable TV company.) For more speciﬁ c instructions on installing cable TV, consult your cable TV company. One possible method of connecting the coverter/descrambler provided by your cable TV company is shown in the diagram below.

RF switch (not included)

2 set signal splitter (not included)

Cable TV Line

OUT

A

IN

B

Cable TV converter/ descrambler

VHF/UHF IN

(not included)

■ The RF switch (not included) is required to provide two inputs (A and B). Setting

the RF switch to position A allows viewing of all unscrambled channels by using the TV channel keys.

■ Setting the RF switch to position B allows viewing of all scrambled channels via the converter/descrambler by using the converter channel keys.

16

Chapter 2 Installing the LCD TV

 METHOD A:

Use a supplied antenna cable to connect the NTSC signal to the LCD TV’s TV CABLE

terminal.

TV

HDTV

CABLE

AIR

VHF/UHF IN

B

ENGLISH

METHOD B:

A

Use a supplied antenna cable to connect the ATSC signal to the LCD TV’s

HDTV AIR terminal.

 Connect the AC power cord at the back of the TV and connect the power cord to wall

outlet.

TV

HDTV

CABLE

AIR

VHF/UHF IN

This TV is equipped with a safety fuse. In the event of an electrical storm or power outage the

safety fuse is designed to protect your TV. If your TV has no power, check the fuse by prying the cover off, following the illustration below. If the fuse is blown, visit your local hardware store and ask for a 4A 250V - 5x20mm Time Lag Fuse (Slow Blow) to replace the fuse.

Firm Plastic Prying Tool D

(Using a metal tool may cause shock)

4A 250V

Back of TV

5x20mm

Fuse

 Press the button on the remote to turn on the LCD TV.

Always disconnect the LCD TV from the main voltage when the LCD TV will not be used for a long period of time. The POWER button on the front panel is only used for switching the LCD TV into standby, it does not disconnect the device from the main voltage. To completely disconnect the main voltage, please remove the power plug from the socket.

Input

 Press the Input button on the remote to

display the Input List. Use the ▲► buttons to select TV( METHOD A), or HDTV (METHOD B), and press the OK button.

TV(CABLE/AIR) 

HDTV (CABLE/AIR)

VIDEO1 (SIDE)

VIDEO2 (REAR)

VIDEO3 (S-VIDEO)

VIDEO4 (YPbPr1)

VIDEO5 (YPbPr2)

VIDEO6 (HDMI)

COMPUTER (VGA)

17

Chapter 2 Installing the LCD TV

Connecting a VCR

Rear of TV

HDMI IN

AUD IO

LR

VIDEO AUD IO

VIDEO2 IN

VGA IN

AUD IO

LR LR

LR

S-VIDEO AUD IO

S-VIDEO IN

AV Cable

YPbPr1 IN

Y Pb Pr AUD IO

YPbPr2 IN

AUDIO Cable

S-VIDEO Cable

LR

STEREO

AUD IO OUT

L

R

DIGITAL

OPTICAL

COAXIAL

TV

CABLE

VHF/UHF IN

HDTV

AIR

A B

 METHOD A:

Use a composite cable to connect the VCR’s composite video/audio jacks to the LCD TV’s

VIDEO2 IN jacks.

METHOD B: Use an audio cable to connect the VCR’s audio output jacks to the LCD TV’s audio

inputs. Use a S-Video cable to connect the VCR’s s-video output jack to the LCD TV’s S-VIDEO IN input jack.

 Connect all AC power sources, before turning on the power switch of the LCD TV or

other connected equipment.

 Press the button on the remote to turn on the LCD TV.  To watch a videotape, press the Input button on the remote to select

VIDEO2( METHOD A), or VIDEO3 (METHOD B).

18

Connecting a Video Camera or Play Station

Chapter 2 Installing the LCD TV

Rear of TV

Right Side

VIDEO

L

AUDIO

R

VIDEO1 IN

or

HDMI IN

AUD IO

LR

VIDEO AUD IO

VIDEO2 IN

VGA IN

AUD IO

LR LR

LR

S-VIDEO AUD IO

S-VIDEO IN

YPbPr1 IN

Y Pb Pr AUD IO

YPbPr2 IN

AUDIO Cable

S-VIDEO Cable

AV Cable

LR

STEREO

AUD IO OUT

L

R

DIGITAL

OPTICAL

COAXIAL

B

TV

CABLE

VHF/UHF IN

PLAYSTATION

A

 METHOD A:

Use a composite cable to connect the video camera’s or play station’s composite video/

audio jacks to the LCD TV’s VIDEO2 IN jacks or VIDEO1 IN jacks.

METHOD B: Use an audio cable to connect the video camera’s or play station’s audio output jacks to

the LCD TV’s audio inputs. Use a S-Video cable to connect the video camera’s or play station’s s-video output jack to the LCD TV’s S-VIDEO IN input jack.

ENGLISH

HDTV

AIR

 Connect all AC power sources, before turning on the power switch of the LCD TV or

other connected equipment.

 Press the button on the remote to turn on the LCD TV.  To watch a video vis camera or play station, press the Input button on the remote to

select VIDEO2/VIDEO1( METHOD A), or VIDEO3 (METHOD B).

Not all cameras have the ability to connect to a TV. Please check your video camera user guide for compatibility.

19

Chapter 2 Installing the LCD TV

Connecting a DVD Player

Rear of TV

HDMI IN

AUD IO

LR

VIDEO AUD IO

VIDEO2 IN

VGA IN

AUD IO

LR LR

LR

S-VIDEO AUD IO

S-VIDEO IN

YPbPr1 IN

Y Pb Pr AUD IO

YPbPr2 IN

AUDIO Cable

S-VIDEO Cable

AV Cable

A

STEREO

LR

or

PrPb

COMPONENT/AUDIO Cable

B

DVD PLAY ER

AUD IO OUT

L

R

DIGITAL

OPTICAL

COAXIAL

C

CABLE

TV

VHF/UHF IN

HDTV

AIR

PrPb

 METHOD A:

Use a composite cable to connect the DVD player’s composite video/audio jacks to the LCD

TV’s VIDEO2 IN jacks.

METHOD B: Use an audio cable to connect the DVD player’s audio output jacks to the LCD TV’s

audio inputs. Use a S-Video cable to connect the DVD player’s s-video output jack to the LCD TV’s S-VIDEO IN input jack.

METHOD C: Use a component cable to connect the DVD player’s component output jacks to the LCD TV’s

YPbPr1 IN or YPbPr2 IN input jacks.

Use an audio cable to connect the DVD player ’s component audio jacks to the LCD TV’s

audio input jacks.

The component video jacks on your DVD player are sometimes labeled YPbPr, or YCbCr. For an explanation of component video, see your DVD player’s user guide.

20

Chapter 2 Installing the LCD TV

 Connect all AC power sources, before turning on the power switch of the LCD TV or

other connected equipment.

 Press the button on the remote to turn on the LCD TV.  To watch a DVD, press the Input button on the remote to select

VIDEO2( METHOD A), or VIDEO3 ( METHOD B), or VIDEO4/VIDEO5 (METHOD C).

For best picture quality, if your equipment has component video output, use a component cable instead of a composite video or S-video cable.

ENGLISH

21

Chapter 2 Installing the LCD TV

Connecting a Digital TV Cable Box or Digital Satellite Receiver

Rear of TV

HDMI IN

AUD IO

LR

VIDEO AUD IO

VIDEO2 IN

VGA IN

AUD IO

LR LR

LR

S-VIDEO AUD IO

S-VIDEO IN

YPbPr1 IN

Y Pb Pr AUD IO

YPbPr2 IN

COMPONENT/AUDIO Cable

PrPb

LR

PrPb

AUD IO OUT

DIGITAL

STEREO

OPTICAL

L

COAXIAL

R

CABLE

TV

VHF/UHF IN

HDTV

AIR

or

 Use a component cable to connect the satellite receiver’s/TV Cable Box’s component

(YPbPr1) output jacks to the LCD TV’s component input jacks.

Use an audio cable to connect the satellite receiver’s/TV Cable Box’s component audio

jacks to the LCD TV’s audio input jacks.

 Connect all AC power sources, before turning on the power switch of the LCD TV or

other connected equipment.

 Press the button on the remote to turn on the LCD TV.

 To watch programs via satellite receiver or TV Cable Box, press the Input button on the

remote to select VIDEO4/VIDEO5.

22

Connecting an AV Equipment with HDMI Connector

Chapter 2 Installing the LCD TV

HDMI IN

AUD IO

LR

VIDEO AUD IO

VIDEO2 IN

Rear of TV

VGA IN

AUD IO

LR LR

LR

S-VIDEO AUD IO

S-VIDEO IN

HDMI Cable

Y Pb Pr AUD IO

YPbPr1 IN

YPbPr2 IN

LR

AUD IO OUT

STEREO

L

R

AV EQUIPMENT

DIGITAL

OPTICAL

COAXIAL

TV

CABLE

VHF/UHF IN

ENGLISH

HDTV

AIR

 Use a HDMI cable to connect the AV equipment’s HDMI output jack to the LCD TV’s HDMI IN

jacks.

 Connect all AC power sources, before turning on the power switch of the LCD TV or

other connected equipment.

 Press the button on the remote to turn on the LCD TV.  Press the Input button on the remote to select VIDEO6.

The HDMI connector provides both video and audio signals, it’s not necessary to connect the audio cable.

23

Chapter 2 Installing the LCD TV

Connecting an AV Equipment with DVI Connector

Rear of TV

HDMI IN

AUD IO

LR

VIDEO AUD IO

VIDEO2 IN

HDMI-to-DVI Cable

VGA IN

AUD IO

LR LR

LR

S-VIDEO AUD IO

S-VIDEO IN

YPbPr1 IN

Y Pb Pr AUD IO

YPbPr2 IN

AUDIO Cable

LR

STEREO

AUD IO OUT

L

R

DIGITAL

OPTICAL

COAXIAL

AV EQUIPMENT

TV

CABLE

VHF/UHF IN

AUD IO

LR

DVI IN

HDTV

AIR

 Use a HDMI-to-DVI cable to connect the AV equipment’s DVI output jack to the LCD TV’s

HDMI IN jacks.

Use an audio cable to connect the AV equipment’s audio output jacks to LCD TV’s HDMI AUDIO jacks.

 Connect all AC power sources, before turning on the power switch of the LCD TV or

other connected equipment.

 Press the button on the remote to turn on the LCD TV.  Press the Input button on the remote to select VIDEO6.

If the LCD TV is connected to AV equipment’s DVI connector, you will need an HDMI-to-DVI cable or an HDMI adapter(not suplied).

24

Connecting a PC

Chapter 3 Using the LCD TV

HDMI IN

AUD IO

LR

VIDEO AUD IO

VIDEO2 IN

Rear of TV

VGA IN

AUD IO

LR LR

LR

S-VIDEO AUD IO

S-VIDEO IN

VGA Cable

YPbPr1 IN

Y Pb Pr AUD IO

YPbPr2 IN

AUDIO Cable

LR

STEREO

AUD IO OUT

L

R

DIGITAL

OPTICAL

COAXIAL

PC

TV

CABLE

VHF/UHF IN

ENGLISH

HDTV

AIR

 Use a D-SUB cable to connect the PC’s D-SUB output jack to the LCD TV’s VGA input

jack. Use an audio cable to connect the PC’s audio output jacks to LCD TV’s.

 Connect all AC power sources, before turning on the power switch of the LCD TV or

other connected equipment.

 Press the button on the remote to turn on the LCD TV.  Press the Input button on the remote to select COMPUTER.

25

p

Chapter 3 Using the LCD TV

Connecting an Audio Receiver or a Dolby Digital 5.1 Sound System

For better sound quality, you may want to play the LCD TV audio through your stereo system.

HDMI IN

AUD IO

LR

VIDEO AUD IO

VIDEO2 IN

VGA IN

AUD IO

LR LR

LR

S-VIDEO AUD IO

S-VIDEO IN

Audio Receiver

YPbPr1 IN

Y Pb Pr AUD IO

YPbPr2 IN

AUDIO Cable

LR

STEREO

AUD IO OUT

L

R

DIGITAL

OPTICAL

COAXIAL

Audio Am

 Connecting to Audio Receiver:

Use an audio cable to connect the audio receiver’s audio LINE IN jacks to LCD TV’s AUDIO OUT jacks.

 Connecting to Digital 5.1 Sound System:

METHOD A:

Use an optical cable to connect the audio ampliﬁ er’s OPTICAL IN jacks to LCD TV’s OPTICAL OUT jacks.

AB

TV

CABLE

VHF/UHF IN

lifier

HDTV

AIR

METHOD B:

Use a coaxial cable to connect the audio ampliﬁ er’s COAXIAL IN jacks to LCD TV’s COAXIAL OUT jacks.

Note: Above mentioned function is only available under HDTV (cable/air) mode.

 Connect all AC power sources, before turning on the power switch of the LCD TV or

other connected equipment.

 Press the button on the remote to turn on the LCD TV.

26

Chapter 3 Using the LCD TV

Chapter 3 USING THE FEATURES

Using Picture-In-Picture

The PIP/POP feature allows simultaneous viewing of video from two sources (TV, VCR, DVD etc). Only one source’s audio is played at a time; the user may select which source’s audio is heard.

NOTE: Picture-in-Picture/Picture-on-Picture do not work when both picture sources are coming from component input (YPbPr).

 Press the PIP button once to enter picture in picture mode.

Main

Sub

ENGLISH

▪ Press ◄ ► to toggle the audio source between the main window and

▪ Press the OK button to change the position of the second window.

the sub window.

1

MAINSUB

2

3

5

▪ Press ◄ ► to activate either the main or sub window, then press the Input

▪ Press ▲▼ to change input source and press the OK button.

button to display the Input List:

Sub

TV(CABLE/AIR)

VIDEO1 (SIDE)

VIDEO2 (REAR) 

VIDEO3 (S-VIDEO)

VIDEO4 (YPbPr1)

VIDEO5 (YPbPr2)

COMPUTER (VGA)

4

27

Chapter 3 Using the LCD TV

 Press the PIP button again to view images side by side.

SubMain

▪ Press ◄ ► to toggle the audio source between the main window and the sub window.

▪ Press the OK button to swap the pictures between the main and sub windows.

▪ Press ◄ ► to activate either the main or sub window, then press the Input button to

display the Input List:

Sub

TV(CABLE/AIR)

VIDEO1 (SIDE)

VIDEO2 (REAR) 

VIDEO3 (S-VIDEO)

VIDEO4 (YPbPr1)

VIDEO5 (YPbPr2)

COMPUTER (VGA)

Press ▲▼ to change input source and press the OK button. NOTE: PIP does not function when VIDEO4 (YPbPr1) and VIDEO5 (YPbPr2) inputs are selected

together.

 Press the PIP button again to exit.

28

Wide Screen Viewing

Chapter 3 Using the LCD TV

Wide Screen function allows viewing of 4:3/16:9 images in wide screen mode, cycling through the following wide screen settings. Press the ASPECT button repeatedly to select the screen format you want.

 NORMAL

Displays at 4:3 aspect ratio.

 FULL

Stretches the image vertically and

horizontally to keeps the image size consistent in the center of the screen and stretches the sides

 WIDE

Stretches the image vertically and

horizontally to ﬁ ll the screen at 1:1.85 aspect ratio.

ENGLISH

 ZOOM

Stretches the image vertically and

horizontally to ﬁ ll the screen at 1:2.35 aspect ratio.

29

Chapter 3 Using the LCD TV

Operating the Menu

 Press the button to turn the LCD TV on.  Press the MENU button on the remote control,the on-screen menu will appear on the

screen. Use the ◄► buttons to select your main menu option.

VIDEO MENU:

Allows you to make adjustments to your picture settings.

▪ If the signal source is VGA, the VIDEO MENU

appears as:

▪ If the signal source is TV/HDTV/VIDOE/SVIDEO/

YPbPr/HDMI, the VIDEO MENU appears as:

Picture Mode Vivid

Contrast 75

Brightness 65

Auto Setting

Phase 20

Manual Clock 128

Display Adjustment

Color Temperature Nature

Video Select Exit

AUDIO MENU:

Allows you to customize the audio options and effects.

▪ If the signal source is VIDOE/SVIDEO/YPbPr/

HDMI/VGA, the AUDIO MENU appears as:

Bass 50

Treble 50

Balance 0

Sound E ec t O

Audio Select Exit

▪ If the signal source is HDTV, the AUDIO MENU appears as:

Bass 50

Treble 50

Balance 0

Sound E ec t O

Picture Mode Vivid

Contrast 75

Brightness 55

Saturation 62

Hue +22

Sharpness 4

Color Temperature Nature

Video Select Exit

▪ If the signal source is TV, the AUDIO MENU

appears as:

Bass 50

Treble 50

Balance 0

Sound E ec t O

MTS System Stereo

Audio Select Exit

30

Chapter 3 Using the LCD TV

SETUP MENU:

Allows you to set up a variety of features: Language, Closed Caption, factory reset, V-Chip, Parental Control sleep timer.

Language English

Timer 15

Closed Caption o

V-Chip

Parental

Default

Setup Select Exit

TV MENU:

Allows you to edit and label channels.

Searching

Tuner Mode Cable-STD

Channel Skip On

Channel Name

TV Select Exit

ENGLISH

HDTV MENU:

Allows you to set up the HDTV program function.

Audio Language ◄ English ►

Time Zone Eastern Time

SPDIF Type PCM

Auto Scan Scan

Manual Scan Press<Enter>

Channel Skip Press<Enter>

Channel Block Press<Enter>

Caption Press<Enter>

HDTV Select Exit

 Use the ▲▼ buttons to select an option of the sub-menu, and press the OK button. While in

adjustment mode, and use the ◄► buttons to change the value of the item.

 Press the MENU button to exit the menu.

31

Chapter 3 Using the LCD TV

Setting up the HDTV Function

Automatically scans and stores all the TV channels

 With the LCD TV connected to a television programming source, press the TV button

on the remote control.

 Press the MENU button on the remote control to display the Main menu, and use

the ◄► buttons to select the HDTV.

Audio Language ◄ English ►

Time Zone Eastern Time

SPDIF Type PCM

Auto Scan Scan

Manual Scan Press<Enter>

Channel Skip Press<Enter>

Channel Block Press<Enter>

Caption Press<Enter>

HDTV Select Exit

 Press the ▼ button to select Auto Scan, and press the OK button. The Auto Scan

automatically creates a list of receivable channels. Press the MENU button at any time to interrupt the memorization process.(the list cannot be created if interrupted)

Status: Scanning..

Channels Found: 2

HDTV Cancel

 Press the OK button to display the received channel list, then press ▲▼the buttons to

select a channel. Or, use the ▪ (Input button) with 0-9 buttons to select digital channel( for

example 9.1)

Channel List

9-1 KQED-HD

9-2 KOED-SD

The digital main channel might include many subchannels (for example 9-1, 9-2..) that are showing program at the same time.

32

 The HDTV menu includes the following options:

Chapter 3 Using the LCD TV

Audio Language Allows to select the audio language:

English/Spanish/French.

Time Zone Allows selection of regional TV systems of USA: Eastern Time/Indiana/

Central time/Mountain Time/Arizona/Paciﬁ c Time/Alaska/Hawaii

SPDIF Type Allows to selection of the digital sound format: PCM/OFF/Dolby Digital

Auto Scan Automatically sets up channel list on TV for all receivable channels.

Manual Scan Allows to set up TV channel manually.

Channel Skip Allows addition/removal of digital channels.

Channel Block Allows to block digital channels. Use the Channel Block function, must enter a four-digit password. The

factory password is 0000.

Caption Allows to set closed caption:

Analog Closed Caption ◄ OFF ►

Digital Closed Caption OFF

Caption Style

ENGLISH

▪ Analog Closed Caption:

HDTV Select Back

Allows to set basic analog closed caption options:OFF/CC1/CC2/CC3/CC4 ▪ Digital Closed Caption: Allows to set digital closed caption options:Service1/Service2/Service3/ Service4/Service5/Service6/OFF ▪ Caption Style: Allows to customize the settings for digital closed caption option:

Caption Style ◄ Custom ►

Font Size Large

Font Color White

Font Opacity Solid

Background Color Black

Background Opacity Solid

Window Color Black

Window Opacity Translucent

HDTV Select Back

33

Chapter 3 Using the LCD TV

Using the Program Guide

The Program Guide feature brings all sorts of information provided by the cable TV company to your screen, such as program title, program duration, time remaining, rating information, closed caption, availability, etc.

 With the LCD TV connected to a television programming source, press the TV button on the

remote control.

 Press the GUIDE button on the remote control, the Program Guide will appear on the

screen:

9-1 ◄ 9-2 KQED-SD ► 9-1

Today 5:00 PM Calfornia’s Gold CC Today 5:30 PM Antiques Roadshow Today 6:00 PM The NewHour with Jim Lehrer CC Today 7:30 PM Zoboomafoo CC Today 7:30 PM Arthur Today 11:00 PM Antiques Roadshow CC

5:00 PM - 5:30 PM Mon, 29 Apr Not Rated Clubs: Dongwa doesn’t communicate with his parents. Eplisode: Explorer’s club/Time for everything

9 - 2 KOED-SD

Monday 29 April 2005 2:36:26 PM

 Press the ▲▼ button to select the program from a list, the Program Guide provides

introduction about the current program being shown on each channel.

Monday 29 April 2005 2:36:26 PM

9-1 ◄ 9-2 KQED-SD ► 9-1

Today 5:00 PM Calfornia’s Gold CC

Today 5:30 PM Antiques Roadshow Today 6:00 PM The NewHour with Jim Lehrer CC Today 7:30 PM Zoboomafoo CC Today 7:30 PM Arthur Today 11:00 PM Antiques Roadshow CC

5:00 PM - 5:30 PM Mon, 29 Apr Not Rated Clubs: Dongwa doesn’t communicate with his parents. Eplisode: Explorer’s club/Time for everything

9 - 2 KOED-SD

 Press the GUIDE button again on the remote control to exit the Program Guide

34

Customizing the VIDEO Settings

Chapter 3 Using the LCD TV

 Press the button to turn the LCD TV on.  Press the MENU button on the remote control to display the Main menu, and use the

◄► buttons to select the VIDEO.

 Use the ▲▼buttons to highlight an individual VIDEO option, use the ◄► buttons to

change the setting, and press the MENU to exit the menu

Picture Mode Vivid

Contrast 75

Brightness 55

Saturation 62

Hue +22

Sharpness 4

Color Temperature Nature

Video Select Exit

 The VIDEO menu includes the following options:

Picture Mode Cycles among display types: Vivid/Hi-Bright/Cinema/Sport/User

Contrast Controls the difference between the brightest and darkest regions of the

Brightness Controls the overall brightness of the picture.

Saturation Controls the color intensity.

picture.

ENGLISH

Hue Controls the difference between the green and red regions of the

Sharpness Increase this setting to see crisp edges in the picture; decrease it for

Color temperature Adjusts color components independently to achieve a warm or cool

▪ Warm: Increases red tint ▪ Nature: Increases natural tint ▪ Cool: Increases blue tint ▪ User: Allows the user to adjust red, green and blue color component levels independently.

picture.

soft edges.

effect: Cool/Middle/Warm/User

35

Chapter 3 Using the LCD TV

Customizing the AUDIO Settings

 Press the button to turn the LCD TV on.  Press the MENU button on the remote control to display the Main menu, and use the

◄► buttons to select the AUDIO.

 Use the ▲▼buttons to highlight an individual AUDIO option, use the ◄► buttons to

change the setting, and press the MENU to exit the menu

Bass 50

Treble 50

Balance 0

Sound E ec t O

MTS System Stereo

Video Select Exit

 The AUDIO menu includes the following options:

Bass Controls the relative intensity of lower-pitched sounds.

Treble Controls the relative intensity of higher pitched sounds.

Balance Adjusts the relative volume of the speakers in a multiple speaker

Sound E ect Allows selection of an audio-enhancement technique from among the

MTS System Allows you to listen to high-ﬁ delity stereo sound while watching TV. ▪ Stereo: Use separate audio tracks for left and right speakers, if available. ▪ SAP: You can enjoy a second audio program from the speakers while

▪ Mono: Allows mono output (useful when stereo is noisy or inconsistent).

system.

following options: Surround/Live/Dance/Techno/Classic/Soft/Rock/POP/ Off.

watching a scene in the original program.

36

Customizing the SETUP Settings

Chapter 3 Using the LCD TV

 Press the button to turn the LCD TV on.  Press the MENU button on the remote control to display the Main menu, and use the

◄► buttons to select the SETUP.

 Use the ▲▼buttons to highlight an individual SETUP option, use the ◄► buttons to

change the setting, and press the MENU to exit the menu.

Language English

Timer 15

Closed Caption o

V-Chip

Parental

Default

Video Select Exit

 The SETUP menu includes the following options:

Language Selects to display all on-screen menus in your language of choice:

Timer Allows to set up clock and to program the TV to turn on and off and tune

English/Trandition Chinese/Simpliﬁ ed Chinese/French/Spanish.

to a speciﬁ c channel.

ENGLISH

▪ Time: Selects to set the current time by hour, minute, second. ▪ Start Time: Selects to set the time that you want the TV to turn on. ▪ Stop Time: Selects to set the time that you want the TV to turn off. ▪ Channel: Selects to set the speciﬁ c channel that you want the TV to tune. ▪ Activate: Selects to turn on/off/once the timer. ▪ Con rm: Selects to conﬁ rm.

37

Chapter 3 Using the LCD TV

Closed Caption Allows to select from 4 closed caption modes: ▪ CC1 /CC2 /CC3 /CC4: Display a printed version of the dialog and sound effects of the

▪ T1/T2: Display station information presented using either half or the whole

▪ T3/T4: Extended Data Services. For example: Network name, program

NOTE: For better viewing CC in text mode will have a black box behind the text.

V-Chip Allows to setup the TV and MPAA Rating Lock options(refer to “Using the

Parental Allows to setup the Parental Lock options.

Default Restores factory settings.

program being viewed.

screen.

name, program length, etc.

V-CHIP Setting”).

38

Using the V-CHIP Settings

Chapter 3 Using the LCD TV

The US has 2 rating system for viewing content: Movie blocking(MPAA) and TV Blocking. The TV Blocking conjuncts with the V-CHIP to help parents block inappropriate programs from their children. The Movie blocking(MPAA) is used for original movies rated by the Motion Picture Association of America(MPAA) as broadcasted on cable TV and not edited for television. The V-CHIP can also be set to block MPAA-rated movies.

 Use the ▼ button to select the V-Chip, and press the OK to display the V-Chip menu.

Block MPAA Rating

Block TV Rating

Block MPAA Unrated No

Block TV None Rating No

 Use the V-CHIP function, must enter a four-digit password. The factory preset password is

0000. This password must be used ﬁ rst before setting your own personal password. It is

recommended that you keep your personal password in a safe place and away from

children. In the event you loose your personal password the master password is 8202.

The master password overrides all passwords. The master password can’t be changed

and should be kept in a safe place away from children.

Inout Your Password Please

* * * *

OK Cancel

ENGLISH

 The MPAA includes the following options:

RATING DESCRIPTION

G General Audiences. Movie is appropriate for all ages.

PG Parental Guidance Suggested. May contain material not suited for younger

PG-13 Contains content that may not be appropriate for viewers under the age of 13.

R Restricted. Contains adult content, no one under 17 admitted without parent.

NC-17 No one 17 and under admitted.

X No one 17 and under admitted.

Use the ▲▼ buttons to select the rating you want and press the OK button repeatedly to select

BLOCK() or UNBLOCK().

viewers

39

Chapter 3 Using the LCD TV

 The TV GUIDELINE has 2 rating methods: Content-Based Rating and Age -Based Rating.

The

AGE-BASED

RATING DESCRIPTION

TV-Y All children

TV-Y7 Directed to children age 7 and older

TV-G General Audience

TV-PG Parental Guidance suggested

TV-14 Parents strongly cautioned

TV-MA Mature Audience only

TV GUIDELINE includes the following options:

FV D L S V

TV-Y

TV-Y7

TV-G

TV-PG

AGE-BASED

TV-14

TV-MA

 : To block programs by both content and age.





CONTENT-BASED

RATING DESCRIPTION

FV Fantasy violence D Suggestive dialogue L Strong language S Sexual situations V Violence

CONTENT-BASED



Use the ▲▼ buttons to select the rating you want and press the OK button repeatedly to select

BLOCK() or UNBLOCK().

 The V-CHIP menu includes the following options:

Block MPAA Rating Selects to activate the MPAA Rating programs

Block TV Rating Selects to activate the TV Rating programs.

Block MPAA Unrated ▪ YES: Block all movies that are broadcast without a MPAA rating. ▪ NO: Allows all movies that are broadcast without a MPAA rating

Block TV None Rating ▪ YES: Block all movies that are broadcast without a TV rating. ▪ NO: Allows all movies that are broadcast without a TV rating.

40

Using the Parental Settings

Chapter 3 Using the LCD TV

The Parental blocking can be set up to the TV to block a Channel or a Video Source.

 Use the ▼ button to select the Parental, and press the OK to display the Parental

menu.

Channel Lock 1

Video Lock VIDEO5(YPbPr2)

Change Password

Setup Select Exit

 Use the V-CHIP function, must enter a four-digit password. The factory password is 0000.

Inout Your Password Please

* * * *

OK Cancel

You need your password for any future access into the V-Chip and Parental Setting,

ENGLISH

 The Parental menu includes the following options:

Channel Lock Selects to block a TV channel.

Video Lock Selects to block a Input source signal.

Change Password Selects to change your password.

41

Chapter 3 Using the LCD TV

Customizing the TV Settings

 Press the button to turn the LCD TV on.  Press the MENU button on the remote control to display the Main menu, and use the

◄► buttons to select the TV.

 Use the ▲▼buttons to highlight an individual TV option, use the ◄► buttons

changes the setting, and press the MENU exits the menu.

Searching

Tuner Mode Cable-STD

Channel Skip On

Channel Name

TV Select Exit

 The TV menu includes the following options:

Searching Automatically sets up channel list on TV for all receivable channels.

Tuner Mode Allows selection between CATV cable and antenna signal sources:

▪ ANTENNA Choose this setting if you are receiving TV channels with an antenna

▪ CABLE STD/CABLE IRC/CABLE HRC Choose this setting if you are receiving TV channels with a CATV

Channel Skip Allows addition/removal of channels on the channel list.

Channel Name Allows channel labels to be edited.

cable.

42

Speci cations

SPECIFICATIONS

MODEL

LCD Panel Panel Size 26’’ TFT LCD 32’’ TFT LCD

Brightness 550 500

Contrast Ratio 1000:1 800:1

Max. Resolution 1366x768 1366x768

Input Connector VIDEO/AUDIO(L/R) 2 2

S-VIDEO/AUDIO(L/R) 1 1

YPbPr/AUDIO(L/R) 2 2

VGA/AUDIO(L/R) 1 1

HDMI/AUDIO(L/R) 1 1

AUDIO OUT(L/R) 1 1

OPTICAL/COAXIAL 1 1

HEADPHONE 1 1

Power Source AC100~240V, 50/60HZ, 2.2A AC100~240V, 50/60HZ, 2.2A

Power Consumption 180 W, standby < 5 W 180 W, standby < 5 W

Dimension 26.7 w x 22.1 h x 7.9 d inch 31.7 w x 25.0 h x 8.4 d inch

WEIGHT 31.97 LB 39.5 LB

FLX-2602 FLX-3202

ENGLISHENGLISHENGLISH

43

Speci cations

MODEL

LCD Panel Panel Size 37’’ TFT LCD

Brightness 500

Contrast Ratio 1000:1

Max. Resolution 1366x768

Input Connector VIDEO/AUDIO(L/R) 2

S-VIDEO/AUDIO(L/R) 1

YPbPr/AUDIO(L/R) 2

VGA/AUDIO(L/R) 1

HDMI/AUDIO(L/R) 1

AUDIO OUT(L/R) 1

OPTICAL/COAXIAL 1

HEADPHONE 1

Power Source AC100~240V, 50/60HZ, 3.0A

Power Consumption 275 W, standby < 8 W

Dimension 36.6 w x 28.2 h x 9.4 d inch

WEIGHT 54 LB

FLX-3702

44

Chapter 4

Chapter 4 Programming your Remote Control

Programming your Remote Control

Introduction

Your remote lets you control four devices with one easy-to-use, compact unit. After installing batteries, you can

Your remote lets you control four devices with one easy-to-use, compact unit. After installing batteries, you can program the remote to control your Universal TV, VCR or DVD, Cable or Satellite Receivers, Ampliﬁ er or Tuner,

program the remote to control your Universal TV, VCR or DVD, Cable or Satellite Receivers, Ampliﬁ er or Tuner, and Auxiliary devices. To do so, follow the instructions in “Programming a Device”. For best results, please read

and Auxiliary devices. To do so, follow the instructions in “Programming a Device”. For best results, please read and follow all the remaining instructions. Keep this guide for future referenc

and follow all the remaining instructions. Keep this guide for future referenc

A Quick Look at Programming a Device

To control VCR or DVD, Cable or Satellite Receivers, Ampliﬁ er or Tuner, and Auxiliary devices, follow these steps.

To control VCR or DVD, Cable or Satellite Receivers, Ampliﬁ er or Tuner, and Auxiliary devices, follow these steps. Before proceeding, ﬁ nd the codes for the devices you want to program in “Manufacturer’s Codes” on the right side

Before proceeding, ﬁ nd the codes for the devices you want to program in “Manufacturer’s Codes” on the right side of this page and write them down or highlight them.

of this page and write them down or highlight them.

NOTE: To program a DVD Player, TV/DVD Combo, TV/VCR/DVD Combo, portable DVD player, or mobile DVD

player, use the DVD key.

1. Turn on the device (for example, DVD player) and, if needed, load media (for example, a DVD).

2. Press a device key (VCR/DVD, CBL/ SAT, or AUX).

3. Press and hold SET until the red LED blinks twice; then release.

4. Enter the ﬁ rst ﬁ ve-digit code for your device. The LED blinks once as each digit is entered. If the code is

4. Enter the ﬁ rst ﬁ ve-digit code for your device. The LED blinks once as each digit is entered. If the code is correct, the LED blinks twice.

correct, the LED blinks twice.

5. Aim the remote at the device and press Power. The device should turn off. If it does not, repeat steps

5. Aim the remote at the device and press Power. The device should turn off. If it does not, repeat steps 3–5, trying each code for your brand until you ﬁ nd one that works. If you cannot ﬁ nd a code that works,

3–5, trying each code for your brand until you ﬁ nd one that works. If you cannot ﬁ nd a code that works, see “Searching for Your Code”.

see “Searching for Your Code”.

6. Repeat steps 1–5 for the other devices you want to control. For future reference, write down each

6. Repeat steps 1–5 for the other devices you want to control. For future reference, write down each working device code below:

working device code below:

7. Press set to save and exit

•

NOTE: If the LED does not blink twice, repeat steps 2 to 4 and try entering the code again.

•

NOTE: If the LED does not blink twice, repeat steps 2 to 4 and try entering the code again.

AUX Code:

AUX Code: CBL Code:

CBL Code: CD Code:

CD Code: DVD Code:

DVD Code: SAT Code:

SAT Code: TNR Code:

TNR Code: VCR Code:

VCR Code:

e.

Searching for your Code

If your device does not respond to the remote after trying all codes listed for your brand, or if your brand is not

If your device does not respond to the remote after trying all codes listed for your brand, or if your brand is not listed, try searching for your code:

listed, try searching for your code:

1. Press a device key once.

2. Press and hold SET until the red LED blinks twice; then release.

3. Enter 9-9-1, then the device group number (0= Cable, 1= TV, 2= VCR, 3= Audio). The LED blinks twice.

4. Aim the remote at the device and press Power. The remote sends IR codes from its library to the

4. Aim the remote at the device and press Power. The remote sends IR codes from its library to the selected device, starting with the most popular code ﬁ rst. If the device responds, go to step 7.

selected device, starting with the most popular code ﬁ rst. If the device responds, go to step 7.

5. If the device does not respond, press CH+. The remote will try the next code. Continue until the

5. If the device does not respond, press CH+. The remote will try the next code. Continue until the device responds.

device responds.

6. To search for other device codes, repeat steps 1 to 5.

7. Press SET to save and exit.

Checking the Codes

If you have set up the remote using the procedure in “Searching for Your Code”, you may need to ﬁ nd out which

If you have set up the remote using the procedure in “Searching for Your Code”, you may need to ﬁ nd out which four-digit code is operating your equipment.

four-digit code is operating your equipment.

For example, to ﬁ nd out which code is assigned to your TV:

1. Press TV once.

•

Note: Press CH- to try the previous code.

•

Note: Press CH- to try the previous code.

AA

2. Press and hold SET until the red LED blinks twice; then release.

3. Enter 9-9-0. The LED blinks twice.

4. To view the code for the ﬁ rst digit, press 1. Count the LED blinks (for example, three blinks = 3), and write

4. To view the code for the ﬁ rst digit, press 1. Count the LED blinks (for example, three blinks = 3), and write down the number in the appropriate code listing in step 8 under “Programming a Device”.

down the number in the appropriate code listing in step 8 under “Programming a Device”.

5. Repeat step 4 for the four remaining digits, using 2 for the second digit, 3 for the third digit, 4 for the fourth

5. Repeat step 4 for the four remaining digits, using 2 for the second digit, 3 for the third digit, 4 for the fourth digit, and 5 for the ﬁ fth digit.

digit, and 5 for the ﬁ fth digit.

6. To check for other device codes, repeat steps 1—5, substituting the device key for TV.

Changing Volume Lock

The remote comes preset to allow independent volume control of each selected device (Global Volume Unlock).

The remote comes preset to allow independent volume control of each selected device (Global Volume Unlock). However, you may change the Volume Lock setting to Global Volume Lock so that one device’s volume will

However, you may change the Volume Lock setting to Global Volume Lock so that one device’s volume will control volume in all other modes. After that, you can perform Individual Volume Unlock on a selected device to

control volume in all other modes. After that, you can perform Individual Volume Unlock on a selected device to set its volume control for independent operation or Global Volume Unlock to remove all volume locking.

set its volume control for independent operation or Global Volume Unlock to remove all volume locking.

Locking Volume Control to One Mode (Global Volume Lock)

Unlocking All Volume Control (Restoring Global Unlock)

independently controlled for all programmed devices.

Unlocking a Single Device’s Volume Control

independently controlled for the selected devices.

Troubleshooting

PROBLEM: LED does not blink when you press a key.

PROBLEM: LED does not blink when you press a key. SOLUTION: Replace battery with new AA size battery.

SOLUTION: Replace battery with new AA size battery. PROBLEM: LED blinks when you press a key, but device does not respond.

PROBLEM: LED blinks when you press a key, but device does not respond. SOLUTION: Make sure the remote is aimed at your device and is not more than 15 feet away.

SOLUTION: Make sure the remote is aimed at your device and is not more than 15 feet away. PROBLEM: LED blinks one long blink.

PROBLEM: LED blinks one long blink. SOLUTION: An entry error has occurred (for example, wrong key). Try entry sequence again.

SOLUTION: An entry error has occurred (for example, wrong key). Try entry sequence again. PROBLEM: Remote does not control devices or commands are not working properly.

PROBLEM: Remote does not control devices or commands are not working properly. SOLUTION: Try all listed codes for the device. Make sure the device operates with an infrared remote control.

SOLUTION: Try all listed codes for the device. Make sure the device operates with an infrared remote control. PROBLEM: CH+, CH-, and LAST do not work for your RCA TV.

PROBLEM: CH+, CH-, and LAST do not work for your RCA TV. SOLUTION: Due to RCA design from 1983 to 1987, only the original remote control will operate these functions.

SOLUTION: Due to RCA design from 1983 to 1987, only the original remote control will operate these functions. PROBLEM: No volume on a device.

PROBLEM: No volume on a device. SOLUTION: See “Changing Volume Lock”.

SOLUTION: See “Changing Volume Lock”. PROBLEM: Channels do not change properly.

PROBLEM: Channels do not change properly. SOLUTION: If the original remote control required you to press Enter to change channels, press Enter on this

SOLUTION: If the original remote control required you to press Enter to change channels, press Enter on this

remote after entering the channel number.

•

NOTE: If a code digit is 0, the LED does not blink.

•

NOTE: If a code digit is 0, the LED does not blink.

1. Press and hold SET until the red LED blinks twice; then release.

2. Enter 9-9-3 and then press the mode key for the device you want to control volume (for example, TV).

2. Enter 9-9-3 and then press the mode key for the device you want to control volume (for example, TV). The LED blinks twice. Now when you press VOL+, VOL-, or Mute, the selected device (for example,

The LED blinks twice. Now when you press VOL+, VOL-, or Mute, the selected device (for example, TV) will control the volume regardless of the current mode.

TV) will control the volume regardless of the current mode.

1. Press and hold SET until the red LED blinks twice; then release.

2. Enter 9-9-3 and then press VOL+. The LED blinks four times. Volume is now

1. Press a device key (TV, VCR/DVD, CBL/ SAT, or AUX).

2. Press and hold SET until the red LED blinks twice; then release.

3. Enter 9-9-3 and then press VOL-. The LED blinks four times. Volume is now

BB

MANUFACTURER’S CODESMANUFACTURER’S CODES

Set Codes for Audio Ampliﬁ ers

Bose 30674

Bose 30674 GE 30078

GE 30078 JVC 30331

JVC 30331 Marantz 30321

Marantz 30321 Nakamichi 30321

Nakamichi 30321 NEC 30264

NEC 30264 Optimus 30395

Optimus 30395 Realistic 30395

Realistic 30395 Sansui 30321

Sansui 30321 Shure 30264

Shure 30264 Sony 30689

Sony 30689 Soundesign 30078

Soundesign 30078 Victor 30331

Victor 30331 Wards 30078

Wards 30078 Yamaha 30354, 30133

Yamaha 30354, 30133

Set Codes for Audio Amp/Tuners

ADC 30531

ADC 30531 Aiwa 31405, 31243, 30121

Aiwa 31405, 31243, 30121 Anam 31609, 31074

Anam 31609, 31074 Audiotronic 31189

Audiotronic 31189 Bose 31229

Bose 31229 Capetronic 30531

Capetronic 30531 Carver 31189

Carver 31189 Coby 31263

Coby 31263 Denon 31360, 31142, 30904

Denon 31360, 31142, 30904 Fonmix 31360

Fonmix 31360 Glory Horse 31263

Glory Horse 31263 Harman/Kardon 30110

Harman/Kardon 30110 Hitachi 31273

Hitachi 31273 Inkel 30027

Inkel 30027 Integra 30135

Integra 30135 JBL 30110

JBL 30110 JVC 30074, 31263

JVC 30074, 31263 Kenwood 31313, 31570, 30027

Kenwood 31313, 31570, 30027 KLH 31428

KLH 31428 Magnavox 31189, 31269, 30531

Magnavox 31189, 31269, 30531 Marantz 31189, 31269, 30039

Marantz 31189, 31269, 30039 MCS 30039

MCS 30039 Onkyo 30842, 30135

Onkyo 30842, 30135 Optimus 31023, 30670, 30531, 31074

Optimus 31023, 30670, 30531, 31074 Panasonic 31518, 30039

Panasonic 31518, 30039 Philips 31189, 31269

Philips 31189, 31269 Pioneer 31023, 30150, 30014, 30630, 30531

Pioneer 31023, 30150, 30014, 30630, 30531 Proscan 31254

Proscan 31254 Qisheng 31609

Qisheng 31609 Quasar 30039

Quasar 30039 RadioShack 31263

RadioShack 31263 RCA 31023, 31609, 31254, 30531, 31074

RCA 31023, 31609, 31254, 30531, 31074 Sharper Image 31263

Sharper Image 31263 Silsonic 30176

Silsonic 30176 Sony 31258, 31759

Sony 31258, 31759 Soundesign 30670

Soundesign 30670 Stereophonics 31023

Stereophonics 31023 Sunﬁ re 31313

Sunﬁ re 31313 Teac 31074, 31267

Teac 31074, 31267 Technics 31308, 31518, 30039

Technics 31308, 31518, 30039 Thorens 31189

Thorens 31189 Victor 30074

Victor 30074 Wards 30014

Wards 30014 Yamaha 30176, 31276, 31176

Yamaha 30176, 31276, 31176

CC

Set Codes for Cable Converters

ABC 00003, 00008, 00014

ABC 00003, 00008, 00014 Americast 00899

Americast 00899 Bell & Howell 00014

Bell & Howell 00014

Bell South 00899

Bell South 00899 Clearmaster 00883

Clearmaster 00883 ClearMax 00883

ClearMax 00883 Coolmax 00883

Coolmax 00883 Daeryung 01877, 00877, 00477, 00008

Daeryung 01877, 00877, 00477, 00008 Digi 00637

Digi 00637 Director 00476

Director 00476 Dumont 00637

Dumont 00637 Gehua 00476

Gehua 00476 General Instrument 00476, 00810, 00276, 00003, 00014

General Instrument 00476, 00810, 00276, 00003, 00014 GoldStar 00144

GoldStar 00144 Hamlin 00009, 00273

Hamlin 00009, 00273 Hitachi 00014

Hitachi 00014 Jerrold 00476, 00810, 00276, 00003, 00012, 00014

Jerrold 00476, 00810, 00276, 00003, 00012, 00014 KNC 00008

KNC 00008 LG 00144

LG 00144 Memorex 00000

Memorex 00000 Motorola 00476, 00810, 00276, 01254, 01376

Motorola 00476, 00810, 00276, 01254, 01376 MultiVision 00012

MultiVision 00012 Pace 01877, 00237

Pace 01877, 00237 Panasonic 00000, 00008, 00107

Panasonic 00000, 00008, 00107 Panther 00637

Panther 00637 Paragon 00000

Paragon 00000 Philips 00317, 01305

Philips 00317, 01305 Pioneer 01877, 00877, 00144, 00533

Pioneer 01877, 00877, 00144, 00533 Pulsar 00000

Pulsar 00000 Quasar 00000

Quasar 00000 RadioShack 00883

RadioShack 00883 Regal 00279, 00273

Regal 00279, 00273 Runco 00000

Runco 00000 Samsung 00000, 00144

Samsung 00000, 00144 Scientiﬁ c Atlanta 01877, 00877, 00477, 00008

Scientiﬁ c Atlanta 01877, 00877, 00477, 00008 Sony 01006

Sony 01006 Starcom 00003, 00014

Starcom 00003, 00014 Supercable 00276

Supercable 00276 Supermax 00883

Supermax 00883 Tocom 00012

Tocom 00012 Torx 00003

Torx 00003 Toshiba 00000

Toshiba 00000 Trans PX 00276

Trans PX 00276 Tristar 00883

Tristar 00883 TS 00003

TS 00003 V2 00883

V2 00883 Viewmaster 00883

Viewmaster 00883 Vision 00883

Vision 00883 Vortex View 00883

Vortex View 00883 Zenith 00000, 00525, 00899

Zenith 00000, 00525, 00899

Set Codes for CD Players

Aiwa 30157

Aiwa 30157 Burmester 30420

Burmester 30420 California Audio Labs 30029

California Audio Labs 30029 Carver 30157, 30179

Carver 30157, 30179 Denon 30873

Denon 30873 DKK 30000

DKK 30000 DMX Electronics 30157

DMX Electronics 30157 Dynamic Bass 30179

Dynamic Bass 30179 Fisher 30179

Fisher 30179 Garrard 30420

Garrard 30420 Genexxa 30032

Genexxa 30032

DD

Harman/Kardon 30157, 30173

Harman/Kardon 30157, 30173 Hitachi 30032

Hitachi 30032 Integra 30101

Integra 30101 JVC 30072

JVC 30072 Kenwood 30826, 30626, 30028, 30037, 30036, 30190

Kenwood 30826, 30626, 30028, 30037, 30036, 30190 Krell 30157

Krell 30157 Linn 30157

Linn 30157 Magnavox 30157

Magnavox 30157 Marantz 30626, 30029, 30157

Marantz 30626, 30029, 30157 MCS 30029

MCS 30029 Miro 30000

Miro 30000 Mission 30157

Mission 30157 MTC 30420

MTC 30420 NSM 30157

NSM 30157 Onkyo 30868, 30101

Onkyo 30868, 30101 Optimus 31063, 30000, 30032, 30037, 30420, 30179, 31075, 30145

Optimus 31063, 30000, 30032, 30037, 30420, 30179, 31075, 30145 Panasonic 30029

Panasonic 30029 Parasound 30420

Parasound 30420 Philips 30626, 30157

Philips 30626, 30157 Pioneer 31063, 31062, 30032

Pioneer 31063, 31062, 30032 Polk Audio 30157

Polk Audio 30157 Proton 30157

Proton 30157 QED 30157

QED 30157 Quad 30157

Quad 30157 Quasar 30029

Quasar 30029 RadioShack 31075

RadioShack 31075 RCA 31062, 30032, 30420, 30179, 30053

RCA 31062, 30032, 30420, 30179, 30053 Realistic 30420, 30179

Realistic 30420, 30179 Rotel 30157, 30420

Rotel 30157, 30420 SAE 30157

SAE 30157 Sansui 30157

Sansui 30157 Sanyo 30179

Sanyo 30179 SAST 30157

SAST 30157 Sharp 30861, 30037

Sharp 30861, 30037 Silsonic 30888, 30036

Silsonic 30888, 30036 Sonic Frontiers 30157

Sonic Frontiers 30157 Sony 30490, 30000, 30100

Sony 30490, 30000, 30100 Soundesign 30145

Soundesign 30145 TAG McLaren 30157

TAG McLaren 30157 Tascam 30420

Tascam 30420 Teac 30420

Teac 30420 Technics 30029

Technics 30029 Victor 30072

Victor 30072 Wards 30157, 30053

Wards 30157, 30053 Yamaha 30888, 30036

Yamaha 30888, 30036 Zonda 30157

Zonda 30157

Set Codes for DVD Players

Aiwa 20641, 21912

Aiwa 20641, 21912 Akai 20770

Akai 20770 Allegro 20869

Allegro 20869 Apex Digital 20672, 20717, 20797, 21061, 20796, 21056, 21937, 20794, 21020, 21915

Apex Digital 20672, 20717, 20797, 21061, 20796, 21056, 21937, 20794, 21020, 21915 Blaupunkt 20717

Blaupunkt 20717 Blue Parade 20571

Blue Parade 20571 Broksonic 20695

Broksonic 20695 Changhong 20627, 21061

Changhong 20627, 21061 CineVision 20869

CineVision 20869 Coby 21086

Coby 21086 Curtis Mathes 21087

Curtis Mathes 21087 CyberHome 21024, 21023, 21129, 20816, 21117

CyberHome 21024, 21023, 21129, 20816, 21117 Daewoo 20833, 21172, 20869

Daewoo 20833, 21172, 20869 Denon 20490

Denon 20490 DVD2000 20521

DVD2000 20521

EE

Emerson 20591, 20675

Emerson 20591, 20675 Enterprise 20591

Enterprise 20591 Fisher 21919

Fisher 21919 Funai 20675

Funai 20675 Gateway 21158, 21073

Gateway 21158, 21073 GE 20522, 20717

GE 20522, 20717 Go Video 20744, 20833, 21099, 20783, 21075, 20869, 21730

Go Video 20744, 20833, 21099, 20783, 21075, 20869, 21730 Greenhill 20717

Greenhill 20717 Harman/Kardon 20582, 20702

Harman/Kardon 20582, 20702 Hitachi 20573, 20664, 21919

Hitachi 20573, 20664, 21919 Hiteker 20672

Hiteker 20672 Initial 20717

Initial 20717 Integra 20627, 21924

Integra 20627, 21924 JBL 20702

JBL 20702 JVC 20558, 20623, 20867

JVC 20558, 20623, 20867 Kenwood 20490, 20534

Kenwood 20490, 20534 KLH 20717, 21020, 21149

KLH 20717, 21020, 21149 Koss 20651, 21980

Koss 20651, 21980 Lasonic 20798

Lasonic 20798 LG 20591, 20869, 20801

LG 20591, 20869, 20801 Liquid Video 21980

Liquid Video 21980 Lite-On 21158, 21058

Lite-On 21158, 21058 Loewe 20511

Loewe 20511 Magnavox 20503, 20539, 21976, 21914, 20675

Magnavox 20503, 20539, 21976, 21914, 20675 Marantz 20539

Marantz 20539 Memorex 20695

Memorex 20695 Microsoft 20522

Microsoft 20522 Mintek 20717

Mintek 20717 Mitsubishi 21521, 20521

Mitsubishi 21521, 20521 Nesa 20717

Nesa 20717 Norcent 21003

Norcent 21003 Onkyo 20503, 20627, 21924, 20792

Onkyo 20503, 20627, 21924, 20792 Oritron 20651, 21980

Oritron 20651, 21980 Panasonic 20490, 21762, 21990

Panasonic 20490, 21762, 21990 Philips 20503, 20539, 20646, 21914

Philips 20503, 20539, 20646, 21914 Pioneer 20525, 20571

Pioneer 20525, 20571 Polaroid 21086, 21061

Polaroid 21086, 21061 Polk Audio 20539

Polk Audio 20539 Portland 20770

Portland 20770 Proscan 20522

Proscan 20522 Qwestar 20651

Qwestar 20651 RCA 20522, 20571, 20717, 20822

RCA 20522, 20571, 20717, 20822 Rio 20869

Rio 20869 Rotel 20623

Rotel 20623 Sampo 20752, 20698

Sampo 20752, 20698 Samsung 20490, 20573, 21932, 21075, 20820

Samsung 20490, 20573, 21932, 21075, 20820 Sansui 20695

Sansui 20695 Sanyo 20695

Sanyo 20695 Sharp 20630, 20752

Sharp 20630, 20752 Sharper Image 21117

Sharper Image 21117 Sherwood 20770

Sherwood 20770 Shinco 20717

Shinco 20717 Shinsonic 20533

Shinsonic 20533 Sonic Blue 20869, 21099

Sonic Blue 20869, 21099 Sony 20533, 20864, 21033, 21904, 21903

Sony 20533, 20864, 21033, 21904, 21903 SVA 20717

SVA 20717 Sylvania 20675

Sylvania 20675 Symphonic 20675

Symphonic 20675 Teac 20717, 21984, 20809

Teac 20717, 21984, 20809 Technics 20490

Technics 20490 Theta Digital 20571

Theta Digital 20571 Toshiba 20503, 20695

Toshiba 20503, 20695 Urban Concepts 20503

Urban Concepts 20503 Xbox 20522

Xbox 20522 Yamaha 20490, 20539, 20545

Yamaha 20490, 20539, 20545 Zenith 20503, 20591, 20869

Zenith 20503, 20591, 20869

FF

Set Codes for Satellite Receivers

AlphaStar 00772

AlphaStar 00772 Chaparral 00216

Chaparral 00216 Crossdigital 01109

Crossdigital 01109 DirecTV 00392, 00566, 00639, 01142, 00247, 00749, 01749, 00724, 00819, 01856, 01076, 01109,

DirecTV 00392, 00566, 00639, 01142, 00247, 00749, 01749, 00724, 00819, 01856, 01076, 01109, 00099, 01392,

00099, 01392,

Dish Network System 01005, 00775, 01505

Dish Network System 01005, 00775, 01505 Dishpro 01005, 00775, 01505

Dishpro 01005, 00775, 01505 Echostar 01005, 00775, 01505

Echostar 01005, 00775, 01505 Expressvu 00775

Expressvu 00775 GE 00566

GE 00566 General Instrument 00869

General Instrument 00869 GOI 00775

GOI 00775 Goodmans 01246

Goodmans 01246 Hisense 01535

Hisense 01535 Hitachi 00819, 00222, 01250

Hitachi 00819, 00222, 01250 HTS 00775

HTS 00775 Hughes Network Systems 01142, 00749, 01749, 01442

Hughes Network Systems 01142, 00749, 01749, 01442 I-Lo 01535

I-Lo 01535 JVC 00775

JVC 00775 LG 01414, 01226

LG 01414, 01226 Magnavox 00724, 00722

Magnavox 00724, 00722 Memorex 00724

Memorex 00724 Mitsubishi 00749

Mitsubishi 00749 Motorola 00869

Motorola 00869 NEC 01270

NEC 01270 Next Level 00869

Next Level 00869 Panasonic 00247, 00701

Panasonic 00247, 00701 Paysat 00724

Paysat 00724 Philips 01142, 00749, 01749, 00724, 01076, 00722, 00099, 01442

Philips 01142, 00749, 01749, 00724, 01076, 00722, 00099, 01442 Proscan 00392, 00566

Proscan 00392, 00566 Proton 01535

Proton 01535 RadioShack 00869

RadioShack 00869 RCA 00392, 00566, 00855, 00143, 01392

RCA 00392, 00566, 00855, 00143, 01392 Samsung 01276, 01109, 01108

Samsung 01276, 01109, 01108 Sanyo 01219

Sanyo 01219 SKY 00856

SKY 00856 Sony 00639, 01640

Sony 00639, 01640 Star Choice 00869

Star Choice 00869 Tivo 01142, 01442

Tivo 01142, 01442 Toshiba 00749, 01749, 00790, 01285

Toshiba 00749, 01749, 00790, 01285 UltimateTV 01640, 01392

UltimateTV 01640, 01392 Uniden 00724, 00722

Uniden 00724, 00722 US Digital 01535

US Digital 01535 USDTV 01535

USDTV 01535 Voom 00869

Voom 00869 Zenith 00856, 01856

Zenith 00856, 01856

01640, 01442, 01414, 01108

Set Codes for TVs

Addison 10092

Addison 10092 Admiral 10093, 10463

Admiral 10093, 10463 Advent 10761, 10842

Advent 10761, 10842 Aiko 10092

Aiko 10092 Aiwa 11914

Aiwa 11914 Akai 10812, 10702, 10030, 10672, 11903

Akai 10812, 10702, 10030, 10672, 11903 Albatron 10700, 10843

Albatron 10700, 10843 America Action 10180

America Action 10180 Anam 10250, 10180, 10700

Anam 10250, 10180, 10700 Anam National 10250, 10650

Anam National 10250, 10650 Anhua 10051

Anhua 10051 AOC 10451, 10093, 10180, 10060, 10030, 10178, 10092

AOC 10451, 10093, 10180, 10060, 10030, 10178, 10092 Apex Digital 10748, 10765, 10879, 10767, 11943

Apex Digital 10748, 10765, 10879, 10767, 11943

GG

Audiovox 10451, 10180, 10875, 10092, 10623

Audiovox 10451, 10180, 10875, 10092, 10623 Baile 10661

Baile 10661 Beijing 10812, 10661

Beijing 10812, 10661 Bell & Howell 10154

Bell & Howell 10154 BenQ 11032

BenQ 11032 Bradford 10180

Bradford 10180 Broksonic 10236, 10463, 11911, 11938, 11905, 11935, 11929

Broksonic 10236, 10463, 11911, 11938, 11905, 11935, 11929 Cailing 10748

Cailing 10748 Candle 10030

Candle 10030 Carnivale 10030

Carnivale 10030 Carver 10054

Carver 10054 Celebrity 10000

Celebrity 10000 Celera 10765

Celera 10765 Changcheng 10051, 10661

Changcheng 10051, 10661 Changhong 10156, 10765, 11156, 10767

Changhong 10156, 10765, 11156, 10767 Ching Tai 10092

Ching Tai 10092 Chun Yun 10000, 10180, 10700, 10092, 10843

Chun Yun 10000, 10180, 10700, 10092, 10843 Chung Hsin 10180, 10053

Chung Hsin 10180, 10053 Cinema 10672

Cinema 10672 Citizen 10180

Citizen 10180 Commercial Solutions 11447, 10047

Commercial Solutions 11447, 10047 Conrowa 10156, 10145, 11156

Conrowa 10156, 10145, 11156 Contec 10180

Contec 10180 Craig 10180

Craig 10180 Crosley 10054

Crosley 10054 Crown 10180

Crown 10180 Curtis Mathes 10047, 10054, 10154, 10451, 10093, 10060, 10702, 10030, 10145, 10166

Curtis Mathes 10047, 10054, 10154, 10451, 10093, 10060, 10702, 10030, 10145, 10166 CXC 10180

CXC 10180 Daewoo 10154, 10451, 10180, 10030, 10178, 10672, 11928, 10092, 10661, 11909, 10623, 10700

Daewoo 10154, 10451, 10180, 10030, 10178, 10672, 11928, 10092, 10661, 11909, 10623, 10700 Dayu 10661

Dayu 10661 Dell 11080

Dell 11080 Denon 10145

Denon 10145 Dumont 10017

Dumont 10017 Durabrand 10463, 10180, 10178, 10171, 11034

Durabrand 10463, 10180, 10178, 10171, 11034 Electroband 10000

Electroband 10000 Emerson 10154, 10236, 10463, 10180, 10178, 10171, 11944, 11909, 11929, 11905, 11928, 10623,

Emerson 10154, 10236, 10463, 10180, 10178, 10171, 11944, 11909, 11929, 11905, 11928, 10623, 11911

11911 Envision 10030

Envision 10030 Ether 10030

Ether 10030 Firstar 10236

Firstar 10236 Fisher 10154

Fisher 10154 Fortress 10093

Fortress 10093 Fujitsu 10809, 10853

Fujitsu 10809, 10853 Funai 10180, 10171, 11904

Funai 10180, 10171, 11904 Furi 10145

Furi 10145 Futuretech 10180

Futuretech 10180 Gateway 11756, 11755

Gateway 11756, 11755 GE 11447, 10047, 11454, 10051, 10451, 10180, 10030, 10178, 11917, 10092, 11907, 11922

GE 11447, 10047, 11454, 10051, 10451, 10180, 10030, 10178, 11917, 10092, 11907, 11922 Gibralter 10017, 10030

Gibralter 10017, 10030 GoldStar 10154, 10030, 10178, 11926

GoldStar 10154, 10030, 10178, 11926 Grunpy 10180

Grunpy 10180 Haier 11034

Haier 11034 Hallmark 10178

Hallmark 10178 Hankook 10180, 10030, 10178

Hankook 10180, 10030, 10178 Harley Davidson 11904

Harley Davidson 11904 Harman/Kardon 10054

Harman/Kardon 10054 Harvard 10180

Harvard 10180 Havermy 10093

Havermy 10093 Helios 10865

Helios 10865 Hello Kitty 10451

Hello Kitty 10451 Hisense 10156, 10748, 10145, 11156

Hisense 10156, 10748, 10145, 11156 Hitachi 10156, 10030, 10178, 11145, 10145, 10092, 11904, 11156

Hitachi 10156, 10030, 10178, 11145, 10145, 10092, 11904, 11156 Hongmei 10093

Hongmei 10093 Huafa 10145

Huafa 10145 Huari 10145

Huari 10145 Huodateji 10051

Huodateji 10051

HH

Imperial Crown 10661

Imperial Crown 10661 Inﬁ nity 10054

Inﬁ nity 10054 Inteq 10017

Inteq 10017 JBL 10054

JBL 10054 JCB 10000

JCB 10000 Jean 10156, 10051, 10236, 10092

Jean 10156, 10051, 10236, 10092 Jensen 10761

Jensen 10761 Jiahua 10051

Jiahua 10051 Jinfeng 10051

Jinfeng 10051 Jinxing 10054, 10156, 10145

Jinxing 10054, 10156, 10145 JVC 10053, 11923, 11253

JVC 10053, 11923, 11253 Kangli 10661

Kangli 10661 KEC 10180

KEC 10180 Kenwood 10030

Kenwood 10030 KLH 10765, 10767

KLH 10765, 10767 Kolin 10180, 10150, 10053

Kolin 10180, 10150, 10053 KTV 10180, 10030

KTV 10180, 10030 Kunlun 10051, 10661

Kunlun 10051, 10661 LG 10060, 10030, 10178, 10856, 10700, 10025

LG 10060, 10030, 10178, 10856, 10700, 10025 Lloyd’s 11904

Lloyd’s 11904 LXI 10047, 10054, 10154, 10156, 10178

LXI 10047, 10054, 10154, 10156, 10178 Magnasonic 11928, 11913

Magnasonic 11928, 11913 Magnavox 11454, 10054, 10030, 10706, 11931, 11254, 11913, 11904, 11944

Magnavox 11454, 10054, 10030, 10706, 11931, 11254, 11913, 11904, 11944 Magnin 11907

Magnin 11907 Marantz 10054, 10030, 10704

Marantz 10054, 10030, 10704 Matsushita 10250, 10650

Matsushita 10250, 10650 Maxent 11755

Maxent 11755 Megapower 10700

Megapower 10700 Megatron 10178, 10145

Megatron 10178, 10145 Memorex 10154, 10463, 10150, 10178, 11911, 11926, 11924, 11920, 11927

Memorex 10154, 10463, 10150, 10178, 11911, 11926, 11924, 11920, 11927 MGA 10150, 10030, 10178, 11907

MGA 10150, 10030, 10178, 11907 Midland 10047, 10017, 10051

Midland 10047, 10017, 10051 Mitsubishi 10154, 10250, 10093, 10236, 10180, 11250, 10150, 10030, 10178, 11917, 10836

Mitsubishi 10154, 10250, 10093, 10236, 10180, 11250, 10150, 10030, 10178, 11917, 10836 Monivision 10843, 10700

Monivision 10843, 10700 Motorola 10093

Motorola 10093 MTC 10060, 10030

MTC 10060, 10030 Mudan 10051

Mudan 10051 Multitech 10180

Multitech 10180 NAD 10156, 10178, 10866

NAD 10156, 10178, 10866 National 10051

National 10051 NEC 10154, 10156, 10051, 10053, 10030, 10178, 11704

NEC 10154, 10156, 10051, 10053, 10030, 10178, 11704 Newave 10093, 10178, 10092

Newave 10093, 10178, 10092 Nikko 10030, 10178, 10092

Nikko 10030, 10178, 10092 Norcent 10748, 10824

Norcent 10748, 10824 NTC 10092

NTC 10092 Onwa 10180

Onwa 10180 Optimus 10154, 10250, 10166, 10650, 11927, 11924, 11913

Optimus 10154, 10250, 10166, 10650, 11927, 11924, 11913 Optonica 10093

Optonica 10093 Orion 10236, 10463, 11929, 11911, 11905

Orion 10236, 10463, 11929, 11911, 11905 Panasonic 10054, 10250, 10051, 10650, 11941, 11927, 11924

Panasonic 10054, 10250, 10051, 10650, 11941, 11927, 11924 Panda 10051, 10706

Panda 10051, 10706 Penney 10047, 10156, 10051, 10060, 10030, 10178, 11926, 11907

Penney 10047, 10156, 10051, 10060, 10030, 10178, 11926, 11907 Philco 10054, 10180, 10030, 10178

Philco 10054, 10180, 10030, 10178 Philips 11454, 10054, 10000, 10051, 10030, 10178, 10092, 10690

Philips 11454, 10054, 10000, 10051, 10030, 10178, 10092, 10690 Pilot 10030

Pilot 10030 Pioneer 10166, 10866, 10679

Pioneer 10166, 10866, 10679 Portland 10092

Portland 10092 Prima 10761

Prima 10761 Princeton 10700

Princeton 10700 Prism 10051

Prism 10051 Proscan 11447, 10047, 11922

Proscan 11447, 10047, 11922 Proton 10030, 10178

Proton 10030, 10178 Pulsar 10017

Pulsar 10017 Qingdao 10051

Qingdao 10051 Quasar 10250, 10051, 11924, 10650

Quasar 10250, 10051, 11924, 10650 RadioShack 10047, 10154, 10180, 10030, 10178, 11920, 11904

RadioShack 10047, 10154, 10180, 10030, 10178, 11920, 11904

II

RC A 11447, 10047, 11454, 10000, 10030, 10178, 11547, 11922,11917, 10092, 11907, 11948,

RC A 11447, 10047, 11454, 10000, 10030, 10178, 11547, 11922,11917, 10092, 11907, 11948, 10090, 10679

10090, 10679 Realistic 10154, 10180, 10030, 10178

Realistic 10154, 10180, 10030, 10178 Rowa 10748

Rowa 10748 Runco 10017, 10030

Runco 10017, 10030 Sampo 10154, 10093, 10030, 10178, 10171, 10700, 10650, 11755, 10092

Sampo 10154, 10093, 10030, 10178, 10171, 10700, 10650, 11755, 10092 Samsung 10154, 10156, 10060, 10812, 10702, 10030, 10178, 11060, 10814, 10092, 11903, 10090,

Samsung 10154, 10156, 10060, 10812, 10702, 10030, 10178, 11060, 10814, 10092, 11903, 10090, 10766

10766 Sansui 10463, 11904, 11935, 11929, 11911

Sansui 10463, 11904, 11935, 11929, 11911 Sanyo 10154, 10156, 10180, 10145, 11907

Sanyo 10154, 10156, 10180, 10145, 11907 Sanyuan 10093

Sanyuan 10093 Scotch 10178

Scotch 10178 Scott 10236, 10180, 10178

Scott 10236, 10180, 10178 Sears 10047, 10054, 10154, 10156, 10178, 10171, 11926, 11904

Sears 10047, 10054, 10154, 10156, 10178, 10171, 11926, 11904 Shaofeng 10145

Shaofeng 10145 Sharp 10093, 10030, 10650, 11917

Sharp 10093, 10030, 10650, 11917 Shen Ying 10092

Shen Ying 10092 Shencai 10145

Shencai 10145 Sheng Chia 10093, 10236

Sheng Chia 10093, 10236 Skygiant 10180

Skygiant 10180 Skyworth 10748

Skyworth 10748 Sony 11100, 10000, 10650, 11925, 11904

Sony 11100, 10000, 10650, 11925, 11904 Soundesign 10180, 10178

Soundesign 10180, 10178 Sowa 10156, 10051, 10060, 10178, 10092

Sowa 10156, 10051, 10060, 10178, 10092 Squareview 10171

Squareview 10171 SSS 10180

SSS 10180 Starlite 10180

Starlite 10180 Studio Experience 10843

Studio Experience 10843 Supreme 10000

Supreme 10000 SVA 10748, 10865

SVA 10748, 10865 Sylvania 10054, 10030, 10171, 11944, 11931

Sylvania 10054, 10030, 10171, 11944, 11931 Symphonic 10180, 10171, 11913, 11904

Symphonic 10180, 10171, 11913, 11904 Synco 10000, 10451, 10093, 10060, 10178, 10092

Synco 10000, 10451, 10093, 10060, 10178, 10092 Tacico 10178, 10092

Tacico 10178, 10092 Tandy 10093

Tandy 10093 Tashiko 10092, 10650

Tashiko 10092, 10650 Tatung 10054, 10154, 10156, 10051, 10060, 11156, 11756, 11254

Tatung 10054, 10154, 10156, 10051, 10060, 11156, 11756, 11254 Technics 10250, 10051

Technics 10250, 10051 Techwood 10051

Techwood 10051 Teco 10051, 10093, 10178, 10092

Teco 10051, 10093, 10178, 10092 Teknika 10054, 10180, 10150, 10060, 10092

Teknika 10054, 10180, 10150, 10060, 10092 Telefunken 10702

Telefunken 10702 Tera 10030

Tera 10030 Thomas 11904

Thomas 11904 Tiane 10093

Tiane 10093 TMK 10178

TMK 10178 TNCi 10017

TNCi 10017 Tobo 10748

Tobo 10748 Toshiba 10154, 10156, 10060, 10145, 11945, 11704, 11936, 11156,11935, 10650, 11918

Toshiba 10154, 10156, 10060, 10145, 11945, 11704, 11936, 11156,11935, 10650, 11918 Tuntex 10030, 10092

Tuntex 10030, 10092 TVS 10463

TVS 10463 V Inc. 11756, 10885, 10864

V Inc. 11756, 10885, 10864 Vector Research 10030

Vector Research 10030 Victor 10250, 10053, 10650

Victor 10250, 10053, 10650 Vidikron 10054

Vidikron 10054 Vidtech 10178

Vidtech 10178 Viewsonic 11755, 10885, 10864

Viewsonic 11755, 10885, 10864 Wards 10054, 10030, 10178, 10866, 11156

Wards 10054, 10030, 10178, 10866, 11156 Warumaia 10661

Warumaia 10661 Waycon 10156

Waycon 10156 White Westinghouse 10463, 11909, 10623

White Westinghouse 10463, 11909, 10623 Yamaha 10030

Yamaha 10030 Yapshe 10250

Yapshe 10250 Zenith 10017, 10463, 10178, 11904, 11929, 11911, 11909, 10092

Zenith 10017, 10463, 10178, 11904, 11929, 11911, 11909, 10092

Set Codes for VCRsSet Codes for VCRs

JJ

ABS 21972

ABS 21972 Admiral 20048, 20209

Admiral 20048, 20209 Aiko 20278

Aiko 20278 Aiwa 20037, 20479

Aiwa 20037, 20479 Alienware 21972

Alienware 21972 America Action 20278

America Action 20278 American High 20035

American High 20035 Amoisonic 20479

Amoisonic 20479 Anam 20162, 20037, 20240, 20278

Anam 20162, 20037, 20240, 20278 Anam National 20162

Anam National 20162 Asha 20240

Asha 20240 Audiovox 20037, 20278

Audiovox 20037, 20278 Beaumark 20240

Beaumark 20240 Bell & Howell 20104

Bell & Howell 20104 Broksonic 20184, 20121, 20209, 20002, 20479

Broksonic 20184, 20121, 20209, 20002, 20479 Calix 20037

Calix 20037 Canon 20035

Canon 20035 Carver 20081

Carver 20081 CCE 20072, 20278

CCE 20072, 20278 Changhong 20048, 20081

Changhong 20048, 20081 Citizen 20037, 20278

Citizen 20037, 20278 Colt 20072

Colt 20072 Craig 20037, 20047, 20240, 20072

Craig 20037, 20047, 20240, 20072 Curtis Mathes 20060, 20035, 20162

Curtis Mathes 20060, 20035, 20162 Cybernex 20240

Cybernex 20240 CyberPower 21972

CyberPower 21972 Daewoo 20045, 20104, 20278

Daewoo 20045, 20104, 20278 Dell 21972

Dell 21972 Denon 20042

Denon 20042 DirecTV 20739

DirecTV 20739 Durabrand 20039, 20038

Durabrand 20039, 20038 Electrohome 20037

Electrohome 20037 Electrophonic 20037

Electrophonic 20037 Emerex 20032

Emerex 20032 Emerson 20035, 20037, 20184, 20240, 20045, 20121, 20043, 20209, 20002, 20278,

Emerson 20035, 20037, 20184, 20240, 20045, 20121, 20043, 20209, 20002, 20278, 20479

20479 Fisher 20047, 20104

Fisher 20047, 20104 Fuji 20035, 20033

Fuji 20035, 20033 Fujitsu 20045

Fujitsu 20045 Gateway 21972

Gateway 21972 GE 20060, 20035, 20240

GE 20060, 20035, 20240 General 20045

General 20045 Go Video 20432

Go Video 20432 GoldStar 20037, 20209, 20038, 20225

GoldStar 20037, 20209, 20038, 20225 Haojie 20240

Haojie 20240 Harman/Kardon 20081, 20038

Harman/Kardon 20081, 20038 Harwood 20072

Harwood 20072 Hewlett Packard 21972

Hewlett Packard 21972 HI-Q 20047

HI-Q 20047 Hitachi 20037, 20042, 20055

Hitachi 20037, 20042, 20055 Howard Computers 21972

Howard Computers 21972 HP 21972

HP 21972 Hughes Network Systems 20042, 20739

Hughes Network Systems 20042, 20739 iBUYPOWER 21972

iBUYPOWER 21972 JVC 20045, 20067

JVC 20045, 20067 KEC 20037, 20278

KEC 20037, 20278 Kenwood 20067, 20038

Kenwood 20067, 20038 KLH 20072

KLH 20072 Kodak 20035, 20037

Kodak 20035, 20037 Kolin 20043

Kolin 20043 LG 20037, 20045, 20042, 20209, 20038

LG 20037, 20045, 20042, 20209, 20038 Logik 20072

Logik 20072 LXI 20037

LXI 20037 Magnavox 20035, 20039, 20081

Magnavox 20035, 20039, 20081 Magnin 20240

Magnin 20240 Marantz 20035, 20081

Marantz 20035, 20081 Marta 20037

Marta 20037

KK

Matsushita 20035, 20162

Matsushita 20035, 20162 Media Center PC 21972

Media Center PC 21972 MEI 20035

MEI 20035 Memorex 20035, 20162, 20037, 20048, 20039, 20047, 20240, 20104, 20209, 20479

Memorex 20035, 20162, 20037, 20048, 20039, 20047, 20240, 20104, 20209, 20479 MGA 20240, 20043

MGA 20240, 20043 MGN Technology 20240

MGN Technology 20240 Microsoft 21972

Microsoft 21972 Mind 21972

Mind 21972 Minolta 20042

Minolta 20042 Mitsubishi 20067, 20043

Mitsubishi 20067, 20043 Motorola 20035, 20048

Motorola 20035, 20048 MTC 20240

MTC 20240 Multitech 20072

Multitech 20072 NEC 20035, 20037, 20048, 20104, 20067, 20038

NEC 20035, 20037, 20048, 20104, 20067, 20038 Newave 20037

Newave 20037 Nikko 20037

Nikko 20037 Noblex 20240

Noblex 20240 Northgate 21972

Northgate 21972 Olympus 20035

Olympus 20035 Optimus 21062, 20162, 20037, 20048, 20104, 20432

Optimus 21062, 20162, 20037, 20048, 20104, 20432 Orion 20184, 20209, 20002, 20479

Orion 20184, 20209, 20002, 20479 Panasonic 21062, 20035, 20162, 20616, 20225

Panasonic 21062, 20035, 20162, 20616, 20225 Penney 20035, 20037, 20240, 20042, 20038

Penney 20035, 20037, 20240, 20042, 20038 Pentax 20042

Pentax 20042 Philco 20035, 20479

Philco 20035, 20479 Philips 20035, 20081, 20739, 20618

Philips 20035, 20081, 20739, 20618 Pilot 20037

Pilot 20037 Pioneer 20042, 20067

Pioneer 20042, 20067 Polk Audio 20081

Polk Audio 20081 Proﬁ tronic 20240

Proﬁ tronic 20240 Proscan 20060

Proscan 20060 Protec 20072

Protec 20072 Pulsar 20039

Pulsar 20039 Qisheng 20060

Qisheng 20060 Quasar 20035, 20162

Quasar 20035, 20162 Radix 20037

Radix 20037 Randex 20037

Randex 20037 RCA 20060, 20035, 20240, 20042, 20880

RCA 20060, 20035, 20240, 20042, 20880 Realistic 20035, 20037, 20048, 20047, 20104

Realistic 20035, 20037, 20048, 20047, 20104 ReplayTV 20616

ReplayTV 20616 Runco 20039

Runco 20039 Sampo 20037, 20048

Sampo 20037, 20048 Samsung 20240, 20045, 20432

Samsung 20240, 20045, 20432 Sanky 20048, 20039

Sanky 20048, 20039 Sansui 20067, 20209, 20479

Sansui 20067, 20209, 20479 Sanyo 20047, 20240, 20104

Sanyo 20047, 20240, 20104 Scott 20184, 20045, 20121, 20043

Scott 20184, 20045, 20121, 20043 Sears 20035, 20037, 20047, 20042, 20104

Sears 20035, 20037, 20047, 20042, 20104 Sharp 20048, 20209

Sharp 20048, 20209 Shintom 20072

Shintom 20072 Shogun 20240

Shogun 20240 Singer 20072

Singer 20072 Sonic Blue 20616

Sonic Blue 20616 Sony 20035, 20032, 20033, 20636, 21972

Sony 20035, 20032, 20033, 20636, 21972 STS 20042

STS 20042 Sylvania 20035, 20081, 20043

Sylvania 20035, 20081, 20043 Systemax 21972

Systemax 21972 Tagar Systems 21972

Tagar Systems 21972 Tashiko 20037

Tashiko 20037 Tatung 20045, 20067

Tatung 20045, 20067 Technics 20035, 20162

Technics 20035, 20162 Teco 20035, 20037, 20048, 20038

Teco 20035, 20037, 20048, 20038 Teknika 20035, 20037

Teknika 20035, 20037 Tivo 20636, 20618, 21503, 20739

Tivo 20636, 20618, 21503, 20739 TMK 20240

TMK 20240 Toshiba 20045, 20042, 20067, 20043, 21503, 21008, 21972

Toshiba 20045, 20042, 20067, 20043, 21503, 21008, 21972

LL

Totevision 20037, 20240

Totevision 20037, 20240 Touch 21972

Touch 21972 Unitech 20240

Unitech 20240 Vector 20045

Vector 20045 Vector Research 20038

Vector Research 20038 Victor 20067

Victor 20067 Video Concepts 20045

Video Concepts 20045 Videomagic 20037

Videomagic 20037 Videosonic 20240

Videosonic 20240 Viewsonic 21972

Viewsonic 21972 Wards 20060, 20035, 20048, 20047, 20081, 20240, 20042, 20072

Wards 20060, 20035, 20048, 20047, 20081, 20240, 20042, 20072 White Westinghouse 20209, 20072

White Westinghouse 20209, 20072 XR-1000 20035, 20072

XR-1000 20035, 20072 Yamaha 20038

Yamaha 20038 Zenith 20039, 20033, 20209, 20479

Zenith 20039, 20033, 20209, 20479 ZT Group 21972

ZT Group 21972

CARE

•

Keep the remote dry. If it gets wet, wipe it dry immediately.

•

Keep the remote dry. If it gets wet, wipe it dry immediately.

•

Use and store the unit only in normal temperature environments.

•

Use and store the unit only in normal temperature environments.

•

Handle the remote gently and carefully. Don’t drop it.

•

Handle the remote gently and carefully. Don’t drop it.

•

Wipe the remote with a damp cloth to keep it looking like new.

•

Wipe the remote with a damp cloth to keep it looking like new.

Manufactured under license from Dolby Laboratories.

“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

For service, support and warranty information, visit www.elementelectronics.com.

Manufactured under license from Dolby Laboratories.

MM

Element FLX-3702, FLX-2602, FLX-3202 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
