Element ELDFT421 User Manual

42” Full HD Digital LCD TV

ELDFT421

Instruction Manual

Read all of the instructions before using this TV and keep the

manual in a safe place for future reference.

Important Safety Instructions

• Read these instructions – All the safety and operating instructions should be read before this product
is operated.

• Keep these instructions – The safety and operating instructions should be retained for future reference.

• Heed all warnings – All warnings on the appliance and in the operating instructions should be adhered to.

• Follow all instructions – All operating and use instructions should be followed.

• Do not use this apparatus near water – The appliance should not be used near water or moisture –for

example, in a wet basement or near a swimming pool, and the like.

• Clean only with dry cloth.

• Do not block any ventilation openings. Install in accordance with the manufacture’s instructions.

• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including

amplifiers) that produce heat.

• Do not defeat the safety purpose of the polarized or grounding plug. A polarized plug has two blades with
one wider than the other. A grounding plug has two blades and a third grounding prong. The wide blade or
the third prong is provided for your safety. If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.

• Protect the power cord from being walked on or pinched particularly at the plugs, convenience receptacles,
and at the point where they exit from the apparatus.

• Only use attachments/accessories specified by the manufacturer.

• Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,

or sold with the apparatus. When a cart or rack is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.

• Unplug the apparatus during lightning storms or when unused for long periods of time.

• Refer all servicing to qualified personnel. Servicing is required when the apparatus has been damaged in any

way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

• Please keep the unit in a well-ventilated environment.

• WARNING：To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. The

apparatus shall not be exposed to dripping or splashing and that objects filled with liquids, such as vases,
shall not be placed on apparatus.

• WARNING: The wall socket plug is used as disconnect device, the disconnect device shall remain readily
operable.

• WARNING: The batteries shall not be exposed to excessive heat such as sunshine, fire or the like.

•

- This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the
presence of non-insulated “dangerous voltage” within the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock.

- Warning: To reduce the risk of electric shock, do not remove cover (or back) as there are no user -serviceable
parts inside. Refer servicing to qualified personnel.

- The exclamation point within an equilateral triangle is intended to alert the user to the presence of important
operating and maintenance instructions in the literature accompanying the appliance.

• The apparatus should be connected to an electrical wall outlet with a protective grounding connection.

Contents

Caution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

What’s Included . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7

Front / Rear View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7

TV Terminal Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Wall Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Connecting to External Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Remote Control Key Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-10

Operating Your Television . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-18

Select Your Onscreen Language Preference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Navigating the Onscreen Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Choosing a TV Channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Selecting Input Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Video Menu Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Picture Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Audio Menu Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

TV Menu Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Channel Skip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Setup Menu Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Caption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

13

PC Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Parental Menu Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19-20

USB multimedia operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-24

FCC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

2

Caution

The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operating and maintenance (servicing) instructions in
the literature accompanying the appliance.

The lightning flash with arrowhead symbol, within an equilateral triangle is
intended to alert the user to the presence of uninsulated “dangerous voltage”
within the products enclosure that may be of sufficient magnitude to constitute a
risk of electric shock to the persons.

3

Safety Information

To ensure reliable and safe operation of this equipment, please read carefully all the instructions
in this user guide, especially the safety information below.

Electrical safety

• The TV set should only be connected to a main power supply with voltage that matches the
label at the rear of the product.

• To prevent overload, do not share the same power supply socket with too many other
electronic components.

• Do not place any connecting wires where they may be stepped on or tripped over.

• Do not place heavy items on them, which may damage the leads.

• Hold the main plug, not the wires, when removing from a socket.

• During a thunderstorm or when not in using the television for long periods, turn off the

power switch on the back of the television.

• Do not allow water or moisture to enter the TV or power adapter. Do NOT use in wet, moist
areas, such as bathrooms, steamy kitchens or near swimming pools.

• Pull the plug out immediately, and seek professional help if the main plug or cable is
damaged, liquid is spilt onto the set, if accidentally exposed to water or moisture, if
anything accidentally penetrates the ventilation slots or if the set does not work normally.

• Do not remove the safety covers. There are no user serviceable parts inside. Trying to
service the unit yourself is dangerous and may invalidate the product’s warranty. Qualified
personnel must only service this apparatus.

• To avoid battery leakage, remove exhausted batteries from the remote control, or when not
using for a long period.

• Do not break open or throw exhausted batteries on a fire.

Physical safety

• Do not block ventilation slots in the back cover. You may place the TV in a cabinet, but
ensure at least 5cm (2”) clearance all around.

• Do not tap or shake the TV screen, or you may damage the internal circuits. Take good care
of the remote control.

• To clean the TV use a soft dry cloth. Do not use solvents or petroleum based fluids.

• Do not install near any heat sources such as radiators, heat registers, stoves or other

apparatus (including amplifiers) that produce heat.

• Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider then the other. A grounding type plug has two blades and a
third grounding prong, the wide blade, or the third prong is provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.

• Protect the power cord from being walked on or pinched particularly at plugs.

• Unplug the apparatus during lightning storms or when unused for long periods.

• Refer all servicing to a qualified service personnel. Servicing is required when the apparatus

has been damaged in any way, such as power-supply cord or plug is damaged, liquid has
been spilled, or objects have fallen into the apparatus, has been exposed to rain or moisture,
does not operate normally, or has been dropped.

• Please always connect your television to a power outlet with protective ground connection.

4

What’s Included

Unit and Accessories

TV Set Remote control with batteries

User’s Manual Quick Start Guide

warranty card Mains cable

5

1. AC power input terminal

2. USB port

3. HDMI 1/HDMI2/HDMI3 input.

4. VGA input.

5.

S-VIDEO input.
Coaxial audio signal out plug.

6.

7.

Component input terminal.

8.

AV1/AV2/AV3 input.

9.

PC audio input.

10.

Headphone output.

11.

Antenna input (75 Ohm VHF/UHF).

20

10 11

5 20

Connecting to external devices

Connecting external devices to your LCD TV

8

Remote Control Key Functions

Power button

Picture mode button Sleep button

Sound mode button

Numeric buttons

MTS button

Channel setup

Signal source selection button

UP

LEFT

Information button

Stop button

Play / Pause button

Rewind button

Prev button

Forward button

NEXT button

CH.LIST button

Freeze button

RED button

Green button

Return channel button

TV setup menu
ENTER

RIGHT

Down
Exit the OSD menu button
Mute button
Channel selection buttonVolume adjust button

Aspect button
ADD / Erase button

FAV button
Time button
EPG button
CC button
V-CHIP button

MMP Menu button

Blue button
Yellow button

If there is light around the TV, the remote control may fail or work abnormally.
If not using the remote for a long period of time, please remove the batteries.

Remote control function keys to practice prevail.

9

Remote Control Key Functions

(TV/AV1/AV2/AV3/S-VIDEO/YPBPR1/YPBPR2/VGA/HDMI1/HDMI2/HDMI3/USB)

10

Operating Your Television

Menu Setup TV(When Using For The First Time Only)

1. Turn on TV, Please press OK to start the wizard.

2.Please select your language.

3.Please select your time zone.

4.Please select your tuner.

5.Connect antenna and Press OK button start channel scan.

11

Operating Your Television

Basic Operations
Turning Your TV On and Off

TURN ON LCD TV

1. Connect to power with the main power cable, at this time the TV will enter STANDBY mode
and the LED will be red.

2. From the STANDBY mode, use the POWER button either on the main unit or on the remote
to turn your television on.

TURN OFF LCD TV

From ON mode, use the POWER button either on the main unit or on the remote to turn your
television to STANDBY mode.

Select Your Onscreen Language Preference

Note: If using your LCD TV for the first time, you should select the language which will be used
for displaying menus and information boxes.

• Press MENU to display the main menu.

• Press

(picture right).

• Select OSD LANGUAGE.

• Press

• When you are satisfied with your choice, press the MENU to exit.

/ repeatedly to select the SETUP (left picture), press OK or button to enter

/ button to select your desired language.

Volume Adjustment

1. Press VOL +/- to adjust the volume

2. If you want to switch the sound off, press the MUTE

, Press again to resume.

12

Operating Your Television

Navigating the Onscreen Display

• Press the MENU button to display the main menu.

• Use / buttons to navigate and select the available menus.

OK

OK

Time Display Mode 12Hour

OK

OK

Choosing a TV Channel

1. Use the CH /CH on the front panel or on the remote control.

• Press CH to increase the channel.

• Press CH to decrease the channel.

2. Using 0-9 remote keys.
Enter the channel number with the 0-9 remote keys, then press “OK” to select the channel.
For example:

1. Press 4, then press “OK” to select channel 4.

2. Press 4, then press 5, then press “OK” to select channel 45.

3. Press 1, then press 2, then press 1, finally press “OK” to select channel 121.

13

Operating Your Television

Selecting Input Source

You can display the input screen menu by pressing SOURCE on the
remote control or SOURCE on the front panel, press / button to
select, press “OK” to confirm.

Video Menu Options

Press the MENU on the front panel or MENU on the remote control and then use / to select the Video
menu, press or OK to enter (see picture below).

TV
AV1
AV2
AV3
S-VIDEO
YPBPR1
YPBPR2
VGA
HDMI1
HDMI2
HDMI3

USB

1. Use / to select what you want to adjust in the Video menu.

2. Press OK or / to adjust (according to the hint below)

3. When you are satisfied with your adjustment, press
to exit.

OK

MENU

Picture Mode

Select the type of picture which best corresponds to your viewing preferences by selecting Picture Mode in
the VIDEO menu. You may select the picture mode directly by pressing the P.MODE button on the
remote control.

Brightness

Press / and then use / to adjust the brightness of the picture.

Contrast

Press / and then use / to adjust the contrast of the picture.

Color

Press / and then use / to adjust the color of the picture.

Sharpness

Press / and then use / to adjust the sharpness of the picture.

Color Temperature

Press “OK” to enter the submenu for Color Temperature. Press / to select mode

----- User, Cool, Standard, Warm
Then press / to select “R Gain, G Gain, B Gain” in “User” mode.

DNR

Press / and then use / to adjust the Digital Noise Reduction of the picture.

14

Operating Your Television

Audio Menu Options

Press MENU on the front panel or MENU on the remote control and then use / to select the AUDIO
menu, press or OK to enter (see picture below).

75

80

1. Use / to select the option you want to adjust
in the Audio menu.

2. Press OK or / to adjust (according to the hints below)

3. When you are satisfied with your adjustment, press MENU

to exit.

Audio Mode

You can select the type of sound which best corresponds to your listening requirements by selecting
Sound in AUDIO menu.

Balance

Press / and then use / to adjust the audio output between left and right speakers.

Bass

Press / and then use / increase or decrease the level of the lower-pitched sounds.

Treble

Press / and then use / to increase or decrease the level of higher-pitched sounds

Sound Mode

Press / to select one of the modes options: Concert, Jazz, User, Voice

Sound Surround

Press / to switch Surround Sound On or Off

SPDIF

Press / to select between PCM, OFF or RAW

Auto Volume Control

Press

/

to switch auto volume control On or Off.

This function allow

s volume to be controlled automatically.

TV Menu Options

Press the MENU on the front panel or MENU on the remote control and then use / to select the TV
menu, press or OK to enter (see picture below).

1. Use / to select the option you want to adjust
in the TV menu.

2. Press OK or / to enter the desired function.

3. When you are done, press MENU to exit.

Tuner Mode

Select the signal input mode: Antenna or Cable

Channel Scan

Select “Channel Scan”; press OK to start the channel scan.
Press MENU to stop or continue until the scan is complete;
Stopping in the middle of a scan will save the
scanned channels up to the stop point.

15

OK

Operating Your Television

Channel Skip

Select “Channel Skip”; press OK to enter the submenu.
Press / to select the desired channel, then press OK.

OK

Setup Menu Options

Press the MENU on the front panel or MENU on the remote control and then use / to select the Setup
menu, press

or OK to enter (see picture below).

1. Use / to select the option you want to adjust
in the setup menu.

2. Press OK or

3. When you are done with your adjustments, press MENU
to exit.

/

to adjust (according to the hint below).

OSD Language

To select language of the OSD menu

OSD Transparency

Press

Time Setup

Select: “Time Setup ”, Press OK to enter the submenu.

Caption

(See next page)

/ to select the transparency mode Low, High or Middle.

Time zone

To select time zone

Time

To set power on and power off times. Press OK to enter to set

the time.

Sleep timer

To select the sleep timer

Time Display mode

To select the Time Display Mode in 12 or 24 hour mode

Reset Default

Select “Reset Default”, Press OK, and it will display “Are you sure”, select “OK” to select the factory
default settings.

16

Operating Your Television

Caption

Select “Caption”, press OK to enter the submenu (see below)

Analog Closed Caption

Press / to select CC1/CC2/CC3/CC4/TEXT1/TEXT2/TEXT3/TEXT4, or select Off.

Digital Closed Caption

Press / to select Service1/Service2/Service3/Service4/Service5/Service6, or select Off.

Digital Caption Style

This item allows you to set the closed caption, press OK to enter Digital Caption style menu:

O K

• Caption Style: press / to select As Broadcaster or Custom. When you select As Broadcaster, all other

options are disabled and can not be adjusted.

• Font Size: press / to select Medium/Large or Small.

• Font Color: press / to select Red/Green/Blue/Yellow/Magenta/Cyan/Black or White.

• Font Opacity: press / to select Solid/Transparent or Translucent.

• Background Color: press / to select Black/White/Red/Green/Blue/Yellow/Magenta/ or Cyan.

• Background Opacity: press / to select Solid/Transparent or Translucent.

• Window Color: press / to select Black/White/Red/Green/Blue/Yellow/Magenta/ or Cyan.

• Window Opacity: press / to select Solid/Transparent or Translucent.

17

Operating Your Television

PC Mode

Connect your computer to the TV using a VGA cable. Change the source to VGA, then press “MENU” and
select “VGA”

Press OK to enter PC setup

noitisop tseb ot erutcip ruoy tsujda otuA

:noitisop .H

Manually
Manually
Manually

esahp lortnoc :esahP

kcolc lortnoc :kcolC

noitisop latnoziroh lortnoc Manually

noitisop lacitrev lortnoc :noitisop .V

VGA Mode

Resolution Vertical Frequency (Hz)

06 084X046
06 006X008
06 867X4201
06 0801X0291

18

Parental Menu Options

Parental Menu Options

Press the MENU on the front panel or remote control and then use / to select the Parental menu,
Press or OK to enter (see picture below).

The factory default password code is 0000 to enter the parental menu.

Change Password: select “Change Password”, press OK to enter the

submenu, and change the password. Press MENU to cancel.

Clean All: Select “Clean All”, Press OK and it will display “Are you

sure”, select “OK” to default to the factory settings.

Program Block
Rating Enable:

Press / to select On/Off.

Blocked Rating

U.S. TV Ratings: Press OK to enter, and use / and / to select, and press OK to confirm.
U.S. Movie Ratings: Press OK to enter, and use / to select, and press OK to confirm.
Canadian English Ratings: Press OK to enter, and use / to select, and press OK to confirm.
Canadian French Ratings: Press OK to enter, and use / to select, and press OK to confirm.

Open V-Chip

Select “V-Chip”. Press OK to enter and you will see an item
again to enter the V-Chip menu (picture below).

Humor Level

Intelligence level

You can select any item, press OK to enter, use / to
select, press OK to confirm.

“Tumbolia region, alternate US

”. Press OK

19

Parental Menu Options

Parental Control

Press Enter to enter the sub-menu and then use the 0-9 to enter the correct password: 0,0,0,0. If used, this option feature can
“block” undesirable programming from appearing on the TV. Parental Control offers the user a wide variety of options and settings
that restrict or “block” the programming that can appear on the TV. Parental Control allows the user the capability of defining which
program rating they consider acceptable, to the younger more sensitive viewer. It can be preset and turned either on or off by the
user who specifies the secret 4-number code, the password. The number of hours blocked are specified. General audiences and
children blocks should be both programmed into the TV’s memory. Viewer ratings are specified for both TV and the motion picture
industry; both rating systems should be used, for complete coverage. The ratings are based on the ages of children.

Overview

To ensure complete coverage for all TV programs, (movies and regular TV shows) choose a rating for MPAA, from the selections
below, as well as ratings from the TV Parental Guidelines Rating Systems below, using the Age Block option for General Audiences,
and for children. In addition to those, you may wish to add additional restrictions from the content block menu, and submenus
examples below.

Things to Consider before Setting up Parental Control

Determine which rating you consider acceptable to the viewer. (For example, if you choose TV-PG, more restrictive ratings will be
automatically blocked; the viewer will not be able to see: TV-PG, TV-14, or TV-MA rated programming.) Do you want to block the
auxiliary video source entirely? (Blocks the signal sent by the equipment, such as VCR, connected to the TV Audio/Video input jacks)
Or leave unblocked, then choose allowable ratings. Block program “Content” based on individual parameters such as: Strong Dialog,
Bad Language, Sex Scenes, Violence Scenes, or Fantasy. Violent Scenes; in Content Blk option. Select a secret password, in the Set
Password option, using the numbers keys on the remote. Do not forget the password, it is the only way you can access the Parental
Control menu and change rating selections, or turn Parental Control off. Do you want the Parental Control to be active at all times? If

not, you can turn it on or off with the Lock On/Off option.

• You can set different Parental Control viewing restrictions for general audiences and for children, both can be active at the same time.

• Simply specifying one content block such as Sex Scenes, will not automatically restrict the programming that appears from the video sources.

• Even if you choose to leave the AUX inputs unblocked, the ratings you specify will automatically restrict the programming that appears from

the video sources.

• You can not disable Parental Control by disconnecting the TV from power. Block hours will be automatically reset to the original block time
setting specified if power is disconnected.

Information

Motion Picture Association of America (MPAA) Rating System

Grade Meaning

G General Audiences Content not offensive to most viewers

PG Parental Guidance Suggested Content is such that parents may not want their children to view the program

PG-13 Parental Guidance Strongly

Cautioned

R Restricted viewing Not for children under 17, Strong element of sex and/or violence

NC-17 No Children Under age 17 Not for children under 17 under any circumstances. Strong sexual content

X Hard Core Films Same as NC-17 rating

No Rating No Rating MPAA Not Rated

Program is inappropriate for preteens, with a greater degree of offensive material suggested than a PG
rated program

TV Parental Guideline Rating System

Grade Meaning

TV-Y Young Children Content not offensive to most viewers

TV-Y7 Children 7 and over Considered suitable for children over 7, may contain Fantasy Violence Scenes

TV-G Parental Audience Considered suitable for all audiences; children may watch unattended

TV-PG Parental Guidence Suggested Unsuitable for younger children, may contain; Suggestive Dialogue, Bad Language, Sex, and Violence Scenes

TV-14 Parents Strongly Cautioned Unsuitable for children under 14, may contain: Strong Dialogue, Bad Language, Sex, and Violence Scenes

TV-MA Mature Audience Only Adults only, may contain Strong Dialogue, Bad Language, Sex, and Violent Scenes

Canadian Rating: Canadian English is used throughout all English-speaking Canada (C, C8+, G, PG, 14+, 18+).

Canadian French is used in Quebec (G, 8 ans+, 13 ans+, 16 ans+, 18 ans+)

Note: The V-Chip will automatically block certain categories that are “more restrictive”. If you block TV-Y

category, then TV-Y7 will be automatically blocked. Similarly, if you block TV-G category, then all the categories
in the “young adult” will be blocked (TV-G, TV-PG, TV-14, and TV-MA).

20

USB multimedia operation

OK

duration.

Video

21

Troubleshooting

If your television does not operate normally or does not turn on, please check the following
troubleshooting questions. Remember to also check the other connected electronic devices, such as DVDs
or Blu-ray players to pinpoint any problem. If the television still fails to operate normally, please contact
technical support (refer to Warranty page).

SYMPTOM POSSIBLE CAUSE REMEDY

Dead. No LED lit No power to the TV. Check all connections to the TV’s AC socket.

Dead. No LED lit orange Set in standby mode.

Blue screen

Noisy, snowy, ghosting
picture (TV)

No sound

No signal.

Incorrect source selected.

Poor antenna signal.

Volume set too low. Check volume settings.

External leads not connected
“if used”.

Press either the Power button or the Standby button
on the remote control.

Press INPUT button to select the correct source

If using an indoor antenna, try adjusting the antenna
postion. Check antenna connections

.FFO ”etuM“ dnuos nruT.”etuM“ dnuoS

Check that all external leads are connected properly.

22

Troubleshooting

Before contacting the service technician, perform the following simple checks. If any problem still persists,
unplug the LCD TV and call for assistance.

PROBLEM POSSIBLE SOLUTION

No sound and picture - Check that the main plug has been connected to a wall

Red LED indicator light Set in standby mode. Press either the POWER button or

Normal picture but no sound - Check the volume

The remote control does not work - Check to see if there are any objects between the TV

Power suddenly turns off - Is the sleep timer set?

Picture appears slowly after switching on - This is normal, the image is muted during the product

Poor Color or picture - Adjust the color in Menu option

Horizontal/vertical bars or picture shaking - Check for local interference, such as an electrical

Blue Screen - Press INPUT button to select correct source

Poor reception on some channels - Station or cable

Lines or streaks in pictures - Check the antenna (change the direction of the

No output from one of the speakers - Adjust balance in the Menu option

outlet

- Check that you have pressed the POWER button on the
front of the TV set

- Check the picture contrast and the brightness setting

the Standby button on the remote control

- Sound muted? Press the MUTE button

- Try another channel, the problem may be with the
broadcast

- Are the audio cables installed properly?

and remote control causing obstruction

- Are batteries installed with correct polarity (+ / -)

- Correct remote operating mode set: TV, VCR, etc?

- Install new batteries

- Check the power control settings. Power may be
interrupted

- No broadcast on the station tuned

start up process. Please contact a service provider if
the picture has not appeared after 5 minutes

- Keep a sufficient distance between the product and the
VCR

- Try another channel, the problem may be with the
broadcast

- Are the VIDEO cables installed properly?

- Activate any function to restore the brightness of the

appliance or power tool

experiencing problems. Tune to

another station

- Station signal is weak, reorient antenna to receive better
reception

- Check for sources of possible interference

antenna)

23

Troubleshooting

NOTE: When there is a problem in VGA mode (only when VGA mode is applied)

PROBLEM POSSIBLE SOLUTION

The signal is out of range - Adjust resolution, horizontal frequency, or vertical

frequency

- Check whether the signal cable is connected or loose

- Check the input source

Vertical bar or stripe on background, horizontal noise and
incorrect position

Screen Color is unstable or is a single Color - Check the signal cable

Maintenance

Early malfunctions can be prevented. Careful and regular cleaning can extend the amount of time you will
have with your new TV. Be sure to turn the power off and unplug the power cord before you begin any
cleaning.

Cleaning the screen

1. A great tip to dust off your screen. Wet a soft cloth in a mixture of lukewarm water and a little fabric
softener or dish washing detergent. Wring the cloth until it’s almost dry, and then use to wipe the
screen.

2. Make sure the excess water is off the screen, then let air-dry before you turn on the TV.

Set the auto configure or adjust clock, phase or H/V
position

- Re-install the PC video card

Cleaning the Cabinet

To remove dirt or dust, wipe the cabinet with a soft, dry, lint-free cloth. Please be sure not to use a wet
cloth.

Extended Absence

If you expect to leave your TV dormant for a long time (such as a vacation), it is a good
idea to unplug the power cord to protect against possible damages from lightning or
power surges.

24

The FCC Wants You To Know

This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed or
used in accordance with the instructions, may cause harmful interference to radio communica­tions. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures: 1) reorient or relocate the receiving an­tenna; 2) increase the separation between the equipment and the receiver; 3) connect the equip­ment to an outlet on a circuit different from that to which the receiver is connected;

4) consult the dealer or an experienced radio/TV technician for additional
suggestions.

Any changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment. Where shielded interface cables have
been provided with the product or specified additional components or accessories elsewhere de­fined to be used with the installation of the product, they must be used in order to ensure com­pliance with FCC regulation.

Canadian DOC statement
Standard Television Receiving Apparatus Canada BETS-7
This Class B digital apparatus complies with Canadian ICES-003.

Specifications

eziSlenaP

epyTyalpsiD

ygolonhceTlenaP

zH021svzH06lenaP

noituloseRyalpsiD

elbitapmoCDH

noituloseRlenaP

oitaRtcepsA

lenap-Dynamic Contrast Ratio

Brightness (Centre Typ.) cd/m2

)GotG(emiTesnopseR

)sruoH.pyT(efiLpmaL

Horizontal Viewing Angle (At CR>10)

42

DCL
TFT

zH60

P0801

9:61
6,000:1
500

6.5 ms

176

yllanogaidsehcni

p0801otpu

0801x0291

sruoh0000,6

Vertical Viewing Angle (At CR>10)

176

25

This product contains electrical or electronic materials. The presence of these materials may, if not disposed of properly, have potential
adverse effects on the environment and human health.
Presence of this label on the product means it should not be disposed of as unsorted waste and must be collected separately. As a
consumer, you are responsible for ensuring that this product is disposed of properly. To find out how to properly dispose of this product,
please go to www.elementelectronics.com and click on Sustainability.

This TV incorporates High-Definition Multimedia Interface (HDMI ) technology. HDMI, the HDMI logo and High-Definition Multimedia

TM

Interface are trademarks or registered trademarks of HDMI Licensing LLC.
