Electro-voice FORCE BROCHURE

FORCE

®

SPEAKER

SERIES

Force®–

Far Beyond the Ordinary!

The Force®series represents
the very best mix of price
and performance without
a sacrifice in sonic integ r ity.
EV engineers took the
classic EV sound and put
it in a speaker that anyone
can afford.

RMD®removes
mechanical and
acoustic resonances
in the enclosure
and components
so that only pure
audio remains.

Force®Amplifier

• Designed to maximize the
performance and protection
of Forc e

®

speakers.

• State-of-the-art limiters
prevent amplifier clipping
and deliver maximum sound
level from the system.

• High-current, Neutrik
Speakon

®

output connectors.

• Rear-mounted,dB-scaled
detented level controls for
easy gain control.

Force®Sub

High-Output, Dual,
15-Inch, Slot-Loaded
Woofer System

• Integral, passive,crossover
filter combined with unique
acoustic design allows
for parallel operation
with full-range systems
for added bass response.

• 300-watt continuous
power-handling
capability.

• Vault-like enclosure
construction with
strong internal bracing
for loss-free bass.

• Top-mounted 1

3

⁄8-inch

stand adapter.

Force

®

Two-Way, Full-Range Speaker

• RMD®(Ring-Mode Decoupling) technology
provides crystal clear highs, detailed mids and
thundering lows with exceptional vocal clarity
and intelligibility.

• Unique enclosure design presents minimal
frontal cross section while still maintaining
substantial internal volume.

• High-Q 60° x 40° CD horn and pure titanium
compression driver project sound further than
any competitive model.

• 200-watt,long-term power rating.

Force®Monitor

12-Inch, Two-Way, High-Output Stage System

• Versatile design allows for use as a floor monitor or stand-mounted
main PA speaker.

• 150-watt,continuous; 600-watt,short-ter m power handling.

• CD hor n provides 55° horizontal x 80° vertical coverage in the
floor-monitor orientation.

• Choice of paralleled

1

⁄4-inch or Neutrik Speakon®(E models) connectors.

• Integral 1

3

⁄8-inch stand mount.

Force

®

Frequency Response 60-20,000 Hz
Power Handling

EIA RS-426A (1980) 200 watts
Sound Pressure Level (1 W/1 m) 99 dB
Dispersion Angle (h x v) 60° x 40°
Impedance (Nominal/Minimum) 8 ohms/5.3 ohms
Connectors

Standard

1

⁄4-in.

E Models Neutrik Speakon

®

Dimensions (hwd) 768 mm (30.25 in.) x

429 mm (16.9 in.) x
381 mm (15 in.)

Net Weight 27.4 kg (60.5 lb)

Force® Sub

Frequency Response 47-125 Hz
Power Handling

EIA RS-426A (1980) 300 watts
Sound Pressure Level (1 W/1 m) 100 dB (half space)
Dispersion Angle (h x v) Omnidirectional
Impedance (Nominal/Minimum) 8 ohms/6.8 ohms
Connectors

Standard

1

⁄4-in.

E Models Neutrik Speakon

®

Dimensions (hwd) 617 mm (24.3 in.) x

516 mm (20.3 in.) x
605 mm (23.8 in.)

Net Weight 40.6 kg (89.5 lb)

Force® Monitor

Frequency Response 90-16,000 Hz
Power Handling

EIA RS-426A (1980) 150 watts
Sound Pressure Level (1 W/1 m) 96 dB
Dispersion Angle (h x v) 55° x 80°

(floor-monitor orientation)
Impedance (Nominal/Minimum) 8 ohms/6.4 ohms
Connectors

Standard

1

⁄4-in.

E Models Neutrik Speakon

®

Dimensions (hwd) 546 mm (21.5 in.) x

361 mm (14.2 in.) x

246 mm (9.7 in.)
Net Weight 12.7 kg (28 lb)

Force® Amplifier

Maximum Midband Output Power

at 8 Ohms, Dual Mode 280 W per channel
at 4 Ohms, Dual Mode 450 W per channel
at 2 Ohms, Dual Mode 650 W per channel
at 8 Ohms, Bridged 900 W

at 4 Ohms, Bridged 1,300 W
THD at Rated Output <0.05%
IMD (SMPTE), 60 Hz/7 kHz <0.08%
Signal/Noise Ratio,A-Weighted 103 dB
Damping Factor at 100 Hz/1 kHz >300/>200
Slew Rate 25 V/µs
Dimensions (hwd) 132.5 mm (5.22 in.) x

483 mm (19.0 in.) x

385.5 mm 15.2 in.)

Net Weight 15 kg (33 lb)

Our goal for EV’s new Force®speaker systems was

simple: make them sound like EV speakers but

cost a lot less.For the price of an ordinary speaker

system, you get the extraordinary EV sound

quality that leading artists, audio eng ineers and

DJs all over the world prefer.You also get the

same EV five-year transferable parts and labor

warranty and world-class service that usually

comes on products with much higher price tags.

Experience the extraordinary difference in

sound…experience the new Force®from EV.

Force

®

Speaker Series features:

• PRO™driver protection circuits

• CD horns for high frequencies

• RMD

®

(Ring-Mode Decoupling)

• Exceptionally strong and compact enclosures

• Ergonomically shaped handles for ease in
lifting and transportation

Force®Systems

Price and performance
come together when you

package our Force

®

system

components for maximum

value.

Top:

Traditional EV sound

at an affordable price:

The package includes

Force

®

Monitor speakers

with RMD

®

and Force

®

Amplifier.

Bottom:

A complete stage system,

with professional sound quality:

The Force

®

System combines the

new Forc e

®

Amplifier,dual Force

®

two-way speakers and accompanying

Force

®

Subs to provide maximum

performance from the individual

components.

Specifications

WHATEVER THE APPLICATION – CLUBS, CHURCHES, STADIUMS AND

EVERYWHERE IN BETWEEN – EV SPEAKERS, MICROPHONES AND

ELECTRONICS SET THE STANDARD FOR INNOVATION, PERFORMANCE,

VERSATILITY AND VALUE. BELIEVE IT TODAY BY PUTTING

EV TO WORK FOR YOU.

USA 12000 Portland Ave.South, Burnsville, MN 55337, Phone: [phone], FAX:[phone]
Canada 705 Progress Avenue,Unit 46, Scarborough, Ontario, Canada, M1H2X1, Phone: [phone], FAX: [phone]
Switzerland Keltenstrasse 11, CH-2563 IPSACH, Switzerland, Phone: [phone], FAX: [phone]
Germany Hirschberger Ring 45, D94302, Straubing, Germany,Phone: [phone], FAX: [phone]
France Parc de Courcerin,Allee Lech Walesa,Lognes, f-77185 Marne La Vallee, France, Phone: [phone], FAX:[phone]
Australia Unit 23,Block C, Slough Business Estate, Silverwater N.S.W. 2128, Australia, Phone: [phone], FAX:[phone]
Hong Kong Unit E & F,21/F,Luk Hop Industrial Bldg., 8 Luk Hop St., San Po Kong, Kowloon, Hong Kong, Phone: [phone], FAX:[phone]
Japan 2-5-60 Izumi, Suginami-ku, Tokyo,Japan 168, Phone: [phone], FAX:[phone]
Singapore 3015A Ubi Rd 1, 05-10, Kampong Ubi Industrial Estate, Singapore 408705, Phone: [phone], FAX: [phone]
Mexico Av.Parque Chapultepec #66-201, Naucalpan Edo. Mex. 53390, Phone: [phone], FAX:[phone]

For customer orders, contact the Customer Ser vice depar tment at

800/685-6386 Fax: [phone]

For warranty repair or service information, contact the

Service Repair department at 800/685-2606

For technical assistance, contact Technical Support at 800/234-6831

Please refer to the Engineering Data Sheet for warranty infor mation.

Specifications subject to change without notice.
