Electro-Voice EVID-P6.2 Data Sheet
Electro-Voice | EVID-P6.2 Pendant speaker 6.5"
EVID-P6.2 Pendant
speaker 6.5"
▪ Full bandwidth overload protection
▪ Front baffle wattage tap adjustment
▪ Magnetic grille for easy tap adjustment access
▪ Indoor and outdoor use
▪ UL1480A and CSA C22.2 certified for indoor
installations and protected outdoor installations
The Electro-Voice EVID-P6.2 loudspeaker system is a
complete two-way pendant loudspeaker. The package
consists of a bezel assembly, magnetic grille, rear
enclosure, 6.5-inch coax two-way loudspeaker and
internal line-matching transformer. The loudspeaker
features a titanium dome tweeter. The EVID-P6.2
loudspeaker utilizes a 2nd order crossover network
with a comprehensive protection circuit to protect the
network, woofer, and tweeter drivers from excessive
power levels. The EVID-P6.2 loudspeaker utilizes a
transformer that offers a selection of 1.88 (70-V only),
3.75W, 7.5W, 15W or 30 watts delivered to the
loudspeaker system using either 70-V or 100-V lines, or
8 ohm bypass. Selection is via a convenient switch on
the front baffle, easily accessible by removing the
magnetic grille.
The perforated grille is finished in semi-gloss black or
white powder-coated enamel. The baffle, bezel, and
rear-enclosure are constructed from UL 94V-0 rated
ABS. The connections on the rear provide access to a
4-pin terminal block that allows direct connection to
the speaker with 12 gauge wire and provides passthrough to additional speakers.
The EVID line of speakers has been designed to work
together as a complete system in a wide range of
different constructions. The pendant and ceiling
loudspeakers provide wide dispersion, high efficiency,
high-maximum output, ease of installation, and widerange reproduction of music or voice.
Technical specifications
Rated frequency range: 60 Hz - 20 kHz
Sensitivity (SPL 1 W/1 m): 87 dB
Coverage pattern1: 115° conical
Power handling (@ 8Ω): 75 W (with overload protection)
Rated impedance: 8 Ω
Recommended High-Pass
frequency:
Input configuration: 8Ω; 70V/100V
70V/100V power taps: 1.8 (70V only)/3.7/7.5/15/30 W
LF transducer: 6.5 in (165 mm) high-compliance
HF transducer: 1 in (25 mm) titanium dome
Mounting system: Rear mounted suspension points
Acoustic design: Ported cabinet, two-way design,
Approvals: CE, UL 1480A, CSA 22.2
Cabinet construction: UL94V-0 rated enclosure and
60 Hz
driver (weatherized cone)
internally damped, w/passive
crossover
baffle
Ø310.0 mm
[12.20 in.]
285.1 mm
[11.23 in.]
301.0 mm
[11.85 in.]
50 100 1000 10000 20000
1
10
100
60
70
80
90
100
Impedance (Ohms)
Sensitivity (dB)
Frequency (Hz)
Frequency Response, Full Space, 8 Ohm Tap
Impedance, 8 Ohm Tap
31.6
3.16
20
100 1000
10000 20000
Horizontal
Vertical
Frequency (Hz)
-
6dB Beamwidth (degrees)
10
50
100
360
10
50
100
360
100 1000 10000 20000
1
10
100
1000
0
10
20
30
Frequency (Hz)
Directivity Index (DI), dB
Directivity
2 | EVID-P6.2 Pendant speaker 6.5"
Grille construction: Powder-coated steel
Colors: Black or white
Dimensions (depth x diam.): 11.9 in x 12.2 in (301.0 mm x
310.0 mm)
Net weight: 11.65 lb (5.28 kg)
Shipping weight: 13.85 lb (6.28 kg)
Included accessories: Grille removal tool
1
Average 1 kHz to 10 kHz
Included hardware:
Pendant Suspension Cable
Material: Steel wire rope
Working load limit: 10 kg (22 lb)
Length: 4.57 m (15 ft.)
Approvals: UL2442
Architectural and engineering specifications:
The EVID P6.2 loudspeaker system shall be comprised
of a UL 94V-0 fire rated ABS baffle/bezel/enclosure
assembly, powder coated grille with safety tether that
attached magnetically to the bezel, transformer with 8
ohm bypass, and 6.5-inch polypropylene low frequency
transducer with coaxially-mounted 1 inch titanium
dome tweeter. The loudspeaker shall meet the
following criteria: power rating shall be 75 watts of EIA
RS-426A pink noise (6 dB crest factor). Frequency
response, uniform from 60 Hz to 20 kHz. Pressure
sensitivity, 87dB SPL at 1 meter (3.3 feet) on axis with
one watt of pink noise (ref. 20μPa). Minimum
impedance, 6.0 ohms. The loudspeaker shall be 301
mm (11.9.0 in.) deep and 310 mm (12.2 in.) in
diameter. Weight shall be 5.28 kg (11.65 lb). The
coaxial pendant loudspeaker shall be the Electro-Voice
model EVID-P6.2.
Dimensions:
Frequency response and impedance:
Beamwidth:
Directivity:
Ordering information
EVID-P6.2B Pendant speaker 6.5" black
Two-way 6.5" pendant speaker, with internal 30W
70/100 volt line transformer with 8 Ohm bypass, black
Order number EVID P6.2B
EVID-P6.2W Pendant speaker 6.5" white
Two-way 6.5" pendant speaker, with internal 30W
70/100 volt line transformer with 8 Ohm bypass, white
Order number EVID P6.2W
