Electro-Voice®Eliminator™i is a family of pro-grade sound
reinforcement components—full-range loudspeakers, subs,
and amp—engineered to play together as an integrated
system. Eliminator i is ideal for bands and mobile DJs who
want incredible sound without burning all their gig money
on equipment, or endlessly tweaking a complicated setup.
Just cable-up the matched Eliminator i components
and play your music.
Stolen Technology
Eliminator i systems sound great because EV®engineers
lifted some advanced technology from our touring concert
sound systems and applied them to Eliminator i components.
For example, every Eliminator i loudspeaker employs our
unique RMD
®
(Ring Mode Decoupling) technology which
controls the sound-mangling mechanical resonances in a
speaker. You get clean, accurate reproduction of voice and
instruments. We also took the Low Pass Notch (LPN) module
from the Electro-Voice AC One Audio Controller and put it into
the Eliminator i amplifier.This innovative circuitry is specifically tuned for the Eliminator i loudspeaker system. Performance
takes a quantum leap. Low-end output is stunning! We’ve
given you more of what you want without adding more gear
to lug around.
Rock-Solid Core
Eliminator i amps and loudspeakers give you a professionallevel core around which you can build a really awesome, yet
affordable, sound system. Add Electro-Voice N/DYM
®
and
Cobalt
™
wired and wireless mics. Add a Venice mixer, the
kid-sister version of the monster touring consoles from
Midas. When music is your life and livelihood, don’t wreck it
with an amateur sound system. Step up to the intense,
incredible performance of Electro-Voice Eliminator i.
Call 800-392-3497, or visit www. electrovoice.com
™
INTEGRATED LOUDSPEAKER, SUBS & AMP
Step up to Electro-Voice
®
Page 2
Frequency response: 13 Hz–45 kHz, +0/-3 dB
Continuous rated output power3:
dual mode, 4Ω: 600 watts bridged mode, 4Ω: 1700 watts
Total harmonic distortion: <0.05%
Input connectors: 3-pin female XLR for each channel; paralleled with male XLR outs for easy signal routing
Output connectors: Neutrik®Speakon®NL4MP for channels A, B, and bridged mode
Operating voltage: 120VAC, 60 Hz
Power consumption4: 870 watts
Cooling: front-to-rear airflow, two 3-speed fans
Dimensions: 5.25”h (3 RU) x 19”w x 15.17”d
(13.25 cm x 48.3 cm x 38.6 cm)
Net weight: 35.2 lbs. (16 kg.)
ELIMINATOR™I TECHNICAL SPECIFICATIONS
Frequency response1: 50 Hz–20 kHz, ±3 dB 50 Hz–20k Hz, ±3 dB 40–100 Hz, ±3 dB 35–160 Hz, ±3 dB
Long-term average power handling2:
350 watts 600 watts 400 watts 1000 watts
Sound pressure level: 99 dB 100 dB 98 dB 101 dB
Dispersion angles: 60° horizontal, 40° vertical 60° horizontal, 40° vertical ——
Impedance: 8Ω nominal, 5.2Ω minimum 4Ω nominal, 3.3Ω minimum 8Ω nominal, 5.1Ω minimum 4Ω nominal
Nominal 4Ω with Eliminator i in
satellite configuration.
Connectors: parallel 1/4” phone jacks parallel Neutrik®Speakon®NL4MP 1/4” phone input, 1/4” phone parallel Neutrik®Speakon®NL4MP
output to Eliminator i.
Dimensions: 30.25”h x 16.9”w x 24”d46”h x 17.4”w x 24.25”d 33.8”h x 17.25”w x 24.13”d 45.7”h x 22.5”w x 23.7”d
(76.8 cm x 42.9 cm x 60.9 cm) (116.84 cm x 44.2 cm x 61.6 cm) (85.9 cm x 43.8 cm x 61.0 cm) (116 cm x 57.2 cm x 60.2 cm)
Net weight: 84 lbs. (38.1 kg.) 119 lbs. (53.98 kg.) 87 lbs. (39.5 kg.) 145 lbs. (65.8 kg.)
Includes 1 3/8-inch stand adapter Includes 1 3/8-inch stand Includes 1 3/8-inch stand adapter
mounted in enclosure bottom. adapter mounted in enclosure mounted in enclosure top,
top, and 18-inch steel pole for and 18-inch steel pole for
elevating Eliminator i full-range elevating Eliminator i full-range
cabinet above subwoofer. cabinet above subwoofer.
Eliminator™i
full-range loudspeaker
Two-way, high-output, 350 watt
stage system. Features a 15-inch
low-frequency driver and
constant-directivity high-frequency
horn for clear, up-front sound
that cuts through difficult
acoustic environments. Black
carpeted enclosure presents
minimal front cross section. Easy
to transport. Rugged, tour-grade
construction, heavy metal grille,
and corner protection.
Eliminator™i amplifier
Low distortion amplifier with substantial headroom for excellent performance from Eliminator i system or similar-voiced
loudspeakers. Dual-channel or bridged operation. LPN module compensates for transducer inertial dampening losses.
Provides full, extended bass response. Sophisticated built-in limiters protect speakers from amplifier clipping while
preserving sonic integrity of source signal. Extensive protection against overload, overtemp, excessive HF, excessive
back-EMF, inrush current, shorted loads, RFI, power up/down transients, and DC faults.
1
Measured at 10 feet on-axis, normalized to 1 watt/1 meter.
2
Per EIA standard RS-426-A.
3
20 Hz–20 kHz at < 1% THD, both channels driven per EIA RS-490.
4
Both channels operating in dual mode at 1/8 max. output power at 4Ω.
©2002 Telex Communications,Inc. PA20535 9/02
Telex Communications, Inc.
12000 Portland Avenue South
Burnsville, Minnesota 55337
p: 952.884.4051
f: 952.884.0043
www.telex.com
Eliminator™ii
dual full-range loudspeaker
Two-way, high-output, 600 watt
stage system. Dual 15-inch drivers
provide very smooth output at lower
frequencies with low distortion.
Constant-directivity high-frequency
horn. Black carpeted enclosure
presents minimal front cross section.
Easy to transport. Rugged, tour-grade
construction, heavy metal grille, and
corner protection.
Eliminator™i
subwoofer
Single 18-inch high-output woofer
designed to complement Eliminator i
and ii full-range cabinets. Integral
low-pass crossover filter, combined
with unique acoustic design, allows
parallel operation with full-range
systems for nice, punchy bass.
Eliminator™kW
high output subwoofer
Dual 18-inch high-output drivers.
Designed for mobile DJs and bands
who demand high-output/SPL and
titanic bass. Features oversized vent
and sealed pocket wheels for easy
transport and set-up.
Turn it on and turn it up!
