Page 1
Item
Model
ProjectName
XBM20 Table Model in
Stainless Steel with
Hub
Powerful motor that provides all the basic
mixer functions faultlessly: kneading of all
sort of pastes, mixing of semiliquid
products, emulsions and various
sauces.The best results, in particular for
the mixing of pastries, is one of the key
features of DITO mixers.The increasing
speed facilitates the preparation of
mousses and emulsions by significantly
reducing the operation time.The easy and
precise speed regulation, highly
appreciated by the chefs, makes it a
versatile appliance suitable for preparing
various recipies.
601718
FEATURES
V With a 750 W rating, the
XBM20 can handle hard, low
hydration kneadings for speciality
breads. Used with the
recommended quantities, it can
also be used to produce pizza
dough.
V Body in stainless steel.
V 18/8 Stainless steel bowl - 3
tools: hook, paddle and whisk.
V Touch button control panel
improves the ergonomics and the
reliability against the humidity or
water jets.
V Control panel equipped with
0-59 minute timer.
Planetary mixers
Page 2
V Revolving and dismountable
safety guard fitted with a removable
feeding arm for adding products
while the machine is operating.
V Accessory drive hub for extra
functions: vegetable cutter, meat
puree strainer and sharpening
grindstone.
V XBM20 is constructed in
compliance with EN 454 European
regulation on Beater-mixers safety
and hygiene.
mincer,
Specifications
MODEL
Bowl Capacity lt 20
External dimensions - mm
width 521
depth 685
height 1010
Working capacity - kg of flour
Choux pastry 3
Shortcrust pastry 5
Cold water paste 6
Sweet pastry 4
Croissant 5
Brioche 5
Meat kg 10
Puree - kg of potatoes 10
Power - kW
installed-electric 0.75
Net weight - kg. 76
Supply voltage 200...240/380...415, 3, 50
XBMF20AXT3
601719
Page 3
Included accessories
CODE DESCRIPTION
653426 BOWL FOR 20LT MIXER 1
653114 DOUGH HOOK FOR 20LT MIXER 1
653116 PADDLE FOR 20LT MIXER 1
653109 WHISK FOR 20LT MIXER 1
Optional accessories
CODE DESCRIPTION
653064 10L BOWL,HOOK,PADDLE,WHISK FOR 20L
MIXER
653426 BOWL FOR 20LT MIXER ✓
653114 DOUGH HOOK FOR 20LT MIXER ✓
653016 MEATMINCER 70MM-H
HUB-ENTERPR.CUT+3DISCS
653116 PADDLE FOR 20LT MIXER ✓
653226 PLANETARY MIXER 10L-H HUB-DISCONN.DRIVE ✓
653187 PUREE STRAINER FOR H HUB WITH 3 GRIDS ✓
653254 REINFORCED WHISK FOR 20LT MIXER ✓
653435 S/S DISH SHELF FOR 20L/30L PLANET. MIXER ✓
653434 S/S TABLE FOR 20LT PLANETARY MIXER ✓
653062 SHARPENING GRINDSTONE FOR H HUB ✓
653225 VEGETAB.CUTTER H
HUB+EJECTOR-DISCONNECT.
653015 VEGETABLE CUTTER H HUB WITH EJECTOR ✓
653109 WHISK FOR 20LT MIXER ✓
✓
✓
✓
Page 4
Installation drawings
XXX
601719
1008
I
685
MODEL
I - Electrical connection 200...240/380...415, 3, 50
The manufacturer reserves the right to modify and make improvements to the products without
giving prior warning. Dimensions, illustrations, technical data, weights, etc. are given as an
indication only.
190
521
XBMF20AXT3
601719
www.dito-electrolux.com
Planetary mixers
ADAC040
