High Productivity Cooking

Electric Tilting Bratt Pan

High Productivity Cooking
Electric Tilting Bratt Pan 80lt

584548 (TFET08EEFO)Electric Tilting Braising Pan –

Short Form Specification

Item No.

Unit to be Electrolux Electric Tilting Braising Pan 80 liter capacity. Electric
characteristics to be ____400 V three phase. Unit shall have polished
chromium nickel molybdenum steel plated cooking surface for roasting,
browning, stewing, preparation of sauces, sautéing, boiling and braising.
Unit shall be floor mounted on two consoles with four adjustable Stainless
steel feet.
Unit shall include motorized variable tilting of pan and fully insulated and
counterbalanced closing lid. Cooking temperature and cooking time can be
precisely set through state of the art control panel.
Food sensor temperature built into base plates permits precise temperature
cooking.

80 liter 400 V

ITEM #

MODEL #

NAME #

SIS #

80lt

AIA #

Main Features

•Cooking vessel in 316 Stainless steel (11 gauge).

•Cooking Surface in 15 mm thick plating with 3 mm

Stainless steel 316 for sautéing, poaching,
steaming, boiling, stewing. Cooking surface
divided in two independent zones in order to cook
different types of food at the same time.

•The bottom remains free of distortion and cracks.

•Double –skin structure of panels and lid to reduce

heat dispersion.

•The lid, mounted on the cross beam of the unit,

shall be counterbalanced by a special hinge that
remains open in all positions.

•Lid is double-lined, insulated in 304 AISI Stainless

steel.

•IPX6 controls water resistance certification.

•Actual cooking/holding temperature setting and

digital display.

•Timer with digital display.

•Built in food temperature sensor for precise

control of cooking process.

•An electronic microprocessor control system with

digital pre-selection of food cooking temperature,
cooking time and starting time.

•“Frying” operating mode with temperature over

110 °C.

•“Cooking” operating mode with temperature equal

or lower than 110 ºC.

•A SOFT setting for a gentle heat input, for delicate

products thus avoiding undesired spillage.

•Heat-insulated: limited heat radiation and low

energy consumption.

•Motorized and variable tilting. Titling and pouring

speeds can be precisely adjusted.

•Offset tilting axle for convenient pouring height.

•Large directional pouring lip.

•Added safety: external heat-insulated paneling.

•Smooth large surfaces, easy access for cleaning.

•All pan internal surfaces round and polished.

•Pan tilts over 90° for complete emptying/cleaning.

Electric Tilting Bratt Pan 80lt

High Productivity Cooking

APPROVAL:

Electrolux Professional

www.electrolux.com/foodservice

[e-mail]

High Productivity Cooking

Electric Tilting Bratt Pan

80lt

Front

Electric

Supply voltage:

584548(TFET08EEFO)400 V/3N ph/50/60 Hz

Total Watts:15.5 kW

Key Information

Distance to floor of pouring lip
when tilted:493 mm

Working Temperature MIN:50 °C
Working Temperature MAX:250 °C
Pan useful capacity:
Width of Pan:730 mm
Height of Pan:200 mm
Depth of Pan:600 mm
Net weight:240 kg

Top

Shipping weight:258 kg
Shipping height:700 mm
Shipping width:1300 mm
Shipping depth:900 mm
Shipping volume:1.58 m³

No clearance needed on rear sides of unit if wall is of non combustible
type. If wall is combustible, minimum 50 mm wall clearance should be
maintained.

Water fill faucet/ shower to be mounted close to unit for filling and
cleaning (not supplied).

CWI=Cold Water inlet

EI=Electrical connection

HWI=Hot water inlet

Side

High Productivity Cooking

Electric Tilting Bratt Pan 80lt

The company reserves the right to make modifications to the products

without prior notice. All information correct at time of printing.
