Page 1
37 29 33
3.45 3.53 3.38
102 129 113
0.92 0.94 0.91
T3190
7.5/17
190
680
6/8
20 500 (6)
Tumble dryer
T3190
Certified in accordance with ISO 9001 and ISO 14001 and approved IP X4.
Main specifications
Rated capacity kg/lb
Drum volume litre
Drum diameter mm
Heating alternatives
electric kW
gas BTU/h (kW)
Consumption data*
Total time full load min
Energy consumption full load kWh
Evaporation g/min
Energy kWh/litre water evaporated kWh
Features and benefits
• High productivity – 2 full loads per hour
• Low energy consumption for optimal efficiency
• Selection of temperature and time for easy operation
• Residual Moisture Control for an accurate drying result
and a low energy consumption
• Reversing drum for less tangling of large items
• Unique Auto Lint Clean (ALC) principle for easy
maintenance and convenient weekly emptying of lint
• Reversable door hanging for a convenient laundry flow
• Easy access to vital parts from front and rear for
simple servicing
• Selecta Microprocessor control
-6 taylor made programs for any drying need
- Accurate temperature control for unmatched drying
accuracy
- Anti-crease cycle for avoiding creasing if the dryer is
not unloaded
- 19 error codes for easy trouble shooting
• Serviceprogram for adjustment of 20 paramenters eg.
temperature and cool-down time
Main options
• Stainless steel front
• Stainless steel drum
• Payment: coinmeter, chipcard reader, CP connection
• Stainless steel base frame
• Heat recovery system: Heat Recovery Pipes (HRP)
• Separate condense system
•
Fresh air intake
• Supply disconnector
6 kW 8 kW Gas 6 kW
* At rated capacity 100% cotton load at 50% initial moisture dryed to 0%.
Page 2
5390
C
A
1
D
B
4
3
K
I
3
F
EH
G
L
4
2
5
T3190
6.3 (20)
8.3 (25)
6.3 (10)
8.3 (16)
0.3 (10)
0.3 (10)
0.3 (10)
0.3 (10)
1/2"
2000
20
2800-5000
30
125
290
290
220
150
150
<70
15
99
110
0.8
720
745
1110
350
990
85
325
55
1030
40
1445
ELECTROLUX LAUNDRY SYSTEMS
Electrical connections
Heating Voltage
El. 200-240V 3AC 50/60 Hz kW(A)
kW(A)
400-440V 3NAC 5 0 /60 Hz kW(A)
kW(A)
Gas 230-240V 3AC 50/60 Hz kW(A)
400-440V 3NAC 5 0/60 H z kW(A)
230V 1AC 50 Hz kW(A)
120V 1AC 60 Hz kW(A)
Gas and air connections
Gas ISO 7/1-R
Gas pressure
Natural gas Pa
mbar
Propane Pa
mbar
Air outlet ø mm
Evacuated air 6 kW (el) m
3
/h
8 kW (el)
6 kW (gas)
Pressure drop (el/gas) 6 kW Max. Pa
8 kW
Sound levels
Airborne sound level
dB(A)
Heat emission
% of installed power, max
Shipping data
net, kg
crated, kg
crated, m
3
Dimensions in mm
A Width
B Depth
C Height
D
E
F
G
H
I
K
L
1 Door opening ø 400
2 Electrical connection
3 Gas connection
Rear side
Front
Left side
Art. No. 438908181/08 04.07
We reserve the right to alter specifications without notice.
The Electrolux Group. The world´s No.1 choice.
The Electrolux Group is the world´s largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers,
washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx. USD 14 billion in more than 150 countries around the world.
Lundtoftegaardsvej 93A, DK-2800 Lyngby, Denmark
Telephone: +45 4526 4800. Telefax: +45 4526 4801
Internet: www.electrolux.com/laundrysystems
E-mail: [email protected]
4 Exhaust connection
5 Central payment connection
* Other voltages available see installation manual.
