Page 1
Electrolux 160 Lt line
Freezer counter 160 Lt
The Electrolux 160 liter is the solution for customers needing reliable, compact and easy to
use cold storage. All the internal finishings are in commercial grade High Impact
Polystyrene. The range consists of 2 undercounter freezers in stainless steel or
pre-painted white with full door.
EASY TO INSTALL
• All models require only 1 phase
220/240V supply. They can
therefore be plugged straight into
an existing power socket.
• Adjustable front feet.
• Reversible door.
EASY TO CLEAN
• The runners for the shelves are
thermoformed and incorporated in
the inner structure therefore being
easily cleanable.
• The whole interior cell is in white
High Impact Polystyrene, has
rounded corners, and has no
joints to eliminate dirt traps.
• IP23 protection index make it
possible to clean the unit with a
hose at standard pressure.
EASY TO USE
• Designed to operate at ambient
temperatures up to 43°C .
• Very quiet operation: noise level
less than 45 dB (A).
• Simple control panel.
• Digital temperature display and
electromechanical or digital
control.
• Door lock on both models.
EASY TO MAINTAIN
• Compact cooling unit easily
accessible from the rear of the
appliance.
• Manual defrost and automatic
evaporation of defrost water.
EASY ON THE ENVIRONMENT
• CFC and HCFC free insulation.
• R134 gas in refrigeration circuit.
• Developed and produced in ISO
9001 and ISO 14001 certified
factory.
Page 2
Electrolux 160 Lt line
Freezer counter 160 Lt
Internet: http://www.electrolux.com/foodservice
HAGA0202010-12-17
Net weight - kg. 50 50 50 50
Noise level - dBA 45 45 45 45
installed-electric 0.124 0.124 0.12 0.12
Power - kW
at evaporation temperature - °C -30 -30 -30 -30
Refrigerant power
Refrigeration power - W 153 153 153 153
Refrigerant quantity - g. 110 110 110 110
Refrigerant type R134a R134a R134a R134a
N° and type of grids (included) 3 3 3 3
Door hinges Right Side Right Side Right Side Right Side
N° and type of door 1 1 1 1
height adjustment 10 10 10 10
height 825 825 825 825
depth/with open doors 637 637 637 637
width 600 600 600 600
External dimensions - mm
Control type Electronic Electronic Electronic Electronic
Cooling unit Built-In Built-In Built-In Built-In
Gross capacity (D.I.N. 8952) - l. 110 110 110 110
panels High Impact White
Polystyrene
High Impact White
Polystyrene
High Impact White
Polystyrene
High Impact White
Polystyrene
Internal material
door Stainless steel
antifingertip
Prepainted white Stainless steel
antifingertip
Prepainted white
External material
top panel Grey ABS White ABS Grey ABS White ABS
side panels Prepainted Steel Prepainted white Prepainted Steel Prepainted white
External panels
Operating mode Static Static Static Static
first compartment - min/max °C -24 / -15 -24 / -15 -24 / -15 -24 / -15
Operating temperature
TECHNICAL DATA
RUCF16X1
727224
RUCF16W1
727226
RUCF16X1G
727225
RUCF16W1G
727227
Page 3
Electrolux 160 Lt line
Freezer counter 160 Lt
Internet: http://www.electrolux.com/foodservice
HAGA0202010-12-17
EI - Electrical connection 230 V, 1, 50 230 V, 1, 50 230 V, 1, 50 230 V, 1, 50
LEGEND
RUCF16X1
727224
RUCF16W1
727226
RUCF16X1G
727225
RUCF16W1G
727227
727224, 727227, 727225, 727226
597
825
1170
565
600
17,5
17,5
455
72
EI
625
10
30
