Electrolux RS06FX1F4 726457, RS06FX1F 726318, RS06F41FS 728303, RS06FW1F 726474, RS06FX2H 726690 Technical Data Manual
...Page 1
Electrolux Benefit Cabinets
Digital freezers - 600 lt
The models detailed on this sheet are 600 liter fan assisted refrigeration cabinets that offer
excellent standards in terms of performance and efficiency. They come in various types of
materials (304 AISI, stainless steel or white painted steel) and are available with solid
doors, either full or half height. Model RS06FX1FR has a remote refrigeration unit.
726318
• External panels in 304 AISI,
stainless steel or white coated
galvanized steel. Galvanized steel
back panel and stainless steel
bottom panel as standard on all
models.
• Digital control panel allowing the
easy and precise setting and
control of the internal temperature.
• Completely automatic defrosting
and automatic evaporation of
defrost water (304 AISI models),
manual emptying of defrost water
(stainless steel models).
• Internal panels and door in 304
AISI or stainless steel .
• 150 mm height adjustable feet.
• High standards of hygiene and
ease of cleaning are guaranteed
by the rounded internal corners of
the cabinet and easily removable
runners and grids (without the use
of tools).
• The refrigeration unit can
operate in tropical climates (+43°C
ambient temperature).
• Excellent forced air cooling
system that ensures the utmost
uniformity of temperature in the
cabinet and guarantees a perfect
storage quality of the goods.
• High-density expanded
polyurethane insulating foam, 60
mm in thickness, with
cyclopenthane injection,
guarantees exceptional, long-term
insulation and notable energy
savings.
• The rational use of the internal
space of the refrigerator
guarantees a large storage area
suitable to contain 2/1 GN grids.
Page 2
Electrolux Benefit Cabinets
Digital freezers - 600 lt
Internet: http://www.electrolux.com/foodservice
HAEB010_Copy2009-07-05
REMOTE UNIT -24-15°C FOR
550/650 LT
880244
PRINTER HACCP BASIC
VERS-REF.DIGIT.CONTR
881457 881457 881457 881457 881457 881457 881457
2/1 GN GREY "RILSAN" GRID 880720 880720 880720 880720 880720 880720 880720
2 WHEELS FOR
REFRIGERATORS/REFRIG.TABLES
880539 880539 880539 880539 880539 880539 880539
ACCESSORIES
2/1 GN GREY "RILSAN" GRID 3 3 3 3 4 3 3
INCLUDED ACCESSORIES
Power supply - V, phases, Hz 230 V, 1, 50 230 V, 1,50230 V, 1, 50 230 V, 1,50230 V, 1,50230 V, 1, 50 230 V, 1, 50
Net weight - kg. 134 134 128 134 134 134 134
Internal light ●
installed-electric 0.66 0.66 0.66 0.66 0.66 0.175 0.66
Power - kW
Refrigeration power - W 780 780 780 780 780 843 780
Refrigerant quantity - g. 300 300 300 300 300 300
Refrigerant type R404a R404a R404a R404a R404a R404a R404a
N° defrost in 24 hrs. 4/30' 4/30' 4/30' 4/30' 4/30' 4/30' 4/30'
N° and type of grids (included) 3, GN 2/1 3, GN 2/1 3, GN 2/1 3, GN 2/1 4, GN 2/1 3, GN 2/1 3, GN 2/1
Door hinges Right Side Right Side Right Side Right Side Right Side Right Side Right Side
height 2000 2000 2000 2000 2000 2000 2005
depth/with open doors 788, 1440 788, 1440 788, 1440 788, 1440 788, 1450 788, 1440 788, 1440
width 720 720 720 720 720 720 720
External dimensions - mm
Cooling unit Built-In Built-In Built-In Built-In Built-In Remote Built-In
Gross capacity (D.I.N. 8952) - l. 600 600 600 600 600 600 600
internal 304 AISI 304 AISI AISI 430 AISI 430 AISI 304
Scotch
Brite
304 AISI 304 AISI
external 304 AISI 304 AISI AISI 430 Prepainted
Steel
AISI 304
Scotch
Brite
304 AISI 304 AISI
Type of stainless steel
Operating mode Ventilated Ventilated Ventilated Ventilated Ventilated Ventilated Ventilated
Operating temperature - min/max
°C
-22/-15 -22/-15 -22/-15 -22/-15 -22/-15 -22/-15 -22/-15
TECHNICAL DATA
RS06FX1F4
726457
RS06FX1F
726318
RS06F41FS
728303
RS06FW1F
726474
RS06FX2H
726690
RS06FX1FR
727104
RS06FX1FG
726966
• Reversible self-closing door, in
positions less than 90°, with a
stop at 95° and a maximum
opening at 180°, equipped with a
magnetic door seal to guarantee
perfect closure. The pressed
stainless steel recessed door
handle without joints makes
opening the cabinet extremely
easy. All the doors are fitted as
standard with locks and keys and
a microswitch to switch off the fan
when the door is opened.
• Feet with stainless steel finish.
• A wide range of optional
accessories are available.
• Extremely quiet operation at 51
Db(A).
• CFC and HCFC free.
• All models comply with the
standards required by the main
international approval bodies and
are H marked.
Page 3
Electrolux Benefit Cabinets
Digital freezers - 600 lt
Internet: http://www.electrolux.com/foodservice
HAEB010_Copy2009-07-05
EI - Electrical connection 230 V, 1, 50 230 V, 1, 50 230 V, 1, 50 230 V, 1, 50
LEGEND
RS06FX1F4
726457
RS06FX1F
726318
RS06F41FS
728303
RS06FW1F
726474
726457, 726474, 728303, 726318
Page 4
Electrolux Benefit Cabinets
Digital freezers - 600 lt
Internet: http://www.electrolux.com/foodservice
HAEB010_Copy2009-07-05
EI - Electrical connection 230 V, 1, 50
LEGEND
RS06FX2H
726690
726690
Page 5
Electrolux Benefit Cabinets
Digital freezers - 600 lt
Internet: http://www.electrolux.com/foodservice
HAEB010_Copy2009-07-05
RI - Remote refrigeration connection ●
EI - Electrical connection 230 V, 1, 50
ED - Remote electrical connection ●
LEGEND
RS06FX1FR
727104
727104
Page 6
Electrolux Benefit Cabinets
Digital freezers - 600 lt
Internet: http://www.electrolux.com/foodservice
HAEB010_Copy2009-07-05
EI - Electrical connection 230 V, 1, 50
LEGEND
RS06FX1FG
726966
726966
