RCDR3M06
file: technical bulletin (wash
Identification:
D04
Technical Bulletin
Bulletin no:
Date:
Issuer:
Factory:
Subject
Model
Problem
Reason
Action in
Factory
CGX2003-19 (page 1 of 1), 3rd
26 February 2004
R. Sartor (Customer Support Dept.)
DW Vallenoncello - Italy
Wash Pump in HT
Hood Type high capacity (LS 10EA-14EA / WT 65E) range.
None.
Suppliers standardization.
Since serial no. 30500001 we have introduced the wash pump 0L0027 instead
of 048216.
The electrical connector is the unique difference between them (they have
same electrical and hydraulic characteristics).
Of course also the wiring harness has been changed according to above new
wash pump.
Action in
Field
OLD
The “new” wash pump is not interchangeable towards the “old” one.
Be aware that the connector of new wash pump has to be fitted as shown in
the picture below (numbers are marked on connectors):
NEW
