Electrolux 370 Lt Line
Refrigerators and Freezers
A range of 370 litre refrigerators and freezers designed to satisfy the food-conservation
requirements of professional caterers who want the high performance and reliability of a
commercial unit but who have limited space in the kitchen. The range consists of 4
compact models. Full door refrigerators and freezers in stainless steel or prepainted white.
727145
• Compact dimensions (60x60 cm
footprint), with top usable for extra
storage.
• LCD display with Turbo Cooling
cycle, a time-based chilling or
freezing cycle to maximise the
food shelf life and automatic
defrost.
• Easy temperature setting.
• Door lock as standard on all
models.
• Internal light as standard on all
refrigerators.
• No-frost technology as standard
in all freezers.
• High standards of hygiene and
ease of cleaning are guaranteed
by the high impact white
polystyrene internal cell with
rounded corners.
• Thick door on all models for
better insulation from the kitchen
environment.
• Fan as standard.
• Front adjustable feet and rear
wheels.
• Bottle holder as option for
optimal storage of wine bottles
and soft drinks.
• Built-in cooling unit for high
ambient temperatures (43°C for
refrigerators, 38°C for freezers).
• HCFC, CFC and HFC free
insulation (Cyclopentane) and
refrigerant gas (R600a).
• Developed and produced in an
ISO 9001 and ISO 14001 certified
factory.
• All models comply with the
standards required by the main
international approval bodies and
are H marked.
Page 2
Electrolux 370 Lt LineRefrigerators and Freezers
Internet: http://www.electrolux.com/foodservice
HAD00102009-10-06Subject to change without notice
Power supply - V, phases, Hz 230-240 V, 1, 50 230-240 V, 1, 50 230-240 V, 1, 50 230-240 V, 1, 50
Net weight - kg. 75 75 75 75
Noise level - dBA 44.5 44.5 44.5 44.5
installed-electric 0.101 0.101 0.066 0.066
Power - kW
at evaporation temperature - °C -26 -26 -30 -30
Refrigerant power
Refrigeration power - W 93 93 167 167
Refrigerant quantity - g. 36 36 46 46
Refrigerant type R600a R600a R600a R600a
N° and type of grids (included) 4 4 4 4
Door hinges Right Side Right Side Right Side Right Side
Min/Max internal humidity - % 70 70
height 1417 1417 1396 1396
depth 435 435 448 448
width 520 520 421 421
Internal dimensions - mm
height 1797 1797 1797 1797
depth/with open doors 597, 1137 597, 1137 597, 1137 597, 1137
width 595 595 595 595
External dimensions - mm
Gross capacity (D.I.N. 8952) - l. 370 370 270 270
panels Polystyrene Polystyrene Polystyrene Polystyrene
Internal material
door Stainless steel
antifingertip
Prepainted white Stainless steel
antifingertip
Prepainted white
panels Prepainted Steel Prepainted white Prepainted Steel Prepainted white
External material
Operating mode Ventilated Ventilated Ventilated Ventilated
Operating temperature - min/max °C 2/8 2/8 -24/-16 -24/-16
TECHNICAL DATA
EI - Electrical connection 230-240 V, 1, 50 230-240 V, 1, 50 230-240 V, 1, 50 230-240 V, 1, 50
LEGEND
R37P7VFX
727145
R37P7VFW
727143
R37F7VFX
727142
R37F7VFW
727147
727145, 727143 727142, 727147
