Electrolux 400 Lt Line
Stainless steel refrigerators & freezers
The Electrolux 400 litre non-gastronorm range is produced for the customer who does not need refrigeration
products suitable for gastronorm containers. This range is exclusive to Electrolux with regards its dimensions
and built quality. The product range comprises of white pre-painted steel models, stainless steel models, glass
door models and wine models. All the internal finishes are commercial grade ABS polystyrene. The models
detailed on this sheet are 5 stainless steel models.
730182
EASY TO INSTALL
• All models require only 1 phase
220/240V supply. They can
therefore be plugged straight into
an existing power socket.
EASY TO CLEAN
• The runners for the shelves are
thermoformed and incorporated in
the inner structure therefore being
easily cleanable.
• The whole interior cell is white
thermoformed polystyrene which
is impact resistant with rounded
corners.
• No joints whatsoever to
eliminate dirt traps.
EASY TO USE
• The models equipped with
roll-bond plate have a plate
installed in the internal backside of
the unit equipped with a special
thermostat to avoid ice formation.
No defrosting phases are required.
• Designed to operate at ambient
temperatures of 43 °C for
refrigerators, 38 °C for freezers
and fish models and 32 °C for
glass models.
• Very quiet operation.
• Fan assisted cooling for even
temperature distribution.
• Digital control panel allowing the
easy and precise setting and
control of the internal temperature.
EASY TO MAINTAIN
• Simple refrigeration system
easily accessible from the rear of
the units.
• All models in range finished in
top quality materials to guarantee
durability.
EASY ON THE ENVIRONMENT
• CFC and HCFC free
environmentally friendly: R134a or
R404a gas in refrigeration circuit.
Gas in foam: Cyclopentane.
• Developed and produced in ISO
9001 and ISO 14001 certified
factory.
Page 2
Electrolux 400 Lt Line
Stainless steel refrigerators & freezers
Internet: http://www.electrolux.com/foodservice
HAF0102011-11-10Subject to change without notice
PVC CONTAINER W/FALSE BOTTOM FOR
400 LT
881072 881072 881072 881072 881072
PRINTER FOR HACCP BASIC VERSION
REFRIG.
881457 881457 881457 881457 881457
PAIR OF GRIDS (WHITE) FOR 400LT
REFRIG.
880292 880292 880292 880292
2 WHEELS FOR
REFRIGERATORS/REFRIG.TABLES
880539 880539 880539 880539 880539
ACCESSORIES
PVC CONTAINER W/FALSE BOTTOM FOR
400 LT
5
PAIR OF GRIDS (WHITE) FOR 400LT
REFRIG.
2 2 2
INCLUDED ACCESSORIES
Net weight - kg. 75 75 77 85 77
Noise level - dBA 53.5 57 56 55 56
Internal light ●
installed-electric 0.17 0.38 0.53 0.19 0.35
Power - kW
at evaporation temperature - °C -12 -10 -29 -12 -12
Refrigerant power
Refrigeration power - W 306 339 881 249 339
Refrigerant quantity - g. 240 200 240 240 200
Refrigerant type R134a R134a R404a R134a R134a
N° defrost in 24 hrs. 2x30' 4/20' 2x30' 4/20'
Defrost type Automatic
(air)
Automatic
(electrical)
Manual Automatic
(air)
Automatic
(electrical)
Compressor power - HP 1/5 1/4 1 1/5 1/4
N° and type of basins 1+4,
600x300;
600x400
N° and type of grids (included) 4, 600x400 4, 600x400 600x400 4, 600x400
Door hinges Right Side Right Side Right Side Right Side Right Side
Min/Max internal humidity - % 84% 84% 84% 85%
height 1755 1755 1755 1755 1755
depth/with open doors 620, 1310 620, 1310 620, 1310 620, 1310 620, 1310
width 703 703 703 703 703
External dimensions - mm
Control type Digital Digital Digital Digital Digital
Cooling unit Built-In Built-In Built-In Built-In Built-In
Gross capacity (D.I.N. 8952) - l. 400 400 400 400 400
door Stainless
Steel
Stainless
Steel
Stainless
Steel
Glass Stainless
Steel
panels Stainless
Steel
Stainless
Steel
Stainless
Steel
Stainless
Steel
Stainless
Steel
External material
Operating mode Ventilated Ventilated Static Ventilated Ventilated
Operating temperature - min/max °C 0/10 -2/8 -24/-15 0/10 -6/6
TECHNICAL DATA
R04PVF4
730188
R04NVF4
730182
R04FSF4
730189
R04PVG4
730190
R04NVF4F
730183
Page 3
Electrolux 400 Lt Line
Stainless steel refrigerators & freezers
Internet: http://www.electrolux.com/foodservice
HAF0102011-11-10Subject to change without notice
EI - Electrical connection 230 V, 1N, 50 230 V, 1N, 50 230 V, 1N, 50
LEGEND
R04PVF4
730188
R04NVF4
730182
R04FSF4
730189
730188, 730189, 730182
700
1755
I
567
619
665
118.5
398.5101.6
55.5
587
55.5
90
90
518
Page 4
Electrolux 400 Lt Line
Stainless steel refrigerators & freezers
Internet: http://www.electrolux.com/foodservice
HAF0102011-11-10Subject to change without notice
EI - Electrical connection 230 V, 1N, 50
LEGEND
R04PVG4
730190
730190
700
1755
I
567
619 25
55.5 587 55.5
118.6398.5101.5
90 518 90
665
Page 5
Electrolux 400 Lt Line
Stainless steel refrigerators & freezers
Internet: http://www.electrolux.com/foodservice
HAF0102011-11-10Subject to change without notice
EI - Electrical connection 230 V, 1N, 50
LEGEND
R04NVF4F
730183
730183
