RANGE
COMPOSITION

N 900: a range of over 150 models
for the professional caterer designed
to guarantee the highest level of
performance, reliability, energy
saving, safety standards and
ergonomic operation. These
concepts are reflected in the total
modularity of the range that ensures
innumerable configurations, either
free-standing, bridged or cantilever.
N900 demonstrates how advanced
technology can satisfy the needs of
the professional caterer. The models
detailed on this sheet are 6/8
burners gas ranges on gas oven with
stainless steel grids.

200104

N 900

6/8 BURNERS GAS RANGES

FUNCTIONAL AND
CONSTRUCTION
FEATURES

� Burners with optimized

combustion interchangeable on site,

TECHNICAL DATA

CHARACTERISTICS MODELS

Power supply Gas Gas Gas Gas
External dimensions - mm
width 1200 1200 1200 1600
depth 900 900 900 900
height 850 850 850 850
height adjustment 50 50 50 50
Oven cavity - mm
width 575 575 575 575
depth 700 700 700 700
height 300 300 300 300
Oven
heat input - kW 8.5 8.5 8.5 17
temperature min-max - °C 120, 280 120, 280 120, 280 120, 280
Storage cupboard - mm
width 335 335 335
depth 740 740 740
height 350 350 350
Back burner dimensions - mm Ø 100, Ø 60, Ø 100 Ø 100, Ø 60, Ø 100 Ø 100, Ø 100, Ø 100 Ø 100, Ø 60, Ø 60, Ø 100
Back burners power - kW 10, 6, 10 7.5, 5.5, 7.5 10, 10, 10 10, 6, 6, 10
Front burners dimension - mm Ø 60, Ø 60, Ø 60 Ø 60, Ø 60, Ø 60 Ø 100, Ø 100, Ø 100 Ø 60, Ø 60, Ø 60, Ø 60
Front burners power - kW 6, 6, 6 5.5, 5.5, 5.5 10, 10, 10 6, 6, 6, 6
Total Power - kW 52.5 40.6 68.5 73
Net weight - kg. 203 203 203 300
Town gas l

INCLUDED ACCESSORIES

2/1 GN CHROME GRID 1 1 1 2
LEFT SIDE DOOR FOR OPEN BASE CUPBOARD 1 1 1

flame failure device and protected
pilot light:

- 60 mm burners with continuous
power regulation from 1,5 to 6 kW

- 100 mm burners with continuous
power regulation from 2,2 to 10 kW

NCFG1200

200104

NCFG1200T

200117

� Gas oven with stainless steel

burners, self-stabilizing flame
positioned beneath the base plate
and a thermostat adjustable from
120° to 280°C.

NCFG1201

200145

ZANUSSI

P R O F E S S I O N A L

NCFG1600

200105

6/8 BURNERS GAS RANGES

N 900

� Worktop in 20/10 stainless steel.

Front and side panels in stainless
steel with Scotch Brite finish.

� All models have right-angled side

edges to allow flush-fitting joins
between units eliminating gaps and
possible dirt traps.

� Stainless steel oven chamber with

3 levels of runners.

� Ribbed, cast-iron oven base plate.
� Inside door panel in stainless

steel.

� Stainless steel feet adjustables up

to a height of 50 mm.

OPTIONAL ACCESSORIES

ACCESSORIES MODELS

2 PANELS FOR SERVICE DUCT (BACK TO BACK) 206202 206202 206202 206202
2 PANELS FOR SERVICE DUCT (SINGLE INST.) 206181 206181 206181 206181
2 SIDE COVERING PANELS FOR TOP-D=900MM 206278 206278 206278 206278
2 SIDE COVERING PANELS H=700 D=900 206134 206134 206134 206134
2 SIDE KICKING STRIPS 206180 206180 206180 206180
2 SIDE KICKING STRIPS F.CONCRETE INSTAL. 206157 206157 206157 206157
2/1 GN CHROME GRID 164250 164250 164250 164250
4 FEET FOR CONCRETE INSTALLATION 206210 206210 206210 206210
4 WHEELS (2 WITH BRAKE) 206188 206188 206188 206188
CHIMNEY UPSTAND 1200MM 206306 206306 206306
DRAUGHT DIVERTER WITH 120 MM DIAMETER 206126 206126 206126 206126
ELECTRIC HEATING UNIT FOR CABINETS 206142 206142 206142
FLANGED FEET KIT 206136 206136 206136 206136
FLUE CONDENSER FOR 1/2 MOD. DIAM.120MM 206155 206155 206155 206155
FRONT.KICK.STRIP F.CONCRETE INST.1000 MM 206150 206150 206150 206150
FRONT.KICK.STRIP F.CONCRETE INST.1200 MM 206151 206151 206151 206151
FRONT.KICK.STRIP F.CONCRETE INST.1600 MM 206152 206152 206152 206152
FRONT.KICK.STRIP F.CONCRETE INST.200 MM 206146 206146 206146 206146
FRONT.KICK.STRIP F.CONCRETE INST.400 MM 206147 206147 206147 206147
FRONT.KICK.STRIP F.CONCRETE INST.800 MM 206148 206148 206148 206148
FRONTAL HANDRAIL 1200 MM 206191 206191 206191 206191
FRONTAL HANDRAIL 1600 MM 206192 206192 206192 206192
FRONTAL HANDRAIL 400 MM 206166 206166 206166 206166
FRONTAL HANDRAIL 800 MM 206167 206167 206167 206167
FRONTAL KICKING STRIP 1000 MM 206177 206177 206177 206177
FRONTAL KICKING STRIP 1200 MM 206178 206178 206178 206178
FRONTAL KICKING STRIP 1600 MM 206179 206179 206179 206179
FRONTAL KICKING STRIP 200 MM 206174 206174 206174 206174
FRONTAL KICKING STRIP 400 MM 206175 206175 206175 206175
FRONTAL KICKING STRIP 800 MM 206176 206176 206176 206176
JUNCTION SEALING KIT 206086 206086 206086 206086
LARGE HANDRAIL(PORTIONING SHELF)400 MM 206185 206185 206185 206185
LARGE HANDRAIL(PORTIONING SHELF)800 MM 206186 206186 206186 206186
LEFT SIDE DOOR FOR OPEN BASE CUPBOARD 206195 206195 206195
PAIR OF CAST IRON GRIDS 206208 206208 206208 206208
PAIR OF COVERING STRIPS FOR END

ELEMENTS
PRESSURE REGULATOR FOR GAS UNITS 927225 927225 927225 927225

REAR FLUE UPSTAND FOR SMALL CHIMNEY 206159 206159 206159 206159
RIGHT SIDE DOOR FOR OPEN BASE CUPBOARD 206194 206194 206194
S/S GRID FOR DOUBLE BURNER-900 LINE 206298 206298 206298 206298
SIDE HANDRAIL-RIGHT/LEFT HAND 206165 206165 206165 206165
SINGLE BURNER RIBBED PLATE 206172 206172 206172 206172
SINGLE BURNER SMOOTH PLATE 206171 206171 206171 206171
SINGLE BURNER(6KW)RADIANT PLATE-900 LINE 206170 206170 206170 206170
SUPPORT FOR "BRIDGE" SYSTEM 1000 MM 206138 206138 206138 206138
SUPPORT FOR "BRIDGE" SYSTEM 1200 MM 206139 206139 206139 206139
SUPPORT FOR "BRIDGE" SYSTEM 1400 MM 206140 206140 206140 206140
SUPPORT FOR "BRIDGE" SYSTEM 1600 MM 206141 206141 206141 206141
SUPPORT FOR "BRIDGE" SYSTEM 400 MM 206154 206154 206154 206154
SUPPORT FOR "BRIDGE" SYSTEM 800 MM 206137 206137 206137 206137
WATER COLUMN EXTENSION FOR 900 LINE 206290 206290 206290 206290
WATER COLUMN WITH SWIVEL ARM 206288 206288 206288 206288

BACA2 2009-06-19 The Company reserves the right to alter technical specifications without prior notice.

� Handles on the base cupboard

and oven in stainless steel.

� Grids in stainless steel are

washable in a dishwasher.

� Main connections can be via the

base of the unit.

� All models provided with service

duct to facilitate installation.

� All gas appliances are supplied for

use with natural gas, with LPG
conversion jets supplied as
standard.

� The special design of the control

knob system guarantees against

NCFG1200

200104

206234 206234 206234 206234

NCFG1200T

200117

NCFG1201

200145

NCFG1600

200105

water infiltration.

� All models can be installed on

cantilever system.

� IPX5 water protection.
