Electrolux air-o-steam - Touchline
Kombiahi LW 20 GN 2/1-gaas
Electrolux air-o-steam Touchline blends tradition with the latest technological research in order to satisfy the
creativity and working requirements of today's professional kitchen and simplify the usage of the control panel.
The air-o-steam range offers a choice of different models available in two levels of operation, providing a high
degree of automation as well as an extensive range of accessories. The air-o-steam combis are designed to
form complete cook&chill systems together with the air-o-chill blast chillers/freezers, therefore, any installation
can be tailored to meet the needs of the caterer.
The air-o-steam combis detailed are 20 GN 2/1 gas Touchline models.
OPERATING MODES
• Selection window with three
cooking modes (Automatic,
Manual and Programs), cleaning
cycles and setting mode.
• Automatic mode: just select the
family and food type and the oven
will do the rest. Temperature,
cooking climate and time are
managed by the oven to achive a
perfect result, regardless of the
food load. The automatic mode is
ideal for less skilled operators.
3 Special automatic cycles:
- Low Temperature Cooking (LTC,
automatic cycle): indicated for
meat and fish, automatically
selects the cooking parameters to
achieve the lowest weight loss and
the maximum quality.
- Reheating cycle: the best
humidity conditions are managed
to quickly reheat the products.
- Proofing cycle: thanks to the
air-o-clima it’s possible to create a
perfect ambient for proofing.
• Programs mode: the recepies
can be stored up to a maximum of
1000, 16-step cooking programs
available.
• Manual Mode: the traditional
way of cooking by selecting the
cooking cycle, temperature, time
and advanced features.
MAIN FEATURES
• Automatic steam generator
water draining with an automatic
scale diagnosis system.
267705
• Traditional cooking cycles:
- Convection cycle (max. 300 ºC):
ideal for products that should be
cooked without humidity. Humidity
generated by the food itself can
be controlled by the air-o-clima
function thanks to the Lambda
sensor, for a natural cooking.
- Steam cycle (max. 130 ºC): for
products that can be cooked in
water. It can be used as Low
temperature Steam (25-99°C),
Steam (100°C) or High
temperature steam (100-130°C).
- Combi cycle (max. 250ºC):
combining convected heat and
steam to obtain a
humidity-controlled cooking
environment (thanks to the
air-o-clima), reducing cooking
times and food shrinkage.
Page 2
Electrolux air-o-steam - Touchline
Kombiahi LW 20 GN 2/1-gaas
• air-o-clima: measures physically
the real humidity level inside the
cooking chamber thanks to the
Lambda Sensor and acts
consequently according to the set
value. This technology guarantee
always the desired cooking
climate regardless of the food
load. With hot air cycles,
air-o-clima also manages to
exhaust the excess umidity
generated by the food.
• air-o-flow: pumps fresh air from
the outside through the
bi-functional fan which pushes the
air, that has been preheated in the
meantime, into the cooking
chamber, thus guaranteeing an
even cooking process.
• air-o-clean: 4 different pre-set
cycles to clean the cooking cell,
according to the actual
requirements. The cleaning
system is built-in (no need for
add-ons). Green functions
available to save energy, water
and rinse aid.
• Multi-sensor food probe: 6
sensors, ½ ºC accuracy.
• Fan speeds: full, half speed (for
delicate cooking such as for
baking cakes) and pulse (pulse
ventilation for baking and low
temperature cooking).
• Low power cycle: for delicate
cooking such as for baking cakes.
• Eco-delta: the temperature
inside the cooking cell is higher
than the temperature of the food
itself and rises accordingly.
• Quick cooling: useful when
switching to a type of cooking that
requires a lower temperature than
the previous one. It works
automatically and manually.
• Manual injection of water in the
cell.
• Food Safe control: automatic
monitoring and validation of the
cooking process in accordance
with HACCP standards, with
regards to microbiological safety
of process.
• HACCP management available
upon request: it allows the
recording of the cooking
programme according to
H.A.C.C.P. standard (Hazard
Analysis and Critical Control
Points).
• USB connection.
CONSTRUCTION
• Stainless steel 304 throughout,
with seamless joints in the cooking
cell.
• Double thermo-glazed door
equipped with drip pans to catch
condensation and prevent
drippings on the floor, for
maximum security. Four holding
positions allowing easier loading
and unloading.
• Halogen lighting in the cooking
cell.
• IPX5 water protection.
• air-o-steam ovens meet IMQ
safety requirements.
AOS202GTG1
TEHNILISED ANDMED
Energia Gaas Gaas
Gaas Naturaalne gaas G20 (20mbar) LPG gaas
Siinide arv 20 20
Juhtraami siinide vahe - mm 63 63
Küpsetustsüklid - °C
õhk-konvektsioon 300 300
aur 130 130
kombineeritud 250 250
Konvektsioon ● ●
Aurufunktisoon ● ●
Konvekstsioon/aur ● ●
Niiskuse kontroll ● ●
Küpseta&hoia ●
Toidu taassoojendamine ● ●
Madala temp. aurutamine ● ●
Kahe kiirusega ventilaator ● ●
Mitme anduriga sondtermomeeter ● ●
Automaatne pesusüsteem ● ●
Programmide arv 1000 1000
Välismõõtmed -mm/laius 1243 1243
Välismõõtmed -mm/sügavus 1107 1107
Välismõõtmed -mm/kõrgus 1795 1795
Sisemõõdud - mm
laius 933 933
Sisemõõdud - m
sügavus 830 830
Sisemõõdud - mm
kõrgus 1450 1450
Võimsus - kW/boiler 55 55
Võimsus - kW
mootor 2 2
kambris 55 55
gaas 95 95
Netokaal - kg 414 414
Pinge 230 V, 1N, 50/60 230 V, 1N, 50/60
267705
AOS202GTD1
267715
EGB0502010-04-22Võib muutuda ilma etteteatamata
Internet: http://www.electrolux.com/foodservice
Page 3
Electrolux air-o-steam - Touchline
Kombiahi LW 20 GN 2/1-gaas
AOS202GTG1
267705
STANDARD LISAVARUSTUS
AHJUTOGI 20X2/1GN, 63MM-LW 1 1
JUHTPANEELI FILTER-20 GN2/1 AHJUDELE 1 1
UKSEKILP KÄRUTA 20 2/1-EELSOOJENDILE 1 1
LISAVARUSTUS
*NOT TRANSLATED* 922277
*NOT TRANSLATED* 922278
1 (1,2KG) GN1/1 REST 8 KANALE 922266 922266
1/1GN AISI 304 RESTIPAAR 922017 922017
2 FRITÜÜRKORVI AHJULE 922239 922239
2/1 GN AISI304 RVT VÕREPAARI 922175 922175
20 2/1 AHJUDE VEEFILTER 1,8L/MIN 922104 922104
20X1/1&2/1 AHJU RASVAFILTRID 922179 922179
AHJUGRILL (ALUMIINIUM) GN 1/1 922093 922093
AHJUTOGI 16X2/1GN, 80MM-LW 922046 922046
AHJUTOGI 20X2/1GN, 63MM-LW 922044 922044
AUTOMAAT VEEPEHMENDI AHJUDELE 921305 921305
BANKETIKÄRU-92 TALDRIKUT-85MM- 20GN 2/1 922055 922055
EKIS HACCP KOMPLEKT 922166 922166
GAASIAHJU VENTLÕÕRI JAHUTI-LW 922235 922235
GN 1/1 TIBURESTIPAAR 922036 922036
KOMP. INTEGREERITUD HACCP AHJULE 922275 922275
KÕPSETUSPLAAT(400*600*38) -PERF.ALU/SIL 922189 922189
KÜPS.PLAAT (400*600*20) -4 SERVA ALU. 922191 922191
KÜPS.PLAAT (400*600*204) 4 SERVA -PERF.A 922190 922190
KÜPSETUSTOGI 16(400X600) 80MM 200X2/1 LW 922069 922069
KUUMAKAITSE 20 GN 2/1 AJUDELE 922242 922242
PESUAINEKORV-SEINALE KINNITATAV 922209 922209
PESUDUŠŠ AHJULE 922171 922171
TEFLON UNIV. PANN GN1/1 H=20 MM 922090 922090
TEFLON UNIV. PANN GN1/1 H=40 MM 922091 922091
TEFLON UNIV. PANN GN1/1 H=65 MM 922092 922092
TERMAALKATE AOS 20 GN 2/1 922049 922049
UKSEKILP KÄRUTA 20 2/1-EELSOOJENDILE 922095 922095
VEEPEHMENDI VAIKPUHASTUS 921306 921306
AOS202GTD1
267715
EGB0502010-04-22Võib muutuda ilma etteteatamata
Internet: http://www.electrolux.com/foodservice
Page 4
267705, 267715
Electrolux air-o-steam - Touchline
Kombiahi LW 20 GN 2/1-gaas
AOS202GTG1
PAIGALDUSJOONIS
CWI - Külma vee ühendus 3/4" 3/4"
D - Kanalisatsioon 2" 2"
DO - Ülevoolutoru ● ●
EI - Elektriühendus 230 V, 1N, 50/60 230 V, 1N, 50/60
G - Gaasiühendus 1" 1"
WIC - Jahutusvee ühendus 3/4" 3/4"
267705
AOS202GTD1
267715
EGB0502010-04-22
Internet: http://www.electrolux.com/foodservice
