Electrolux LVA100, LVA100D, 660071, 660072 User Manual

Page 1
Item Model ProjectName
LVA100
This Dito washing and drying machine presents all those characteristics of efficiency, functionality and hygiene which makes it an essential component on the modern kitchens. This appliance is designed for the efficient and safe treatment of vegetables in the commercial kitchen. It has been constructed on the basis of rigorous technical principles to guarantee functionality, long term reliability and efficient running costs.
660072
FEATURES
V Bearing frame, external panelling, lid
and extractable basket all in 304 AISI stainless steel and mounted on height adjustable feets.
V Basket support in corrosion resistant
aluminium.
V Lid microswitch to prevent the
starting of the machine when the lid is open.
V Electromagnectic device immediately
stops the machine when the lid is opened during use.
V Very efficient and easy to clean
filtering system.
V Pressed well with rounded corners. V 1 self cleaning cycle of the well. V This model is endowed with a
cleansing container with detergent liquid display and include sanitizing doser kit.
Veg.washer/Spin dryer
Page 2
V Drainage solenoid valve for rapid
opening and closing to guarantee easy and efficient well drainage.
V Water inlet solenoid valve for rapid fill of
the well.
V Manual and 3 automatic washing cycles
V Possibility to regulate the washing water
power according to the type of product to be treated and reducing damaging in delicate vegetable during washing / drying operations.
V IPX5 water protection.
available.
V Cycle time can be set by the operator in
the model 660071.
Specifications
LVA100B
MODEL
Well capacity - lt. 30 30 External dimensions - mm width 700 700 depth 700 700 height 1000 1000 Loading capacity - kg. light vegetables 2-3 2-3 heavy vegetables 6 6 Rotation speed - rpm 300 300 Power - kW installed-electric 0.9 0.9 Net weight - kg. 82 82 Supply voltage 230 V, 1N, 50 230 V, 1N, 50
Programmable cycle times
660072
LVA100D
660071
Optional accessories
CODE DESCRIPTION
921014 BASKET W/SMALL HOLES F.VEGETABLE
WASHER
LVA100B
660072
LVA100D
660071
Page 3
Installation drawings
XXX
660072, 660071
LVA/100
1684
981
900
MODEL
46
604
L=1.15m
C
Ø40(int)
46
I
35
L=2.15m
MAX 290
86
B
49
564
700
755
46
176
700
LVA100B
660072
INLET PIPE
3/4'' F
Ø40
C
B
3/4'' M
I
220
349
3/4'' F
1500
80
82
LVA100D
660071
B - Cold water inlet 3/4" 3/4" C - Water drain 40mm 40mm I - Electrical connection 230 V, 1N, 50 230 V, 1N, 50
120
Page 4
The manufacturer reserves the right to modify and make improvements to the products without giving prior warning. Dimensions, illustrations, technical data, weights, etc. are given as an indication only.
www.dito-electrolux.com
AGCA010
Veg.washer/Spin dryer
