42" BUILT-IN REFRIGERATOR E42BS75EPS
professional series
Page 2
E42BS75EPS professional series
E42BS75EPS 04/05 © 2005 Electrolux Home Products, NA Printed in the U.S.A.
42" Built-In Refrigerator Specifications
• Product Weight – 610 Lbs.
• Voltage Rating –120V / 60 Hz / 15 or 20 Amps
• Electrical supply with grounded branch circuit or
circuit breaker recommended. Install grounded 3prong electrical receptacle recessed into rear wall.
(See Local Electrical Codes.)
• Cutout must be prepared with electrical and
water supply.
• Water line can enter opening through floor or rear
wall. Copper tubing recommended between cold
water line and water connection location. Water line
tubing recommended is 48" minimum length by
1/4" diameter. Installation of easily accessible
shutoff valve in water line required.
• Optimum door swing factory set for 130°. When
installing next to wall where handle may make
contact, allow 4" minimum clearance for 90° door
swing. At 90° door stop position, drawer access
will be maintained but removal will be restricted.
• Refrigerator must be placed on level surface of hard
material, same height as flooring. Surface must
support approximately 1500 lbs. when fully loaded.
Unit equipped with 4-point leveling.
Note: Refer to Product Installation Guide for detailed
instructions on the web at www.electroluxusa.com.
True Built-In Side-By-Side
Flush stainless steel dispenser fascia, toe
kick and grill cover blend harmoniously
with the exterior of this slim profile
refrigerator to create a true built-in look.
PureAdvantage™Filtration System
The most advanced water filtration system
available offers cleaner, fresher ice and
water. And it is simple to operate,
providing a light that alerts when the filter
needs to be changed. With one touch, the
drip-free cartridge is replaced.
Dynamic Cool™with Easy Set
™
Digital Temperature Control System
Sensor-controlled chilling with dual
evaporator cooling system. Amazingly
consistent interior temperature will keep
your food fresher longer.
Showcase Interior Illumination
Tri-level lighting with ultrawhite bulbs
reduces shadows and illuminates contents
for easy visibility regardless of shelf
placement.
Easy Access Ice Maker Door
Ice and water are accessible from inside
the freezer door, allowing you to fill larger
containers effortlessly.
SpillSafe™Full-Depth Shelving
Shelves contain spills of up to 24 ounces
for quick and easy cleanup and fully
extend for complete access to all
contents.
Express Ice
™
Creates ice according to your family’s
needs with the touch of a button.
42" BUILT-IN REFRIGERATOR
CAPACITIES
Total Capacity 25.2 Cu. Ft.
Fresh Food Volume 15.6 Cu. Ft.
Freezer Volume 9.6 Cu. Ft.
ICE /WATER DISPENSER
Electronic Touch Control Yes
Night Light Yes
Temperature Display Yes
Crushed /Cubes/Water Yes
Express Ice
™
Yes
Lock Yes
Filter Reset Yes
Interior Easy Access Door Yes
FRESH FOOD CONVENIENCES
Filtration System PureAdvantage
™
Filter Location Front
Door Ajar Alarm Yes
SpillSafe™Shelving 3
Smooth-Glide™Crisper Drawers 3
Humidity Controls 2
1-Gallon Fixed Door Bin 1
2-Liter Adjustable Door Bin 3
Dairy Compartment with Clear Door 1
Door Bin Snuggers 3
Showcase Interior Illumination Yes
Dynamic Cool™Digital Temperature Control System Yes
FREEZER CONVENIENCES
Automatic Ice Maker with Ice Server Factory Installed
Smooth-Glide™Baskets 2
Fixed Door Bin 3
Dual-Level Lighting Yes
INSTALLATION
Adjustable Rollers Yes
Door Stops Yes
SPECIFICATIONS
Cutout Dimensions –
Height
83-1/2" min.
84-1/2" max.
Width 41-1/2"
Depth 24"
Product Weight 610 Lbs.
Shipping Weight 630 Lbs.
UPC (0-12505-) 69166-9
NOTE: Always consult local and /or national electric codes. Refer to Product
Installation Guide for detailed installation instructions on the web at
www.electroluxusa.com.
High standards of quality at Electrolux Home Products mean we are constantly working to improve
our products. We reserve the right to change specifications or discontinue models without notice.
USA
•
250 Bobby Jones Expressway •Augusta, GA 30907
1-877-4electrolux (1-877-435-3287)
•
www.electroluxusa.com
CANADA
•
5855 Terry Fox Way •Mississauga, ON L5V 3E4
1-800-668-4606
•
www.electroluxca.com
41"
case width
84"
from
floor
to
top
frame
25
3
/8"
*83
3
/4"
at rear
42"
frame to frame
26
7
/8"
including
handle
130°
Door Swing
12-3/16"
41"
16"
24"
23
7
/8"
behind
frame
41"
90°
Door Swing
4"min. to wall
