ALL-MOUNT RANGE HOOD
36" W
E36WC45FSS
designer series
Page 2
E36WC45FSS designer series
Dimensions from base of hood
to ceiling, and include clearance
required for installation.
35 7/8"
19
5
/8"
3"
29
15
/16" min.
48
1
/2" max.
22
3
/4"
(min. height
with one
cover)
11
5
/8"
115/16"
36"-Wide Wall-Mount Range Hood
pecifications
S
Wall-Mount Installation
•
• Electrical Requirements – 120 Volts AC,
5 or 20 Amps, 60 Hertz
1
• Always consult local and /or national electric codes.
Vent unit outside of building only.
•
• Diameter of Exhaust Duct Required – 6"
• Thermal breaks such as short section of
onmetallic duct, should be used in areas
n
of extreme cold.
• For most efficient airflow exhaust, use a straight run
or as few elbows as possible.
• Use metallic flex ducting only to connect rigid duct
directly to transitions
(if allowed by code).
• Cold weather installations should have additional
backdraft damper installed.
• For most efficient operation, position hood low to
cooktop. Recommended installation is 24"-30"
above countertop.
or national electric codes.
NOTE: Always consult local and
Check local building codes for installation requirements,
as they may var
Refer to Pr
instructions on the web at electroluxusa.com.
y per locale.
oduct Installation Guide for detailed
/
Four-Speed,
Centrifugal Blower
E
ood and cooking odors at 400 CFM.
f
Electronic Multi-Function
Touch Control
Controls are convenient and easy to
u
and knobs makes cleanup easy and adds
o styling.
t
Dual Halogen Lighting
Two overhead halogen bulbs evenly
illuminate the cooking surface and provide
abundant light to enhance the cooking
experience.
Washable Stainless Steel Filters
Saturated filters can be rinsed and cycled
through the dishwasher. The stainless steel
filter provides strength and durability not
found in foam filters.
ffectively removes the most persistent
nderstand. The absence of buttons
3
6" RANGE HOOD
Nominal Width 36"
Installation Type Wall Mount
A
ir Discharge Vertical
Air Delivery 400 CFM
Blower Type Centrifugal
C
ontrols Electronic
Fan Speeds 4
H
alogen Lights 2
Washable Stainless Steel Filters Yes
E
xhaust Duct External
Diameter of Duct 6"
SPECIFICATIONS
Electrical –120 V AC /60 Hz /15 or 20 Amps Required
S
hipping Weight 68 Lbs.
Sones Rating 9.0
U
PC (0-12505-) 55799-6
N
OTE: Always consult local and /or national electric codes. Check local
b
uilding codes for installation requirements, as they may vary per locale.
R
efer to Product Installation Guide for detailed instructions on the web at
e
oluxusa.com.
lectr
•
USA
250 Bobby Jones Expressway •Augusta, GA 30907
1-877-4electrolux (1-877-435-3287)
•
CANADA
1-800-668-4606
E36WC45FSS 04/06 © 2006 Electrolux Major Appliances, NA Printed in the U.S.A.
5855 Terry Fox Way •Mississauga, ON L5V 3E4
•
electroluxca.com
•
electroluxusa.com
High standards of quality at Electrolux Major Appliances mean we are constantly working to improve
our products. We reserve the right to change specifications or discontinue models without notice.
