ELECTROLUX ERC07002W8 User Manual [fr]

user manual

notice d'utilisation

benutzerinformation

Refrigerator

Réfrigérateur

Kühlschrank

ERC07002W8

2 electrolux

This Quick user manual contains all the basic facts of your new product and is easy to use. Electrolux

wants to lower our paper consumption related to user manuals by some 30%, which will help spare

12,000 trees every year. The Quick user manual is one of many steps taken by Electrolux for the

environment. It may be a small step, but just by doing a little you do a lot.

A complete user manual can be found at www.electrolux.com

SAFETY INFORMATION

In the interest of your safety and to ensure the cor­rect use, before installing and first using the appli­ance, read this user manual carefully, including
its hints and warnings. To avoid unnecessary mis­takes and accidents, it is important to ensure
that all people using the appliance are thoroughly
familiar with its operation and safety features.
Save these instructions and make sure that they
remain with the appliance if it is moved or sold,
so that everyone using it through its life will be
properly informed on appliance use and safety.
For the safety of life and property keep the pre­cautions of these user's instructions as the man­ufacturer is not responsible for damages caused
by omission.

Children and vulnerable people safety

• This appliance is not intended for use by per­sons (including children) with reduced physical,
sensory or mental capabilities, or lack of expe­rience and knowledge, unless they have been
given supervision or instruction concerning use
of the appliance by a person responsible for
their safety.
Children should be supervised to ensure that
they do not play with the appliance.

• Keep all packaging well away from children.
There is risk of suffocation.

• If you are discarding the appliance pull the plug
out of the socket, cut the connection cable (as
close to the appliance as you can) and remove
the door to prevent playing children to suffer
electric shock or to close themselves into it.

• If this appliance featuring magnetic door seals
is to replace an older appliance having a spring
lock (latch) on the door or lid, be sure to make
that spring lock unusable before you discard
the old appliance. This will prevent it from be­coming a death trap for a child.

General safety

Caution! Keep ventilation openings clear

of obstruction.

• The appliance is intended for keeping foodstuff
and/or beverages in a normal household as ex­plained in this instruction booklet.

• Do not use a mechanical device or any artificial
means to speed up the thawing process.

• Do not use other electrical appliances (such as
ice cream makers) inside of refrigerating appli­ances, unless they are approved for this pur­pose by the manufacturer.

• Do not damage the refrigerant circuit.

• The refrigerant isobutane (R600a) is contained
within the refrigerant circuit of the appliance, a
natural gas with a high level of environmental
compatibility, which is nevertheless flammable.
During transportation and installation of the ap­pliance, be certain that none of the compo­nents of the refrigerant circuit become dam­aged.
If the refrigerant circuit should become dam­aged:
– avoid open flames and sources of ignition
– thoroughly ventilate the room in which the ap-

pliance is situated

• It is dangerous to alter the specifications or mod­ify this product in any way. Any damage to the
cord may cause a short-circuit, fire and/or elec­tric shock.

Warning! Any electrical component (power

cord, plug, compressor) must be replaced
by a certified service agent or qualified service per­sonnel.

1. Power cord must not be lengthened.

2. Make sure that the power plug is not squash­ed or damaged by the back of the appli­ance. A squashed or damaged power plug
may overheat and cause a fire.

3. Make sure that you can come to the mains
plug of the appliance.

4. Do not pull the mains cable.

5. If the power plug socket is loose, do not in­sert the power plug. There is a risk of elec­tric shock or fire.

6. You must not operate the appliance with­out the lamp cover

• This appliance is heavy. Care should be taken
when moving it.

• Do not remove nor touch items from the freez­er compartment if your hands are damp/wet,
as this could cause skin abrasions or frost/freez­er burns.

• Avoid prolonged exposure of the appliance to
direct sunlight.

1)

of interior lighting.

1) If the lamp cover is foreseen

electrolux 3

•

Bulb lamps

2)

used in this appliance are special
purpose lamps selected for household applian­ces use only. They are not suitable for house­hold room illumination.

Daily Use

• Do not put hot pot on the plastic parts in the
appliance.

• Do not store flammable gas and liquid in the ap­pliance, because they may explode.

• Appliance's manufacturers storage recommen­dations should be strictly adhered to.

• Do not place carbonated or fizzy drinks in the
ice-maker compartment as it creates pressure
on the container, which may cause it to ex­plode, resulting in damage to the appliance.

• Ice lollies can cause frost burns if consumed
straight from the appliance.

Care and cleaning

• Before maintenance, switch off the appliance
and disconnect the mains plug from the mains
socket.

• Before using the appliance for the first time,
wash the interior and all internal accessories
with lukewarm water and some neutral soap
so as to remove the typical smell of a brand­new product, then dry thoroughly.

• Do not clean the appliance with metal objects.

• Do not use sharp objects to remove frost from
the appliance. Use a plastic scraper.

• Never use a hair drier or other heating applian­ces to speed up defrosting. Excessive heat
may damage the plastic interior, and humidity
could enter the electric system making it live.

Installation
Important! For electrical connection carefully

follow the instructions given in specific
paragraphs.

• Unpack the appliance and check if there are
damages on it. Do not connect the appliance if

it is damaged. Report possible damages imme­diately to the place you bought it. In that case
retain packing.

• It is advisable to wait at least four hours before
connecting the appliance to allow the oil to
flow back in the compressor.

• Adequate air circulation should be around the
appliance, lacking this leads to overheating. To
achieve sufficient ventilation follow the instruc­tions relevant to installation.

• Wherever possible the back of the product
should be against a wall to avoid touching or
catching warm parts (compressor, condenser)
to prevent possible burn.

• The appliance must not be located close to ra­diators or cookers.

• Make sure that the mains plug is accessible af­ter the installation of the appliance.

•

Connect to potable water supply only.

3)

Service

• Any electrical work required to do the servicing
of the appliance should be carried out by a quali­fied electrician or competent person.

• This product must be serviced by an author­ized Service Centre, and only genuine spare
parts must be used.

Environment Protection

This appliance does not contain gasses

which could damage the ozone layer, in ei­ther its refrigerant circuit or insulation materials.
The appliance shall not be discarded together
with the urban refuse and rubbish. The insulation
foam contains flammable gases: the appliance
shall be disposed according to the applicable reg­ulations to obtain from your local authorities.
Avoid damaging the cooling unit, especially at the
rear near the heat exchanger. The materials used

on this appliance marked by the symbol

are

recyclable.

OPERATION

Switching on

Insert the plug into the wall socket.
Turn the Temperature regulator clockwise to a me­dium setting.
The Temperature Regulator is situated on the
side of the cabinet.

Switching off

To turn off the appliance, turn the Temperature
regulator to the "O" position.

2) If the lamp is foreseen

3) If a water connection is foreseen

Temperature regulation

The temperature is automatically regulated.
To operate the appliance, proceed as follows:

• turn the Temperature regulator toward lower

settings to obtain the minimum coldness.

• turn the Temperature regulator toward higher

settings to obtain the maximum coldness.

4 electrolux

In the ice-making compartment -2 ºC or low-

er temperature can be reached if the Tem­perature regulator is set according to following ta­ble:

Ambient tempera­ture

Temperature regu­lator setting

DAILY USE

Important! this appliance is sold in France.
In accordance with regulations valid in this coun­try it must be provided with a special device (see
figure) placed in the lower compartment of the
fridge to indicate the coldest zone of it.

CARE AND CLEANING

Caution! Unplug the appliance before

carrying out any maintenance operation.

This appliance contains hydrocarbons in its

cooling unit; maintenance and recharging
must therefore only be carried out by authorized
technicians.

Many proprietary kitchen surface cleaners con­tain chemicals that can attack/damage the plas­tics used in this appliance. For this reason it is rec­ommended that the outer casing of this appli­ance is only cleaned with warm water with a little
washing-up liquid added.
After cleaning, reconnect the equipment to the
mains supply.

Defrosting of the ice-maker compartment

A certain amount of frost will always form

around the ice-maker compartment.
Important! Defrost the ice-maker compartment

when the frost layer reaches a thickness of about
3-5 mm.

+10... +16 ºC "1"
+16... +25 ºC "1-2"
+25... +32 ºC "2-3"
+32... +38 ºC "3-4"

Using of the ice-maker compartment

This appliance is equipped with an ice-maker com­partment.
In the ice-maker compartment can be reached -2
°C or lower temperature depending on setting of
thermostat control.
This compartment is suitable for making and stor­ing ice-cubes. (You can purchase the needed ice­cube tray from a specialist shop.)

Important! Do not use metallic instruments to
remove the ice-cube tray from the freezer.

To remove the frost, do these steps:

1. Turn the Temperature regulator to the "0" set­ting and disconnect the mains plug from the
mains socket.

2. Empty the ice box.

3. Leave the door of the appliance and ice-mak­er compartment open.

4. Defrosting usually takes several hours. When
finished, pour defrost water gathered out of
the tray and wipe the surfaces dry.

5. Insert the plug into the wall socket and turn
the thermostat control to a medium setting.

Warning! Never use sharp metal tools to

scrape off frost from the evaporator as you
could damage it. Do not use a mechanical device
or any artificial means to speed up the thawing
process other than those recommended by the
manufacturer.

WHAT TO DO IF…

Normal Operating Sounds

• You may hear a faint gurgling and a bubbling
sound when the refrigerant is pumped through
the coils or tubing. This is correct.

• When the compressor is on, the refrigerant is
being pumped around and you will hear a whir­ring sound and a pulsating noise from the com­pressor. This is correct.

electrolux 5

• The thermic dilatation might cause a sudden
cracking noise. It is natural, not dangerous phys­ical phenomenon. This is correct.

• When the compressor switches on or switches
off, you will hear a faint "click" of the tempera­ture regulator. This is correct.

TECHNICAL DATA

Dimension
Height 520 mm
Width 525 mm
Depth 587 mm

The technical information are situated in the rat­ing plate on the internal left side of the appliance
and in the energy label.

INSTALLATION

Caution! Read the "Safety Information"

carefully for your safety and correct
operation of the appliance before installing the
appliance.

Positioning

This appliance can be installed in a dry, well ven­tilated indoor (garage or cellar) also, but for opti­mum performance install this appliance at a loca­tion where the ambient temperature corresponds
to the climate class indicated on the rating plate
of the appliance:

Climate

class

SN +10°C to + 32°C
N +16°C to + 32°C
ST +16°C to + 38°C
T +16°C to + 43°C

Rear spacers

In the bag with the documentation, there are two
spacers which must be fitted as shown in the fig­ure.
Using fine strokes of hammer put them in their
place.

Ambient temperature

Location

The appliance should be installed well away from
sources of heat such as radiators, boilers, direct
sunlight etc. Ensure that air can circulate freely
around the back of the cabinet. To ensure best
performance, if the appliance is positioned below
an overhanging wall unit, the minimum distance
between the top of the cabinet and the wall unit
must be at least 100 mm . Ideally, however, the
appliance should not be positioned below over­hanging wall units. Accurate levelling is ensured
by one or more adjustable feet at the base of the
cabinet.
If the cabinet is placed in a corner and the side
with the hinges facing the wall, the distance be­tween the wall and the cabinet must be at least
10 mm to allow the door to open enough so that
the shelves can be removed.

6 electrolux

Warning! It must be possible to

disconnect the appliance from the mains
power supply; the plug must therefore be easily
accessible after installation.

~10 cm

AB

~2,5 cm

Door reversibility
Important! To carry out the following

operations, we suggest that this be made with
another person that will keep a firm hold on the
doors of the appliance during the operations.

To change the opening direction of the door, do
these steps:

1. Remove the plug from the power socket.

2. Remove the top hinge cover.

3. Unscrew the 2 retaining screws, and remove

the hinge from the appliance.

~2,5 cm

2

1

4. Take the door off.

5. Remove the screw fixing the lower door

hinge and the other screw fixing the lower
door hinge and the foot. Then remove the
door hinge and the foot as shown in the Figure.

6. Loosen the screw fixing the foot opposite the

lower door hinge in order to remove the foot.

7. Fix the door hinge and the corresponding
foot on the opposite side and then the other
loosened foot at the former place of the door
hinge as shown in the Figure.

8. Please make sure to place the lower

foot below the door hinge. The lower
foot is recognizable by its 4 ribs on the
outer surface.

9. Fix the door onto the lower hinge pin.

10. To fit top door hinge, remove the plastic blank­ing plugs carefully, and refit them in the holes
left by the hinge retaining screws.

11. Refit the top hinge using the 2 retaining
screws, taking care that the edge of the door
is parallel with side of the cabinet.

12. Replace the hinge cover.

13. Relocate the handle and the plastic plugs to
the opposite side.

14. Level the appliance, wait for at least four
hours and then connect it to the power socket.

Do a final check to make sure that:

• All screws are tightened.

• The door opens and closes correctly.

If the ambient temperature is cold (i.e. in Winter),
the gasket may not fit perfectly to the cabinet. In
that case, wait for the natural fitting of the gasket.
In case you do not want to carry out the above
mentioned operations, contact the nearest After
Sales Service Force. The After Sales Service spe-

electrolux 7

cialist will carry out the reversibility of the doors at
your cost.

Electrical connection

Before plugging in, ensure that the voltage and
frequency shown on the rating plate correspond
to your domestic power supply.
The appliance must be earthed. The power sup­ply cable plug is provided with a contact for this

ENVIRONMENTAL CONCERNS

The symbol on the product or on its
packaging indicates that this product may not be
treated as household waste. Instead it should be
taken to the appropriate collection point for the
recycling of electrical and electronic equipment.
By ensuring this product is disposed of correctly,
you will help prevent potential negative

purpose. If the domestic power supply socket is
not earthed, connect the appliance to a separate
earth in compliance with current regulations, con­sulting a qualified electrician.
The manufacturer declines all responsibility if the
above safety precautions are not observed.
This appliance complies with the E.E.C. Directives.

consequences for the environment and human
health, which could otherwise be caused by
inappropriate waste handling of this product. For
more detailed information about recycling of this
product, please contact your local council, your
household waste disposal service or the shop
where you purchased the product.

8 electrolux

Ce Guide d'utilisation, simple à utiliser, vous procure des informations, nécessaires à l'utilisation de

votre nouvel appareil. Electrolux souhaite réduire de 30 % sa consommation de papier concernant ses

notices d'utilisation, ce qui permettra de sauvegarder 12 000 arbres par an. Ce Guide d'utilisation

n'est autre qu'une des nombreuses mesures adoptées par Electrolux en faveur de l'environnement.

Pour vous procurer la notice d'utilisation originale, rendez-vous sur www.electrolux.com

Une petite mesure qui permettra d'obtenir de grands résultats.

CONSIGNES DE SÉCURITÉ

Pour votre sécurité et garantir une utilisation cor­recte de l'appareil, lisez attentivement cette noti­ce, y compris les conseils et avertissements,
avant d'installer et d'utiliser l'appareil pour la pre­mière fois. Pour éviter toute erreur ou accident,
veillez à ce que toute personne qui utilise l'appa­reil connaisse bien son fonctionnement et ses
fonctions de sécurité. Conservez cette notice
avec l'appareil. Si l'appareil doit être vendu ou cé­dé à une autre personne, veillez à remettre cette
notice au nouveau propriétaire, afin qu'il puisse
se familiariser avec son fonctionnement et sa sé­curité.
Pour la sécurité des personnes et des biens, con­servez et respectez les consignes de sécurité fi­gurant dans cette notice. Le fabricant décline tou­te responsabilité en cas de dommages dus au
non-respect de ces instructions.
Lors de sa fabrication, cet appareil a été construit
selon des normes, directives et/ou décrets pour
une utilisation sur le territoire français.

Pour la sécurité des biens et des personnes
ainsi que pour le respect de l'environne­ment, vous devez d'abord lire attentivement
les préconisations suivantes avant toute uti­lisation de votre appareil.

Attention Pour éviter tout risque de

détérioration de l'appareil, transportez-le
dans sa position d'utilisation muni de ses cales
de transport (selon le modèle). Au déballage de
celui-ci, et pour empêcher des risques
d'asphyxie et corporel, tenez les matériaux
d'emballage hors de portée des enfants.

Attention Pour éviter tout risque (mobilier,

immobilier, corporel,...), l'installation, les
raccordements (eau, gaz, électricité, évacuation
selon modèle), la mise en service et la
maintenance de votre appareil doivent être
effectuées par un professionnel qualifié.

Attention Votre appareil a été conçu pour

être utilisé par des adultes. Il est destiné à
un usage domestique normal. Ne l'utilisez pas à
des fins commerciales ou industrielles ou pour
d'autres buts que ceux pour lesquels il a été
conçu. Vous éviterez ainsi des risques matériel et
corporel.

Attention Débranchez l'appareil avant

toute opération de nettoyage manuel.

N'utilisez que des produits du commerce non
corrosifs ou non inflammables. Toute projection
d'eau ou de vapeur est proscrite pour écarter le
risque d'électrocution.

Attention Si votre appareil est équipé d'un

éclairage, débranchez l'appareil avant de
procéder au changement de l'ampoule (ou du
néon, etc.) pour éviter de s'électrocuter.

Attention Afin d'empêcher des risques

d'explosion ou d'incendie, ne placez pas de
produits inflammables ou d'éléments imbibés de
produits inflammables à l'intérieur, à proximité ou
sur l'appareil.

Attention Lors de la mise au rebut de

votre appareil, et pour écarter tout risque
corporel, mettez hors d'usage ce qui pourrait
présenter un danger : coupez le câble
d'alimentation au ras de l'appareil. Informez-vous
auprès des services de votre commune des
endroits autorisés pour la mise au rebut de
l'appareil.

Attention Respectez la chaîne de froid dès

l'acquisition d'un aliment jusqu'à sa
consommation pour exclure le risque
d'intoxication alimentaire.

Veuillez maintenant lire attentivement cette
notice pour une utilisation optimale de votre
appareil.

Sécurité des enfants et des personnes
vulnérables

• Cet appareil n'est pas destiné à être utilisé par

des enfants ou des personnes dont les capaci­tés physiques, sensorielles ou mentales, ou le
manque d'expérience et de connaissance les
empêchent d'utiliser l'appareil sans risque lors­qu'ils sont sans surveillance ou en l'absence
d'instruction d'une personne responsable qui
puisse leur assurer une utilisation de l'appareil
sans danger.
Empêchez les enfants de jouer avec l'appareil.

• Ne laissez pas les différents emballages à por-

tée des enfants. Ils pourraient s'asphyxier.

• Si l'appareil doit être mis au rebut, veillez à cou-

per le câble d'alimentation électrique au ras de
l'appareil pour éviter les risques d'électrocu­tion. Démontez la porte pour éviter que des en­fants ne restent enfermés à l'intérieur.
