Electrolux EN3850DOX User Manual [en, es]

EN3850DOX

................................................ .............................................

EN FRIDGE FREEZER USER MANUAL 2
PT COMBINADO MANUAL DE INSTRUÇÕES 29
ES FRIGORÍFICO-

CONGELADOR

MANUAL DE
INSTRUCCIONES

58

www.electrolux.com

2

CONTENTS

1. SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2. PRODUCT DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

3. CONTROL PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

4. DAILY USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

5. HOW TO USE THE WATER DISPENSER WITH PUREADVANTAGE FILTER CARTRIDGE

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

6. HELPFUL HINTS AND TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

7. CARE AND CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

8. TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

9. INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

10. NOISES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

11. TECHNICAL DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

WE’RE THINKING OF YOU

Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it
decades of professional experience and innovation. Ingenious and stylish, it has been designed
with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great
results every time.

Welcome to Electrolux.

Visit our website for:

Get usage advice, brochures, trouble shooter, service information:

www.electrolux.com

Register your product for better service:

www.electrolux.com/productregistration

Buy Accessories, Consumables and Original spare parts for your appliance:

www.electrolux.com/shop

CUSTOMER CARE AND SERVICE

We recommend the use of original spare parts.
When contacting Service, ensure that you have the following data available.
The information can be found on the rating plate. Model, PNC, Serial Number.

Warning / Caution-Safety information
General information and tips
Environmental information

Subject to change without notice.

ENGLISH 3

1.

SAFETY INSTRUCTIONS

In the interest of your safety and to ensure
the correct use, before installing and first
using the appliance, read this user manual
carefully, including its hints and warnings.
To avoid unnecessary mistakes and acci­dents, it is important to ensure that all
people using the appliance are thoroughly
familiar with its operation and safety fea­tures. Save these instructions and make
sure that they remain with the appliance if
it is moved or sold, so that everyone using
it through its life will be properly informed
on appliance use and safety.
For the safety of life and property keep
the precautions of these user's instruc­tions as the manufacturer is not responsi­ble for damages caused by omission.

1.1 Children and vulnerable
people safety

• This appliance is not intended for use
by persons (including children) with re­duced physical, sensory or mental ca­pabilities, or lack of experience and
knowledge, unless they have been giv­en supervision or instruction concerning
use of the appliance by a person re­sponsible for their safety.

Children should be supervised to en­sure that they do not play with the ap­pliance.

• Keep all packaging well away from chil­dren. There is risk of suffocation.

• If you are discarding the appliance pull
the plug out of the socket, cut the con­nection cable (as close to the appliance
as you can) and remove the door to
prevent playing children to suffer elec­tric shock or to close themselves into it.

• If this appliance featuring magnetic
door seals is to replace an older appli­ance having a spring lock (latch) on the
door or lid, be sure to make that spring
lock unusable before you discard the
old appliance. This will prevent it from
becoming a death trap for a child.

1.2 General safety

WARNING!

Keep ventilation openings, in the appli­ance enclosure or in the built-in structure,
clear of obstruction.

• The appliance is intended for keeping
foodstuff and/or beverages in a normal
household and similar applications such
as:

– staff kitchen areas in shops, offices

and other working environments;

– farm houses and by clients in hotels,

motels and other residential type en­vironments;

– bed and breakfast type environ-

ments;

– catering and similar non-retail appli-

cations.

• Do not use a mechanical device or any
artificial means to speed up the thawing
process.

• Do not use other electrical appliances
(such as ice cream makers) inside of re­frigerating appliances, unless they are
approved for this purpose by the manu­facturer.

• Do not damage the refrigerant circuit.

• The refrigerant isobutane (R600a) is
contained within the refrigerant circuit of
the appliance, a natural gas with a high
level of environmental compatibility,
which is nevertheless flammable.

During transportation and installation of
the appliance, be certain that none of
the components of the refrigerant cir­cuit become damaged.

If the refrigerant circuit should become
damaged:

– avoid open flames and sources of ig-

nition

– thoroughly ventilate the room in

which the appliance is situated

• It is dangerous to alter the specifica­tions or modify this product in any way.
Any damage to the cord may cause a
short-circuit, fire and/or electric shock.

WARNING!

Any electrical component (power
cord, plug, compressor) must be
replaced by a certified service
agent or qualified service person­nel to avoid hazard.

www.electrolux.com

4

• This appliance is heavy. Care should be

• Do not remove nor touch items from

• Avoid prolonged exposure of the appli-

• Bulb lamps (if foreseen) used in this ap-

1.3 Daily Use

• Do not put hot pot on the plastic parts

• Do not store flammable gas and liquid

• Do not place food products directly

• Frozen food must not be re-frozen once

• Store pre-packed frozen food in ac-

• Appliance's manufacturers storage rec-

• Do not place carbonated or fizzy drinks

1.

Power cord must not be length­ened.

2.

Make sure that the power plug is
not squashed or damaged by the
back of the appliance. A squashed
or damaged power plug may over­heat and cause a fire.

3.

Make sure that you can come to
the mains plug of the appliance.

4.

Do not pull the mains cable.

5.

If the power plug socket is loose,
do not insert the power plug. There
is a risk of electric shock or fire.

6.

You must not operate the appli­ance without the lamp cover (if
foreseen) of interior lighting.

taken when moving it.

the freezer compartment if your hands
are damp/wet, as this could cause skin
abrasions or frost/freezer burns.

ance to direct sunlight.

pliance are special purpose lamps se­lected for household appliances use
only. They are not suitable for house­hold room illumination.

in the appliance.

in the appliance, because they may ex­plode.

against the air outlet on the rear wall. (If
the appliance is Frost Free)

it has been thawed out.

cordance with the frozen food manu­facturer's instructions.

ommendations should be strictly ad­hered to. Refer to relevant instructions.

in the freezer compartment as it creates
pressure on the container, which may
cause it to explode, resulting in damage
to the appliance.

• Ice lollies can cause frost burns if con­sumed straight from the appliance.

1.4 Care and cleaning

• Before maintenance, switch off the ap­pliance and disconnect the mains plug
from the mains socket.

• Do not clean the appliance with metal
objects.

• Do not use sharp objects to remove
frost from the appliance. Use a plastic
scraper.

• Regularly examine the drain in the re­frigerator for defrosted water. If neces­sary, clean the drain. If the drain is
blocked, water will collect in the bottom
of the appliance.

1.5 Installation

For electrical connection carefully
follow the instructions given in
specific paragraphs.

• Unpack the appliance and check if
there are damages on it. Do not con­nect the appliance if it is damaged. Re­port possible damages immediately to
the place you bought it. In that case re­tain packing.

• It is advisable to wait at least four hours
before connecting the appliance to al­low the oil to flow back in the compres­sor.

• Adequate air circulation should be
around the appliance, lacking this leads
to overheating. To achieve sufficient
ventilation follow the instructions rele­vant to installation.

• Wherever possible the back of the
product should be against a wall to
avoid touching or catching warm parts
(compressor, condenser) to prevent
possible burn.

• The appliance must not be located
close to radiators or cookers.

• Make sure that the mains plug is acces­sible after the installation of the appli­ance.

• Connect to potable water supply only (If
a water connection is foreseen).

1.6 Service

• Any electrical work required to do the
servicing of the appliance should be
carried out by a qualified electrician or
competent person.

• This product must be serviced by an
authorized Service Centre, and only
genuine spare parts must be used.

1.7 Environment Protection

This appliance does not contain
gasses which could damage the

2. PRODUCT DESCRIPTION

2 5 64 7 109

3 81

ENGLISH 5

ozone layer, in either its refrigerant
circuit or insulation materials. The
appliance shall not be discarded
together with the urban refuse and
rubbish. The insulation foam con­tains flammable gases: the appli­ance shall be disposed according
to the applicable regulations to
obtain from your local authorities.
Avoid damaging the cooling unit,
especially at the rear near the heat
exchanger. The materials used on
this appliance marked by the sym-

are recyclable.

bol

Fruit drawers

1

FreshZone drawer

2

Glass shelves

3

Dynamic Air Cooling

4

Bottle rack

5

12 11

Control panel

6

Butter shelf

7

Door shelves

8

Water dispenser

9

Bottle shelf

10

www.electrolux.com

6

Freezer baskets

11

3. CONTROL PANEL

12

1

Rating plate

234567

Display

1

Drink Chill button and Appliance ON/

2

OFF button
Temperature colder button

3

Temperature warmer button

4

Fridge Compartment button

5

Freezer Compartment button

6

Mode button

7

It is possible to change predefined sound
of buttons to a loudly one by pressing to­gether Mode button and Temperature
colder button for some seconds. Change
is reversible.

3.1 Display

A DCB E F G H I

K J

A)

Fridge temperature indicator

B)

Fridge OFF indicator

C)

HolidayMode

D)

Fridge EcoMode

E)

ShoppingMode

F)

Alarm indicator

G)

Freezer EcoMode

H)

FastFreeze mode

I)

Freezer temperature indicator

J)

DrinksChill mode

K)

FreeStore mode

After selection of the fridge or
freezer compartment the anima-

tion
After selection of the temperature
the animation flashes for a few mi­nutes.

3.2 Switching on the appliance

To switch on the appliance do these
steps:

1.

Connect the mains plug to the power
socket.

2.

The temperature indicators show the
set default temperature.

starts.

If DEMO appears on the Display, the ap­pliance is in demonstration mode: refer to

“WHAT TO DO IF....” paragraph.

To select a different set temperature refer
to "Temperature regulation".

3.3 Switching off the fridge

To switch off the fridge:

1.

Press the Fridge Compartment button
for few seconds.

2.

The fridge OFF indicator is shown.

3.4 Switching on the fridge

To switch on the fridge:

1.

Press the Fridge Compartment but­ton.

The fridge OFF indicator goes off.
To select a different set temperature refer
to "Temperature regulation".

3.5 Switching off

To switch off the appliance do these
steps:

1.

Press the Appliance ON/OFF button

for 3 seconds.

2.

The display switches off.

3.

To disconnect the appliance from the

power disconnect the mains plug

from the power socket.

3.6 Temperature regulation

Select the fridge or freezer compartment.
Press the temperature button to set the
temperature.
Set default temperature:

• +4°C for the fridge

• -18°C for the freezer
The temperature indicators show the set
temperature.
The set temperature will be reached with­in 24 hours.

After a power failure the set tem­perature remains stored.

3.7 HolidayMode

This function allows you to keep the re­frigerator closed and empty during a long
holiday period without the formation of a
bad smell.

ENGLISH 7

The fridge compartment must be
empty with holiday function on.

To switch on the function:

1.

Press the Mode button until the cor­responding icon appears.

The Holiday indicator flashes for few
seconds.

The fridge temperature indicator
shows the set temperature.

To switch off the function:

1.

Press the Mode button until the Holi­day indicator flashes.

2.

The Holiday indicator goes off.

The function switches off by se­lecting a different fridge set tem­perature.

3.8 EcoMode for Fridge and
Freezer Compartment

For optimal food storage select the Eco­Mode .
To switch on the function:

1.

Select the fridge/freezer compart­ment.

2.

Press the Mode button until the cor­responding icon appears.

The EcoMode indicator flashes for
few seconds.

The temperature indicator shows the
set temperature:

– for the fridge: +4°C
– for the freezer: -18°C

3.

The EcoMode indicator is shown.

To switch off the function:

1.

Select the fridge/freezer compart­ment.

2.

Press the Mode button until the Eco­Mode indicator flashes.

3.

The EcoMode indicator goes off.

The function switches off by se­lecting a different set temperature.

3.9 ShoppingMode

If you need to insert a large amount of
warm food, for example after doing the
grocery shopping, we suggest activating
the ShoppingMode to chill the products
more rapidly and to avoid warming the

www.electrolux.com

8

other food which is already in the refriger­ator.
To switch on the function:

1.

The ShoppingMode shuts off automatical­ly after approximately 6 hours.
To switch off the function before its auto­matic end:

1.

2.

3.10 FastFreeze mode

To switch on the function:

1.

2.

This function stops automatically after 52
hours.
To switch off the function before its auto­matic end:

1.

2.

3.

3.11 DrinksChill mode

The DrinksChill mode is to be used to set
an acoustic alarm at the preferred time,
useful for example when a recipe requires
to cool down a mixture for a certain peri­od of time, or when a reminder is needed
in order not to forget the bottles placed in
the freezer for fast cooling.
To switch on the function:

1.

Press the Mode button until the cor-

responding icon appears.

The ShoppingMode indicator flashes

for few seconds.

Press the Mode button until the

ShoppingMode indicator flashes.

The ShoppingMode indicator goes

off.

The function switches off by se­lecting a different fridge set tem­perature.

Select the freezer compartment.

Press the Mode button until the cor-

responding icon appears.

The FastFreeze indicator flashes for

few seconds.

Select the freezer compartment.

Press the Mode button until the Fast-

Freeze indicator flashes.

The FastFreeze indicator goes off.

The function switches off by se­lecting a different freezer set tem­perature.

Press the DrinkChill button.

The DrinksChill indicator appears.

The Timer shows the set value (30 mi-

nutes).

2.

Press the Temperature colder button
and Temperature warmer button to
change the Timer set value from 1 to
90 minutes.

3.

The Timer start to flash (min).
At the end of the countdown the Drinks­Chill indicator flashes and an audible
alarm sounds:

1.

Remove any drinks contained in the

freezer compartment.

2.

Press the DrinkChill button to switch

off the sound and terminate the func-

tion.
It is possible to deactivate the function at
any time during the countdown:

1.

Press the DrinkChill button.

2.

The DrinksChill indicator goes off.
It is possible to change the time during
the countdown and at the end by press­ing the Temperature colder button and
the Temperature warmer button.

3.12 High temperature alarm

An increase in the temperature in the
freezer compartment (for example due to
an earlier power failure) is indicated by:

• flashing the alarm and freezer tempera-

ture indicators

• sounding of buzzer.
To reset the alarm:

1.

Press any button.

2.

The buzzer switches off.

3.

The freezer temperature indicator

shows the highest temperature

reached for a few seconds. Then

show again the set temperature.

4.

The alarm indicator continue to flash

until the normal conditions are re-

stored.
When the alarm has returned the alarm in­dicator goes off.

3.13 Door open alarm

An acoustic alarm will sound if the door is
left open for a few minutes. The door
open alarm conditions are indicated by:

• flashing Alarm indicator

• acoustic buzzer
When normal conditions are restored
(door closed), the alarm will stop.
During the alarm, the buzzer can be
switched off by pressing any button.

3.14 FreeStore mode

To switch on the function:

1.

Press the Mode button until the cor­responding icon appears.

The FreeStore indicator flashes for
few seconds.

2.

The FreeStore indicator is shown.

To switch off the function:

1.

Press the Mode button until the Free­Store indicator flashes.

4. DAILY USE

2.

The FreeStore indicator goes off.

If the function is activated auto­matically the FreeStore indicator is
not shown (refer to "Daily use").
The activation of the FreeStore
mode increases the energy con­sumption.

ENGLISH 9

4.1 Storage of frozen food

When first starting-up or after a period out
of use, before putting the products in the
compartment let the appliance run at least
2 hours.
The freezer drawers ensure that it is quick
and easy to find the food package you
want. If large quantities of food are to be
stored, remove all drawers except for the
bottom drawer which needs to be in place
to provide good air circulation. On all
shelves it is possible to place food that
protrude until 15 mm from the door.

In the event of accidental defrost­ing, for example due to a power
failure, if the power has been off
for longer that the value shown in
the technical characteristics chart
under "rising time", the defrosted
food must be consumed quickly
or cooked immediately and then
re-frozen (after cooling).

4.2 Thawing

Deep-frozen or frozen food, prior to being
used, can be thawed in the refrigerator

compartment or at room temperature, de­pending on the time available for this op­eration.
Small pieces may even be cooked still fro­zen, directly from the freezer: in this case,
cooking will take longer.

4.3 Freezing fresh food

The freezer compartment is suitable for
freezing fresh food and storing frozen and
deep-frozen food for a long time.
To freeze fresh food activate the Fast
Freeze function at least 24 hours before
placing the food to be frozen in the freezer
compartment.
Place the fresh food to be frozen in the
bottom compartment.
The maximum amount of food that can be
frozen in 24 hours is specified on the rat-
ing plate, a label located on the inside of
the appliance.
The freezing process lasts 24 hours: dur­ing this period do not add other food to
be frozen.

www.electrolux.com

10

4.4 DYNAMICAIR

4.5 Movable shelves

The refrigerator compartment is equipped
with a device that allows for rapid cooling
of foods and more uniform temperature in
the compartment.
This device activates by itself when nee­ded, for example for a quick temperature
recovering after door opening or when the
ambient temperature is high.
Allows you to switch on the device man­ually when needed (refer to "DYNAMICAIR
Function").

The DYNAMICAIR device stops when the
door is open and restarts immediately af­ter the door closing.

The walls of the refrigerator are equipped
with a series of runners so that the
shelves can be positioned as desired.

4.6 Bottle rack

Place the bottles (with the opening facing
front) in the pre-positioned shelf.

If the shelf is positioned horizontally, place
only closed bottles.
This bottle holder shelf can be tilted in or­der to store previously opened bottles. To
obtain this result, pull the shelf up so it
can rotate upwards and be placed on the
next higher level.

4.7 Positioning the door shelves

1

2

3

4.8 Freshzone drawer

ENGLISH 11

To permit storage of food packages of
various sizes, the door shelves can be
placed at different heights.
To make these adjustments proceed as
follows:
gradually pull the shelf in the direction of
the arrows until it comes free, then reposi­tion as required.

The FreshZone drawer is suitable for stor­ing fresh food like fish, meat, seafood, be­cause the temperature is lower here than
in the rest of the fridge.

4.9 Removal of freezing baskets from the freezer

The freezing baskets have a limit stop to
prevent their accidental removal or falling
out. At the time of its removal from the
freezer, pull the basket towards yourself

2

1

and, upon reaching the end point, remove
the basket by tilting its front upwards.
At the time of putting it back, slightly lift
the front of the basket to insert it into the
freezer. Once you are over the end points,
push the baskets back in their position.

5. HOW TO USE THE WATER DISPENSER WITH
PUREADVANTAGE FILTER CARTRIDGE

5.1 Pure advantage water filter
unit

Internal components:

www.electrolux.com

12

A
B

C

D

E

F

External components:

A
B

C

5.2 Initial operations to use your
water dispenser

1.

Remove every tape and other protec­tion system from the tank assembly

•A. Cover + lid

• B. Including pure water cartridge

• C. Internal tank

•D. Water tank

• E. Pure water Memo - the electronic
cartridge exchange indicator

•F. Valve + gasket

• A. Dispenser

•B. Water lever

• C. Water drop tray

2.

clean the components, as described
into "Water dispenser cleaning proce­dure", to remove eventual residue.

ENGLISH 13

5.3 Water dispenser cleaning procedure

• Unblock the two stopping elements on
the sides of the tank as shown in the
pictures:

• take out the PUREADVANTAGE car­tridge from the water filter unit

• press the stopping elements in the mid­dle and move it up

• move the stopper into direction of the
central tank.

• Push up the tank along the direction of
the valve.

• Remove the cover and the internal tank

• Unscrew the valve in counter clockwise
(pay particular attention not to lose the
Valve Gasket because is necessary to a
correct functioning of the features).

• Clean the tank lid, the valve and the
gasket with a solution of warm water
and neutral soap. Rinse it and put it in­side the door hole during the cleaning
of the other components (in order to
avoid cold air leakage from the fridge).

• Clean the tank and the internal tank
with a solution of warm water and neu­tral soap and rinse them.

• After the tank components cleaning
take back the valve from the fridge door
and assembly the tank in the inverse or­der (4;3;2;1) of disassembly (pay atten­tion at the valve gasket positioning).

• Put the assembled tank on the door
along the valve direction.

• Block the stopping elements in the in­verse order of unblock.

• Insert again the PUREADVANTAGE
cartridge in the internal tank.

www.electrolux.com

14

5.4 How to use the PUREADVANTAGE filter cartridge

Step 2: Insert in the internal tank

Step 1: Preparing the cartridge

To prepare your PUREADVANTAGE filter
cartridge, remove the protective wrapper
(note: cartridge and inside wrapper may
appear moist, this is simply condensa­tion).
Immerse the cartridge in cold water and
shake it gently to remove any air bubbles.
The filter now is ready to use.
As required for some other water filter
cartridges, there is no need to pre-soak
the new PUREADVANTAGE Cartridge.

Remove the cover. Before inserting the
cartridge, remove the internal tank and
clean it thoroughly by rising it and wiping
it dry.
Then, thoroughly clean the inside of the
water tank with a dump cloth and wipe it
dry as well.
Place the cartridge into the filter tank and
push downwards until it 'clicks' firmly into
place.
The cartridge should stay in place if the
internal tank is turned upside down.

Step 3: Rinse the cartridge

2x

Step 4: Refill the water tank

3x

Take the internal tank out of the PUREAD­VANTAGE water filter unit, fill it under the
tap with cold tap water and allow it to filter
through.
Discard the first two fillings into the sink.
These first two fillings are used to flush
the filter cartridge.
Then, place the internal tank back into
PUREADVANTAGE water filter unit.
Place the cover back onto the jug and
press it carefully downwards to ensure it
fits correctly into place.

To fill the tank with cold water, simply
open the flip top lid, take a jug of tap wa­ter and pour it inside the tank through the
cover as shown into the picture (use the
lid every time that you want to fill your wa­ter) or take out the water tank (pull the
handle (1) and then take it out from its
place (2)) and fill it with cold water under
the tap.

2

1

Allow the water to filter through and re­peat "Step 4" as many times as you want
until the PUREADVANTAGE water filter
unit is filled up.

5.5 Remove cartridge with ring pull handle

ENGLISH 15

In order to avoid risk of spillage of
water during closing and opening
of the refrigerator door, we rec­ommend to not fill completely the
water tank ,maximum 4 liters.

If you have not used all filtered
water in the water tank within 1-2
days, please discard any water left
inside the PUREADVANTAGE wa­ter filter unit and wash before refill­ing it.

To exchange the cartridge after four
weeks, simply use the ring pull handle on
the top of the cartridge to remove it from
the internal tank, and repeat steps 1 - 3
above.

www.electrolux.com

16

5.6 The PUREADVANTAGE Memo

Start the Memo display

For maximum filter performance and opti­mum taste, it is important to change your
PUREADVANTAGE cartridge regularly.
PUREADVANTAGE recommends that you
replace the cartridge in the PUREAD­VANTAGE unit of your fridge every four
weeks.
PUREADVANTAGE Memo automatically
reminds you when to change the car­tridge.
The unique PUREADVANTAGE Memo
measures the recommended time of use
of your cartridge.
The PUREADVANTAGE Memo is located
in front of the water tank.

To start Memo press and hold down the
start button on the lid until all four bars
appear in the display and flash twice. The
Memo is now set.

Functional control

Life time indicator

The flashing dots on the Memo indicates
that the Memo is working.

5.7 Important information

• The fridge door valve hole must be
closed with the Water Valve during the
regular functioning of the appliance.

• Use only drinking water. The use of any
other drink type can leave residues,
taste or odor in the reservoir and in the
tap.

• It is possible to hear some noises
caused by air entering when the water
left the reservoir.

• In case the water does not flow well,
press the driving lever once again.
Keep the glass below the tap for some
instants, in order to assure that all the
water is collected by the glass.

• Do not use gasified drinks, such as soft
drinks. The drink can leak due to the
gas pressure.

• Remember that water is a foodstuff.
Please consume filtered water within
one to two days.

• Should your PUREADVANTAGE water
filter unit not be in use for a prolonged
period (e.g. vacation), we recommend
that you discard any water left inside

ENGLISH 17

The Life time indicator is only de­signed to be used with PUREAD­VANTAGE filter cartridges.

The Life Time Indicator reminds you when
it is time to change the PUREADVANT­AGE™ filter. Each dot refers to a lifetime
of about one week. The recommended
PUREADVANTAGE™ filter lifetime of four
weeks (30 days) equals four dots (100%).
After each week one circle will disappear
to show the remaining filter life time. This
is how the Life Time Indicator works:

1.

Push the STATUS button to activate
the display.

2.

To see the status of the PUREAD­VANTAGE™ filter anytime; press the
button 0.5-2 seconds. For example;
when four lights are visible the filter is
100% full with four weeks of usage
left

3.

To reset the timing press the button 3
seconds or more.

4.

Change the PUREADVANTAGE™ fil­ter when all the lights are blinking

the system and leave the cartridge in­side the filter tank.

Before using the system again take out
the cartridge and repeat steps 1 to 4 of
"How to use the PUREADVANTAGE fil­ter cartridge".

• The PUREADVANTAGE water filter unit
is designed for use only with municipally
treated tap water (note: this water is
constantly controlled and according to
legal regulations safe to drink) or with
water from private supplies which has
been tested safe to drink.

If an instruction is received from the au­thorities that mains water must be
boiled, the PUREADVANTAGE filtered
water has also to be boiled. When the
instruction to boil water is no longer in
force, the entire filter system must be
cleaned and a new cartridge inserted.

More information on the use of
PUREADVANTAGE filter cartridg­es and the Memo can be found in
the PUREADVANTAGE informa­tion guide.

www.electrolux.com

18

You can purchase new PUREAD­VANTAGE filter cartridges and
Memo through consumer service
network of Electrolux

6. HELPFUL HINTS AND TIPS

6.1 Normal Operating Sounds

• You may hear a faint gurgling and a
bubbling sound when the refrigerant is
pumped through the coils or tubing.
This is correct.

• When the compressor is on, the refrig­erant is being pumped around and you
will hear a whirring sound and a pulsat­ing noise from the compressor. This is
correct.

• The thermic dilatation might cause a
sudden cracking noise. It is natural, not
dangerous physical phenomenon. This
is correct.

6.2 Hints for energy saving

• Do not open the door frequently or
leave it open longer than absolutely
necessary.

• If the ambient temperature is high and
the Temperature Regulator is set to low
temperature and the appliance is fully
loaded, the compressor may run con­tinuously, causing frost or ice on the
evaporator. If this happens, set the
Temperature Regulator toward warmer
settings to allow automatic defrosting
and so a saving in electricity consump­tion.

6.3 Hints for fresh food

refrigeration

To obtain the best performance:

• do not store warm food or evaporating
liquids in the refrigerator

• do cover or wrap the food, particularly if
it has a strong flavour

• position food so that air can circulate
freely around it

6.4 Hints for refrigeration

Useful hints:

Meat (all types) : wrap in polythene bags
and place on the glass shelf above the
vegetable drawer.
For safety, store in this way only one or
two days at the most.
Cooked foods, cold dishes, etc..: these
should be covered and may be placed on
any shelf.
Fruit and vegetables: these should be
thoroughly cleaned and placed in the spe­cial drawer(s) provided.
Butter and cheese: these should be
placed in special airtight containers or
wrapped in aluminium foil or polythene
bags to exclude as much air as possible.
Milk bottles: these should have a cap and
should be stored in the bottle rack on the
door.
Bananas, potatoes, onions and garlic, if
not packed, must not be kept in the re­frigerator.

6.5 Hints for freezing

To help you make the most of the freezing
process, here are some important hints:

• the maximum quantity of food which
can be frozen in 24 hrs. is shown on
the rating plate;

• the freezing process takes 24 hours.
No further food to be frozen should be
added during this period;

• only freeze top quality, fresh and thor­oughly cleaned, foodstuffs;

• prepare food in small portions to enable
it to be rapidly and completely frozen
and to make it possible subsequently to
thaw only the quantity required;

• wrap up the food in aluminium foil or
polythene and make sure that the
packages are airtight;

• do not allow fresh, unfrozen food to
touch food which is already frozen, thus
avoiding a rise in temperature of the lat­ter;

• lean foods store better and longer than
fatty ones; salt reduces the storage life
of food;

• water ices, if consumed immediately af­ter removal from the freezer compart­ment, can possibly cause the skin to be
freeze burnt;

• it is advisable to show the freezing in
date on each individual pack to enable
you to keep tab of the storage time.

6.6 Hints for storage of frozen

food

The freezer baskets ensure that it is quick
and easy to find the food package you
want. If large quantities of food are to be
stored, remove all drawers except for the

7. CARE AND CLEANING

ENGLISH 19

bottom basket which needs to be in place
to provide good air circulation.
To obtain the best performance from this
appliance, you should:

• make sure that the commercially frozen
foodstuffs were adequately stored by
the retailer;

• be sure that frozen foodstuffs are trans­ferred from the foodstore to the freezer
in the shortest possible time;

• not open the door frequently or leave it
open longer than absolutely necessary;

• once defrosted, food deteriorates rap­idly and cannot be refrozen;

• do not exceed the storage period indi­cated by the food manufacturer.

7.1 Cleaning the interior

Before using the appliance for the first
time, wash the interior and all internal ac­cessories with lukewarm water and some
neutral soap so as to remove the typical
smell of a brand-new product, then dry
thoroughly.

Do not use detergents or abrasive
powders, as these will damage
the finish.

CAUTION!

Unplug the appliance before car­rying out any maintenance opera­tion.

This appliance contains hydrocar­bons in its cooling unit; mainte­nance and recharging must there­fore only be carried out by author­ized technicians.

7.2 Periodic cleaning

The equipment has to be cleaned regular­ly:

• clean the inside and accessories with
lukewarm water and some neutral
soap.

• regularly check the door seals and wipe
clean to ensure they are clean and free
from debris.

• rinse and dry thoroughly.

Do not pull, move or damage any
pipes and/or cables inside the
cabinet.
Never use detergents, abrasive
powders, highly perfumed clean­ing products or wax polishes to
clean the interior as this will dam­age the surface and leave a
strong odour.

Clean the condenser (black grill) and the
compressor at the back of the appliance
with a brush. This operation will improve
the performance of the appliance and
save electricity consumption.

Take care of not to damage the
cooling system.

Many proprietary kitchen surface cleaners
contain chemicals that can attack/dam­age the plastics used in this appliance.
For this reason it is recommended that
the outer casing of this appliance is only
cleaned with warm water with a little
washing-up liquid added.
After cleaning, reconnect the equipment
to the mains supply.

www.electrolux.com

20

7.3 Defrosting the refrigerator

7.4 Defrosting of the freezer

The freezer compartment of this model,
on the other hand, is a "no frost" type.
This means that there is no buildup of
frost when it is in operation, neither on the
internal walls nor on the foods.

Frost is automatically eliminated from the
evaporator of the refrigerator compart­ment every time the motor compressor
stops, during normal use. The defrost wa­ter drains out through a drain hole into a
special container at the back of the appli­ance, over the motor compressor, where
it evaporates.
It is important to periodically clean the de­frost water drain hole in the middle of the
refrigerator compartment channel to pre­vent the water overflowing and dripping
onto the food inside.
Use the special cleaner provided, which
you will find already inserted into the drain
hole.

The absence of frost is due to the contin­uous circulation of cold air inside the
compartment, driven by an automatically
controlled fan.

8. TROUBLESHOOTING

CAUTION!

Before troubleshooting, discon­nect the power supply.
Only a qualified electrician or com­petent person must do the trou­bleshooting that is not in this man­ual.

Problem Possible cause Solution
The appliance is

noisy.

The compressor op­erates continually.

The door is not closed

The door has been

The product temperature

The appliance is not sup­ported properly.

The Temperature regulator
may be set incorrectly.

correctly.

opened too frequently.

is too high.

There are some sounds during
normal use (compressor, refriger­ant circulation).

Check if the appliance
stands stable (all the four
feet should be on the floor).

Set a warmer temperature.

Refer to "Closing the door".

Do not keep the door open
longer than necessary.

Let the product tempera­ture decrease to room tem­perature before storage.

Problem Possible cause Solution

The room temperature is

too high.

The Fast freezing function

is switched on.

Water flows on the
rear plate of the re­frigerator.

Water flows into the
refrigerator.

During the automatic de­frosting process, frost de­frosts on the rear plate.

The water outlet is clog­ged.

Products prevent that wa-

ter flows into the water

Decrease the room temper­ature.

Refer to "Fast freezing
function"

This is correct.

Clean the water outlet.

Make sure that products do
not touch the rear plate.

collector.

Water flows on the
ground.

The melting water outlet
does not flow in the evap­orative tray above the

Attach the melting water
outlet to the evaporative
tray.

compressor.

There is too much
frost and ice.

The door is not closed

Products are not wrapped
properly.

Wrap the products better.

Refer to "Closing the door".

correctly.

The Temperature regulator

Set a higher temperature.

may be set incorrectly.

The temperature in
the appliance is too

The door is not closed
correctly.

Refer to "Closing the door".

high.

The product temperature

is too high.

Let the product tempera­ture decrease to room tem­perature before storage.

Many products are stored

at the same time.

The temperature in
the refrigeration is

There is no cold air circu­lation in the appliance.

too high.
The temperature in

the freezer is too

Products are too near to
each other.

Store less products at the
same time.

Make sure that there is cold
air circulation in the appli­ance.

Store products so that
there is cold air circulation.

high.
The appliance does

not operate.

The mains plug is not con-

The appliance is switched
off.

nected to the mains sock-

Switch on the appliance.

Connect the mains plug to
the mains socket correctly.

et correctly.

ENGLISH 21

www.electrolux.com

22

Problem Possible cause Solution

The appliance has no

The lamp does not
work.

"dEMo" appears on
the display.

The buzzer sounds.
The Display is red..

Upper or lower
square is shown in
the temperature dis­play.

As much as the advice does not lead to result, call the nearest brand-mark service.

8.1 Replacing the lamp

The appliance is equipped with a longlife
LED interior light.
Only service is allowed to replace the
lighting device. Contact your Service Cen­ter .

power. There is no voltage
in the mains socket.

cal appliance to the mains
socket. Contact a qualified
electrician.

The lamp is in stand-by. Close and open the door.

Connect a different electri-

The appliance is in dem­onstration mode.

Keep pressed approxi­mately 10 sec the Mode
button since a long sound
of buzzer is heard and the
display shut off for a short
while: appliance start works
regularly.

The door is not closed
correctly.

An error has occurred in
measuring the tempera­ture.

Refer to "Door open
alarm".

Call your service represen­tative (the cooling system
will continue to keep food
products cold, but temper­ature adjustment will not be
possible).

2.

If necessary, adjust the door. Refer to
"Installation".

3.

If necessary, replace the defective
door gaskets. Contact the Service
Center.

8.2 Closing the door

1.

Clean the door gaskets.

9. INSTALLATION

WARNING!

Read the "Safety Information"
carefully for your safety and cor­rect operation of the appliance
before installing the appliance.

9.1 Positioning

Install this appliance at a location where
the ambient temperature corresponds to
the climate class indicated on the rating
plate of the appliance:

Cli-

Ambient temperature
mate
class

SN +10°C to + 32°C
N +16°C to + 32°C
ST +16°C to + 38°C
T +16°C to + 43°C

9.2 Electrical connection

Before plugging in, ensure that the volt­age and frequency shown on the rating
plate correspond to your domestic power
supply.
The appliance must be earthed. The pow­er supply cable plug is provided with a
contact for this purpose. If the domestic

9.3 Location

100 mm

min

A

20 mm

B

ENGLISH 23

power supply socket is not earthed, con­nect the appliance to a separate earth in
compliance with current regulations, con­sulting a qualified electrician.
The manufacturer declines all responsibili­ty if the above safety precautions are not
observed.
This appliance complies with the E.E.C.
Directives.

The appliance should be installed well
away from sources of heat such as radia­tors, boilers, direct sunlight etc. Ensure
that air can circulate freely around the
back of the cabinet. To ensure best per­formance, if the appliance is positioned
below an overhanging wall unit, the mini­mum distance between the top of the
cabinet and the wall unit must be at least
100 mm . Ideally, however, the appliance
should not be positioned below overhang­ing wall units. Accurate levelling is ensur­ed by one or more adjustable feet at the
base of the cabinet.

WARNING!

It must be possible to disconnect
the appliance from the mains
power supply; the plug must
therefore be easily accessible after
installation.

9.4 Rear spacers

4

2

1

3

You can find the two spacers in the bag
with documentation.
Do these steps to install the spacers:

1.

Release the screw.

2.

Engage the spacer below the screw.

3.

Turn the spacer to the right position.

4.

Tighten again the screws.

www.electrolux.com

24

9.5 Levelling

9.6 Door reversibility

When placing the appliance ensure that it
stands level. This can be achieved by two
adjustable feet at the bottom in front.

A

B

E

F

DC

WARNING!

Before carrying out any opera­tions, remove the plug from the
power socket.

To carry out the following opera­tions, we suggest that this be
made with another person that will
keep a firm hold on the doors of
the appliance during the opera­tions.

To change the opening direction of the
door, do these steps:

• Open the doors. Unscrew the middle
hinge (B). Remove the plastic spacer (A)

• Remove the spacer (F) and move to the
other side of the hinge pivot (E).

• Remove the doors.

• Remove the left-hand cover pin of the
middle hinge (C, D) and move to the
other side.

• Fit the pin of the middle hinge (E) into
the left-hand hole of the lower door.

ENGLISH 25

• Unscrew the upper hinge pivot and
screw it on the opposite side.

• Remove the cover with the help of a

A

tool. (A).

• Unscrew the lower hinge pivot (B) and
the spacer (C) and place them on the
opposite side.

• Re-insert the cover (A) on the opposite
side.

B

C

• Remove the covers (B). Remove the

C

B

A

C

B

A

cover pins (A).

• Unscrew the handles (C) and fix them
on the opposite side .

• Re-insert the cover pins (A) on the op­posite side.

Do a final check to make sure that:

• All screws are tightened.

• The magnetic seal adheres to the cabi­net.

• The door opens and closes correctly.

If the ambient temperature is cold (i.e. in
Winter), the gasket may not fit perfectly to
the cabinet. In that case, wait for the nat­ural fitting of the gasket.
In case you do not want to carry out the
above mentioned operations, contact the
nearest After Sales Service Force. The Af­ter Sales Service specialist will carry out
the reversibility of the doors at your cost.

www.electrolux.com

26

10. NOISES

There are some sounds during normal
running (compressor, refrigerant circula­tion).

SSSRRR!

HISSS!

CLICK!

BRRR!

OK

CLICK!

BRRR!

CRACK!

BLUBB!

CLICK!

BRRR!

BLUBB!

BLUBB!

HISSS!

ENGLISH 27

HISSS!

SSSRRR!

CRACK!

11. TECHNICAL DATA

Dimension
Height 2014 mm
Width 595 mm
Depth 658 mm
Rising Time 18 h
Voltage 230-240 V
Frequency 50 Hz

SSSRRR!

CRACK!
