Page 1
User Manual
8221913- 89 -02
Model EME1925
English
Page 2
Page 3
EME1925 U English
Contents
Safety Instructions 4
Utensil safety
Testing suitability of cookware 5
Foil containers
Food safety 5
Oven utensil s and accessories guide 7
Technical Data
Unpacking 8
Installation
Connecting to the mains
The microwave and accessories 9
Name and function of parts
Accessories
Control panel 10
Display window
Turntable installation
How to operate your micro wave oven 11
Setting the clock
Child safety lock
Microwave cooking 12
Microwave setting guide
Microwave cooking in or and three st ages 13
Manual Defrosting 14
Auto Defrost 15
Auto Programmes 16
Auto Programme Example 17
Charts
Recommendations for Defrost ing using 160W 18
Microwave Hints 19
Microwave Tips
Care and cleaning 20
Service and spare parts 21
3
Page 4
EME1925 U English
Congratulations on the purchase of your new Microwave Oven
Thank you for having chosen a Electrolux product. We are convinced that you will find your new microwave
oven very useful and that it will be of great help to you. As with all new kit c hen appliances, it will take some
time to learn all the new functions and features, but with time, t his oven will become indispensable t o you.
Before using your Microwave Oven
Read through the instruction manual carefully and ensure that you f ollow the recommendations giv en, these
instructions have been prepared so that you get the best from your new Electrolux Microwave Oven.
It is important that this instruction book is retained with the appliance for future reference. Should t he appliance
be sold or transferred to another ow ner, or if you move house and leave the appliance, always ensure that t he
book is supplied with the app liance so that the new owner can be acquainted with the functi oning of the
appliance and the relevant warnings.
Safety Instructions
• The built-in safety interlock swit ches prevent the
microwave oven from operating when the door is
open.
• Do not tamper with them, or attempt to operate
the oven with the door open as open door
operation can result in exposur e t o microwave
energy.
• Do not allow food spills or cleaner residue to
accumulate on door sealing surfaces. See t he
Cleaning and Care section for cleaning
instructions.
• It is particularly important t hat the oven door
closes properly and that there is no damage to
the: (1) door (warped), (2) hinges and lat ches
(broken or insecure), (3) door seals and seal ing
surface.
WARNING : If the door,
hinges/latch es or door seals are damaged,
the microwave must not be operated until
it has been repai red by a authorized
service person.
WARNING : It is hazardous for
anyone except factory trained service
personnel to service or make adjustments
to this oven. Contact your nearest
authorised service agent if service should
be required.
specifically designed to heat , cook, or defrost
food. It is not designed for industr ial or laboratory
use neither for commercial use as t his will
invalidate the guarantee.
Do not operate the oven empty. I f food or water is
•
not present to absorb the microwave e nergy, the
magnetron tube can be damage d.
Do not store this appliance out doors. Do not use
•
this product near water.
Do not attempt to dry clothing or newspapers in
•
the microwave oven. These items can ignite.
Do not use the cavity for storage purposes. Do
•
not leave paper products, cooking ut ensils, or
food in the cavity when not in use.
WARNING : If smoke is observed,
switch off or unplug the appl iance and
keep the door closed in order to stifle any
flames. Never use water.
WARNING : Only allow children or
infirm persons to use th e mi crowave,
without supervision, when adequate
instructions have been given so that the
child or infirm person is able to use the
microwave in a safe way and understand
the hazards of improper use.
Utensil safety
• Do not remove the outer case, door or control
panel at any time. Doing so may cause exposure
to extremely high voltage.
• Install or locate this oven only in accordance with
‘installation instructions’ found in this manual.
Use the appliance for its intended use as
•
described in this manual. Do not use corrosive
chemicals in this appliance. T his type of oven is
Most glass, glass ceramic and heat-resistant glassware utensils are excellent f or use in the micro-wave
oven. Although microwave ener gy will not heat most
glass and ceramic items, these utensils can become
hot as heat transfers from the f ood to the container.
The use of oven gloves to remove dishes is
recommended.
4
Page 5
EME1925 U English
Testing suitability of cookware
• Utensils should be checked to ensure t hey are
suitable for use in Microwave Ovens.
• Place the cookware in the microwave a long with a
glass half full of water. Heat on
one minute. If the cookware feels hot, you should
not use it. If it is just slightly warm, you can use it
for reheating but not for cooking. If the dish is
room temperature, it is suitable f or microwave
cooking.
• Paper napkins, wax paper, paper towels, plates,
cups, cartons, freezer wrap and cardboard are
great convenience utensils. Always be sure
containers are filled wit h food to absorb energy
and thus avoid the possibility of overheating or
ignition.
• Many plastic dishes, cups, freezer containers and
plastic wraps may be used in the microwave
oven. Follow manufacturer ’s inst ructions when
using plastics in the oven. Avoid usin g plast ic
utensils with foods that have high fat or sugar
content since these foods reach high
temperatures and could melt some plastics.
Do not leave oven unatt ended, and look at it from
•
time to time when heating or cooking food in
plastic, paper or other combustible containers.
Metal utensils and utensils with metallic trim
•
should not be used in the microwav e oven, unless
specifically recommended for microwave use.
Containers with restricted openings, such as
•
bottles, should not be used for microw ave
cooking.
Use caution when removing a lid or cover fr om a
•
dish to avoid steam burns.
(800W) (100%) for
Foil contai ne rs
Shallow foil containers may safe ly be used t o reheat
foods in your microwave oven providin g the following
rules are observed:
1. Foil containers should not be more than 3 cms
(1 1/4”) deep.
2. Foil lids must not be used.
3. The foil containers must be at least two-thirds full
of food. Empty containers must never be used.
4. Foil containers should be used singly in the
microwave oven and should not be allowed to
touch the sides. If your oven has a metal turntable
or cooking rack, the foil container should be
placed on an upturned oven-proof plate.
5. Foil containers should never be re-used in the
microwave oven.
6. If the microwave oven has been in use for 15
minutes or more, allow it to cool before using it
again.
7. The container and turntable may become hot
during use, take great care when removi ng either
from the oven. It is advisable to use an oven cloth
or glove when doing so.
8. Remember when using an alum inium foil
container that the reheating or cooking times may
be longer than you are used to, always ensure
that the food is piping hot bef ore serving.
Food safety
Do not heat food in a can in the microwave oven.
•
Always remove the food to a suitable co ntainer.
Deep fat frying should not be done in the
•
microwave oven, because the fat temperature
cannot be controlled, hazardous situations can
result.
Popcorn may be prepared in the microwave oven,
•
but only in special packages or uten sils designed
specifically for this purpose. This cooking
operation should never be unattended.
Pierce foods with non-porous skins or
•
membranes to prevent steam build-up and
bursting. Apples, potatoes, chicken livers, and
egg yolks are examples of items that should be
pierced.
The contents of feeding bottles and baby food jars
•
are to be stirred or shaken and the temper ature is
to be checked before consumption, in order to
avoid burns.
WARNING : Liquids or other foods
must not be heated in sealed containers
since they are liable to explode.
WARNING : Microwave heating of
beverages can resul t i n delayed eruptive
boiling, therefore care mu st be taken when
handling the container.
WARNING : When heating liquids,
e.g. soups, sau ces and beverages in your
microwave oven, overheating the liquid
beyond boiling point can occur without
evidence of bubbling. This could result in a
sudden boil over of the hot liquid. To
prevent this possibil ity the following steps
should be taken:
5
Page 6
EME1925 U English
1. Avoid using straight-sided cont ainers with narrow
necks.
2. Do not overheat.
3. Stir the liquid before placin g the container in the
oven and again halfway through the heating time.
4. After heating, allow to st and in the oven for a
short time, stirring again before caref ully removing
the container.
WARNING : Some products such as
whole eggs and sealed containers – for
example, closed glass jars – may explode
and should not be heated in this oven.
Occasionally, poached eggs may explode
during cooking. Always pierce the yolk,
then cover and allow the stan ding time of
one minute before removing cover.
• Do not force the turntable to rotat e by hand. This
may cause malfunctioning.
• Arcing in the oven during microwave operation
usually occurs from use of metallic utensils.
Continuous arcing, however, can damage the
unit. Stop the programme and check the ut ensil.
• Care should be taken not to obstr uct any air vents
located on the top, rear, side and bot tom of the
oven.
m WARNING : Do no t use this oven for
commercial pu rposes. This oven is made
for domestic use only.
KEEP THESE INSTRUCTIONS !
It is quite normal for steam to be emitted
around the door, or for misting to occur on the
door, or even for water droplets to appear
below the door during the cooking cycle. This
is merely condensation from the heat of the
food and does not affect t he safety of your
oven. The door is not intended to seal
the oven cavity completely.
6
Page 7
EME1925 U English
Oven utensils and accessories guide
A variety of Utensils and Materials may be us ed f or cooking in your microwave oven. For your safet y and to
prevent damaging utensils and your oven choose, appropriate utensils and materials for each cooking met hod.
The list below is a general gu ide.
Material Utensils Microwave Cooking
Ceramic & Glass
China
Pottery YES
Plastic
Metal
Paper
Waxed Paper YES
Wood NO
Accessories
Corning ware
Heat resistant glass ware
Glass ware with metal decoration
Lead crystal glass
Without metal decoration
Microwave oven heat-proof we ar
Plastic wrap
Metal baking pan
Aluminium foil*
Cups, plates, towels
Turntable
Turntable support
YES
YES
NO
NO
YES
YES
YES
NO
YES
YES
YES
YES
YES: Utensils and accessories to use
NO: Utensils and accessories to avoid
*NOTE: Use alumini um foil only for shielding p u rpo ses, overuse may cause arcing.
Technical data
Overall dimension Width
Depth 322 mm
Height 265 mm
Cavity dimension Width
Depth 318 mm
Height 192 mm
460 mm
304 mm
Power source
Fuse
Power consumption
Microwave (Power)
Weight
Volume
230 V, 50 Hz
10 A
1250W
800W
13.5 kg
19 litre
7
Page 8
EME1925 U English
Unpacking
N.B. When you unpack the oven, check that the
product is free from damage. Damage or any missing
parts must be reported immediately to the retailer.
Installation.
1. Remove any promotion label f r om the door.
2. The oven should be installed on a flat, level
surface. The surface must be strong enough to
safely bear the weight (13.5 kg) of t he oven, and
the contents. To av oid the possibility of causi ng
vibration or noise the oven must be in a stable
position.
3. Keep the oven away from heat and wat er.
Exposure to heat and water can lower ove n
efficiency and lead to malfuncti oning, so be sure
to install the oven away from heat and water
sources.
4. Do not block air vents on the top and the sides of
the cabinet and also do not place an y articles on
the top of the oven. If air vents are blocked during
operation, the oven may overheat , and this may
lead to malfunctioning. Hot air escapes from the
vents, so be sure not to obstruct it or let curtains
come between the oven and the rear wall.
5. Place the oven as far away from radios and T V ’s
as possible. This oven does conform to EEC
requirements of radio interference suppression,
but some interference may occur if it is placed too
close to a radio or TV, so keep them as far apart
as possible.
6. If positioned in a corner, leave a gap of at least
15 cm from the walls and 17 cm above the
microwave.
IMPORTANT! The oven can be placed almost
anywhere in the kitchen. Make sure t he oven is
placed on a flat, level surface and that vents as
well as the surface underneath the oven are not
blocked (for sufficient ventilat ion).
The oven, parts of the oven or the accessories may
be wrapped by a protection foil. If so, you must
remove this foil before using the oven. Do not leave
packing material so that small chil dren can play with
it. This can be hazardous.
Connecting to the mains
The oven is delivered with the power cord and a plug
for 230V, 50Hz, earthed socket outlet .
Earth protection minimises the risks should a short
circuit occur. Check to ensure the voltage of the oven
matches the supply.
N.B. If the oven is connected to the socket via an
extension cord, make sure the cord is earth ed.
WARNING : This appliance must not
be used on a non-earth protected power
supply. Contact an electrician if you are
uncertain regardi ng electrical connection
of the oven or provision of earth protection
of the supply.
WARNING : This appliance must be
earthed. If this appliance is fitted with a
non-rewireable plug for which your socket
is unsuitable, the plug should be cut off
and the appropriate plug fitted. If it is
necessary to change th e fuse in a nonrewireable plug, the fuse cover must be
refitted. If the fuse cover is l ost or
damaged, the plug must not be used until
a replacement is obtai ned.
WARNING : It is hazardous for
anyone other than factory trained service
personnel to carry out any service or
repair operation that involves the removal
of a cover that gives pro t ecti on against
exposure to microwave energy.
WARNING : If the supply cord is
damaged, it must b e rep laced by the
manufacturer, its servi ce agent or similarl y
qualified persons in order to avoid a
hazard.
8
Page 9
EME1925 U English
The Microwave and Accessories
1
3
2
5
4
4
6
7
Name and function of parts Turntable Installation
1. Cooking compartment. W ipe t he compartment
clean after using the oven.
2. Viewing window. Food can be checked while the
microwave oven is in operation.
3. Oven door. The door must always be firmly
closed while cooking.
4. Latch hook, Safety interlock system.
5. Control panel.
6. Drive shaft for turntable
7. Turntable. Made of special he at-resistant glass.
Food in a suitable container is placed on this tray
for cooking. Do not use the oven without the
turntable.
8. Turntable support. Place the support on the floor
of the cooking chamber to support the turntable.
1. Place the turntable support on t he cavity Bottom.
2. Place the turntable on top of the turntable support
as shown in the diagram. Make sure that turntable
hub is securely locked in the turntable shaft. Never
place the turntable upsi de down.
• Both turntable and turntable support must always
be used during cooking.
• All food and containers of food are a lways placed
on this turntable for cooking.
• This turntable rotates clockwise and a nticlockwise;
this is normal.
Turntable
Roller rest
8
Page 10
EME1925 U English
Control Panel
1. Display windo w - showing time of day,
operating mode and cooking time.
2. Auto Defrost by weight.
Poultry
Meat
Fish
3. Auto Cook
Pizza
Beverage
Potato
Hold Warm
Popcorn
Plated Meal
4. Clock. To set the time.
5. Cook Time - For setting cook time.
6. Start - Press to start your program.
7. Door Open - Press to open the door.
8. Power - To set power.
9. Number pad - To enter time, weight and power.
10. Clear - Press to clear the current program.
9
Page 11
EME1925 U English
How to operate your microwave oven.
Setting the clock
When your oven is plugged in for the first time or
when power resumes after a power Int errupt ion, the
clock symbol and numbers in the display window
flash and the time is reset to 0:00.
Example: To set 4.30
1. Set the desired time (12 hour format) using the
number pad.
2. Touch the Clock button (
and start the clock running.
If you need to change the time of day after
setting, press the clo ck butto n, the numbers in
the display window wi ll flash. You can then set
the time as above.
Example: To change th e time to 11. 45
) to lock in the time
Child safety lock
This oven has a safety feature whic h prevents the
Accidental running of the oven by a chi ld. After the
lock has been set, no part of the microwave oven will
operate until the child lock feature has been
cancelled.
To set:
1. Open the door and touch the Cle ar (
button so that the time of day only is displayed
2. Touch ’
3. Touch Start (
displayed
To cancel the child lock, simply repeat the setting
procedure. Loc disappears and the time of day
Display reappears in the window.
’ button.
) button 5 times, Loc will be
)
1. Press and the Clock button (
the display window will flash.
2. Set the desired time (12 hour format) using the
number pad.
3. Touch the Clock button (
and start the clock running.
). The numbers in
) to lock in the time
10
Page 12
EME1925 U English
Microwave cooking
This basic microwave cooking method allows you to
cook food for a desired time. In addition to the
maximum power level, you can select dif ferent
microwave power from 10 levels, Hi W(800W) to 80W
for the foods that require slower cooking.
Example: To cook at 400W for 1 min 30 sec’s:
1. Open the door and touch Clear (
2. Touch the cook time button (
3. Set the desired time by pressing buttons ’
4. Touch the power button (
5. Set the desired power (400W = 5) by pressing b utton ’
6. Close the door and touch Start (
).
).
).
’ , ’ ’ then ’ ’ on t he number pad.
).
Foods with high moisture content should be cooked
on maximum power as this is the fastest cooking
method and best maintains the natural flavour and
texture of the foods.
’ on the number pad.
The Microwave oven is automatically set to 800W(HiW). If this power level is required f or cooking,
you may set the time and then press start (You do not need to select the required power) At t he end of
the cooking time, the microwave power will automatically stop. T he cooling fan and oven light will
continue to run whilst 5 soft audible bell sounds are heard. ’ End ’ will appe ar in the display window.
After the cooking time has finished pressing Pause/Clear will reset the display window to the time of
day.
Microwave setting guide
Power Setting Suggested use
80W PL-1 Keeping warm : Keeping foods wa rm
160W PL-2 Defrost : Thawing frozen foods.
240W PL-3
320W PL-4 Medium Low : Baked custards or cheesecakes.
400W PL-5 Medium : Faster defrosting for casseroles and stews.
480W PL-6 Medium Hi : Baking cakes and sponge puddings
560W PL-7 Reheat Low : Reheating of casseroles and stews..
640W PL-8 Reheat : Reheating pre-cooked foods.
720W PL-9 Reheat Hi : Roasting joints of meat and poultry.
800W PL-10
Simmer : Completing the cooking cycle of some pot roasts.
Casseroles and stews.
Max Power: Boiling or reheating l iquids. Cooking vegetables.
Preheating a browning dish.
12
Page 13
EME1925 U English
Microwave cooking in two or three stages
This basic microwave cooking method allows you to
cook food for a desired time at diff erent power levels.
In addition to the maximum power lev el, you can
select different microwave power f r om 10 levels,
HiW(800W) to 80W for the foods that require slower
cooking.
Example: To cook at 400W for 1 min 30 sec’s, then at 800W for 7min.
1. Open the door and touch Clear (
2. Touch the cook time button (
3. Set the desired time by pressing buttons ’
4. Touch the power button (
5. Set the desired power (400W = 5) by pressing b utton ’
6. Touch the cook time button (
).
).
).
).
Foods with high moisture content should be cooked
on maximum power as this is the fastest cooking
method and best maintains the natural flavour and
texture of the foods.
’ , ’ ’ then ’ ’ on t he number pad.
’ on the number pad.
7. Set the desired time by pressing buttons ’
8. Touch the power button (
9. Set the desired power (800W = 10) by pressin g button ’
10. Close the door and touch Start (
).
).
’ , ’ ’ then ’ ’ on t he number pad.
’ then ’ ’on t he number pad.
If you wish to cook in three stages, simply repeat steps 2, 3, 4 and 5 before you press the start button.
13
Page 14
EME1925 U English
Manual defrosting
For manual defrosting (without operating the Auto Defrost f eature), use 160W. The blue defrost symbol
appears in the window display whenever this power level is selected. T o speed up the defrosting of dense
foods over 450g (1lb), the oven may be started on Hi W(800W) power for 1- 3 minutes, t hen reduce t o 160W
until defrosting is complete.
Example: To defrost at 160W for 8 min 30 sec’s:.
1. Open the door and touch Clear (
2. Touch the cook time button (
3. Set the desired time by pressing buttons ’
4. Touch the power button (
5. Set the desired power (160W = 2) by pressing b utton ’
6. Close the door and touch Start (
).
).
).
’ , ’ ’ then ’ ’ on t he number pad.
’ on the number pad.
).
At the end of the defrosting time, the microwave power will automatically stop. The cooling fan and
oven light will continue to run whilst 5 soft audible bell sou nds are heard. ’ End ’ will appear in the
display window. After the defrosting time has finished pressing Pa use/Clear will reset the display
window to the time of day.
Defrosting Tips
1. It is better to underestimate def rosting time if you are unsure. Food will continue to defrost during the
standing time.
2. Separate food as soon as possible.
3. Turn large items, e.g. joints, halfway through the defrosting t ime, or at pause.
4. Remove any thawed food as soon as possible.
5. Remove or open any packaging before defrosting.
6. Place food in a larger container than t hat which it was frozen in, this will allow for easy stirring.
7. Begin thawing poultry, breast side down and turn over halfway through defrosting time or at pause.
Delicate areas such as wing tips can be shielded with small pieces of smooth foil.
8. Standing time is very important, particularly for large, dense foods which cannot be stirred to ensure that
the centre is completely defrosted bef ore cooking.
14
Page 15
EME1925 U English
Auto Defrost
Auto Defrost by Weight is an accurate defrost ing method for frozen meat, poultry or fish.
Programme Microwave mode Quantity Display
Defrost Poultry Microwave Only 0.1kg – 3.0kg de f1
Defrost Meat Microwave Only 0.1kg – 2.0kg de f2
Defrost Fish Microwave Only 0.1kg – 2.0kg de f3
Example: To defrost 1.7 kg of Po ultry:
1. Open the door and touch Clear (
2. Touch Poultry Defrost button once (
3. Set the desired weight ( 1.7 kg ) by pressing b ut tons '
4. Close the door and touch Start (
Example: To defrost 0.8 kg of Meat:
1. Open the door and touch Clear (
2. Touch Meat Defrost button once (
3. Set the desired weight ( 0.8 kg ) by pressing b ut tons '
4. Close the door and touch Start (
Example: To defrost 1.2 kg of Fish :
).
).
).
).
).
).
' then ' ' on the number pad.
' then ' ' on the number pad.
1. Open the door and touch Clear (
2. Touch Fish Defrost button once (
3. Set the desired weight ( 1.2 kg ) by pressing b ut tons '
4. Close the door and touch Start (
The Auto Defrost function can be used in conjunction with two and t hree stage cooking. Auto Defrost
can only be set for the first stage. F ollow the instructions for two and three stage cooking to add an
extra cooking stage.
).
).
' then ' ' on the number pad.
).
15
Page 16
EME1925 U English
Auto Programmes
The Auto Programme features allow you to simply and automatically cook or reheat a range of popular foods.
Your oven offers the following Auto programmes.
Programme Microwave mode Quantity Display
Pizza Slice Microwave Only 1, 2 or 3 Slices P1, P2, P3
(Chilled Pizza)
Beverage Microwave Only 1, 2 or 3 mugs CU P1, CU P2, CU P3
Potato Microwave Only 1, 2 or 3 potatoes PO1, PO2, PO3
Popcorn Microwave Only 100g POP
(1 standard pack)
Hold Warm Microwave Only Any (Hold Warm Indicator)
Reheat Plated meals Microwave Only Small (170g). SAL,
Regular (250g). rEG,
Large (350g). bIG,
Pizza Slice
To automatically reheat slices of Pizza, you simply press the ’ Pizza ’ (
depending on the number of Pizza Slices, you can now close the door and press Start (
) button 1, 2 or 3 times
).
Beverage
To automatically heat up a drink, you simply press the ’ Beverage ’ ( ) button ( once f or 1 cup, t wice
for 2 cups and three times for 3 cups ), you can now close the door a nd press St art (
Potato
To automatically cook potatoes, you simply press the ’ Potato ’ (
on the number of potatoes, you can now close the door and press Start (
Pierce foods with non-porous skins or membranes to prevent steam build-up and bursting. Apples,
potatoes, chicken livers, and egg yolks are examples of items that should be pi erced.
Popcorn
To automatically cook a bag of popc orn, you simply press the ’ Popcorn ’ ( ) button once , you can
now close the door and press Start (
Use only one packet of Microwave Popcor n at a time. Do not leave the oven unattended during this
program. Do not try to pop un-poppe d kernels. If the popcorn does not pop sufficiently, DO NOT press
the popcorn button again. Always follow the Popcorn manufacture rs guidelines. Face the bag away
from you when opening to avoid contact with any steam that is released.
Hold Warm
The Hold Warm function is used to keep f ood warm for a maximum of 30 minutes (in steps of 10
minutes) after cooking has finished. Set your cooking programme as usual. To set this program simply
touch the Hold Warm (
you can now close the door and press Start (
).
) button 1, 2 or 3 times depending
).
).
) button. (Once for 10 mins. Twice for 20 mins. Three t imes f or 30 mins. )
).
Reheat Plated meals
To automatically reheat a plated meal, you simply press the ’ Reheat Plated Meals ’ (
or 3 times depending on the size of the plated meal ( once for a regular meal, two t imes for a small
meal and three times for a large meal ), you can now close the door and press Start (
) button 1, 2
).
16
Page 17
EME1925 U English
Auto Programmes Examples
Example: To Reheat 2 Slices o f Pizza:
1. Open the door and touch Clear (
2. Touch the Pizza Slice button (
3. Close the door and touch Start (
Example: To Reheat 3 beverages
1. Open the door and touch Clear (
2. Touch the Beverage button (
3. Close the door and touch Start (
Example: To cook 2 potatoes
1. Open the door and touch Clear (
2. Touch the Potato button (
3. Close the door and touch Start (
Example: To cook a bag o f Micro wave Popcorn (100g)
) 2 times.
).
) 2 times.
).
).
) 3 times.
).
).
).
1. Open the door and touch Clear (
2. Touch the Popcorn button (
3. Close the door and touch Start (
Example: To set the Hold Warm fu nction for 20 mins
1. Open the door and touch Clear (
2. Set your cooking programme as usual.
3. Touch the Hold Warm button (
4. Close the door and touch Start (
Example: To Reheat a regular sized plated meal:
1. Open the door and touch Clear (
2. Touch the Reheat Plated Meals b utton (
3. Close the door and touch Start (
) once.
).
).
).
) 2 times.
).
).
) once.
).
At the end of the cooking time, t he microwave power will automatically stop. The cooling fan and
oven light will continu e to run whilst 5 soft audible bell sou nds are heard. ’ End ’ will appear in the
display window. After the cooking time has finished pressing Pause/Clear will reset the display window
to the time of day.
17
Page 18
EME1925 U English
Recommendations for Defrosting (Using 160W)
Some foods such as bread and fruit, can successfully be thawed manually by using t he power setting.
FOOD PREPARATION (160W)
Bread
Small loaf
Sliced large loaf
2 slices Place on kitchen paper. 45–60 sec. 5 min.
1 bread roll Place on kitchen paper. 45–60 sec. 5 min.
2 bread rolls Place on kitchen paper. 1–11/2 min. 5 min.
Cakes and Pastry
Gateau 450g/1 lb Remove from packaging, place on plate. 9–11 min. 15–30 min.
Cheesecake
450g/1 lb
Pie (cooked)
450g/1 lb
Pastry 450g/1 lb Remove from packaging, place on plate. 7– 9 min. 15–30 min.
Butter
250g/8.8 oz
(1 packet)
Fruit
225g/8 oz
Soft berry fruits
450g/1 lb
Soft berry fruits
Plated meal
400g/14 oz
Vegetables
Place on microwave-proof rack or kitchen paper.
Turn over halfway through defrosting time.
Place on microwave-proof rack or kitchen paper.
Turn over halfway through defrosting time.
Remove from packaging, place on plate. 9–11 min. 15–30 min.
Remove from packaging, place on plate. 7– 9 min. 15–30 min.
If foil wrapped, remove from wrapper and place on a
plate
Place in a single layer in a sha llow dish. 5– 6 min. 5–10 min.
Place in a single layer in a sha llow dish.
Cover with a plate or non P.V.C. cling f ilm.
To reheat, microwave on 100% (800W) for 3–4 minutes.
It is not necessary to defrost vegetables before cooking.
All vegetables can be thawed and cooked on
100% (800W)
8–10 min. 10–15 min.
10–13 min. 10 min
3– 4 min. 5–10 min.
7– 8 min. 5–10 min.
7– 8 min 5–10 min.
STANDING
TIME
18
Page 19
EME1925 U English
Microwave Tips
Microwave Hints
Always keep the oven clean – avoid spill-overs
•
and do not forget to clean under the glass tray
and the inside of the door.
Preferably use round or oval casseroles with a lid
•
when cooking in your microwave oven.
Do not use metal or metal decorated cass eroles.
•
Certain plastic materials can melt and be warped
by hot food.
Cover the food when cooking. Use a glass lid, a
•
plate or grease proof paper.
Pastry, bread and the like can be defrost ed
•
directly in a bread basket or on a paper towel.
If frozen food is heated in its packaging, the
•
packaging should be opened. Packaging
containing metal or metal decoration must not be
used unless specifically recommended for use in
the microwave. Remove metal clips and wire ties.
Smaller pieces of aluminium foil can be used to
•
cover parts that easily over cook such as chicken
legs.
Food with peel or skin should be pierced with a
•
fork – e.g. potatoes and sausages. Do not boil
eggs in the microwave oven as they can explode.
Put large, thick pieces close to the edge of the
•
casserole and try to cut the food in t o even sized
pieces. Always place the food in the centre of the
oven.
The food will be evenly cooked if you stir or turn it
•
a few times.
Always set a shorter cooking time than indicat ed
•
in your recipe to avoid over cooking. The larger
the amount of food the longer it takes.
Use little or no water for vegetables.
•
Use less salt and spices than for ‘normal’ cooking.
•
Season afterwards.
•
Allow a few minutes ‘standing ’ time after the oven
•
has switched off to ensure complete and even
cooking results.
Always ensure food is piping hot throughout
•
before serving.
Use pot holders or gloves when taking dishes and
•
food from the oven.
Softening Honey
•
If you have a jar of honey which has
crystallised, remove lid and place the jar in the
oven, microwave on medium power for 2
minutes.
Melting Chocolate
•
Break 100g of chocolate into squares, place in
a bowl and heat on high power for 1-2
minutes and stir well.
Softening or Melting Butter
•
Melting takes a few seconds on high po wer.
Softening is best done more gent ly on low
power.
Freshen or Warm Bread
•
Use medium power for few seconds.
Peeling Garlic easily
•
Heat 3 or 4 cloves of garlic on high power f or
15 seconds. Squeeze at one end until t he
clove pops out.
Fruit Juice
•
Citrus fruits will yield more juice if they are
heated on high power for 15 seconds bef ore
squeezing.
Cooking Porridge
•
Porridge is easily cooked in the serving dish
with no sticky pan to wash. Follow f ood
manufacturers’ recommendations.
19
Page 20
EME1925 U English
g
Care and cleanin
The oven must always be clean. Residu e of food from spillovers or spatters wil l at tract microwave energy
causing it to burn on. This could reduce the efficiency of the oven and may cause bad odours. Do not attempt
to tamper with or make any adjustments or repairs to any part of the oven. Repairs shoul d only be done by a
qualified service technician.
Be sure the oven is disconnected from the electricity supply before cleaning.
Cleaning the accessories (turntable and support)
Clean them with mild deterge nt after removing them from the cavity. The turntable support should be carefully
handled.
CAUTION: The inside of the oven and turntable get very hot, so do not t ouch them immediately after use.
Cleaning the interior
Always keep the inside of the oven clea n. Wipe up spill-overs and food spatters imme diately. Deposits that are
allowed to remain on the oven walls, door seal and door surface will absorb microwave energy, reduce the
efficiency of the oven, and possibly damage the oven interior. Use mild, liquid detergent, warm water and a
soft, clean cloth to remove deposits.
NEVER USE ABRASIVE CLEANERS, COMMERCIAL OVEN CLEANERS OR STEEL WOOL PADS ON
ANY PART OF THE MICROWAVE OVEN.
To loosen difficult depos its, boil a cup of water in the microwave oven for 2 or 3 minutes.
NEVER USE A KNIFE OR ANY UTENSIL TO REMOVE DEPOSITS FROM OVEN SURFACES.
To remove odours from the oven interior, boil a cup of water plus 2 tablespoons of lemon juice for 5 minutes.
Cleaning the exterior
Open the oven door when cleaning the control panel. This will prevent the oven from being turned on
accidentally. You should clean out side surfaces of the oven with mild liquid detergent and water followed by a
wiping with clear water to remove a ny excess det ergent. Dry with a soft cloth.
Spray-on window cleaners or all purpose spray-on kitchen cleaners can also be us ed. Never use abrasive
cleaners, scouring pads or harsh chemicals on out side surfaces of your oven. To prevent damage to the
working parts, do not allow wat er to seep into ventilation openings.
20
Page 21
EME1925 U English
After-sales service and spare parts
If the appliance does not work correctly, carry out
the following checks first before contacting the
local After-Sales Service Centre.
If the oven does not start:
• Check that the appliance is connected to the mains.
• Check that the plug is pushed in properly.
• If appropriate, replace the fuse in the plug by
another of the same rating and check that the plug
is wired correctly.
• Check that any switch, at the wall socket or
elsewhere in the circuit, is ON.
• Check that the wall socket is working by plugging in
something else that you know is working.
• Check the fuse in the fuse-box.
If the microwaves are not operating:
• The child security feature might have been set
(available on some models)
• Check that the controls have been set correctly.
• Check the adjustments/procedures by referring to
the instruction manual.
• Check that the door is closed properly. (If particles
of food or other things remain stuck in the doorway,
the door will not close correctly and the microwave
oven will not operate.)
• Check that the Start button is activated.
If the oven still does not work properly after the above
checks, contact the local Electrolux After-Sales Service
Centre. The address can be found on the following
pages of this user guide.
IMPORTANT :
If you call out a technician for one of the above
faults or to repair a fault caused by incorrect
install ation or operation, you will be cha rged for this
call-out even if the appliance is still under
guarantee.
When you make your call to the After-Sales Service
Centre, you will be asked for the following information:
1. Your name, address and postcode
2. Your telephone number
3. Clear and concise details about the fault
4. The model number
5. The serial number
6. The purchase date
We advise you to write down the information below so
that you will have the details to hand:
Model number: EME1925
Serial number:
P.N.C:
Purchase date:
If your appl iance is still unde r guarantee, y ou m us t
be sure that the necessary checks have been made,
because a technician call-out charge will be levied if
the problem is not mechanical or electrical.
Please note that your proof of purchase will be
required f or any call-out ma de during the guarant e e
period.
Spare parts
Spare parts can be purchased through your After-Sales
Service Centre.
Customer service
For all general enquiries about your Electrolux appliance
or for other information on Electrolux products, contact
our Customer Service centre by mail or telephone.
21
Page 22
EME1925 U English
22
Page 23
Page 24
Loading...
