Electrolux EBP100O User Manual

Electrolux Industrial Cooking

Boiling Pans - Promix

The Electrolux electric boiling pans are high benefit solutions, customized to the specific needs like: high
capacity, high power, motor tilting, comfortable electronic control, etc.
The range consists of 5 lines : 1 – Easyline pan with electromechanical control, 2- Standardline pans with
electromechanical control, 3 - Smartline pan with electronic control, 4- Variomix pans with electronic control
and with a variable speed grid stirrer, 5- Promix pans with electronic control and with a variable speed multi
purpose impeller. The models detailed on this sheet are electric (steam heated as option) from 100 up to 300 lt
with a variable speed multi purpose impeller.

EASY TO USE

• Food is uniformly heated through

the base and side walls of the pan by
an indirect heating system which uses
integrally generated saturated steam
at a temperature of 120°C in a jacket
with an automatic deaeration system.

• High thermal input and fast heat up.

• Electronic control with the

possibility to store up to 50 programs,
large display for easy use and a
complete control over the following
functions: cooking time and
temperature, water filling and mixing
speed.

• The lid is made of an insulating

material which keeps the surface
temperature low. There are no
removable parts to the lid and it is
easy to handle thanks to its light
weight.

• Variable speed bottom agitator

moves at up to 170 rpm (for 100 to
150 liters) and up to 140 rpm (for 200
to 300 liters) and is strong and fast
enough to mix even compact food,
such as mashed potatoes.

• Motorised tilting.

• Fast reaction, digital display and

error-message facility.

• Manual water filling system.

• The curve of the pan base also

allows the appliances to be suitable
for small quantities of food.

• Tilting axis is located at the front of

the pan to keep the pouring lip high
and allows tall vessels to be filled.

• Fast working thanks to the high

efficient heating technology and well
insulation that keeps the heat inside
the well.

232184 plus options and accessories

• Ergonomic and user friendly thanks

to the high tilting position, the well
designed pouring lip that makes the
filling container operation easy.

• Safe thanks to the high water

protection IPX5 and low temperature
outside the panels and the safety grid
(available as optional accessory)
which protects the mixing process.

• The electric heating elements are

submerged directly in the water of the
jacket. The heat losses are minimized
and the efficiency of the pan is raised
accordingly.

• Safety valve avoids overpressure of

the steam in the jacket.

• Safety thermostat prevents from

having a dangerously low water level.

• Max pressure at 1.0 bar.

Electrolux Industrial Cooking

Boiling Pans - Promix

EASY TO MAINTAIN

• Constructed to meet the highest

hygiene standards.

• AISI 304 stainless steel construction

with the deep drawn pan with
rounded edges manufactured from
AISI 316 stainless steel.

• Vessel can be tilted beyond 90° to

completely empty the food.

• Meets the requirements of H for

safety.

• Isolated upper rim maintains a low

temperature to avoid the risk of the
user burning his/herself.


EASY ON THE ENVIRONMENT

• The high-quality thermal insulation

of the pan saves energy and keeps
operating ambient temperature low.

• 98% recyclable by weight.

• Packing free of toxic substances.

FUNCTIONALITY

• Agitator control:

- Multi purpose impeller - the most
powerful on the market, while still
providing very gentle mixing

- mixes at speeds up to 170 rpm (100
to 150 liters) and up to 140 rpm (200
to 300 liters)
direction

- step program facilitates the removal
of food by moving the agitator step
by step

- possibility to run the mixer without
protection (i.e. grid or lid) by holding
down the button. - provides

continuous rotating and is easy to
use because it rotates in only one

ACCESSORIES:

- Cleaning tool - may be fitted on the
rotating shaft to facilitate cleaning of
the cooking surface and safety grid.
After use, it may be placed directly in
the dishwasher. The brushes may be
replaced.OPTIONS:

- Automatic water filling - makes it
possible to preset the desired quantity
of water.

- Automatic cooling - allows cooling
down of the food connecting the
jacket to the tap network.

- Food sensor - placed on the bottom

of the vessel, it provides efficient
temperature control even with small
amounts of food. Can be connected
to Haccp integrated system.

- Spray gun - integrated spray unit.



EBP100O

232182

TECHNICAL DATA

External dimensions - mm
depth 906 906 906 960
height 900 900 900 900
Net vessel useful capacity - Lt. 100 150 200 300
Working temperature - min/max - °C 30, 121 30, 121 30, 121 30, 121
Power - kW
installed-electric 24.7 32.2 40.5 53
Tilting mechanism Automatic Automatic Automatic Automatic
Bearing Front Front Front Front
Supply voltage 400 V, 3N, 50 400 V, 3N, 50 400 V, 3N, 50 400 V, 3N, 50

EBP150O

232183

EBP200O

232184

EBP300O

232185

DDE0502011-07-11Subject to change without notice

Internet: http://www.electrolux.com/foodservice

Electrolux Industrial Cooking

Boiling Pans - Promix

EBP100O

232182

ACCESSORIES

BRUSH (LONG) FOR SPRAY UNIT 928083 928083 928083 928083
BRUSH (SHORT) FOR SPRAY UNIT 928082 928082 928082 928082
CARRIER SCREW F.CLEANING TOOL 100L 928067
CARRIER SCREW F.CLEANING TOOL 150L 928068
CARRIER SCREW F.CLEANING TOOL 200L 928069
CARRIER SCREW F.CLEANING TOOL 300L 928070
CLEANING TOOL FOR 100L 928045
CLEANING TOOL FOR 150L 928046
CLEANING TOOL FOR 200L 928047
CLEANING TOOL FOR 300L 928048
DISTANCE RING F.CONNECT.(PREV.VERS.PAN) 928049 928049 928049 928049
FASTENING FRAME FOR RIGHT COLUMN 150-300 928036 928036 928036
FASTENING FRAME LEFT COLUMN(FOR BOLTING) 928034 928034 928034 928034
FASTENING FRAME RIGHT COLUMN 50-100L 928035
FIXTURE 150-300L 928030 928030 928030
FIXTURE 50-100L 928029
FOUNDATION FRAME LEFT COLUMN 928031 928031 928031 928031
FOUNDATION FRAME RIGHT COLUME 150-300L 928033 928033 928033
FOUNDATION FRAME RIGHT COLUMN 50-100L 928032
LEFT COLUMN+BEARING,COVER P.F.RIGHT COL. 928023 928023 928023 928023
OPTION AUTOMATIC COOLING 100 LT 928104
OPTION AUTOMATIC COOLING 150 LT 928105
OPTION AUTOMATIC COOLING 200 LT 928106
OPTION AUTOMATIC COOLING 300 LT 928107
OPTION AUTOMATIC WATER FILLING 928102 928102 928102 928102
OPTION FOOD TEMPERATURE+HACCP 200/300 LT 928101 928101
OPTION FOOD TEMPERATURE+HACCP 50/150 LT 928100 928100
OPTION PROTECTION GRID 100L-VARIO/PROMIX 928096
OPTION PROTECTION GRID 150L-VARIO/PROMIX 928097
OPTION PROTECTION GRID 200L-VARIO/PROMIX 928098
OPTION PROTECTION GRID 300L-VARIO/PROMIX 928099
OPTION SPRAY UNIT 928108 928108 928108 928108
STRAINER 100L 928025
STRAINER 150L 928026
STRAINER 200L 928027
STRAINER 300L 928028
TROLLEY TO STORE TOOLS FOR 2 BOIL. PANS 928044 928044 928044 928044
TROLLEY TO STORE TOOLS FOR 5 BOIL. PANS 928043 928043 928043 928043

EBP150O

232183

EBP200O

232184

EBP300O

232185
